Mic Unit Parts - Icom IC-7410 Service Manual

[MIC UNIT]
REF PARTS
NO. NO.
C1 4030006900 S.CER C1608 JB 1H 103K-T
C2 4030006900 S.CER C1608 JB 1H 103K-T
C3 4030006900 S.CER C1608 JB 1H 103K-T
C4 4030007130 S.CER C1608 CH 1H 101J-T
C5 4030006900 S.CER C1608 JB 1H 103K-T
C6 4030006900 S.CER C1608 JB 1H 103K-T
C7 4030006900 S.CER C1608 JB 1H 103K-T
C8 4030007090 S.CER C1608 CH 1H 470J-T
J1 6510000191 CON FM214-8SS(P)-1
J2 6510019971 S.CON 52808-1071
EP2 6910012350 S.BEA MMZ1608Y 102BT
EP3 6910012350 S.BEA MMZ1608Y 102BT
EP4 6910012350 S.BEA MMZ1608Y 102BT
EP5 6910012350 S.BEA MMZ1608Y 102BT
EP6 6910018930 S.BEA MPZ2012S601A
EP7 6910018930 S.BEA MPZ2012S601A
EP9 6910015130 S.BEA MMZ1608D 301BT
EP10 6910015130 S.BEA MMZ1608D 301BT
EP11 6910012350 S.BEA MMZ1608Y 102BT
EP12 6910018930 S.BEA MPZ2012S601A1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
T 15.5/16.2
T 13.3/16.6
T 12.0/16.4
T
T
T
T
T 15.0/15.6
T
T
T
T 13.2/16.4
T 21.4/12.1
T
T
T
T
T 16.9/16.4
T
S.=Surface mount
H/V
8.2/3.7
17.5/2.5
8.2/2.5
7.8/11.4
4.0/10.2
18.2/3.7
11.7/2.5
8.0/8.4
9.5/13.3
8.2/4.9
8.2/6.1
9.8/16.9
5 - 29
