Page 1: Installation Manual
INSTALLATION MANUAL Model: QS09-VJ115 QS12-VJ115 QS09-VP115 QS12-VP115 (Refrigerant R410A) -
Page 2: Part Ⅱ : Installation And Maintenance
Service Manual Part : Installation and Maintenance Ⅱ 7. Notes for Installation and Maintenance Safety Precautions: 10. If the power cord or connection wire is not long enough, please get the specialized power cord or connection wire Important! from the manufacture or distributor. Prohibit prolong the wire by yourself. -
Page 3: Main Tools For Installation And Maintenance
Service Manual Main Tools for Installation and Maintenance 1. Level meter, measuring tape 2. Screw driver 3. Impact drill, drill head, electric drill 4. Electroprobe 5. Universal meter 6. Torque wrench, open-end wrench, inner hexagon spanner 7. Electronic leakage detector 8. -
Page 4: Installation Dimension Diagram
Service Manual 8. Installation 8.1 Installation Dimension Diagram Installation dimension diagram Space to the wall Space to the wall At least 0.5ft. At least 0.5ft. Drainage pipe Installation and Maintenance... -
Page 5: Installation Procedures
Service Manual Installation procedures Start installation Preparation before installation Read the requirements select installation Prepare tools for electric connection location Select indoor unit Select outdoor unit installation location installation location Install the support of outdoor unit Install wall-mounting (select it according to the actual situation) frame, drill wall holes Connect pipes of indoor Fix outdoor unit... -
Page 6: Installation Parts-Checking
Service Manual 8.2 Installation Parts-checking 8.4 Requirements Forelectric Connection Name Name 1. Safety precaution Indoor unit Sealing gum (1) Must follow the electric safety regulations when installing Outdoor unit Wrapping tape the unit. Support of outdoor (2) According to the local safety regulations, use qualified Connection pipe unit power supply circuit and air switch. - Page 7 Service Manual 3. Install Wall-mounting Frame 5. Connect the Pipe of Indoor Unit (1) Choose the position of piping hole according to the direction (1) Aim the pipe joint at the corresponding bellmouth.(As show of outlet pipe. The position of piping hole should be a little in Fig.5) lower than the wall-mounted frame.(As show in Fig.1) (2) Pretightening the union nut with hand.
- Page 8 Service Manual 7. Connect Wire of Indoor Unit 8. Bind up Pipe (1) Open the panel, remove the screw on the wiring cover and (1) Bind up the connection pipe, power cord then take down the cover.(As show in Fig.11) and drain hose with the band.(As show in Fig.14) (2) Reserve a certain length of drain hose and power cord for installation when binding them.
-
Page 9: Installation Of Outdoor Unit
Service Manual 8.6 Installation of Outdoor Unit Refer to the following table for wrench moment of force: 1. Fix the support of outdoor unit(select it according to the Hex nut diameter(inch) Tightening torque(N.m) actual installation situation) 1/4" 15~20 3/8” 30~40 (1) Select installation location according to the house structure. -
Page 10: Vacuum Pumping And Leak Detection
Service Manual 8.8 Check after Installation and Test (3) The water outlet can't be placed in water in order to drain smoothly.(As show in Fig.27) operation 1. Check after Installation Check according to the following requirement after finishing installation. The drain hose can't be fluctuant Items to be checked Possible malfunction Has the unit been...
