Safety Precautions Equipment tested for compliance as a RCT6672W23 complete unit FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 3
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / T V technician for help. Warning : Changes or modifications not expressly approved by the party responsible for compliance (MLB International Inc., P.O.
IMPORTANT SAFETY INSTRUCTIONS PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE Some of the following information may not apply to your particular product; however, as with any electronic product, precautions should be observed during handling and use. • Read these instructions. •...
Page 5
• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Startup Overview of Controls Front Camera Rear Camera Power Button Headphone Jack Microphone Micro-USB Port DC Jack Vol+/- Button Micro SD Card Slot Speaker Reset EN - 6...
Reset the tablet. Buttons Power Button Power the Tablet On Press & hold the Power button until the RCA logo appears. Power the Tablet Off Press & hold the Power button until a message box displays. Select "Power off". Tap "OK" and the tablet will be powered off.
Sleep Mode Briefly press the Power button to put the tablet in sleep mode. If you don’t operate for some time, the tablet will enter sleep mode automatically. Tip: You can go to Settings > DEVICE > Display > Sleep to set the screen timeout. Wake the Tablet from Sleep Mode Press the Power button to wake the tablet from sleep mode.
Navigating the Home Screen Notification Bar Status Bar Google Search App Icons Settings Back Home Speakers Recent All App Apps EN - 9...
Page 11
Notification & Status Bar Some indicators that inform you about the status of your tablet are shown at the top of the screen. Notification Shade Notifications may come from the system, a game, an application such as E-mail, or the music player. When Notifications are available, related icons will appear in the top left corner of the screen.
Page 12
Notification & Status Icons The below table lists some of the frequently used icons in the Notification & Status bar: Item Description Message Received new message. Music The Google Play Music app is running. Screenshots Screenshot captured. USB tethering Has connected to a PC and the USB tethering is turned on.
Page 13
Apps screen. Widgets are app information displays that can be placed on your Home screen. • Get more apps: Tap the Google Play Store icon • View info about an App: Press & hold it, and drag it to the top of the screen, then drop the app over the App Info icon i .
Connections Battery Management and Charging The tablet has a built-in rechargeable battery. Battery Icon The battery icon in the upper-right corner shows the battery level or charging status. Full battery Low battery Need to be Charging charged Charging the Battery AC Adapter To DC Jack To Wall Outlet...
Page 15
charging again. Keep the battery charged as needed. • If tablet has not been used for a long period of time, the battery might be in over discharge protection mode and may take longer to charge. Prolong the Battery Life Here are some tips for how to prolong the life of the battery: •...
Micro-USB Connect your tablet to a PC or a USB storage device with a USB cable (not included), to transfer music, pictures and other files in both directions. Note: To change your tablet’s USB connection options, you should go to Settings > Device > Storage, and tap Menu icon at the upper right corner.
Micro SD To Micro SD Card Slot Micro SD Card (not included) Inser t the micro SD card, with contacts facing the screen, into the tablet’s Micro SD slot until it clicks. To check the storage of the micro SD card, go to Settings >...
Wi-Fi Connect to a Wi-Fi Network 1. Go to Settings > Wireless & networks > Wi-Fi, and slide the Wi-Fi switch to the ON position. 2. The device will scan Wi-Fi networks automatically and display the available names. • If the device finds a network that you connected to previously, it will connect to it automatically.
5. If your network does not broadcast its SSID, tap the Plus icon + at the top of the screen, and enter the Network SSID (name) of the network. If necessary, enter security or other network configuration details. Note: you can tap Menu icon at the upper right corner in the Settings screen for advanced settings.
Basic Operation First Time Operation Turning Your Tablet On for the First Time When using the tablet for the first time, you will be required to setup the following: 1. Select the language, then tap 2. Set the Wi-Fi. 3. If you have a Google Account, select "Yes". Then tap a network name to see more details or connect to it, and enter a password if necessary.
Page 21
Press & Hold In some instances, touching the item and holding your finger on it will present other options or menus. Drag or Swipe While holding an item such as an icon, it can sometimes be moved by dragging it to another area or screen.
Customizing the Home Screen • From All Apps screen to Home screen: Tap All Apps icon to open All Apps screen,press & hold an icon or widget and slowly to drag it to the location of your choice. This makes it much easier to change your Home screen layout.
Voice Search & Voice Actions Turn Voice Search or Voice Action On You can initiate a Voice Search or Voice Action by tapping the Microphone icon in the top left corner of the Home screen. When you’re viewing the Google Now screen, you don’t have to touch anything.
Google Play In addition to the apps that come preinstalled on your tablet, you can download Android apps and games, music, movies, TV shows, and magazines on Google Play. 1. On the App menu, touch the Google Play Store icon. 2.
Page 25
ScreenshotSetting—Set Select delay time to capture the screen, Set the location of screenshot storage and enable or disable Show the screenshot button in the statusbar. Storage—View available space in INTERNAL STORAGE, SD CARD and USB STORAGE /set the related items. Battery—View battery status.
SYSTEM Date & time—Enable or disable Automatic date & time, and select preferences for date, time, time zone, time format, and date format. Accessibility—Select preferences for SERVICES and SYSTEM. Printing — Enable or disable PRINT SERVICES. About tablet Check System updates, Status, Legal information etc. Google A Google Account lets you organize and access your personal information from any computer or mobile device.
Remove an Account To remove a Google account, go to Settings > ACCOUNTS > Google > [account- name] Menu icon > Remove account. Preinstalled Apps Your tablet comes with many apps preinstalled to allow you to browse the web, send and receive email, and access entertainment.
Page 28
Tablet is frozen or a serious error appears • If the tablet is frozen or suspended, you may need to close the app program or reset the tablet. • If the tablet is frozen or slow to respond, press & hold the power button for 8 seconds to reset the tablet.
Specifications Power: DC IN 5V (operate with AC adapter) Front camera: 0.3 Megapixe, rear camera: 2.0 Megapixe Copyright and Trademark Notices Android, Google, Google Play and other marks are trademarks of Google Inc. The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance.
Limited Warranty AVC MULTIMEDIA (“AVC”) makes the following limited warranty. This limited warranty extend to the original consumer purchaser and is limited to non-commercial use of the product. One Year Parts & Labor Warranty AVC products purchased in the United States or Canada are warranted to be free from defects in materials or workmanship for a period of one year from the date of their original retail purchase.
Page 31
Packaging and Shipping Instruction When you send the product to the AVC service facility you must use the original carton box and packing material or an equivalent as designated by AVC. Your Responsibility (1) You must retain the original sale receipt to provide proof of purchase.
Page 32
All warranties implied by state law, including the implied warranties of merchantability and fitness for a particular purpose, are expressly limited to the duration of the limited warranties set forth above. With the exception of any warranties implied by state law as hereby limited, the foregoing warranty is exclusive and in lieu of all other warranties, guarantees, agreements and similar obligations of manufacturer or seller with respect to the repair or...
