Risk of electric shock!
Care

Warranty

Unplug from main power supply!
Danger of explosion! No solvents!
Machine housing, control panel Suds discharge pump
- Wipe with soft, moist cloth. Set cycle selector to Off, unplug from power supply.
- Do not use any scouring cleaning agent.
1. Open service door and remove.
- Remove residues of detergent and cleaning agent immediately.
- Absolutely no cleaning with water jet.
Clean detergent dispenser ... 2. Loosen screws and remove protective foil.
3. Remove emptying hose from the holder.Take off cap, let
... when there are detergent or fabric softener residues.
sudsy water drain out. Replace cap.
1. Pull out, press indent down, completely remove.
2. Removing dispenser: Press the dispenser up from below with your finger. 4. Carefully unscrew pump cap (remaining water).
Clean dispensing shell and dispenser with water and brush and dry off.
5. Clean interior, threads of the pump cap and pump housing (pump impeller
3. Set in dispenser and click in (stick the cylinder on the guide pin). must be able to be turned).
4. Push in detergent dispenser.
6. Replace pump cap and screw on tightly, handle is
vertical. Replace emptying hose in the holder.
Leave detergent dispenser open, so that remaining water can dry.
7. Screw on protective foil.
8. Replace service door and close.
Washing drum
Leave the loading door open so that the drum can dry. To prevent unused detergent from flowing into the outlet during the next wash:
Rust spots - use chlorine free cleaner, no steel wool. Pour 1 liter of water into dispenser II and start Drain cycle.
Descaling No laundry in the machine!
Screen in water supply
Not necessary if proper amount of detergent used. In case it is needed follow the descaling
agent manufacturer's instructions.
Dispenser for liquid detergent insert depending on model
Release water pressure in the supply hose:
Positioning the detergent dispenser for dosing of liquid detergent:
1. Close water tap!
- Completely remove detergent dispenser -> Page 8.
2. Select desired cycle (except for Spin/Drain ).
- Push liquid detergent insert forwards. 3. Select Start/Pause. Let cycle run approx. 40 seconds.
4. Set cycle selector to Off. Unplug from main power supply!
Not using liquid detergent insert (push up):
- for gel type detergent and powder detergent.
Cleaning screen:
1. Remove hose from water faucet.
- Rinse the strainers under flowing water.
- Remove hoses on the rear,
take out screen with pliers and clean.
2. Replace hose and check for leaks.
8
What to do if ...
Danger of scalding!
Let sudsy water cool down!
Close water tap!
Water is running out. - Fasten drain hose correctly / replace.
F
- Tighten screw connection of the supply hose.
F No water supply running in. - Start/Pause not selected?
Detergent not rinsed. - Water tap not opened?
- Screen possibly clogged? Clean screen -> Page 9.
- Supply hose kinked or pinched?
F The loading door will not - Safety function active. Cycle interrupted? -> Page 4.
open. - No final spin (spin stop = without final spin) selected?
max . -> Page 4.
158 F°
- Opening only possible using emergency unlock? -> Page 6
F Cycle does not start. - Start/Pause selected?
- Loading door closed?
F Sudsy water is not pumped - Clean pump -> Page 9.
out. - Clean drain pipe and/or drain hose.
F Water cannot be seen in - No malfunction - Water is below visible area.
drum.
F Spin results not satisfactory. - Wash small and large items together.
- Reduced ironing selected? -> Page 5.
- Selected speed too slow? -> Page 3.
F Spinning several times. - No malfunction - Imbalance control system equalizes
imbalance.
F ispenser 2 - Remove dispenser. Clean detergent dispenser and liquid
D not completely
detergent insert -> Page 8.
rinsed out.
F Odor in washing machine. - Perform Regular/Cotton Hot cycle without adding laundry.
Also use detergent.
F Foam comes out of the - Too much detergent added?
dispenser drawer. Mix 1 tablespoon fabric softener with ½ liter water and put
into disperser II of the dispenser drawer.
- Too much soap or non - HE soap used?
Mix 1 tablespoon of fabric conditioner with 1 pt ( ½ liter) of
water and pour into detergent dispenser II.
- Reduce amount of detergent for next wash cycle.
F Strong odor, vibrations and - Are machine feet fixed?
"walking" during spinning. Secure machine feet -> Installation instructions Page 5.
- Shipping lock removed?
Remove shipping lock -> Installation instructions Page 3.
F Display lamps not functioning - Power outage?
during operation. - Fuse blown? Flip / replace fuse.
- If the malfunction happens repeatedly, call customer service.
F Cycle runs longer than usual. - No malfunction - Imbalance control system equalizes
imbalance by frequent distribution of the wash.
- No malfunction - Foam control system is active - a rinse
cycle is turned on.
F Detergent residue on the - Some phosphate free detergents contain water insoluble
laundry. residues.
- Select Refresh or brush off the laundry after washing.
F Start/Pause blinks very fast - Water level too high. Adding laundry not possible. If
and a signal sounds in Pause necessary close loading door immediately.
condition. - Select Start/Pause to continue the cycle.
F If a malfunction cannot be repaired by yourself or if a repair is necessary:
- Set cycle selector to Off and remove the plug from main power supply.
9 10
- Close water tap and call customer service -> Page 13.

Important Safety instructions

Important Safety instructions
d d - When children become old enough to operate the appliance, it is legal responsibility of the parents or
WARNING
legal guardians to ensure that they are instructed in safe practices by qualified persons.
To reduce the risk of fire, electric shock, serious injury or death when using your washing To reduce the risk of fire, electric shock, serious injury or death when using your washing
- Do not allow children to play on or with appliance. Close supervision of children is necessary when
machine, follow basic precautions, including the following:
the appliance is used near children.
- BOSCH washers are provided with an Operating, Care and Installation Instructions Manual.
- Keep pets away from the washing machine.
Read and understand all instructions before using the washing machine.
- Do not insert/pull out the power plug with wet hands.
- Do not wash articles that have been previously cleaned, washed, soaked, or spotted with gasoline,
- Do not touch the door if washing at high temperatures.
dry cleaning solvents, other flammable or explosive substances as they give off vapors that could
ignite or explode. This includes articles that have been exposed to Naptha. - Use caution when draining hot water.
- Do not add gasoline, dry cleaning solvents, or other flammable or explosive substances to the wash - Do not climb onto the washing machine and lean on the open door.
of water. These substances give off vapors that could ignite or explode.
- Do not sit or stand on the top of the washing machine.
- Under certain conditions hydrogen gas may be produced in a hot water system that has not been
T
- o reduce the risk of fire or electrical shock, DO NOT use an extension cord or an adapter to
used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been
connect the washing machine to the power supply.
used for this length of time, turn on all hot water faucets and let the water flow out of each faucet for
several minutes before using the washing machine. This will release any accumulated hydrogen gas. - The washing machine must only be used for its intended purpose.
As the gas is flammable, do not smoke or use an open flame while carrying out this procedure.
- Always follow the fabric care instructions recommended by the clothing manufacturer.
- Before the appliance is removed from service or discarded, remove the door and the power - Do not use the washing machine if it has a worn power cord or loose plug. Contact an authorized
cord/plug. service agent.
- Do not reach into the appliance if the wash drum is moving. - Make sure that all water connections to the washing machine have shut off valve(s) and are readily
accessible. Close the washing machine water shut off valve(s) at the end of each wash day.
- Do not install or store this appliance where it will be exposed to the weather.
- Check the fill hose connections on a regular basis to ensure that they are tight and not leaking.
- Do not use bleach. Hazardous fumes can form.
- Always read and follow the instructions of the manufacturer of the detergent(s), cleaning aid(s), fabric
- Do not tamper with the controls.
softener(s) and static eliminator(s) which you are using. Heed all warnings and precautions.
- Do not repair or replace any part of the appliance or attempt any service unless specifically
- Store all laundry chemicals and aids in a cool dry place according to the manufacturers' instructions.
recommended in the user maintenance instructions or in published user repair instructions that you
- To reduce the risk of poisoning or chemical burns, keep all cleaning products out of the reach of
understand and have the skills to carry out.
children.
- Always unplug the washing machine from the power supply before attempting any service.
- Do not operate the washing machine if any guards, panels and/or fasteners and transport fixing
Disconnect the power cord by grasping the plug, not the cord.
bolts have been removed.
- To reduce the risk of fire, clothes, cleaning rags, mop heads and the like which have traces of any
Check the fill hose connections on a regular basis to ensure that they are tight and not leaking.
flammable substance, such as vegetable oil, cooking oil, petroleum based oils or distillates, waxes,
- Do not operate the washing machine if parts are missing or broken.
fats, etc., must not be placed in the washing machine. These items may contain flammable
substances which, even after washing, may smoke or catch fire. - Do not bypass any safety devices.
- To avoid floor damage and mold growth, do not let spills or splashes cause standing water around
- Do not machine wash fiberglass materials (such as curtains and window coverings that use
or under the appliance.
fiberglass materials). Small particles may remain in the washing machine and stick to fabrics in
subsequent wash loads causing skin irritation. - Do not operate this washing machine until you are sure that:
a. the washing machine has been installed according to the INSTALLATION INSTRUCTIONS.
b. all water, drain, power and grounding connections are in compliance with all local regulations
and/or other applicable regulations and requirements.
- Failure to install, maintain and/or operate the washing machine according to the manufacturer's
instructions may result in injury and/or damage.
- Check the fill hose connections on a regular basis to ensure that they are tight and not leaking.
- Removing any panel, including the service panel in the front can expose sharp edges and points,
electrical connections and hot surfaces.
- To avoid damage to the door, do not push against the door when moving the unit. Precautions
should be taken to avoid damage to the floor.
- The water connections should be made and tested before electrical power is applied to the machine.
11
Important Safety instructions
Notes:
- The IMPORTANT SAFEGUARDS and WARNINGS indicated in this manual do not cover all possible
conditions which may occur. Common sense, caution and care must be exercised when installing, conditions which may occur. Common sense, caution and care must be exercised when installing,
maintaining or operating the washing machine.
- Always contact your dealer, distributor, service agent or the manufacturer about any problems or
conditions that you do not understand.
GROUNDING INSTRUCTIONS
- This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce
the risk of electric shock by providing a path of least resistance for the electric current. This
appliance is equipped with a cord that has an equipment grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
- Improper connection of the equipment grounding conductor can result in electric shock. Connect to
individual Branch Circuit. Check with a qualified electrician or serviceman if you are in doubt as to
whether the washer is properly grounded. DO NOT modify the plug provided with the appliance
if it will not fit the outlet have a proper outlet installed by a qualified electrician.
- KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
In case of change of ownership, manual should be conveyed with the washer.
SAVE THESE INSTRUCTIONS.
Read these instructions before switching on the washing machine!
Also follow the separate Installation instructions.
Follow the safety instructions on pages 11-13!
12 13
