Page 1: Table Of Contents
SAFETY III - This PDF Download was downloaded from SatelliteGuys.US PORTABLE MEDIA PLAYER 1 GETTING STARTED 5 DISH NETWORK AUDIO/VIDEO 15 SECOND SOURCE AUDIO/VIDEO 21 THE PHOTO ALBUM 33 THE AUDIOCORDER 41 THE BROWSER 47 SYSTEM SETUP 53 TROUBLESHOOTING 61...
Page 2 Table of Contents NOTES...
Page 3 For your safety: To charge the Li-Ion battery, only use the AC/DC adapter that came with the PocketDISH Never leave the PocketDISH in a hot environment like your car. Ambient temperature may not exceed 140F/60C. Failing to do so can cause permanent damage to equipment and can result in serious personal injury.
Page 4 Disconnect the AC/DC adapter from the power during lightning storms or when unused for long periods of time. To help avoid possible damage to the PocketDISH electronics, do not expose the PocketDISH to excessive vibration or any magnetic objects, such as speakers, electric motors, transformers, etc.
Page 5 Set the volume level of your PocketDISH to a safe level before permanent damage to your ears has occurred. If you start to hear ringing in your ears, reduce the volume level or stop using the headphones or ear buds.
Page 6 Safety NOTES...
Page 7: Portable Media Player
Portable Media Player About Your PocketDISH ORTABLE EDIA LAYER This chapter gives you an overview and a description of your Portable Media Player. • O VERVIEW • C ONTROLS AND NDICATORS • C ONNECTORS...
Page 8 Chapter 1 VERVIEW Features include the following: Video Player: DISH Network content and MPEG-4. Music Recorder & Player: DISH Network content, MP3, WMA and WAV. Photo Viewer/Slideshow: JPG, JPEG, BMP. Games Console: Mophun 2D/3D Games. Built-in Help: Additional on-screen information.
Page 9 When pressed for at least three seconds: - Function key 1 is also used as a general key lock. - Function key 2 is also used to select either the PocketDISH screen or TV. OFF: press and hold to turn off PocketDISH.
Page 10 Chapter 1 ONNECTORS The USB Host and Device connector types used on the PocketDISH are: USB Mini Type A (USB-A) and USB Mini Type B (USB-B) USB-A (Host): connect USB (mass storage device) compatible equipment, like a camcorder, digital photo camera or a USB flash drive.
Page 11: Getting Started
Getting Started Connections and Setup ETTING STARTED Use this information to get started and connect your PocketDISH to other devices. • U DISH NPACK THE OCKET • F IRST • B ASIC PERATION • C DISH N ONNECT A ETWORK •...
Page 12 Keep the plastic packaging away from children. The plastic packaging may cling to the nose and mouth and cause suffocation. Keep the packaging materials for a period of time. In case of warranty claims, return the PocketDISH in the original packaging to protect the electronics. Failing to do so might void the warranty.
Page 13 The Li-Ion battery is a high capacity power source. Do not use another battery charger or AC/DC adapter. For your safety, charge the Li-Ion battery only with the AC/DC adapter that came with the PocketDISH. Failing to do so can cause permanent damage to equipment and can result in serious personal injury.
Page 14 ASIC PERATION The PocketDISH has a battery saver which shuts down the display or the entire PocketDISH after a certain period of time. You can change these settings in the Setup - Power menu. Note that any change will influence battery power life span.
Page 15 DISH N ONNECT A ETWORK When connected to an external device, the PocketDISH uses more power than normal. Therefore, connect the PocketDISH to power to prevent an unwanted shutdown. 1 Connect the PocketDISH to power. 2 Turn the DVR and the PocketDISH on.
Page 16 PocketDISH to power to prevent an unwanted shutdown. The PocketDISH is compatible with Windows ME/2000/XP and Mac OS 10.2.4 or higher. Note that on some Windows versions the PocketDISH displays in the Windows Explorer as a Removable Disk.
Page 17 Getting Started ONNECT A When connected to an external device, the PocketDISH uses more power than normal. Therefore, connect the PocketDISH to power to prevent an unwanted shutdown. 1 Connect the PocketDISH to power. 2 Turn the PocketDISH on. LAYBACK 3 Install the analog AV-cable directly in the AV connection (center jack) of the PocketDISH.
Page 18 Chapter 2 ONNECT AN UDIO EVICE When connected to an external device, the PocketDISH uses more power than normal. Therefore, connect the PocketDISH to power to prevent an unwanted shutdown. 1 Connect the PocketDISH to power. 2 Turn the PocketDISH on.
Page 19 For example, connecting to a computer without the need to install additional software. Consult the user’s guide that came with your USB flash drive, MP3 player, digital photo or video camera if it is compliant with the USB mass storage device protocol. If yes, the PocketDISH can get the files from it.
Page 20 The operation of your PocketDISH is done via options and setup menus. The options and setup menus shown on the desktop (which appears directly after power up) are:...
Page 21: Dish Network Audio/Video
DISH Network Audio/Video Transfer and Playback DISH N ETWORK UDIO IDEO This chapter helps you learn how to send and playback DISH Network audio and video recordings. • I NTRODUCTION • S DISH N ECORDINGS FROM THE ETWORK • P...
Page 22 PocketDISH, and not vice-versa. It is possible to send your recorded programs from your compatible DISH Network DVR onto the PocketDISH when connected with the USB cable. Please note that recorded content from the DISH Network audio channels will also appear in the Video folder of the PocketDISH.
Page 23 2 On the DVR’s PocketDISH pop-up, select Add. The "My Recordings" list displays. 3 On the DVR’s remote control, use UP and DOWN ARROW and SELECT to choose the recordings that you want to send to your PocketDISH. Before each selected event, a mark in the check box displays.
Page 24 DISH N LAYBACK THE ETWORK ECORDINGS The PocketDISH always remembers where you stopped the last file for playback. On the desktop, select Resume to start playback from that point forward. ASIC OPERATION 1 Turn the PocketDISH on. 2 Allow the PocketDISH time for the desktop to display.
Page 25 DISH Network Audio/Video DDITIONAL FEATURES WHEN A FOLDER IS HIGHLIGHTED Function key 1: Function key 2: Function key 3: Info: displays folder information. Parent: goes to the previous No option available. Create folder: makes a new menu level. folder. Hide thumbnails: displays only the file names.
Page 26 Chapter 3 DDITIONAL FEATURES WHEN VIEWING VIDEO Function key 1: Function key 2: Function key 3: Normal playback (default). Setup: opens the setup Hide: removes the on-screen menu. menu temporarily. Slow motion x2, x4, x8. Set Screen format: Auto, Full, 4:3 or 16:9. Set bookmark: for future access to the selected scene.
Page 27: Second Source Audio/Video
Second Source Audio/Video Transfer and Playback ECOND OURCE UDIO IDEO This chapter gives you the procedure to transfer audio or video files from different multimedia devices and play them back on the PocketDISH. • I NTRODUCTION • I NTERNET INKS • T...
Page 28 PocketDISH will playback. On the hard drive of the PocketDISH you will find a set of PC tools (MPEG-4 Translator) that you can use to convert video files into a playable format. You have to transfer the folder onto your computer, so you can install the conversion tools.
Page 29 UDIO IDEO ILES Note that the PocketDISH can display on your computer under different names. Possible names are PocketDISH or Removable Disk. 1 Onto your PC, shut down all programs before you start. 2 Use the USB cable to connect the PocketDISH to the PC.
Page 30 Chapter 4 LAYBACK A OMPATIBLE IDEO The PocketDISH always remembers where you stopped the last file for playback. On the desktop, select Resume to start the playback from that point forward. ASIC OPERATION 1 Turn the PocketDISH on. 2 Allow the PocketDISH time for the desktop to display.
Page 31 Second Source Audio/Video DDITIONAL FEATURES WHEN A FOLDER IS HIGHLIGHTED Function key 1: Function key 2: Function key 3: Info: displays folder information. Parent: goes to the previous No option available. Create folder: makes a new menu level. folder. Hide thumbnails: displays only the file names.
Page 32 Chapter 4 DDITIONAL FEATURES WHEN VIEWING VIDEO Function key 1: Function key 2: Function key 3: Normal playback (default). Setup: opens the setup Hide: removes the on-screen menu. menu temporarily. Slow motion: x2, x4, x8. Set Screen format: Auto, Full, 4:3 or 16:9. Set bookmark: for future access to the selected scene.
Page 33 Second Source Audio/Video LAYBACK A OMPATIBLE The PocketDISH always remembers where you stopped the last file for playback. On the desktop, select Resume to start the playback from that point forward. ASIC OPERATION 1 Turn the PocketDISH on. 2 Allow the PocketDISH time for the desktop to display.
Page 34 Chapter 4 DDITIONAL FEATURES WHEN HIGHLIGHTING THE MUSIC FOLDER BROWSE HARD DRIVE Function key 1: Function key 2: Function key 3: Parent: goes to the previous Info: displays folder Record: opens the information. menu level. AudioCorder to make an Create folder: makes a new audio recording.
Page 35 LAYLISTS 1 Turn the PocketDISH on. 2 Allow the PocketDISH time for the desktop to display. 3 Highlight the Music icon and press ON to access the content. 4 In the ARCLibrary, make your selection (Artist - Year) and press ON to access the content.
Page 36 Setup menu. Highlight the option PlayMode and press ON to access the options. 1 Turn the PocketDISH on. 2 Allow the PocketDISH time for the desktop to display. 3 Highlight the Music icon and press ON to access the content.
Page 37 The MPEG-4 Translator is only available for personal computers (PC) with a Windows Operating System. Note that on some Windows versions the PocketDISH displays in the Windows Explorer as a Removable Disk. For Mac there are conversion tools available for purchase from the Internet.
Page 38 DivX codec into C:\PocketDISH\source\codec\divx 2 Shut down all programs including e-mail, internet and anti-virus programs before installation. 3 In the folder C:\PocketDISH\source\codec\divx locate the .exe file. 4 Double click the .exe file and follow the on-screen instructions. IRTUAL UB PROGRAM For a seamless installation with the MPEG-4 Translator, install VirtualDub in its default folder.
Page 39: The Photo Album
The Photo Album Transfer and Playback HOTO ALBUM This chapter gives you the procedure how to transfer photos or images from different multimedia devices and play them back on the PocketDISH. • I NTRODUCTION • T RANSFER IGITAL HOTOS MAGES FROM THE OMPUTER •...
Page 40 Chapter 5 NTRODUCTION In addition to the playback of DISH Network content, the PocketDISH can also display photos or images from other sources. These photos (images) need to be either in JPEG (.jpg) or BMP (.bmp) format. With your PocketDISH you can transfer digital photos (images) from your computer, your camera, camcorder, USB flash drive or any other multimedia device which operates as a mass storage device.
Page 41 HOTOS MAGES FROM THE OMPUTER Note that the PocketDISH can display on your computer under different names. Possible names are PocketDISH or Removable Disk. 1 On your PC, shut down all programs before you start. 2 Use the USB cable to connect the PocketDISH to the PC.
Page 42 With your PocketDISH you can transfer digital photos and images from your computer, your camera, camcorder, USB flash drive or any other multimedia device which operates as a mass storage device. 1 Connect the PocketDISH to your camera as described in Getting Started - Connect a USB Mass Storage Device on page 13.
Page 43 HOTO OR MAGE ASIC OPERATION 1 Turn the PocketDISH on. 2 Allow the PocketDISH time for the desktop to display. 3 Highlight the Photo icon. 4 Press ON to access the content. IEWING A SINGLE PHOTO 1 Highlight the desired photo.
Page 44 Chapter 5 IEWING A LIDESHOW ELECT HOTO ELECT LIDESHOW IEW YOUR LIDESHOW DDITIONAL FEATURES WHEN A FOLDER IS HIGHLIGHTED Function key 1: Function key 2: Function key 3: Parent: goes to the previous Info: displays additional No option available. information. menu level.
Page 45 The Photo Album DDITIONAL FEATURES WHEN A FILE IS HIGHLIGHTED BROWSER Function key 1: Function key 2: Function key 3: Parent: goes to the previous Slideshow: displays the No option available. photos one after another. menu level. Info: displays additional information.
Page 46 Chapter 5 PECIAL FUNCTIONS MAGNIFYING THE PHOTO IMAGE ON DISPLAY Magnifying a photo might result in a poorer quality when viewing. This is related to the resolution of the original photo size. The bigger the file size, the better the magnification view will be. 1 When a single picture is displayed, press Function key 3 to hide the on-screen menu.
Page 47: The Audiocorder
The AudioCorder Description and Operation UDIO ORDER This chapter gives you the description and operation for the AudioCorder. • D ESCRIPTION • O PERATION • I NCREMENTAL RECORDING • E DITING...
Page 48 (for example, breaking up a lengthy track or a live concert into separate digital files). ILE EDITING The PocketDISH lets you edit your audio files. You can cut out a section from a recording that you want to keep. ILE LOCATION All recordings are stored in the Music folder.
Page 49 The AudioCorder PERATION 1 Connect the PocketDISH as described in Getting Started - Connect an Audio Device on page 12. 2 On the desktop, select the AudioCorder icon and press ON. 3 In the pre-record screen, if necessary, use the keys to set the recording level.
Page 50 (folder), the recording that you want to rename, then press Function key 2 (Rename). Once the PocketDISH is connected to the computer, you also can use the computer to rename the files or folders. You can only make use of the Incremental recording feature during recording. You can use it to breakup the running recording into several separate recordings.
Page 51 The AudioCorder DITING You can only edit the analog recordings, which have been made with use of the analog AV-cable or the microphone. You cannot edit transferred songs that originate from an external source. 1 On the desktop, select the Music icon and press ON. 2 Highlight the Browse hard drive folder and press ON.
Page 52 Chapter 6 NOTES...
Page 53: The Browser
The Browser Description and Operation ROWSER This chapter gives you the description and operation for the PocketDISH Browser. • D ESCRIPTION • H OW TO SE THE ROWSER • V ILES OR OLDERS • C ILES OR OLDERS • R...
Page 54 : holds the video files that you have send from the DISH Network DVR. In the Browser itself, one file (UPDATE_AV402E.AOS) is displayed. This file is mandatory and may not be deleted! This file is required to recover the PocketDISH after a system crash or to facilitate future software upgrades.
Page 55 5 Make your selections as applicable. Please note that unsupported file formats can been seen in the folder, but the PocketDISH will not play or display the file content. These files can be viewed or played once transferred to a computer, which has the programs that go with the file (for example, *.doc is used by Microsoft Word).
Page 56 Chapter 7 ILES OR OLDERS DDITIONAL FEATURES WHEN A FOLDER IS HIGHLIGHTED Function key 1: Function key 2: Function key 3: No option available. No option available. Info: displays additional information. Parent: goes to the next folder level up (only for sub-folders). Create: makes a new folder.
Page 57 ENAME ILES OR OLDERS When the PocketDISH is connected to the PC, you also can use the PC to rename the files or folders. This procedure is for use with the PocketDISH virtual keyboard. 1 Select the Browser menu. 2 Locate the function File or Folder and press the adjacent Function key.
Page 58 Chapter 7 NOTES...
Page 59: System Setup
System Setup Description and Operation YSTEM ETUP This chapter explains how to personalize and set up your PocketDISH. • D ESCRIPTION • S OUND • P • C LOCK MENU • D ISPLAY • A PPEARANCE • P OWER • L OCKS •...
Page 60 Locks : sets the age based view ratings and allows for locking and unlocking the system and changing the password. The DISH Network DVR password is not the same as on PocketDISH. System : set, upgrade and review the system data (firmware).
Page 61 System Setup OUND In the Sound menu, you can set your personal preferences for: Volume : sets the overall sound level. Bass : sets the lower sound frequencies. Treble : sets the higher sound frequencies. Balance : sets the balance between the left and right speaker. Bass Boost : increases the level of the lower sound frequencies.
Page 62 : sets the menu language. TV Standard : sets the NTSC (USA) or PAL (Europe) standard. Video Output : selects the PocketDISH or TV set for viewing. Image Display : sets Interlaced (video) or Progressive (photo). Video OSD : sets the view time of the function menus.
Page 63 In the Power menu, you can set the power save mode for battery operation as well as for DC-power operation: Power Off : sets the inactive usage time before the PocketDISH completely shuts down automatically. Backlight Off : sets the inactive usage time before the PocketDISH turns off the display only.
Page 64 Show all Files : displays all files or just the playable files. With the Update Firmware option, you can manually update the software version once it is downloaded in the PocketDISH. Firmware version : to review the current software version.
Page 65 3 Press OFF repeatedly to exit the session. O CHANGE THE WALLPAPER SETTINGS 1 On the PocketDISH desktop, highlight the Setup icon and press ON. 2 In the Setup menu, highlight the Display option and press ON. 3 In the Display menu, highlight the Appearance option, and press ON.
Page 66 NTERNET 1 Download the latest software version from www.archos.com to your computer. 2 Connect the PocketDISH to the computer. Note that the "USB cable attached" pop-up displays. 3 On the computer, locate the PocketDISH drive and double click. 4 Note that a file called UPDATE_AV402E.AOS is present.
Page 67: Troubleshooting
Troubleshooting Tips and Tricks ROUBLESHOOTING This chapter provides help for questions or problems you may have. • P OWER • DISH N ETWORK • C ONNECTIONS • F ILES • G AMES • M ULTIMEDIA • C OMPUTER • I F NOTHING HELPS...
Page 68 I expected. to an external device. external device, the PocketDISH uses more energy than normal. Therefore, always connect the PocketDISH to power to prevent an unwanted shutdown. 2 The PocketDISH switches The battery power is low. Connect the AC/DC adapter off automatically.
Page 69 Troubleshooting Question Possible Cause How to Resolve 3 The display turns black Power settings are set to save a.Turn on the PocketDISH. after a few seconds. battery power. b.Highlight the Setup icon. c. Press ON once. d.Highlight the Power icon.
Page 70 4 It seems that the battery Li-Ion battery is worn out. Please contact the Archos does not charge. Customer Service Center. 5 Can I use PocketDISH and Yes you can. The AC/DC its AC/DC adapter abroad? adapter can be used between 100Vac-240Vac / 50Hz-60Hz.
Page 71 The in-line volume control of Adjust the in-line volume my headphone. the headphone is set to control to a higher level until minimum. sound is heard. The PocketDISH volume is set On PocketDISH, use the too low or minimum. key to increase the volume.
Page 72 Press ON once. h. In the Video out option, press key. i. Now the TV screen displays. j. Use the PocketDISH keys as usual to select your video. k. On shut down, PocketDISH reverts to its own LCD. 6 Are USB hubs supported?
Page 73 Windows Media Player to PocketDISH. convert your multimedia file into a playable format. PocketDISH only supports the formats as specified in this manual. You are limited by the Locks. Enter your password to view the file.
Page 74 PocketDISH. operate correctly. PocketDISH. Transfer the files first to a computer and from there onto the PocketDISH. 2 I cannot synchronize with You only can synchronize from In Windows Media Player Windows Media Player. Windows Media Player to your locate the Sync tab and follow PocketDISH.
Page 75 Microsoft Windows ME/2000/ Mac OS 10.2.4 or higher supported? XP or higher. 2 Which USB drivers do I The PocketDISH acts as a The PocketDISH acts as a need? mass storage device that is mass storage device that is recognized by the listed recognized by the listed operating systems.
Page 76 "Safely button that displays behind the Remove Hardware" icon. PocketDISH drive. 7 On the PocketDISH, I see This is normal, sometimes the This is normal, sometimes the files that I did not create. computer transfers files for...
Page 77 Troubleshooting If nothing helps Question Possible Cause How to Resolve 1 The PocketDISH is frozen, You have activated the Press and hold Function none of the buttons work. “Buttons Locked!” option. key 1 for three seconds. Do a reset by pressing and...
Page 78 Chapter 9 NOTES...
Page 79 Warranty, Compliance and Agreements PPENDIX This appendix informs you about warranties, compliance and agreements. • E XTENT OF IMITED ARRANTY • L IMITATIONS OF ARRANTY • L IMITATIONS OF IABILITY • L OCAL • FCC C OMPLIANCE • S OFTWARE OWNLOADS •...
Page 80: Appendix
Appendix This Limited Warranty is a legal document. Keep it in a safe place. Remember to retain your Proof of Purchase for warranty service. Any items returned without a copy of the Proof of Purchase will be considered out of warranty. XTENT OF IMITED ARRANTY...
Page 81 To the extent allowed by law, EchoStar makes no warranty, expressed or implied, as to the PocketDISH, including but not limited to any warranties or conditions of merchantability, satisfactory quality, fitness for a particular purpose, title and noninfringement.
Page 82 Appendix For example, some states in the United States, as well as some governments outside the United States (including provinces in Canada), may: preclude the disclaimers and limitations in this Warranty Statement from limiting the statutory rights of a consumer (e.g., the United Kingdom), otherwise restrict the ability of a manufacturer to enforce such disclaimers or limitations, or grant the customer additional warranty rights, specify the duration of implied warranties which the manufacturer cannot disclaim, or not allow limitations on the duration of implied warranties.
Page 83 EchoStar Technologies Corporation reserves the right, for whatever reason, to revise, change or modify the software that can be used by your PocketDISH without the obligation to notify or warrant any person or organization of such change. Therefore, please check the downloads that come via the EchoStar satellite or visit the internet site www.archos.com, on a regular basis, for the latest software available.
Page 84 Appendix OPYRIGHT AND RADEMARKS © 2005 EchoStar Technologies Corporation. All rights reserved worldwide. This user’s guide has been provided pursuant to an agreement containing restrictions on its use. This user’s guide is also covered by Federal Copyright Law. No part of this user’s guide may be copied, distributed, transmitted, stored in a retrieval system or translated into any human or computer language, in any form or by any other means, electronically, mechanically, magnetically, manually or otherwise or disclosure to third parties without the express written permission of EchoStar Technologies Corporation.
