Problem
Outdoor
symptom
unit indi-
cation
(LED1)
Indoor unit
Lighting
operates.
or OFF
Outdoor unit
does not
operate.
Indoor unit
Lighting
operates.
or OFF
Outdoor unit
does not
operate.
Indoor and
Lighting
outdoor units
or OFF
do not oper-
ate.
Indoor and
Normal
outdoor units
blinking
do not oper-
or OFF
ate.
Indoor and
Normal
outdoor units
blinking
do not oper-
or OFF
ate.
Indoor unit
Malfunc-
tion No.
Lamp
Main Sub
Timer (Orange)
17
0
Operation (Green)
Plasmacluster
(Blue)
Timer (Orange)
18
0
Operation (Green)
Plasmacluster
(Blue)
Timer (Orange)
1
Operation (Green)
Plasmacluster
(Blue)
Timer (Orange)
19
0
Operation (Green)
Plasmacluster
(Blue)
Timer (Orange)
20
0
Operation (Green)
Plasmacluster
(Blue)
Content of diagnosis
Main
Sub
Wiring
Serial open-cir-
between
cuit
units
Wiring
Serial short-cir-
between
cuit
units
Serial erroneous
wiring
Indoor unit
Indoor unit fan
fan
error
Indoor unit
EEPROM data
control PWB
error
3-21
Check point
(1) Check the wires
(1) Connect stable
between units.
power supply.
Correct the wiring.
(2) Check voltage
(2) Replace the out-
between N and 1 the
door unit control
indoor/outdoor unit
PWB assembly.
terminal boards.
(3) Check the outdoor
(3) Replace the fuse/
unit fuse.
outdoor unit con-
trol PWB assem-
bly.
(4) Check 15-V,13-V
(4) Replace the out-
and 5-V voltages on
door unit control
the PWB.
PWB assembly.
Check resistance
between IPM termi-
nals.
(5) Check pins No.5 and
(5) Replace the out-
8 of connector CN3
door unit fan
of the outdoor unit
motor.
fan motor for short-
circuit.
(6) No abnormality
(6) Replace the out-
found in above
door unit control
inspections (1)
PWB board.
through (5).
(1) Check the wiring
(1) Correct the wiring.
between units.
(1) Check the wiring
(1) Correct the wiring.
between units.
(1) Check the indoor fan
(1) Replace the indoor
motor for proper
fan motor.
rotating operation.
(Check fan lock.)
(2) Check the lead wire
(2) Replace the indoor
of the indoor fan
fan motor.
motor for open-cir-
cuit.
(3) Check connector of
(3) Correct the instal-
the indoor unit fan
lation of the indoor
motor for secure
fan motor connec-
installation.
tor.
(4) No abnormality
(4) Replace the indoor
found in above
unit control PWB.
inspections (1)
through (3).
(1) (EEPROM read data
(1) Replace the indoor
error)
unit control PWB.
AY-ZP35PR
