SAFE & EASY
®
FILTER
OW N E R S M A N UA L
This Owner's Guide provides specific operating instructions for your model.
Use the Safe & Easy Filter only as instructed in this Service Guide.
Versión en español
Si desea obtener una copia en español de este Manual de el Usuario,
sirvase escribir a la dirección que se incluye a continuación.
1-800-KEATING
www.keatingofchicago.com
037402
Advertisement
Related Manuals for Keating Of Chicago Top-Side 1-800
Summary of Contents for Keating Of Chicago Top-Side 1-800
- Page 1 SAFE & EASY ® FILTER OW N E R S M A N UA L This Owner’s Guide provides specific operating instructions for your model. Use the Safe & Easy Filter only as instructed in this Service Guide. Versión en español Si desea obtener una copia en español de este Manual de el Usuario, sirvase escribir a la dirección que se incluye a continuación.
- Page 2 READ AND SAVE THIS MANUAL FOR FUTURE REFERENCE Record the Model No. and Serial No. (located on the back of the motor housing) of this Safe & Easy Filter in the space provided below. Serial No. ____________________________________________________________ Model No. ____________________________________________________________ Keep these numbers for future reference IMPORTANT: Keep a copy of your bill of sale.
- Page 3 OPERATING INSTRUCTIONS A. PREPARING THE FILTER-DRAWER CAUTION WATER IN ANY FORM & HOT OIL DON'T MIX! NOTE: Operator should be outfitted with proper protective attire: safety goggles, oil and heat resistant gloves, apron and footwear Filter assembly inside of cabinet: 1.
- Page 4 9. Sprinkle Keating Acidox Powder evenly over the paper. 10. Replace crumb basket and push drawer fully into cabinet. Ensure the connection on top of the housing mates with the connection inside the cabinet. Pull the front of the filter system lightly to verify proper connection NOTE: Cabinet door should be closed during filtration.
- Page 5 Failure to do so may cause the drain lines to clog up. NOTE: If the pump shuts down, turn it off and let the motor cool. Push the motor reset button located on the filter panel. Check filtering procedure or clean tub and paper if needed. 6.
- Page 6 4. Push the small black knob on the filter panel to the left (“Oil to Hose”). 5. Place the nozzle of the hose in an approved discard container. 6. Drain the oil. 7. Plug the filter into the receptacle. 8. Turn the motor switch ON (the green light will illuminate). CAUTION A KEATING FRYER OR FILTER SHOULD BE DRAINED ONLY UNDER THE SUPERVISION OF PROPERLY...
- Page 7 SAFE & EASY Front View Motor & Pump Assembly 055173 Front View Motor & Pump Assembly 052982 FILTER PARTS LIST ® – 5 – Description 1. Quick Connect Coupler Compression Fitting Straight Female 2. Caster Swivel 2" -16 Acorn Nut Split Lockwasher 009085 3.
- Page 8 PROBLEM Tub not set up properly. Motor runs but will not pump oil. Tub not connected to the motor housing properly Filter not connected inside of cabinet Valve not switched to “Oil to Fryer” If there’s more than one fryer, return valve not open.
- Page 9 PROBLEM Oil has not penetrated the filter Motor runs but will not paper pump oil. Not plugged in Motor not making any noise Motor has overheated Valve not switched to “Oil to Hose” Oil not pumping through the hose PREVENTIVE MAINTENANCE: Familiarize yourself with the proper filtering procedure prior to attempting to filter To remove water, stir oil until bubbling stops;...
-
Page 10: Wiring Diagram
# 052982 (See parts list) NOTE: Use this diagram with motor/pump part # 055173 (See parts list) KEATING OF CHICAGO, INC. 8901 West 50th Street, McCook, Illinois 60525-6001 Tel. 708-246-3000 • Fax 708-246-3100 If you have any questions regarding filtering Toll Free 1-800-KEATING (In U.S. - Page 12 REMARKS: ______________________________________________ I HAVE READ THE INSTALLATION AND OPERATION INSTRUCTIONS. SIGNED: __________________________________________________________________________________ DATE:__________________________________ SERVICE INFORMATION KEATING OF CHICAGO, INC. 8901 West 50th Street, McCook, Illinois 60525-6001 Phone: (708) 246-3000 FAX: (708) 246-3100 Toll Free 1-800-KEATING (In U.S. and Canada) www.keatingofchicago.com...
