11. PCB Diagrams STANDBY DVD/VIDEO-CD/CD PLAYER DVD-709 POWER OPEN/ OPEN/ CLOSE CLOSE 24bit 96kHz AUDIO D/A CONVERTER SPATIALIZER N-2-2 DIGITAL VIDEO 12. Wiring Diagram DVD-709 13. Schematic Diagrams © Samsung Electronics Co., Ltd. NOV. 1999 Printed in Korea AH68-00137A REV.-2...
Page 2: Precautions
Melal Part cal return path to the chassis. Any current measured must not exceed 0.5mA. Reverse the instrument power cord plug in the out- ohmmeter let and repeat the test. See Fig. 1-1. Fig. 1-2 Insulation Resistance Test Samsung Electronics...
Page 3 (5) antenna wiring. Always inspect in all areas tinuously and new instructions are issued whenev- for pinched, out-of-place, or frayed wiring, Do not er appropriate. change spacing between a component and the printed-circuit board. Check the AC power cord for damage. Samsung Electronics...
Page 4: Servicing Precautions
Components i-enti- fied by shading, by( ) or by ( ) in the circuit dia- gram are important for safety or for the characteris- tics of the unit. Always replace them with the exact replacement components. Samsung Electronics...
Page 5 (6) Do not remove a replacement ESD device from its protective package until immediately before your are ready to install it.(Most replacement ESD devices are packaged with leads electrically short- ed together by conductive foam, aluminum foil or comparable conductive materials). Samsung Electronics...
Page 6 3 Be sure to put on a wrist strap grounded to the sheet. 3 Be sure to lay a conductive sheet made of copper etc. Which is grounded to the table. Samsung Electronics...
Page 7 4) Insert FPC into Main PCB CN6 and switch SW3 on 4) Disassemble the deck PCB. deck PCB to ÒONÓ. (See Fig 1-4) Note : If the assembly and disassembly are not done in correct sequence, the Pick-up may be damaged. TO MAIN PCB (CN6) Fig. 1-4 Samsung Electronics...
Page 8: Reference Information
"L":normal speed, "H":double speed DEM0 De-emphasis frequency select pin DZFR Rch zero input detect pin De-emphasis frequency select pin DZFL Lch zero input detect pin DEM1 Note : Allinput pins except internal pull-down pins should not be left floating. Samsung Electronics...
Page 9 DDVD1 ENV_SEL(02H) 58 BCA ACD1 GAIN_FE(03H) MIRR OFSTHOLD BCD1 ABCD_OFST(O6H) CCD1 56 DPDVCC FE_0FST(05H) DCD1 55 DFCT2 AVCC CDRSEL(00H) 54 DFCT1 LDONB(00H) TESEL(OOH) ANALOG VREFA VC AMP 53 DFCTTH1 ENVELOPE DEFECT 52 DFCTTH2 ALPC FOFST FOFST 51 DVCC Samsung Electronics...
Page 10 Reference Information Samsung Electronics...
Page 11 Reference Information 2-1-3 SIC1 (KS1452 ; Digital Servo) DIRC SSTOP /PSO SMON LOCK DFCT FOKB MIRR TZCA PHI1 XOUT TEST RSTB TILTO TILTI Samsung Electronics...
Page 12 Reference Information Samsung Electronics...
Page 13 Reference Information 2-1-4 DIC1 (KS1453 ; DVD Data Processor) Samsung Electronics...
Page 14 Reference Information Samsung Electronics...
Page 15 D a t a O u t p u t E n a b l e P o w e r ( + 5 V ) P o w e r ( + 3 . 3 V ) N . C No Connection Samsung Electronics...
Page 16 D V D - D A T A 7 / C D G - S C L K Global VREQUEST I n t e r f a c e VSTROBE A_VSS Signals ERROR A_VDD P10[10:0] V-DACK/ASTROBE AREQUEST R E S E T A-DACK ZiVA Decoder Samsung Electronics...
Page 17 Raster Contral 1 for video port. This pin receives/provides a VS/FS/FSEQ signal. RCV1 Raster Contral 2 for video port. This pin provides an HS pulse of programmable length or receives I / O RCV2 an HS pulse. 2-10 Samsung Electronics...
Page 18 The 12C-bus receiver waits for the START condition. S C L 12C serial clock input S D A I / O 12C serial data input/output TTXRQ Teletext Request output, indicating when text bits are requested T T X Teletext bit stream input Samsung Electronics 2-11...
Page 19 P30(RD) P31(WR) 8BIT PWM (T03)P73 P32(HWR) (TIMER 3) P33(WAIT) PORT 3 P34(BUSRQ) (INT4/T14)P80 P35(BUSAK) (INT5/T15)P81 16BIT TIMER P36(R/W) (T04)P82 (TIMER 4) P37(RAS) (T05)P83 16BIT TIMER (INT6/T16)P84 CS/WAIT P40(CS0/CAS0) (TIMER 5) (INT7/T17)P85 CONTROLLER P41(CS1/CAS1) (T06)P86 (3-BLOCK) P42(CX2/CAS2) (INTO)P87 2-12 Samsung Electronics...
Page 20 Reference Information Samsung Electronics 2-13...
Page 21 Chip Enable and Output Buffers Prog Logic Gating Decoder A0-A19 Address 2,097,152-Bit Inputs Cell Matrix Decoder TOP VIEW NAME FUNCTION A0-A19 Address Inputs Chip Enable Input Data Input/Outputs DQ0-DQ7 Output Enable Input Vcc Syply Voltage OE/VPP Ground 2-14 Samsung Electronics...
Page 22 Reference Information 2-1-10 FIC2 (LC866232 ; Front Micom) Samsung Electronics 2-15...
Page 23 Reference Information MEMO 2-16 Samsung Electronics...
Page 24 Color Signal : 0.286Vp-p (75ohm load) DVD-709 : L, R Mixed Audio Out DVD-909 : L1/L2, R1/R2 Analog Audio Out F/L, F/R, R/L, R/R, C/T, S/W ; DVD-909 Only Analog : 2Vrms (1KHz, odBFS) Output Level Digital : DVD-709 ; 500mVp-p (Coaxial) Audio Output DVD-909 ;...
Page 25: Product Specification
B (Blue) : 0.714Vp-p (75ohm load) Composite Video : 1.0Vp-p (75ohm load) Video Output Composite Video - DVD-909 ; 2 channel : 1.0Vp-p (75ohm load) DVD-709 ; 1 channel : 1.0Vp-p (75ohm load) Component Video Y : 1.0Vp-p (75ohm load) ; <DVD-909 Only>...
Page 26: Operating Instructions
4. Operating Instructions 4-1 NTSC (DVD-909/709) Samsung Electronics...
Page 27 Operating Instructions Samsung Electronics...
Page 28 Operating Instructions Samsung Electronics...
Page 29 Operating Instructions Samsung Electronics...
Page 30 Operating Instructions Samsung Electronics...
Page 31 Operating Instructions 4-2 PAL (DVD-909/709) Samsung Electronics...
Page 32 Operating Instructions Samsung Electronics...
Page 33 Operating Instructions Samsung Electronics...
Page 34 Operating Instructions Samsung Electronics...
Page 35 Operating Instructions 4-10 Samsung Electronics...
Page 36 Operating Instructions Samsung Electronics 4-11...
Page 37 Operating Instructions 4-12 Samsung Electronics...
Page 38 Operating Instructions Samsung Electronics 4-13...
Page 39 Operating Instructions 4-14 Samsung Electronics...
Page 40: Disassembly And Reassembly
Note : If Tray Œ doesnÕt open, insert a Screw driver ¨ into the Emergency hole ˇ(as shown in detailed draw- ing) and then turn it in the direction of arrow ÒBÓ. Open Tray manually. Œ TRAY ´ DOOR-TRAY "A" ˇ EMERGENCY HOLE "B" ¨ SCREW DRIVER <Bottom View> Fig. 5-1 Door-Tray Removal Samsung Electronics...
Page 41 1) Remove 3 Screws Œ on the back Top Cabinet. 2) Remove 2 Screws ´, ˇ on the left and right side. 3) Lift up the Top Cabinet in direction of arrow. Œ 3 SCREWS ´ 1 SCREW ˇ 1 SCREW Fig. 5-2 Top Cabinet Removal Samsung Electronics...
Page 42 5) Remove 4 Screws ’ and Play PCB ˝. ¨ 2 SCREWS Œ 2 SCREWS ˆ BRACKET-PHONE Ø PHONE/POWER PCB ’ 4 SCREWS ˝ PLAY PCB ˇ KNOB-VOLUME ´ ASS'Y FRONT-PANEL ” KNOB-SUHTTLE ∏ KNOB -JOG Fig. 5-3 Ass’y Front-Panel, Phone/Power PCB, Play PCB Removal (DVD-909) Samsung Electronics...
Page 43 2) Remove 2 Screws ˇ and Power PCB ¨. 3) Remove 3 Screws ˆ and Play PCB Ø. Œ 2 SCREWS ˇ 2 SCREWS ¨ POWER PCB ˆ 3 SCREWS Ø PLAY PCB ´ ASS'Y FRONT-PANEL Fig. 5-4 Ass’y Front-Panel, Power PCB, Play PCB Removal (DVD-709) Samsung Electronics...
Page 44 3) Remove 3 Screws ¨ and lift up the Main PCB ˆ. Œ 4 SCREWS ˇ JACK PCB ¨ 3 SCREWS ˆ MAIN PCB ´ 5 SCREWS Fig. 5-5 Main PCB, Jack PCB Removal (DVD-909 ; Component Video RCA Jack Model) Samsung Electronics...
Page 45 3) Remove 3 Screws ¨ and lift up the Main PCB ˆ. Œ 4 SCREWS ˇ JACK PCB ¨ 3 SCREWS ˆ MAIN PCB ´ 1 SCREW Fig. 5-6 Main PCB, Jack PCB Removal (DVD-709 ; Component Video RCA Jack Model) Samsung Electronics...
Page 46 3) Remove 3 Screws ¨ and lift up the Main PCB ˆ. Œ 4 SCREWS ˇ JACK PCB ¨ 3 SCREWS ˆ MAIN PCB ´ 6 SCREWS Fig. 5-7 Main PCB, Jack PCB Removal (DVD-909 ; Scart Jack Model) Samsung Electronics...
Page 47 3) Remove 3 Screws ¨ and lift up the Main PCB ˆ. Œ 4 SCREWS ˇ JACK PCB ¨ 3 SCREWS ˆ MAIN PCB ´ 3 SCREWS Fig. 5-8 Main PCB, Jack PCB Removal (DVD-709 ; Scart Jack Model) Samsung Electronics...
Page 48 Disassembly/Reaasembly 5-1-9 Ass’y Deck Removal 1) Remove 4 Screws Œ from the AssÕy Deck and lift it up. Œ 4 SCREWS Fig. 5-9 Ass’y Deck Removal Samsung Electronics...
Page 49: Pcb Location
Disassembly/Reaasembly 5-2 PCB Location DVD-909 JACK PCB MAIN PCB PHONE/POWER PCB PLAY PCB DVD-709 JACK PCB POWER PCB MAIN PCB PLAY PCB Fig. 5-10 PCB Location 5-10 Samsung Electronics...
Page 50 JACK PCB MAIN PCB ” MAIN PCB JACK PCB CN11 ’ DECK PCB MAIN PCB ˝ MAIN PCB DECK PCB Ô CON23 PHONE/POWER PCB JACK PCB CN17 CN17 JACK PCB PHONE/POWER PCB CON23 Fig. 5-11 Connector Diagram (DVD-909) Samsung Electronics 5-11...
Page 51 JACK PCB MAIN PCB Ø MAIN PCB JACK PCB CN12 ∏ CN11 JACK PCB MAIN PCB ” MAIN PCB JACK PCB CN11 ’ DECK PCB MAIN PCB ˝ MAIN PCB DECK PCB Fig. 5-12 Connector Diagram (DVD-709) 5-12 Samsung Electronics...
Page 52 3) Pull the Tray Ø to disassemble, while simultaneously pushing the Hook ∏, ” in direction of arrow ÒAÓ, ÒBÓ. Œ 2 SCREWS ´ COVER SHEET ˇ ASS'Y - DECK CLAMPER ∏ HOOK "C" "B" "D" ” HOOK Ø TRAY ˆ SCREW DRIVER "A" ¨ EMERGENCY HOLE <Bottom View> Fig. 5-13 Tray Removal Samsung Electronics 5-13...
Page 53 2) Disassemble the AssÕy-Deck Sub ¨ in direction of arrow ÒBÓ, while simultaneously pushing the Hook ˇ in direction of arrow ÒAÓ. ¨ ASS'Y - DECK SUB "B" "A" ˇ HOOK ´ ASS'Y - PCB DECK Œ 2 SCREWS Fig. 5-14 Ass’y-Deck Sub Removal 5-14 Samsung Electronics...
Page 54 ALIGN TWO ARROWS ’ GEAR - CAM SUB Æ GEAR - SYNCRO Ú SHAFT - SYNCRO Æ GEAR - SYNCRO Ò LEVER - OPEN S/W 1 SCREW Ô ASS'Y - MOTOR LOAD Fig. 5-15 Chassis-Main Parts Removal Samsung Electronics 5-15...
Page 55 Disassembly/Reaasembly 5-4-4 Ass’y-Brkt Deck Removal 1) Remove 4 Screws Œ. 2) Lift up the AssÕy-Brkt Deck ´. Œ 4 SCREWS ´ ASS'Y - BRKT DECK Fig. 5-16 Ass’y-Brkt Deck Removal 5-16 Samsung Electronics...
Page 56 GEAR - FEED B Ô WASHER - PLAIN Ø ASS'Y - PICK UP Ú ASS'Y GEAR - FEED CU/CL ˇ SHAFT - P/U Ò WASHER - PLAIN ˆ RACK - SLIDE ¨ 2 SCREWS Fig. 5-17 Ass’y- Deck Parts Removal Samsung Electronics 5-17...
Page 57 Disassembly/Reaasembly MEMO 5-18 Samsung Electronics...
Page 58: Circuit Descriptions
Input : Common power to transformer (Vp). Fig. 6-2 The output Vs of transformer is determined by the ratio of 1st Np and 2nd Ns. Vs = (Ns/Np) x Vp Fig. 6-3 Vout Vout is output (DC) by diode and condensor. Fig. 6-4 Samsung Electronics...
Page 59 Fig. 6-6 3 Terms 1) 1st : Common power input to 1st winding. 2) 2nd : Circuit followings output winding of transformer. 3) f (Frequency) : Switching frequency (T : Switching cycle) 4) Duty : (Ton/T) x 100 Samsung Electronics...
Page 60 ´ Rectify to PD12 and smooth to PE6. ˇ Use the output of transformer as PIC1 Vcc : The loads are different before and after PIC1 driving. (Vcc of PIC1 decreases below OFF voltage, using only the resistance due to load increase after PIC1 driving.) Samsung Electronics...
Page 61 Reverse sequence of the above description --> Duty down --> Vout down --> Maintain 5.8V (i.e., the feedback to maintains 5.8V). Œ PR35, PR36 : Reduce 5.8V overshoot ´ PR37, PC44 : Prevent PIC3 oscillation(for phase correction) ˇ PC09 : Adjust feedback response rate Samsung Electronics...
Page 62 Fig. 6-9 6-1-3 (b) PIC1 (STR-G6153T) Internal Block Diagram V c c Voltage Sync. 6.3V UVLO Ref. OSC. Drain Feedback 2.5R Source Voffset Sense Rsense Reset Sense 7.5V Reset Thermal Protection Control IC O C P Fig. 6-10 Samsung Electronics...
Page 63 RF SUM & AGC. It controls RF SUM & AGC gain by means of Pin 89-95 and interfaces with PWM signal, (output from PWM terminal of KS1453, via low-pass filter to adjust boost gain and peak frequency. EQout terminal is connected with EQin (Pin 86). Samsung Electronics...
Page 64 Œ EQG (Pin 97) : Changes the gain of peak frequency with EQ frequency characteristic. Convert PWM signal, output from KS1453, into DC via low-pass filter. ´ EQF (Pin 98) : Changes the peak frequency with EQ frequency characteristic. Convert PWM signal, output from KS1453, into DVD via low-pass filter. Samsung Electronics...
Page 65: System Control
KS1461 KS1452 KS1453 ZIVA-3 SAA7128/7120 AK4324 FIC1 MIC1 MIC2 FRONT MICOM MAIN MICOM ADDR LATCH LC86P6232 TMP93CM41F 74AC573 MIC7 ADDR DECODER DATA BUS 74HC00 MIC5 MIC8 EEPROM EPROM KS24C020 AT27C080 MICOM BLOCK LOW ADDRESS HIGH ADDRESS Fig. 6-13 Samsung Electronics...
Page 66 • CH2 : DSPCS (DIC1-2, DATA PROCESSOR CHIP SELECT) • CH3 : DVDCS (VIC1-206, A/V DECODER CHIP SELECT) • CH4 : SRVCS (SIC1-10, DIGITAL SERVO CHIP SELECT) • CH5 : WR (MIC1-73, MICOM OUTPUT WRITE SIGNAL) • CH6 : RD (MIC1-72, MICOM OUTPUT READ SIGNAL) Samsung Electronics...
Page 67 • CH2 : DSPCS (DIC1-2, DATA PROCESSOR CHIP SELECT) • CH3 : DVDCS (VIC1-206, A/V DECODER CHIP SELECT) • CH4 : SRVCS (SIC1-10, DIGITAL SERVO CHIP SELECT) • CH5 : WR (MIC1-73, MICOM OUTPUT WRITE SIGNAL) • CH6 : RD (MIC1-72, MICOM OUTPUT READ SIGNAL) 6-10 Samsung Electronics...
Page 68 6-4-2 Block Diagram DISC SLED M/T SPINDLE M/T HALL MIC1 TMP 93CS41F › HA1+ HA1– SIC8 HA2– NJM2903 RIC1 HA2+ KS1461 SLED+ SLED– SIC1 KS1452 & DRIC2 FOCUSING F– KA3010D TRACKING T– SPINDLE DRIC1 KA3011D “ Fig. 6-17 Samsung Electronics 6-11...
Page 69 Meanwhile, DVD repeats the track jump from 1 to 4 in inner direction at normal play (because data- read speed from disc is faster than data output speed on screen). ´ For CD, VCD Receive the signal output through E, F of Pick-up, from RIC1. The tracking error signal is similar to DVD. 6-12 Samsung Electronics...
Page 70 If the existing track count is within fine seek range, tracking begins using fine seek. 4) CLV SERVO(DISC MOTOR CONTROL SERVO) Input RF signal (from Pick-up) to SIC1 pin59. Detect SYNC signal from RF in SIC1, and output PWM signal to SIC1 pin 55 for constant linear velocity. Samsung Electronics 6-13...
Page 71 177, 178 SDATA[7..0] DVD-D[7..0] VIC1 EFMI PLCK CSTROBE VSTROBE (ZiVA-3) PLCK DATREQ REQUEST DIC1 DATACK DACK (KS1453) HDATA[7..0] DTER *ERR HADDR[3..0] MDAT[7:0] MRZA(3) ZCS(2) /INT MWR(128) MRD(127) ZIRQZD(126) AD[7..0] INTO(ZIRQZD) HA[23..8] INT4(/INT) *RD(72) *WR(73) MIC1 TMP93CM41F Fig. 6-19 6-14 Samsung Electronics...
Page 72 It measures the timing that data processed in DIC1 at DVD playback. STROBE DACK SDATA all Fig. 6-20 • CH1 : STROBE (DIC1-69, CLOCK) • CH2 : REQ (DIC1-70, DATA REQUEST) • CH3 : DACK (DIC1-58, DATA ACKNOWLEDGE) • CH4 : SDATA (DIC1-60~67, DATA) Samsung Electronics 6-15...
Page 73 Video signal converted into analog signal is outputted via amplifier of analog part. (Main Board) (Output Board) CVBS-1 Video VIC1 CVBS-2 VIC52 data A/V Decoder Amplifier ZiVA-3 BA7660 VIC50 SAA7128 Video encoder MIC1 VIC51 Main Micom Amplifier TMP93CM41F BA7660 Fig. 6-21 Video Output Block Diagram 6-16 Samsung Electronics...
Page 74 13). Pin9, Pin12 and Pin14 of VIC51 and VIC52 are feedback pin to SAG compensation(DC characteristic compen- sation of signal). Resistance(VR3-VR14) which is inserted to input terminal is bias resistance for input offset. The signal to which gain is adjusted by amplifier is outputted from jack via 75ohm. Samsung Electronics 6-17...
Page 75 CVBS/Y_VCR_OUT SIC2 SIC3 SIC4 R_TV_OUT (14053) (14053) (NJM2267) G_TV_OUT Switch Switch Amplifier CVBS_VCR_OUT CVBS_S B_TV_OUT CVBS_TV_IN R/C_TV_OUT R_VCR_IN R_VCR_IN SIC1 SIC5 SIC6 G_TV_OUT (14053) (14053) (BA7660) G_VCR_IN G_VCR_IN B_TV_OUT Switch Switch Amplifier B_VCR_IN B_VCR_IN CVBS_VCR_OUT Fig. 6-23 6-18 Samsung Electronics...
Page 76 D/A CONVERTER FRONT-R FILTER VIC1 (ZiVA-3) A/V Decoder DATA2 POST AIC3 SURROUND-L FILTER AK4324 POST D/A CONVERTER SURROUND-R FILTER DATA3 POST AIC4 CENTER FILTER AK4324 POST D/A CONVERTER SUB WOOFER FILTER Fig. 6-24 Audio Output Block Diagram Samsung Electronics 6-19...
Page 77 The 2 channels data is converted through audio decoder 2-channel data and Data 0 and Data 1 are outputted in digital audio interface.Via IEC-958 output process, they is transmitted to digital amplifier or AC-3/MPEG/DTS amplifier built in the external digital input source with IEC-958/1937 transmission format. 6-20 Samsung Electronics...
Page 78: Troubleshooting
7. Troubleshooting Samsung Electronics...
Page 79 Troubleshooting Samsung Electronics...
Page 80 Troubleshooting Samsung Electronics...
Page 81 Troubleshooting Samsung Electronics...
Page 82 Troubleshooting Samsung Electronics...
Page 83 Troubleshooting Samsung Electronics...
Page 84 Troubleshooting Samsung Electronics...
Page 85 Troubleshooting Samsung Electronics...
Page 86 Troubleshooting Samsung Electronics...
Page 87 Troubleshooting 7-10 Samsung Electronics...
Page 88 Troubleshooting Samsung Electronics 7-11...
Page 89 Troubleshooting 7-12 Samsung Electronics...
Page 90: Exploded View And Parts List
Page 8-1 Cabinet Assembly (DVD-909) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-2 Cabinet Assembly (DVD-709) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 91: Exploded Views And Parts List
Exploded Views and Parts List 8-1 Cabinet Assembly (DVD-909) Samsung Electronics...
Page 92 Refer to table below ASSY-DOOR TRAY;DVD-739,ABS,XAA Refer to table below KNOB-VOLUME;-,ABS94,HB,L/GRAY,-,DVD-909 Refer to table below KNOB-JOG;-,ABS94,HB,BLK,-,DVD-909 Refer to table below KNOB-SHUTTLE;-,ABS94,HB,BLK,-,DVD-909 AH61-00194A HOLDER-DECK A;-,ABS 94HB,-,DVD-909 AH64-80001E FOOT-FRONT;-,ABS94,HB,T2,SIL,H/STAMP,DVD AH61-00194B HOLDER-DECK B;-,ABS 94HB,-,BLK,-,DVD-909 AH61-00194C HOLDER-DECK C;-,ABS 94HB,-,BLK,-,DVD-909 Refer to table below ASSY-CABINET TOP;ABS, Refer to table below SCREW-TAPTITE;BH,+,B,M3,L10,SWCH1018...
Page 93 Exploded Views and Parts List 8-2 Cabinet Assembly (DVD-709) Samsung Electronics...
Page 94 Loc. No Parts No. Description ; Specification Remark Refer to table below ASSY-CABINET FRONT;DVD-709,ASSY,EXPORT Refer to table below ASSY-DOOR TRAY;DVD-709,ABS AH61-00194A HOLDER-DECK A;-,ABS 94HB,-,DVD-909 AH64-80001E FOOT-FRONT;-,ABS94,HB,T2,SIL,H/STAMP,DVD AH61-00194B HOLDER-DECK B;-,ABS 94HB,-,BLK,-,DVD-909 AH61-00194C HOLDER-DECK C;-,ABS 94HB,-,BLK,-,DVD-909 Refer to table below ASSY-CABINET TOP;DVD-709,ABS Refer to table below SCREW-TAPTITE;BH,+,B,M3,L10,BLK,SWCH1018...
Page 95: Deck Assembly
Exploded Views and Parts List 8-3 Deck Assembly S.N.A. S.N.A. S.N.A. S.N.A. : Service Not Available Samsung Electronics...
Page 96 Exploded Views and Parts List Loc. No Parts No. Description ; Specification Remark AH91-60117A ASSY-DECK CLAMPER;DVD860,-,DP-1 AH92-00035A ASSY-PCB-DECK;DP-3,- 3809-001125 CABLE-FLAT;30V,80C,140MM,8P,1MM,UL2896 AH91-60147A ASSY-BRKT DECK;DP-3,DVD-909,- AH66-90054A TRAY-DVD;DP,ABS,-,BLK,-,DP-1 AH91-60154A ASSY-DECK HOUSING;DP-3,DVD-909,- AH66-30087A LEVER-OPEN SW;DP,KEPITAL,T0.7,L26,F20-03 AH66-20194A GEAR-CAM CENTER;DP,KEPITAL F20-03,M1.2,Z AH66-20183A GEAR-CAM SUB;DP,KEPITAL FT2020,M1,2,Z7,- AH66-20185A GEAR-TRAY A;DP,KEPITAL F20-03,M0.4/M0.5,...
Page 97 Exploded Views and Parts List MEMO Samsung Electronics...
Page 98: Electrical Parts List
2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 MR37 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 DRE9 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 MR38 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 DRIC1 1003-001130 IC-MOTOR DRIVER;KA3011DTF,SOP,28P,-,QUAD MR39 2007-000103 R-CHIP;120Kohm,5%,1/16W,DA,TP,1608 DRIC2 1003-001067 IC-MOTOR DRIVER;KA3010D,SOP,28P,375MIL,Q 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 DRL1 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- MR40 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608 DRL2 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- MR43 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
Page 99 RR43 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 RC55 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608 RR44 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 2203-001052 C-CERAMIC,CHIP;560pF,10%,50V,X7R,TP,1608 RR45 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 2203-001640 C-CERAMIC,CHIP;390pF,10%,50V,X7R,TP,1608 RR46 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,- RR47 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, RR48 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608 0401-000008 DIODE-SWITCHING;DAN217,80V,100mA,SOT-23, RR49 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 0403-001079 DIODE-ZENER;UDZ3.9B,7%,200MW,SOD-323,TP 2007-001056 R-CHIP;6.2Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
Page 100 VC21 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, SIC8 1202-000121 IC-VOLTAGE COMP.;2903,SOP,8P,150MIL,DUAL VC22 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- VC23 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- VC24 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- VC25 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP VC26 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 VC27 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, Samsung Electronics...
Page 101 1105-001165 IC-SDRAM;416S1020,512Kx16BITx2,TSOP,50P NTSC VR50 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 VIC4 1105-001259 IC-DRAM;416S1020,16BIT,TSOP,50P,400MIL,8 VR51 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 VIC6 AH14-10004R IC;M74HCU04,SOP,TAPE 14P VR52 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- VR54 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 VL10 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 VR55 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 VL11 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- VR56 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
Page 102 VR66 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 AC19 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,- DVD-909 ONLY VR67 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, VR68 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 AC20 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY VR69 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 AC21 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY 2007-000116 R-CHIP;120ohm,5%,1/16W,DA,TP,1608 AC22 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY VR70 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 AC23 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,...
Page 103 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- DVD-909 ONLY 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3, DVD-909 ONLY AOP1 1201-000163 IC-OP AMP;4560,SOP,8P,150MIL,DUAL,100V/M 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, AOP2 1201-000163 IC-OP AMP;4560,SOP,8P,150MIL,DUAL,100V/M DVD-909 ONLY 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, AOP3 1201-000163 IC-OP AMP;4560,SOP,8P,150MIL,DUAL,100V/M DVD-909 ONLY 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- AOP4 1201-000163 IC-OP AMP;4560,SOP,8P,150MIL,DUAL,100V/M DVD-909 ONLY 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- AOP5 1201-000163 IC-OP AMP;4560,SOP,8P,150MIL,DUAL,100V/M...
Page 104 AH39-00035A LEAD CONNECTOR-ASSY;-,5264-08,35023-08,8 AR44 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY CN15 3711-000665 CONNECTOR-HEADER;BOX,12P,1R,2mm,ANGLE DVD-909 ONLY AR45 2007-000766 R-CHIP;330OHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY CN17 AH39-00037A LEAD CONNECTOR-ASSY;-,51004-06,35023-06, DVD-909 ONLY AR46 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY CN18 3711-000967 CONNECTOR-HEADER;BOX,4P,1R,2mm,ANGLE,SN AR47 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V AR48 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3...
Page 105 Description ; Specification Remark 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 JP230 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 PAL ONLY FIC1 AH09-00010A IC-MICOM MASKING;LC866232,100PIN,QIP,FLT JP231 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 DVD-909 PAL ONLY FIC2 1203-001252 IC-VOL. DETECTOR;7545,TO-92,3P,-,PLASTIC JP232 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 DVD-909 PAL ONLY FIC3 0801-002166 IC-CMOS LOGIC;7SHU04,INVERTER,SSOP,5P,63 JP233 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 DVD-909 PAL ONLY...
Page 106 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP PAL ONLY PR35 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM SCQ12 0504-000156 TR-DIGITAL;DTA124EKA,PNP,200mW,22K-22KDVD-909 PAL ONLY PR36 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SCQ13 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23, DVD-909 PAL ONLY PR37 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SCQ14 0504-000156 TR-DIGITAL;DTA124EKA,PNP,200mW,22K DVD-909 PAL ONLY PR38 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm SCQ17 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT- PAL ONLY PR39 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m...
Page 107 VR115 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3.2MM SCR67 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012 PAL ONLY VR116 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3.2MM SCR7 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012 PAL ONLY VR117 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 NTSC ONLY SCR8 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012 PAL ONLY VR12 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM SCR9 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012 PAL ONLY VR121 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012 PAL ONLY...
Page 108 Electrical Parts List Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark ASSY-PCB-PHONE POWER;DVD-909 ASSY-PCB-DECK;DP-3 CON23 3711-001062 CONNECTOR-HEADER;BOX,6P,1R,2mm,STRAIGHT, 3708-001081 CONNECTOR-FPC/FC/PIC;11P,1mm,STRAIGHT,SN CON23-A AH39-00030A LEAD CONNECTOR-ASSY;-,51004-04,35023-04, 3708-001001 CONNECTOR-FPC/FC/PIC;20P,1mm,SMD-A,SN 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3.2MM 3711-000827 CONNECTOR-HEADER:BOX,2P,1R,2mm,STRAIGHT, HPJ01 3722-000345 JACK-PHONE;3P,6.4mm,AG,BLK,- 3708-001108 CONNECTOR-FPC/FC/PIC;8P,1.0MM,ANGLE,SN 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3.2MM...
Page 109 Electrical Parts List MEMO 9-12 Samsung Electronics...
Page 110: Block Diagrams
10. Block Diagrams 10-1 NTSC DVD-909 DECK ASS'Y 2K EEPROM Remote Control MIC1 FIC1 MIC8 8M EPROM (TMP93CM41F) (LC86P6232) Optical Main Controller Front Controller Coaxial Pick-UP AIC4 & I/V Amp (AK4324) Audio DAC Disc Feed RIC1 AIC3 Motor Motor (KS1461) (AK4324) RF Amp &...
Page 111 Actuator & Motor Driver Driver DIC2 4M DRAM VIC4/10 32M SDRAM Coaxial DIC1 (KS1453) AIC1 DVD & CD Processor VIC1 (AK4324) (ZiVA-3) Audio DAC A/V Decoder SIC1 (KS1452) Digital Servo CVBS VIC50 (SAA7128) Yout Video Encoder Cout 10-2 Samsung Electronics...
Page 112 Block Diagrams 10-3 PAL DVD-909 DECK ASS'Y 2K EEPROM Remote Control MIC1 FIC1 MIC8 8M EPROM (TMP93CM41F) (LC86P6232) Optical Front Controller Main Controller Coaxial Pick-UP AIC4 & I/V Amp (AK4324) Audio DAC Disc Feed RIC1 AIC3 Motor Motor (KS1461) (AK4324) RF Amp &...
Page 113 Disc Motor Motor Driver Driver DIC2 4M DRAM VIC4/10 32M SDRAM Coaxial DIC1 (KS1453) DVD & CD Processor AIC1 VIC1 (AK4324) (ZiVA-3) Audio DAC A/V Decoder SIC1 (KS1452) CVBS Digital Servo Yout Cout VIC50 (SAA7128) Video Encoder 10-4 Samsung Electronics...
Page 114: Pcb Diagrams
11-2 Jack - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11-3 11-3 Phone/Power (DVD-909 Only) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11-4...
Page 115 PCB Diagrams 11-1 Main 11-2 Samsung Electronics...
Page 116 PCB Diagrams 11-2 Jack Samsung Electronics 11-3...
Page 117 PCB Diagrams 11-3 Phone/Power (DVD-909 Only) 11-6 Deck 11-4 Power (DVD-709 Only) 11-5 Play 11-4 Samsung Electronics...
Page 118: Wiring Diagram
12. Wiring Diagram MAIN PCB JACK PCB (DVD-909) <PIN1 ~ 12> PHONE/POWER PCB (DVD-909 ONLY) (DVD-909) <PIN1 ~ 12> PLAY PCB DECK PCB POWER PCB (DVD-709 ONLY) Samsung Electronics 12-1...
Page 119 Wiring Diagram MEMO 12-2 Samsung Electronics...
Page 120 13-12 Component (DVD-909 Only ; Option) - - - - - - - - - - - - - - - - - - - - - - - - - - 13-13 13-13 Scart Jack (DVD-909 PAL Only) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13-14...
Page 121: Schematic Diagrams
Schematic Diagrams 13-1 S.M.P.S. 13-2 Samsung Electronics...
Page 122 Schematic Diagrams 13-2 Main Power Supply Samsung Electronics 13-3...
Page 123 Schematic Diagrams 13-3 Main Micom 13-4 Samsung Electronics...
Page 124 Schematic Diagrams 13-4 Servo Samsung Electronics 13-5...
Page 125 Schematic Diagrams 13-5 Video (DVD-909 OPTION) (DVD-909 OPTION) Y Output C Output CVBS Output 13-6 Samsung Electronics...
Page 126 Schematic Diagrams 13-6 Audio (DVD-909 OPTION) Samsung Electronics 13-7...
Page 127 Schematic Diagrams 13-7 5.1 Channel Audio (DVD-909 Only) 13-8 Samsung Electronics...
Page 128 Schematic Diagrams 13-8 RF Samsung Electronics 13-9...
Page 129 Schematic Diagrams 13-9 ZiVA 13-10 Samsung Electronics...
Page 130 Schematic Diagrams 13-10 DSP Samsung Electronics 13-11...
Page 131 Schematic Diagrams 13-11 Front Micom/VFD Display U.S.A. FRANCE CON23-A (DVD-909) CON24 (DVD-709) TO KEY CN18 CN15 (DVD-909 ; PIN12) CN16 (DVD-709 ; PIN6) TO KEY CON22 (PIN6) TO KEY CON21 (PIN12) 13-12 Samsung Electronics...
Page 132 Schematic Diagrams 13-12 Component (DVD-909 Only ; Option) Samsung Electronics 13-13...
Page 133 Schematic Diagrams 13-13 Scart Jack (DVD-909 PAL Only) R Output (Scart Jack) G Output (Scart Jack) B Output (Scart Jack) 13-14 Samsung Electronics...
Page 134 Schematic Diagrams 13-14 Mute Samsung Electronics 13-15...
Page 135 Schematic Diagrams 13-15 Play & Phone/Power (DVD-909 Only) PLAY PHONE/POWER 13-16 Play & Power (DVD-709 Only) PLAY POWER 13-16 Samsung Electronics...
Page 136 Schematic Diagrams 13-17 Deck Samsung Electronics 13-17...
Page 137 Schematic Diagrams 13-18 Remote Control 13-18 Samsung Electronics...
Page 138 DVD-YURO909/709 11/4/95 9:59 AM Page 2 afety Information TO REDUCE THE RISK OF ELECTRIC WARNING SHOCK, DO NOT REMOVE THE COVER(OR BACK). To reduce the risk of fire or shock haz- NO USER-SERVICEABLE PARTS ARE RISK OF ELECTRIC SHOCK ard, do not expose this DVD player to INSIDE.
Page 139 DVD-YURO909/709 11/4/95 9:59 AM Page 3 are & Maintenance For trouble free operation, follow the instructions shown below. Handling Cautions Accessories • Before connecting other components to this player, be sure to turn them all off. Remote Control • Do not move the player while a disc is being played, or the disc may be scratched or broken, and the player’s internal parts may be damaged.
Page 140 DVD-YURO909/709 11/4/95 9:59 AM Page 4 TABLE OF CONTENTS...
Page 141 Using the Setup Menu .......... 32 Setting Up Audio Options ........36 Setting Up the Language Features ...... 33 Surround Sound Speaker Setup(DVD-909 only) .. 37 Setting Up the Parental Level ......35 Setting Up Display Options ........38 Controlling a TV with the Remote ......40 Specifications (DVD-909) ........
Page 142: Disc Features
An important scene can be viewed in slow motion. You can repeat a song or movie simply by pressing Programmed Play the REPEAT button. You can program tracks to play in desired order. DVD-909 SKIP DVD/VIDEO-CD/CD PLAYER DVD-909 STANDBY/ON PHONE LEVEL OPEN/ OPEN/ OPEN/...
Page 143: Disc Type And Characteristics
DVD-YURO909/709 11/4/95 9:59 AM Page 7 isc Type and Characteristics Your DVD player is capable of playing discs with the following logos. Max. Recording Disc Types Logos Disc Size Playing Characteristics Types Time Single-sided • DVD contains excellent sound and 240 min.
Page 144: Front Panel (Dvd-909)
You can attach headphones here for pri- • vate listening. HEADPHONES VOLUME • Use to adjust headphones volume level. DISPLAY (See below) Operation indicators are displayed here. SKIP • DVD/VIDEO-CD/CD PLAYER DVD-909 STANDBY/ON PHONE LEVEL DISC TRAY OPEN/ OPEN/ OPEN/ CLOSE CLOSE CLOSE •...
Page 145: Front Panel (Dvd-709)
DVD-YURO909/709 11/4/95 9:59 AM Page 9 escription-Front Panel DVD-709 Front Panel Controls STANDBY LAMP • When the unit is first plugged in, the indi- cator lights. When power is pressed on, the lamp goes out. STANDBY ON/OFF • Use to switch your player on and off (standby). DISPLAY (See below) •...
Page 146: Rear Panel (Dvd-909)
DVD-YURO909/709 11/4/95 9:59 AM Page 10 escription-Rear Panel DVD-909 FRONT CENTER NTSC SECAM SURROUND TV SYSTEM SELECT OPTICAL COAXIAL DIGITAL AUDIO OUT ANALOG AUDIO OUT MIXED AUDIO OUT VIDEO OUT S-VIDEO OUT Rear Panel DIGITAL AUDIO OUT JACK S-VIDEO OUT JACK •...
Page 147 DVD-YURO909/709 11/4/95 9:59 AM Page 11 escription-Rear Panel DVD-709 NTSC SECAM DIGITAL ANALOG AUDIO OUT VIDEO OUT S-VIDEO OUT TV SYSTEM SELECT AUDIO OUT Rear Panel DIGITAL AUDIO OUT JACK S-VIDEO OUT JACK • Use a coaxial digital cable to connect to an A/V Amplifier that •...
Page 148 DVD-YURO909/709 11/4/95 9:59 AM Page 12 system select You can enjoy NTSC or PAL encoded discs by using your TV SYSTEM SELECT switch to choose the appro- priate system. • Only when you playback PAL-encoded DVD with NTSC-TV. The play- er can not playback the disc.
Page 149 DVD-YURO909/709 11/4/95 9:59 AM Page 13 Tour of the Remote Contro l DVD Function Buttons DVD POWER Button NUMBER Buttons OPEN/CLOSE Button SETUP Button • Brings up the DVD player’s Setup menu. ZOOM Button SEARCH Buttons • Allows you to search forward/backward through a disc.
Page 150 • Check if remote sensor is blocked by obstacles. • Check if there is any fluores- cent lighting nearby. To Connect Headphones (not included) (DVD-909 only) Turn the headphone volume down to the minimum setting before connecting. Adjust to your desired volume after connection. NOTE This icon indicates an invalid button press.
Page 151: Connecting To A Tv
DVD-YURO909/709 11/4/95 9:59 AM Page 15 DVD-909 hoosing a Connection The following diagrams show common connection examples that can be used for connecting your DVD player to a TV or other equipment. Before Connecting the DVD Player Connecting to a TV (For Video) •...
Page 152: Connecting To An Audio System
DVD-YURO909/709 11/4/95 9:59 AM Page 16 hoosing a Connection (Cont d) Connecting to an Audio System Method 1 Method 2 Method 3 AUDIO SYSTEM 2ch Amplifier 5.1ch Analog Amplifier Dolby Digital Decoder Audio Input Jacks Audio Input Jacks Digital Audio Input Jacks Front (RH) Front (LH) Center...
Page 153 DVD-YURO909/709 11/4/95 9:59 AM Page 17 hoosing a Connection DVD-709 The following diagrams show common connection examples that can be used for connecting your DVD player to a TV or other equipment. Before Connecting the DVD Player Connecting to a TV (For Video) •...
Page 154 DVD-YURO909/709 11/4/95 9:59 AM Page 18 hoosing a Connection (Cont d) Connecting to an Audio System Method 1 Method 2 AUDIO SYSTEM 2ch Amplifier Dolby Digital Decoder Audio Input Jacks Digital Audio Input Jack PLAYER DIGITAL ANALOG AUDIO OUT AUDIO OUT Analog Audio Out Digital Audio Out Rear Panel...
Page 155: Playing A Disc
DVD-YURO909/709 11/4/95 9:59 AM Page 19 laying a Disc Before Playback • Turn on a TV and press the TV/VIDEO button to select video mode. • Turn on your Audio System to select AUX, CD or DVD. • Refer to your AUDIO Owner’s Manual. 1.,3.
Page 156 Slow Motion Playback (Except CD) Press the FWD or REV SEARCH button on the remote or turn the SHUTTLE dial (DVD-909 only) on the front of the DVD player during PAUSE or STEP mode. - By pressing or shuttling, you can select slow motion playback for 1/2, 1/4 or 1/8 of normal speed.
Page 157: Searching & Skipping Through A Chapter Or Track
Searching through a Chapter or Track Press the FWD or REV SEARCH button on the remote or turn the SHUTTLE dial (DVD-909 only) on the front of the DVD player during PLAY mode. • Press the REVERSE or FORWARD SEARCH button on the remote and press again to search at a faster speed(2X/8X/16X/32X/normal speed, in order) on DVD.
Page 158: Using The Display Function
DVD-YURO909/709 11/4/95 10:00 AM Page 22 sing the Display Function If you want to display the title, chapter, time, audio and subtitle information on a DVD, press the DISPLAY but- ton. If you want to display the track and time information on a VCD or CD, press the DISPLAY button. When Playing a DVD When Playing a CD/VCD During playback, press the...
Page 159 DVD-YURO909/709 11/4/95 10:00 AM Page 23 epeat Play Repeat play allows you to repeat a track, title, or the entire disc. When playing a DVD When playing a CD/VCD Press the REPEAT button Press the REPEAT button once to display the current once to display the current status.
Page 160 DVD-YURO909/709 11/4/95 10:00 AM Page 24 sing the A-B Repeat Function The A-B Repeat function lets you mark the beginning (A) and the end (B) of a segment. Marking the segment allows you to review it by pressing the REPEAT button. To set up A-B Repeat Press the A-B REPEAT button at the beginning (A) of the segment you want to review.
Page 161 DVD-YURO909/709 11/4/95 10:00 AM Page 25 rogram Playback in a Specific Order Program playback lets you set up an order of playback for the titles, chapters, or tracks of a specific disc. Your player must be in stop mode for this feature to work. Program VCD or CD Program DVD To program chapters 5 and 7 in order.
Page 162: Using The Disc View Function
DVD-YURO909/709 11/4/95 10:00 AM Page 26 sing the Disc View Function The desired music or video display can be accessed directly without using the menu function. Track View (VCD) Index View (VCD) Displays the beginning view of Displays the equally divided 9 each track and the track number.
Page 163: Selecting Audio
DVD-YURO909/709 11/4/95 10:00 AM Page 27 electing Audio You can select a desired language quickly and easily with the AUDIO button. If a menu is encoded on the disc, you can also select by using the MENU button. Using the Audio Button Using the Menu Button During playback, press the When playing a DVD...
Page 164: Selecting The Subtitle Language
DVD-YURO909/709 11/4/95 10:00 AM Page 28 electing the Subtitle Language When a DVD is recorded with subtitles, you can use the Subtitle feature to view the subtitles on-screen. If a menu is encoded on the disc, you can also select by using the MENU button. Using the SUBTITLE button Using the MENU button Press the SUBTITLE but-...
Page 165 DVD-YURO909/709 11/4/95 10:00 AM Page 29 electing the Desired Screen Angle When a DVD contains multiple angles of a particular scene, you can use the Angle function. Using the ANGLE button Check to see if an ‘ANGLE ( )’ mark is present at the upper right hand corner of the screen.
Page 166 DVD-YURO909/709 11/4/95 10:00 AM Page 30 sing the Bookmark Function The Bookmark function lets you select parts of a DVD or VCD (MENU OFF mode) so that you can quickly find the section at a later time. Using the Bookmark Function (DVD/VCD) During playback, press the BOOKMARK button on the remote.
Page 167 DVD-YURO909/709 11/4/95 10:01 AM Page 31 sing the Zoom and 3D Sound Using the Zoom Function (DVD/VCD) During playback or pause mode, press the ZOOM button on the remote. The square frame will be displayed on screen. Use the UP/DOWN or LEFT/RIGHT button to select the part of the screen you want to zoom.
Page 168: Using The Setup Menu
DVD-YURO909/709 11/4/95 10:01 AM Page 32 sing the Setup Menu The Setup Menu allows you to customize your DVD player by adjusting the settings for such things as lan- guage preference, parental level, and type of television screen used. Press the SETUP button on the remote in the play or stop mode.
Page 169: Setting Up The Language Features
DVD-YURO909/709 11/4/95 10:01 AM Page 33 etting Up the Language Features You can set the language for your DVD player in advance. Using the Player Menu Setting up in ENGLISH. Press the SETUP button when in play or stop mode. Use the UP/DOWN button to select the PLAYER MENU.
Page 170 DVD-YURO909/709 11/4/95 10:01 AM Page 34 etting Up the Language Features (Cont d) Using the Disc Menu Language Using the Audio Language Using the Subtitle Language This function changes the lan- Setting up in ENGLISH. Setting up in ENGLISH. guage only for the text on the disc menu screens.
Page 171 DVD-YURO909/709 11/4/95 10:01 AM Page 35 etting Up the Parental Level The Parental Level function works in conjunction with DVDs that have been assigned a rating - which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc. SETTING THE SETTING THE PASSWORD...
Page 172 DVD-YURO909/709 11/4/95 10:01 AM Page 36 etting Up Audio Options Press the SETUP button SPEAKER SETUP (DVD-909 when in play or stop mode. only) To select the SPEAKER SETUP to Use the UP/DOWN button to hear surround sound. select AUDIO OPTIONS. Then Use the UP/DOWN button to press the ENTER button.
Page 173: Surround Sound Speaker Setup(Dvd-909 Only)
Page 37 urround Sound Speaker Setup (DVD-909 only) The DVD-909 has a Speaker Setup feature that allows you to customize your surround sound setup. Only when the DVD disc is played or the disc isn’t loaded, this feature will be activated.
Page 174: Setting Up Display Options
DVD-YURO909/709 11/4/95 10:02 AM Page 38 etting Up Display Options Press the SETUP button in play or stop mode. Use the UP/DOWN button to select DISPLAY OPTIONS. Then press the ENTER button. Use the UP/DOWN button to select the desired item.
Page 175 DVD-YURO909/709 11/4/95 10:02 AM Page 39 etting Up Display Options (Cont d) Use the UP/DOWN button to select the desired item. Then press the ENTER button. TV ASPECT 4:3 LETTER BOX : Select when you want to see the total 16:9 ratio screen DVD supplies, even though you have a TV with a 4:3 ratio screen.
Page 176 The remote can also be set up to control most TVs. To program the remote, use the code that corresponds to your brand. TV Codes CODE BRAND SAMSUNG D SAMSUNG F, LG A, LOEWE, PHILPS, FINLUX A, YOKO, LOEWE OPTA A, MITSUBISHI A, PHONOLA A, RADIOLA A,SCHNEIDER SAMSUNG A SAMSUNG B SAMSUNG C...
Page 177 • Go to the contents and find the section of the instruction book that contains the explanations regarding the current problem, and follow If you experience other the procedure once again. problems. • If the problem still cannot be solved, please contact your nearest authorized service center or call 1-800-SAMSUNG.
Page 178 DVD-YURO909/709 11/4/95 10:02 AM Page 42 pecifications DVD-909 Power Requirements AC 110 ~ 240V, 50/60Hz Power Consumption 19 W Weight 3.4 kg General Dimensions W 430 mm x D 280 mm x H 89 mm Operating Temperature Range +5°C to +35°C...
Page 179 DVD-YURO909/709 11/4/95 10:02 AM Page 43 pecifications DVD-709 Power Requirements AC 110 ~ 240V, 50/60Hz Power Consumption 17 W Weight 3.4 kg General Dimensions W 430 mm x D 280 mm x H 89 mm Operating Temperature Range +5°C to +35°C Operating Humidity Range 10% to 75% Reading Speed : 3.49 m/sec...

This manual is also suitable for:

Dvd-709

Samsung DVD-909 Service Manual

DVD Player Service Manual

Surround Sound Speaker Setup(DVD-909 Only)/Setting up Display Options

Quick Links

Chapters

Related Manuals for Samsung DVD-909

Summary of Contents for Samsung DVD-909

This manual is also suitable for:

Table of Contents
