Item
Qty
No.
Req.
1
23612627
1
1
23612626
2
1
23612387
3
1
23612475
4
1
23612385
5
1
23612470
6
2
23612472
7
1
23612397
8
1
23612386
9
1
23612460
10
1
23612473
11
1
23612461
12
1
21156
13
1
23612383
14
1
23612398
15
1
23612478
16
1
23612479
17
1
23612480
2
23612384
18
19
5
23612462
20
1
23612662
21
1
23612663
Figure 6-6. 2-Roll Drive Stand
Part
No.
2 ROLL GEARED WIRE DRIVE SYSTEM, CONSISTS OF:
PRESSURE ARM ASSY ., (incls. 2, 3, 4, 7, 8)
AXLE, PRESSURE ROLL
PRESSURE ARM
CIRCLIP, PRESSURE ROLL
PIVOT PIN
CIRCLIP
PRESSURE ROLL, SMOOTH
GEARED ADAPTOR, PRESSURE ROLL
PRESSURE DEVICE ASSY .
LOCATING PIN
INLET GUIDE
DRIVE ROLL, .035" - .045"
GEARED ADAPTOR DRIVE ROLL
FEED ROLL RETAINING SCREW
FEED PLATE
FEED ROOL KEY
MOTOR SHAFT SNAP RING (Not Shown)
LOCATING SCREW
SCREW
SPACER TUBE (Pressure Arm)
SPRING PRESSURE ARM
35
