Enlarged version
LC-32A37M
LCD COLOUR TELEVISION

OPERATION MANUAL

Supplied accessories
Remote control unit
"AA" size battery (g2)
Operation manual
Contents
Page
Supplied accessories ...........................1
Selecting a preset AV Mode ................8
Dear SHARP customer .........................2
Picture menu .........................................9
Important Safety Precautions .............2
Audio menu ...........................................9
Trademarks ...........................................2
Power Control menu ..........................10
Attaching the stand ..............................3
Setup menu .........................................10
Setting the TV .......................................3
Option menu .......................................12
Picture and still image .......................12
Remote control unit .............................5
Wide Mode ..........................................12
Part names ............................................6
Teletext function .................................13
Turning the TV on/off ...........................7
Connecting a PC .................................13
Auto Installation ....................................7
Appendix .............................................15
Programme Setup ................................7
Specifi cations .....................................16
AC cord
Stand unit
Stand base
Screws (g 4)
Page
Printed in Malaysia
TINS-E375WJZZ
09P09-MA-NP
Dear SHARP customer
Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many
years of trouble-free operation of your product, please read the Important Safety Precautions
carefully before using this product.
Important Safety Precautions
• Cleaning - Unplug the AC cord from the AC outlet before cleaning the product. Use a soft damp cloth to clean the
product. Do not use liquid cleaners, aerosol cleaners or chemical cloth to clean it, as such materials may damage the
product.
• Water and moisture - Do not use the product near water, such as bathtub, washbasin, kitchen sink, laundry tub,
swimming pool and in a wet basement.
• Do not place vases or any other water-fi lled containers on this product.
The water may spill onto the product causing fi re or electric shock.
• Stand - Do not place the product on an unstable cart, stand, tripod or table. Doing so can cause the product to fall,
resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table
recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the
manufacturer's instructions. Use only the mounting hardware recommended by the manufacturer.
• When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops, excessive force and
uneven fl oor surface can cause the product to fall from the cart.
• Ventilation - The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents
and openings since insuffi cient ventilation can cause overheating and/or shorten the life of the product. Do not place the
product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed
for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation
is provided or the manufacturer's instructions are followed.
• The LCD panel used in this product is made of glass. Therefore, it can break when the product is struck forcefully or with a
sharp object. If the LCD panel is broken, be careful not to be injured by broken glass.
• Heat sources - Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating
products (including amplifi ers)
• To prevent fi re, never place any type of candle or naked fl ames on the top or near the TV set.
• To prevent fi re or shock hazard, do not place the AC power cord under the TV set or other heavy items.
• Do not place heavy objects on this product or stand on it. Doing so could cause injury if the product overturns. Take
special care near children and pets.
• The LCD panel is a very high technology product with 1,049,088 pixels, giving you fi ne picture details.
Due to the very large number of pixels, occasionally a few non-active pixels may appear on the screen as a fi xed point of
blue, green or red.
This is within product specifi cations and does not constitute a fault.
• Precautions when transporting the TV
When transporting the TV, never carry it by holding or otherwise putting pressure onto the display. Be sure to always carry
the TV by two people holding it with two hands - one hand on each side of the TV.
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
• Install the product on the place where the AC cord can be unplugged easily from the AC outlet, or from the AC INPUT
terminal on the rear of the product.
Trademarks
• "HDMI, the HDMI logo and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC."
1
2

Advertisement

Table of Contents
loading

Related Manuals for Sharp Aquos LC-32A37M

Summary of Contents for Sharp Aquos LC-32A37M

  • Page 1: Table Of Contents

    Dear SHARP customer Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of trouble-free operation of your product, please read the Important Safety Precautions carefully before using this product. LC-32A37M Important Safety Precautions LCD COLOUR TELEVISION •...

  • Page 2: Attaching The Stand

    Attaching the stand Connecting external devices • Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal. You can connect many types of external equipment to your TV, like a VCR, game console, camcorder, DVD •...

  • Page 3: Remote Control Unit

    Remote control unit Part names Colour (Red/Green/Yellow/Blue) TV (Front/Side) TELETEXT mode: Select a page. (See page 13.) 10 AV MODE Select an audio and video setting. (See page 8.) 11 SLEEP Set the Sleep timer. 0hr.30min. 1hr.00min. 1hr.30min. POWER (On/Off) button 2hr.30min.

  • Page 4: Turning The Tv On/Off

    Turning the TV on/off Programme Setup Programme Setup (Continued) Erase Programme The individual programme can be erased. Turning on the power Auto Search • 179.25 MHz: Press 1 s 7 s 9 s 2 s 5. Repeat steps 1 to 4 in Auto Search. •...

  • Page 5: Picture Menu

    H Colour Temp. (Colour Temperature) H Power Management (PC input mode only) Picture menu Audio menu (Continued) Adjusts the colour temperature to give the best white Repeat steps 1 to 2 in Power Control menu. image. H Auto Vol MENU [Picture] Press a/b to select “Power Management”, Picture Audio...

  • Page 6: Option Menu

    H DNR (Digital Noise Reduction) WSS signal 4:3 screen Setup menu (Continued) Setup menu (Continued) Reduce noise on the screen and produces a clearer 4:3 mode “Panorama” 4:3 mode “Normal” video image. (Off, High, Low) H HDMI Setup (HDMI input mode only) Press a/b to select “Change password”, and H Colour System then press ENTER.

  • Page 7: Teletext Function

    Button functions Wide Mode (Continued) Connecting a PC (Continued) RS-232C commands list Buttons Description Commands “4:3 Mode” menu Command format CH (r/s) Increase or decrease the page number. • Commands not indicated here are not guaranteed To set the type of the wide screen, select “Panorama” Eight ASCII codes e CR Colour You can select a group or block of pages...

  • Page 8: Appendix

    Repeat steps 1 to 2 in Setting a Password. (See pages 10 to 11.) CAUTION • This TV should be mounted on the wall only with the AN-37AG5 (SHARP) wall mount bracket. The use of other wall mount The Password input screen displays.
