- Page 1 Quick User Manual Naviter Oudie 3 Naviter d.o.o., Planina 3, 4000 Kranj, Slovenia www.oudie3.com support@naviter.com...
-
Page 2: Introduction
Introduction Thank you for choosing Oudie 3! Company Naviter is dedicated to solving glider pilot's problems and Oudie is one of the answers in this challenge. It´s intended use is helping glider, para-glider and hang glider pilots navigate during leisure, cross country and competition flights. -
Page 3: Table Of Contents
Index Introduction ............1 Index ..............2 What's in the box ..........3 Getting to know Oudie 3 ........4 Turning Oudie on and off ........5 Charging the battery ..........6 Internal GPS reception .......... 7 Starting the navigation .......... 8 Troubleshooting ............ -
Page 4: What's In The Box
What's in the box Your Oudie 3 was delivered in a sealed package with the following items: 1. Oudie 3 2. Protective case 3. Getting started manual 4. Car charger 5. Wall charger with 4 exchangeable plugs 6. USB cable 7. -
Page 5: Getting To Know Oudie 3
Getting to know Oudie 3 1. Power On/Off button 2. Power indicator 3. Earphone jack 4. MicroSD card slot 5. Quick charger 6. Mini USB port 7. Stylus 8. Speaker 9. Reset key... -
Page 6: Turning Oudie On And Off
Turning Oudie on and off To turn the Oudie ON press the power button for one second then confirm this action by pressing the button on the screen within five seconds. To turn the Oudie OFF, press the power button for 1 second while the device is running then choose the desired action: Power Off: will stop the navigation and... -
Page 7: Charging The Battery
Charging the battery There are several ways to charge Oudie's internal battery.: Connect the wall charger cable to AC 110- • 240 V power source and insert the connector to the charging slot on the Oudie (fast charge). Connect the car charger to the DC 12-24 V •... -
Page 8: Internal Gps Reception
Internal GPS reception When the navigation device is turned on for the first time or after a long period of non-use, initialising the integrated GPS receiver can take up to 60 minutes. To acquire GPS satellite reception as quickly as possible you should have a clear view of the sky, not obstructed by roof, other buildings or trees and by and standing still until the GPS position has... -
Page 9: Starting The Navigation
Starting the navigation When you turn the Oudie on for the first time or after a reset, navigation software is started automatically. For more information about how to use the Oudie software please consult the documentation supplied on the web site www.oudie3.com... -
Page 10: Troubleshooting
60 minutes. If you still cannot acquire satellites check Menu > Settings > Input options. Symptom: Navigation software displays NODATA in the GPS Fix navbox. Solution: Check the Menu > Settings > Input options. For other problems contact support@naviter.com... -
Page 11: Notice Of Non-Liability
Using the system improperly could cause failure and lead to possible property damage and/or personal injury. Naviter assumes no responsibility for property damage, accidents, injury or death that may result from the misuse of this device/equipment. This includes any use of this device/equipment outside the scope of common sense, the User Manual, inserts and other related documentation. -
Page 12: Limited Warranty
Naviter reserves the right to determine if repairs are to be done under warranty or at a nominal charge. As a proof of activated warranty you must send a copy of... -
Page 13: Technical Specification
Technical specification Device Processor ARM 11, 500 MHz 128 MB Built-in Flash 8 GB Loudspeaker Buttons On/Off, Reset Battery 9600 mAh Battery indicator Battery autonomy >12h Size 135 x 86 x 25 mm Weight 350 g Vario Yes, high sensitivity Pressure altitude Yes, high precision Flight recorder... - Page 14 Technical specification Touch screen Display size 5" TFT LCD Resolution 480 x 272 Aspect ratio '16:9 Portrait mode Landscape mode Touchscreen Yes, Resistive Screen lock Yes, Smart Gloves optimized Connectivity Built-in GPS Yes, aviation grade USB 2.0 Mass Storage Active Sync External Flash microSDHC Headphones...
- Page 15 Software Languages Moving map Preinstalled maps World-wide Airspaces World-wide Airspace updates Automatic & Free 3D Airspace warning Max. Altitude warning Final glide calculator OLC & FAI optimization Profiles Unlimited Navboxes Flight statistics Race To Goal Yes, automatic Assigned Area Task route optimization Yes, automatic Wind calculator...
- Page 16 www.naviter.com...
