Television Video Cassette Recorder
Television Video Cassette Recorder
Chassis :
C17A (TS-10 )
Model :
TI21B4DF4X/XEU
TW14N54X/BWT
TW14N64X/BWT
TW21B4D4X/BWT
TX14P1DF4X/XEC
1.
Precautions
2.
3.
4.
5.
6.
Exploded View and Parts List
7.
8.
9.
10.
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung TI21B4DF4X

Summary of Contents for Samsung TI21B4DF4X

  • Page 1: Table Of Contents

    Television Video Cassette Recorder Chassis : C17A (TS-10 ) Model : TI21B4DF4X/XEU TW14N54X/BWT TW14N64X/BWT TW21B4D4X/BWT TX14P1DF4X/XEC Television Video Cassette Recorder CONTENTS Precautions Specifications Disassembly and Reassembly Alignment and Adjustment Troubleshooting Exploded View and Parts List Electrical Parts List Block Diagram...

  • Page 2: Specifications

    20” (486 x 473 x 485) 21” (520 x 495 x 508) Weight 14” (11.1 kg) 15” (14.8 kg) 20” (19 kg) 21” (23.4 kg) Operating temperature 5°C - 40°C (41°F - 104°F) Relative humidity 10% - 75% Samsung Electronics...

  • Page 3: Disassembly And Reassembly

    3-1-1 Top View Œ ´ ˇ ¨ ˆ Ø Fig. 3-1 Top parts Location-1 Œ GEAR FL CAM ´ MOTOR LOADING ASS’Y ˇ LEVER FL ARM ASS’Y ¨ HOLDER FL CASSETTE ASS’Y ˆ LEVER FL DOOR Ø SLIDER FL DRIVE Samsung Electronics...
  • Page 4 ´ CYLINDER ASS’Y ˝ GEAR IDLE ˇ ACE HEAD ASS’Y Ô LEVER IDLE ¨ LEVER UNIT PINCH ASS’Y  LEVER T BRAKE ASS’Y ˆ LEVER #9 GUIDE ASS’Y Ò DISK T REEL Ø LEVER TENSION ASS’Y ∏ BAND BRAKE ASS’Y Samsung Electronics...
  • Page 5 Œ GEAR JOINT 1 ´ GEAR JOINT 2 ˇ BRACKET GEAR ¨ MOTOR CAPSTAN ASS’Y ˆ LEVER T LOAD ASS’Y Ø GEAR LOADING DRIVE ∏ LEVER S LOAD ASS’Y ” HOLDER CLUTCH ASS’Y ’ BELT PULLEY ˝ SLIDER CAM Samsung Electronics...
  • Page 6 Lever FL Cassette-R ´ at disassembling and "B" reassembling. ´ LEVER FL DOOR ˇ HOOK "C" Fig. 3-4 Lever FL Door Removal RAIL [B] Œ HOLDER FL CASSETTEE ASS`Y ´ LEVER FL CASSETTEE -R "A" BOSS [A] Fig. 3-5 Holder FL Cassette Ass’y Removal Samsung Electronics...
  • Page 7 Fig. 3-8 Lever FL Arm Ass’y Removal ´ GEAR FL CAM Œ SLIDER FL DRIVE Fig. 3-6 Slider FL Drive Removal Œ GEAR FL CAM GEAR WORM WHEEL POST TIMING POINT Fig. 3-7 Gear FL Cam, Gear Worm Samsung Electronics...
  • Page 8 1) Remove the screw Œ. 1) Remove the Gear Worm wheel Œ. 2) Remove the Motor Loading Ass’y ´. ´ MOTOR LOADING ASS`Y Œ SCREW Œ GEAR WORM WHEEL Fig. 3-10 Motor Loading Ass’y Removal Fig. 3-9 Gear Worm Wheel Removal Samsung Electronics...
  • Page 9 Fig. 3-11 Bracket Gear, Gear Joint 1,2 Removal Fig. 3-13 Gear Loading Drive, Slider Cam, Lever T, S Load Ass’y Removal Œ GEAR JOINT1 ´ GEAR JOINT2 ˇ SLIDER CAM TIMING POINT 2 TIMING POINT 1 Fig. 3-12 Gear Joint 1,2 Assembly Samsung Electronics...
  • Page 10 LEVER LOAD T LEVER LOAD S Lever Tension Drive Removal TIMING POINT 2 TIMING POINT 3 PIN A PIN C PIN D PIN B ˇ SLIDER CAM Fig. 3-14 Gear Loading Drive, Slider Cam, Lever Load S, T Ass’y Assembly Samsung Electronics...
  • Page 11 ˇ SPRING BRAKE Œ SPRING TENTION LEVER STOPPER Œ LEVER S BRAKE ASS`Y HOOK(C) "A" MARK[B] HOOK(B) ´ LEVER T BRAKE ASS`Y Fig. 3-16 Lever Tension Ass’y, Band Brake Ass’y Removal Fig. 3-17 Lever Brake S, T Ass’y Removal Samsung Electronics...
  • Page 12 ´ DISK T REEL add oil in the boss of Lever Idle Œ. "A" Œ LEVER IDLE ´ GEAR IDLE "B" ´ GEAR IDLE HOOK "C" Fig. 3-19 Disk S, T Reel Removal Fig. 3-18 Gear Idle Ass’y Removal Samsung Electronics 3-10...
  • Page 13 Fig. 3-21 Lever Up Down Ass’y Removal DETAIL B SPRING GEAR CENTER ASS'Y GUIDE LEVER UP DOWN ASS'Y RING GEAR <GOOD> <BAD> POST HOOK Fig. 3-20 Holder Clutch Ass’y Removal MAIN BASE Fig. 3-22 Lever Up Down Ass’y Removal 3-11 Samsung Electronics...
  • Page 14 Œ GUIDE CASSETTE DOOR Œ LEVER UNIT PINCH ASS`Y HOOK [A] ´ PLATE JOINT ˇ SPRING PINCH DRIVE Fig. 3-23 Guide Cassette Door Removal Fig. 3-24 Lever Unit Pinch Ass’y, Plate Joint, Spring Pinch Drive Removal Samsung Electronics 3-12...
  • Page 15 2) After reinstalling, check the bottom side of the Post #9 Guide to the top side of Main Base. "A" Œ SPRING #9 GUIDE ´ LEVER #9 GUIDE ASS`Y "B" Fig. 3-26 FE Head Removal Fig. 3-25 Lever #9 Guide Ass’y Removal 3-13 Samsung Electronics...
  • Page 16 2) Remove the screw Œ. 3) Lift the ACE Head Ass’y ´. Œ SLIDER S ASS`Y Œ SCREW ´ SLIDER T ASS`Y ´ HEAD ACE ASS`Y Fig. 3-28 Slider S, T Ass’y Removal Fig. 3-27 ACE Head Removal Samsung Electronics 3-14...
  • Page 17 1) Release the Hook Œ. 2) Lift the Lever Head Cleaner Ass’y ´. ´ LEVER HEAD CLEANER ASS'Y Œ HOOK SLEEVE-HEAD CLEANER ˇ CYLINDER ASS'Y Fig. 3-29 Plate Ground Deck, Cylinder Ass’y Removal Fig. 3-31 Level Head Cleaner Ass’y Removal 3-15 Samsung Electronics...
  • Page 18 3) Rotate Gear Worm Œ clockwise using screw driver again up to the state of eject mode and then pick out the tape.(Refer to Fig.3-33) ˇ MOTOR CAPSTAN ASS'Y Fig. 3-32 Damper Capstan,Motor Capstan Ass’y Removal FRAME Fig. 3-34 Samsung Electronics 3-16...
  • Page 19 ∆ CAPSTAN MOTOR PULLEY BELT PULLEY ∆ HOLDER CLUTCH ASS’Y GEAR CENTER ASS’Y GEAR IDLE (2Point) LOADING MOTOR BAND BRAKE ASS’Y BRAKE T ASS’Y ∆ : Cleaning O : Check and replacement in necessary : Add Oil 3-17 Samsung Electronics...
  • Page 20 Fig. 3-4-1 Location of Tape Transport Adjustment PINCH ROLLER FE HEAD CYLINDER ASS'Y GUIDE ROLLER "S" GUIDE ROLLER "T" POST TENSION #8 GUIDE POST #9 GUIDE POST #3 GUIDE POST MAIN BASE ACE HEAD CAPSTAN SHAFT Fig. 3-4-2 Tape Travel Diagram Samsung Electronics 3-18...
  • Page 21 Fig. 3-5-1 Location of ACE Head Adjustment Screw 4-5-1(d) ACE HEAD POSITION (X-POINT) ADJUSTMENT 1) See “2. Alignment and Adjustment” for ACE Head AUDIO HEAD position (X-Point) adjustment. VIDEO HEAD 0 ~ 0 .25 mm CONTROL HEAD Fig. 3-5-2 ACE Head Height Adjustment 3-19 Samsung Electronics...
  • Page 22 ) driver to obtain a flat video RF envelope as shown in Fig. 3-8. IDEAL ENVELOPE S HEIGHT TOO HIGH S HEIGHT TOO LOW T HEIGHT TOO HIGH T HEIGHT TOO LOW GUIDE ROLLER S GUIDE ROLLER T Fig. 3-5-6 Guide Roller S, T Height Adjustment Samsung Electronics 3-20...
  • Page 23 3) Brake is operated by slider cam at FF/REW mode. 4) Transportation of accurate driving force is done by gears. (Gear Center Ass’y) Note : If the spec. does not meet the followings speci- fications, replace the holder clutch ass’y and then recheck. 3-21 Samsung Electronics...

  • Page 24: Alignment And Adjustment

    Adjustment, Option and Reset. 3. Access the Adjustment Mode by pressing the “VOLUME” keys ( Up or Down). The adjust- ment parameters are listed in the accompany- ing table, and selected by pressing the CHAN- NEL keys (L,M). Samsung Electronics...
  • Page 25 "FACTORY" key . Even if the TV power is cut off, the Aging Mode is not cancelled. The "AGING" marking is displayed on the screen. The AGINGmode is cancelled by repressing the "FACTORY" key. Samsung Electronics...
  • Page 26 2HD/2HDLP/4HD/HIFI G-CODE SHOWVIEW/VIDEO PLUS/NONE ATS OPTION ON/OFF VPS/PDC PDC/VPS/NONE ON/OFF 4-3 Reset BYTE ITEM Contrast Bright Sharpness Color Tint Volume Program Number Color System Sound System 3DB LNA Panel Lock Language Clock Timer On Time Sleep PICTURE MODE Samsung Electronics...

  • Page 27: Other Adjustments

    2. Turn on the TV. Set the Brightness and Contrast controls to minimum (zero beam current). 3. The high voltage should not exceed 27.5KV. 4. Adjust the Brightness and contrast controls to both extremes. Ensure that the high voltage does not exceed 27.5KV under any conditions. Samsung Electronics...
  • Page 28 9. Slowly move the deflection yoke forward, and adjust for the best overall green screen. 10. Temporarily tighten the deflection yoke. 11. Produce blue and red rasters by adjusting the low-light controls. Check for good purity in each field. 12. Tighten the deflection yoke. Samsung Electronics...

  • Page 29: White Balance Adjustment

    1. Input either a Lion Head or a “pure white” pattern. 2. Warm up the TV for 30 minutes. 3. Check the data in the Service Mode 4. Adjust RG, BG in the Factory Mode. 4-4-7 (B) LOW-LIGHT ADJUSTMENT 1. Automatically accomplished during the high-light adjustment. Samsung Electronics...
  • Page 30 2. DC VOLTMETER 1. Connect DC Voltmeter to AFT terminal of TUNER IF-MODULE. 2. After selecting P00, input to IF1 terminal of TU002(38.9 MHz Using PM5518) 3. After selecting P00, set to 2.5V±0.2V(Using FRANCE : T101, PAL/SCAM B/G,I,D/K : L102) Samsung Electronics...
  • Page 31 7. Pattern Generator : PAL color bar. 100% White (100%) White. White (75%) 0.7V Burst 0.3V 0.3V Horizontal sync signal Color bar signal waveform Fig. 4-4 Alignment Tape White Black 100% Color bar pattern Fig. 4-6 Color bar signal of alignment tape (75% Color Bars) Samsung Electronics...
  • Page 32 Play, Rec,F-PS,Still,SLOW,F-ADV STOP1 Stop (Play position 5 Min. over) STOP 2 (MAIN Break ON MODE) FF / REW 1 High speed Rew, Low speed FF FF / REW 2 High speed FF, Low speed Rew X : DON’T CARE Samsung Electronics...

  • Page 33: Troubleshooting

    Pin 54 Voltage 3.3V? 19~22V? Check IC801S /Zener diode Check/Replace Check T801S H.V SYNC on IC201S Pins 33, 21, 22 Check/Replace IC901. Check IC201S Pin 11 is High when power is On. Check/Replace IC902. Check the voltage of TU001. Samsung Electronics...
  • Page 34 5-2 No RF Picture / Sound Check IC201S #40, #24 Check Another I bus line Check After Check bus line open IC201S R, G, B, pins 51, 52, 53 Replace IC201S Check Q401, Q402 Replace Check FBT Replace Samsung Electronics...
  • Page 35 3. 2nd If : Check 5V (ICT01), Video out, Audio out 4. Video Defect : IC701 Check 5. Audio Defect : IC701 Check 6. Standby Recording Defect, ICM601 #42 Line: 7. VPS (PDC) Recording Defect: Check ICP01, #5, #27, #24, #2 Samsung Electronics...
  • Page 36 3. Check the R-Y, B-Y Line : IC201S #51~#53 5-8 No Vertical SCAN 1. Check L301, L302, C310 2. Check IC301, #2 3. Check IC201S #21, #22 4. Check DY Connector 5-9 Horizontal Size 1. Check LR401S, L402, CR402S Samsung Electronics...
  • Page 37 Press Play Button Play Indication in (Regulator Inoperative) Display Mechanism (Mechanism Does Not Operation Operate in Play Mode) Does Not Operate or Operates but Stops Soon Video Missing in PB-Video Play Mode See (PB Audio) Audio Missing in Play Mode Samsung Electronics...
  • Page 38 OK but VCR Stops Soon Check CYL FG. (SW 25Hz) ICM601-93 ICM601-24 Capstan (Capstan Does Rotation Not Rotate) PTM601, PTM602, S, T Reel Supply/Take Up Reel Sensor ICM601-99,98 PTM601, PTM602 Deck Loading Motor Prog, SW State ICM601-63,64,65 Mechanism Replace ICM601 Samsung Electronics...
  • Page 39 Load VCR With a Blank Tape and Press Record Button Rec SW Logic Tape Eject Change Tape Replace ICM601 Replace SWM611 D/ REC (H) Check ICM601 ICM601-66 High (Video Missing in REC-Video Record Mode) See (Audio Mising in Record Mode) Samsung Electronics...
  • Page 40 5-13 Fast Forward Mode Inoperative Load VCR With a Tape and Press F.Fwd Button Mechanism (STOP) (Mechanism Does Not State ICM601-63, Operate In Play Mode) 64,65 (F.FWD) (STOP) Capstan Motor (Capstan Does Rotation Not Rotate) (Rotate) Check Mechanism Samsung Electronics...
  • Page 41 5-14 Rewind Mode Inoperative See (Fast Forward Mode Load VCR With Inoperative) a Tape (Rotate) Press Rewind Button Mechanism (STOP) (Mechanism Does Not State ICM601-63, Operate In Play Mode) 64,65 (Rew) (STOP) Capstan Motor See ICM601-25 Rotation (Rotate) Check Mechanism Samsung Electronics...
  • Page 42 5-15 Rev Search Mode Inoperative See Play Mode Play Inoperative Operation Press REV Search Button Play Speed Check Mechanism Replace ICM601 Capstan Speed Serach Speed Rec SW Logic Noise Bar Locking Change Tape Replace ICM601 Capstan Motor Replace ICM601 5-10 Samsung Electronics...
  • Page 43 5-16 Cassette Loading Mechanism Does Not Operate Turn the VCR Power On and Insert a Tape Check (Control Pulse) Check Start/End Tape Loading ICM601-76,77 Sensor ICM601 Check ICM601 - 39 Press Eject Button LM B+ Line ICM602-12:LOW Replace Check ICM601 ICM602-11:HIGH ICM602 Samsung Electronics 5-11...
  • Page 44 Troubleshooting 5-17 No Servo Lock Play C-FG Check Start/End ICM601-93 Sensor ICM601 Check CTL Pluse A/C Head ICM601-4 Check CTL Pulse AC Level (SP, LP : Over 2Vp-p) Replace ICM601 5-12 Samsung Electronics...
  • Page 45 CNM603-5 Power Supply AL 5V Check A5V at AL6V Line of Power Supply CNM603-8 Place the VCR In Play Mode Check I-LIMIT. CNM603-3 2.5V RM618 2.5V Check C.M CTL/ Check CNM603-4 RM606, RM604 ICM601 Check Capstan Motor Samsung Electronics 5-13...
  • Page 46 Troubleshooting 5-19 Drum Does Not Rotate Check 12V Check 12V ICM602-9,21 Place the VCR In Play Mode Faster Check D-FG,D-PG CYL-Speed ICM601-96,97Square Wave Slower Replace (8 MHz) XTM601, CM609, CM610 XTM601 Check Cylinder Motor 5-14 Samsung Electronics...
  • Page 47 5-20 Video Missing In Play Mode See (Video Missing Video EE Mode In EE Mode) Operation Place VCR Play Mode Check Video FM In Check ICM301-18 Video Head ICM301-17 Video Check ICM301-20 QM302 Video Check Video Out Line ICM301-29 Replace ICM301 Samsung Electronics 5-15...
  • Page 48 Troubleshooting 5-21 Video Missing In Record Mode Video EE Mode TV Switching Operation Circuit Check Place VCR Record Mode FM-Video Replace ICM301 ICM301-21 FM-Video Check RM313 ICM301-18 Check Video Head 5-16 Samsung Electronics...
  • Page 49 Troubleshooting 5-22 Color Missing In Play Mode FM-ENV See (Video Missing ICM301-61 In Play Mode) Color S/W 25Hz Check ICM301-71 ICM601 ICM301-11 Check XTM301 : 4.43MHz Change XTM301 Replace ICM301 Samsung Electronics 5-17...
  • Page 50 Troubleshooting 5-23 Color Missing In Record Mode (VIdeo In) TV Switching Record Mode Circuit Check Check Color Replace XTM301 XTM301 : 4.43MHz ICM301-61 Replace ICM301 FM Signal Check CM351 ICM301-71 Replace ICM301 5-18 Samsung Electronics...
  • Page 51 1 : PB Audio Signal Block (AUDIO HEAD AZIMUTH) (Small Signal) Check ICM301 Check CM301 pin100 : PB audio signal (Small Signal) Check ICM301 Replace ICM301 pin96 : PB Audio Signal Check TV NICAM PART(Sound Block) Samsung Electronics 5-19...
  • Page 52 Check PC 5V Line ICM301 pin 75: Check Replace ICM301 ICM301 pin7 REC audio signal Check Check CM370, RM357, RM358 FLM501 Pin5 REC CM371, CM373, CM372, bias signal QM312, RM359 Check Check A/C CNM302 , Pin5 Head Assembly Replace CNM302 5-20 Samsung Electronics...
  • Page 53 Exploded View & Parts List 6-4 Mechanical Parts (Top Side) Loc. No Parts No. Description ; Specification Remark B410 AC31-00012A MOTOR-LOADING ASSY;-,TS-10,-,-,-,-,-,-,- B440 AC60-10515A SCREW-MACHINE;-,PH,+,-,M3,L3,ZPC,-,YEL B448 AC66-00008A GEAR-WORM WHEEL;TS-10,POM,0.8,40,-,NAT,3 G001 B452 AC66-00011A GEAR-FL CAM;TS-10,POM,0.8,59,-,BLK,48.48 B473 AC61-00105A SPRING-PINCH DRIVE;TS-10,SUS304-WPB,-,-, B474 AC61-30180A PLATE-JOINT;-,SECC20/20,T0.8,-,X-9 B575 AC47-00002A...
  • Page 54 B501 AC66-00022A LINK-LOADING T;TS-10,SECC E20/20,0.8,-,- B560 AC31-00010A MOTOR-CAPSTAN;-,SANKYO,-,- B570 AC60-10514A SCREW-CAPSTAN;-,PH,+,M2.6,L6,- G542 AC66-60051A BELT-PULLEY;-,5CM-70,2 * 2,-,71.3,-,X-9 K200 AC61-21012A HOLDER-CLUTCH ASSY;-,-,-,-,-,X-9 K222 K221 AC66-20581A GEAR-CENTER ASSY;-,POM,M=O.5,-,HIGHT T., K200 K222 AC60-30306A WASHER-SLIT;-,-,ID2.1,OD5.0,T0.5,-,POLYS K225 AC66-00006A LEVER-UP DOWN;TS-10,POM,-,-,-,-,NAT,- K225 K221 B478 B570 Samsung Electronics...

  • Page 55: Electrical Parts List

    Code No. Description ; Specification Remark ASSY CHASSIS 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW AA62-30171J HEAT SINK-ES;-,-,-,SILVER,-,DREAM1,-,-,- Q813 AA96-50305D ASSY H/S;-,POWER,AA62-30012E,KSD73Y,STY AA91-05521C ASSY CHASSIS;TI21B4DF4X/XEU,C17A,EU,SEB& 0502-000298 TR-POWER;KSD73,NPN,30000mW,TO-220,TP,12 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW AA94-11761A ASSY PCB MISC-A/V;TB20A54X/XSA,C17A AA62-30012E HEAT SINK-ES;-,A6063 EXTR,-,-,TO-220 H55 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, AA97-13462A ASSY AUTO-POWER;C17A,21,EU,SEB&SDIHU,54 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb D822 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,...
  • Page 56 AA60-40011A K EYELET;ID2.0,OD2.8,BST C827 2401-000901 C-AL;22uF,20%,160V,GP,TP,10x20,5 EY403 AA60-40011A K EYELET;ID2.0,OD2.8,BST C401 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5 EY404 AA60-40011A K EYELET;ID2.0,OD2.8,BST C304 2401-001115 C-AL;330uF,20%,25V,GP,TP,10x12.5,5 EY405 AA60-40011A K EYELET;ID2.0,OD2.8,BST C808 2401-001192 C-AL;33uF,20%,50V,GP,TP,6.3x11,5 EY411 AA60-40011A K EYELET;ID2.0,OD2.8,BST C306 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5 EY419 AA60-40011A K EYELET;ID2.0,OD2.8,BST Samsung Electronics...
  • Page 57 AA91-60319A ASSY-HOLDER,SENSOR;-,ABS,HB,BLK,TR LED,T R711 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4 0603-001011 PHOTO TR;NPN,35V,6V,50mA,75mW,BK RM641 2001-000118 R-CARBON(S);180OHM,5%,1/2W,AA,TP,2.4X6.4 HOLDER AA61-00005A HOLDER-SENSOR;TVN-502V,ABS,-,-,-,BLK,HB RM349 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M LDM602 AA96-00462A ASSY LED GUIDE;-,-,DL-11S2R1,RED RM316 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M AA97-12949A ASSY ROBOT;,C17A R723 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M IC702 0801-000213 IC-CMOS LOGIC;4052,MULTIPLEXER,DIP,16P,3 RM335 2001-000232 R-CARBON;1.3KOHM,5%,1/8W,AA,TP,1.8X3.2M Samsung Electronics...
  • Page 58 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM RT14 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM604 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM657 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM306 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM674 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R704 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM678 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM RT06 2001-000674 R-CARBON;360OHM,5%,1/8W,AA,TP,1.8X3.2MM RM679 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R201 2001-000689 R-CARBON;390KOHM,5%,1/8W,AA,TP,1.8X3.2M RM653 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM331 2001-000723 R-CARBON;4.3KOHM,5%,1/8W,AA,TP,1.8X3.2M Samsung Electronics...
  • Page 59 C223 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 CM615 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 0203-001123 TAPE-PAPER;#53131,T0.15,W6.0,L200000,YEL CM621 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CM601 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP CM624 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CM630 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V CM634 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CM629 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V CM613 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CM628 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V CM612 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CM622 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V Samsung Electronics...
  • Page 60 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm C606 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 LT02 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm CT18 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5 LM302 2701-000207 INDUCTOR-AXIAL;56uH,5%,2.5x3.4mm C101 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5 LM308 2702-000120 INDUCTOR-RADIAL;15mH,5%,6.2x7.4mm C601 2401-001115 C-AL;330uF,20%,25V,GP,TP,10x12.5,5 XTT01 2801-000300 CRYSTAL-UNIT;4MHz,20ppm,28-AAM,14pF,80oh CM639 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 XTM601 2801-003750 CRYSTAL-UNIT;8MHZ,30PPM,28-AAA,22PF,80OH CM365 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 X901 2801-003937 CRYSTAL-UNIT;12MHz,25ppm,28-AAM,30pF,30o Samsung Electronics...
  • Page 61 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) D101 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) JG034 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) DM601 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) JG035 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J100 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) JG036 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J101 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics...
  • Page 62 AA61-01214A BRACKET-FRAME;,SECC,T1.0 GT02 AA60-40014A PIN-GT,ASSY;AUTO AA63-00520A SHIELD-BOTTOM;20A5S,SPTE,T0.3 AA97-12929A ASSY SMD;,C17A AA91-03961A ASSY-SHIELD DRUM;,AA63-00521A+TAPE,20A5 ICM301 1204-001649 IC-VIDEO PROCESS;LA71598M,QFP,100P,-,PLA AA63-00521A SHIELD-DRUM;20A5S,SECC,T0.5 ICP01 1204-001794 IC-AUDIO PROCESSOR;LC74775NM-9808,MPF,30 AA65-30009A CLAMPER CORE-FBT;-,ABS,V0,-,BLK,- ICT01 1204-001931 IC-IF CIRCUIT;TDA9885TS,SSOP,24P,208MIL, AA41-00549C PCB-MAIN;TF20P1D4X,FR-1,1L,C,1.6T,330X24 AA97-06858A ASSY MICOM;,C17A,UPD784928,SNM-740MD,011 ICM601 AA09-00261A IC MICOM;UPD784927GF-230-3BA,TF20P1DF,1 Samsung Electronics...
  • Page 63 ASSY CPT AA91-05785A ASSY CPT;C17A,21,SEB&SDIHU,A51EER33X40 LC801S AA27-20003Z COIL DEGAUSSING;-,21,13.5ohm,25T,L2380,E AA03-00279A CRT COLOR;A51EER33X,+380MG,2.07MH,21.0MH AA98-70030A ASSY TBC WIRE(P);DP,21,AA98-70014C,1P,TV ASSY COVER REAR AA90-03899A ASSY COVER REAR;TI21B4DF4X/XEU AA64-02263A CABINET BACK;21B5S,HIPS FV2,GR503 AA65-30008A CLAMPER CORE-CORD;-,PE,HB,-,BLK,- ASSY COVER FRONT AA90-04149A ASSY COVER FRONT;TI21B4DF4X/XEU,C17A CB+CF 6002-000515 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(WHT),SWR CRT+CF AA60-10050Q SCREW-ASSY;-,SWRCH18A,M5,L26.5,HH,+,WC,-...
  • Page 64 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6. 4 D828 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 R830 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4 4 D815 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 R806 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4 4 D301 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 R810 2001-001192 R-CARBON(S);820OHM,5%,1/2W,AA,TP,2.4X6.4 4 D405 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 RX801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x 4 D809 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 7-10 Samsung Electronics...
  • Page 65 4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm 4 GT803 AA60-40014A PIN-GT,ASSY;AUTO 4 J818 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 GT806 AA60-40014A PIN-GT,ASSY;AUTO 4 J817 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 GT807 AA60-40014A PIN-GT,ASSY;AUTO 4 J815 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 GT808 AA60-40014A PIN-GT,ASSY;AUTO Samsung Electronics 7-11...
  • Page 66 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 R712 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 DZ201 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 R901 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 DZ203 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 R902 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 RM639 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 DZ205 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 RM637 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 7-12 Samsung Electronics...
  • Page 67 R-CARBON;2.2OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R215 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM346 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R721 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM334 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R714 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM313 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R715 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R210 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R716 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-13...
  • Page 68 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM346 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 5 C205 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM344 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 5 C204 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 C219 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 5 CM354 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM392 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 5 CM352 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 C212 2401-000647 C-AL;2.2uF,20%,50V,BP,TP,5x11,5 7-14 Samsung Electronics...
  • Page 69 INDUCTOR-AXIAL;330nH,10%,2.5x3.4mm 5 JG039 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 L903 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm 5 JG040 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 L901 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm 5 JP03 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 LM310 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm 5 JPM303 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics 7-15...
  • Page 70 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 H/S501 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2 5 J140 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) AA97-13016A ASSY AUTO-MAIN;CS21A5 5 J135 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 D504 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 5 J121 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 D503 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 7-16 Samsung Electronics...
  • Page 71 AA68-02264A MANUAL USERS;,RUS,W/P100(G),2,B5,C17A,56 3 DE+FD 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) HA68-00816B CARD WARRANTY;RUSSINA,2,W/P 120G,BOTH FA 3 PW+FD 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/ 3 FD+BF 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW AA61-00862A FRAME-DECK;S-PJT,HIPS V0,BLK,ONE-BOARD AA61-01214A BRACKET-FRAME;,SECC,T1.0 AA63-00520A SHIELD-BOTTOM;20A5S,SPTE,T0.3 AA91-03961A ASSY-SHIELD DRUM;,AA63-00521A+TAPE,20A5 AA63-00521A SHIELD-DRUM;20A5S,SECC,T0.5 AA65-30009A CLAMPER CORE-FBT;-,ABS,V0,-,BLK,- Samsung Electronics 7-17...
  • Page 72 R-CARBON(S);270OHM,5%,1/2W,AA,TP,2.4X6.4 D820 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, R818 2001-001134 R-CARBON(S);360ohm,5%,1/2W,AA,TP,2.4x6.4 D806 0401-000006 DIODE-SWITCHING;BAV21,250V,250mA,DO-35,T R838 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6. D828 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP R839 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6. D815 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP R830 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4 D301 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP R806 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4 D405 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP R810 2001-001192 R-CARBON(S);820OHM,5%,1/2W,AA,TP,2.4X6.4 7-18 Samsung Electronics...
  • Page 73 AA60-40011B K EYELET;ID2.2,OD3.2,BSP FD802S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS GT805 AA60-40014A PIN-GT,ASSY;AUTO F801B 3602-000114 FUSE-HOLDER;-,-,30mohm GT804 AA60-40014A PIN-GT,ASSY;AUTO F801A 3602-000114 FUSE-HOLDER;-,-,30mohm GT803 AA60-40014A PIN-GT,ASSY;AUTO J818 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) GT806 AA60-40014A PIN-GT,ASSY;AUTO J817 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) GT807 AA60-40014A PIN-GT,ASSY;AUTO Samsung Electronics 7-19...
  • Page 74 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM DZ206 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 R906 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM DZ701 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 R905 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ZDM602 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 R712 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM DZ201 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 R901 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM DZ203 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 R902 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 RM639 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 7-20 Samsung Electronics...
  • Page 75 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M R912 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M RM329 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M RM344 2001-000454 R-CARBON;2.2MOHM,5%,1/8W,AA,TP,1.8X3.2M R105 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M RM359 2001-000458 R-CARBON;2.2OHM,5%,1/8W,AA,TP,1.8X3.2MM R215 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M RM346 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M R721 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M RM334 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M R714 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM RM313 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M R715 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-21...
  • Page 76 C-AL;1uF,20%,50V,GP,TP,3x5,5 CM327 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP C605 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 CM301 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP CM611 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C231 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP CM346 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C205 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP CM344 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C204 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP C219 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 CM354 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP CM392 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 7-22 Samsung Electronics...
  • Page 77 JG037 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) L204 2701-000169 INDUCTOR-AXIAL;3.9uH,10%,2.5x3.4mm JG038 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) L101 2701-000171 INDUCTOR-AXIAL;330nH,10%,2.5x3.4mm JG039 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) L903 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm JG040 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) L901 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm JP03 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics 7-23...
  • Page 78 1201-001541 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA J138 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) SCR501 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR J139 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) H/S501 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2 J140 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) AA97-13016A ASSY AUTO-MAIN;CS21A5 J135 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) D504 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 7-24 Samsung Electronics...
  • Page 79 AA90-02598A ASSY COVER MISC-FRAME;SEH TVCR,STYX C17A HA68-00816B CARD WARRANTY;RUSSINA,2,W/P 120G,BOTH FA DE+FD 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/ PW+FD 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) FD+BF 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW AA61-00862A FRAME-DECK;S-PJT,HIPS V0,BLK,ONE-BOARD AA61-01214A BRACKET-FRAME;,SECC,T1.0 AA63-00520A SHIELD-BOTTOM;20A5S,SPTE,T0.3 AA91-03961A ASSY-SHIELD DRUM;,AA63-00521A+TAPE,20A5 AA63-00521A SHIELD-DRUM;20A5S,SECC,T0.5 AA65-30009A CLAMPER CORE-FBT;-,ABS,V0,-,BLK,- Samsung Electronics 7-25...
  • Page 80 2001-000232 R-CARBON;1.3KOHM,5%,1/8W,AA,TP,1.8X3.2M SFT01 2904-001063 FILTER-SAW AV;38.9MHz,SIP5K,TP,18.5dB,B/ RM323 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M JS701 3722-000183 JACK-SCART;21P,4mm,SN,BLK,NO RM307 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M IC201S AA09-00285A IC MICOM;TDA9381PS/N2/3/0749,SPM-744WOT RM339 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M TU01S AA40-00069A TUNER;TEDE9-802A,PAL,181CH,38.9MHZ,75OHM RM358 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M AA97-12965A ASSY AUTO;,C17A RT07 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M DM609 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 7-26 Samsung Electronics...
  • Page 81 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M RM648 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM345 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M RM682 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R221 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M RM694 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R914 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M RM690 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R919 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M RM689 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM324 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M RM688 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R220 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M Samsung Electronics 7-27...
  • Page 82 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V CT13 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CM345 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V CT04 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CM309 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V CT01 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V C227 2301-000104 C-FILM,PEF;1.2NF,5%,50V,TP,6.5X3.0X5.5MM CM656 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CT06 2301-000108 C-FILM,PEF;1.5nF,5%,50V,TP,6.5x3.0x5.5mm CM396 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CM372 2301-000160 C-FILM,PEF;12nF,5%,50V,TP,11.0x6.0x9.0mm CM334 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V CM368 2301-000175 C-FILM,PEF;15nF,5%,50V,TP,7.1x3.5x13mm,5 7-28 Samsung Electronics...
  • Page 83 JB806 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C229 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 JB901 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C214 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 JB902 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C213 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 JB903 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C209 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 JB5V08 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics 7-29...
  • Page 84 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J217 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) JG011 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J235 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) JG012 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J256 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) JG013 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J257 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 7-30 Samsung Electronics...
  • Page 85 AA61-01045A SUPPORT-PCB;DASS-T 9N,NYLON ,9.4,NTR Q804 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T AA63-00609A SHIELD-CASE;DP,20P1,AA63-00518A Q801 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP AA65-30111A CLAMPER CORE-WIRE;ALL MODEL,NYLON,V0,-,W R301 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM D810 AA96-00243D ASSY H/S;-,BRIDGE,AA62-00045A,D06U20S,D R408 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M 0205-000129 GREASE-SILICON;SC102,JAPAN R825 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 Samsung Electronics 7-31...
  • Page 86 AA60-40011A K EYELET;ID2.0,OD2.8,BST C309 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5 EY801 AA60-40011A K EYELET;ID2.0,OD2.8,BST C301 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15 EY406 AA60-40011A K EYELET;ID2.0,OD2.8,BST CR405S 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm EY407 AA60-40011A K EYELET;ID2.0,OD2.8,BST C821 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m EY408 AA60-40011A K EYELET;ID2.0,OD2.8,BST C810 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m EY409 AA60-40011A K EYELET;ID2.0,OD2.8,BST 7-32 Samsung Electronics...
  • Page 87 2202-000825 C-CERAMIC,MLC-AXIAL;680pF,10%,50V,Y5P,TP AV+CF 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW C502 2301-000213 C-FILM,PEF;220nF,5%,250V,TP,21.5x11,7.5 KP+CF 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW C506 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m C504 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5 JC500 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) JC501 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) AA41-00550A PCB-CRT;TF21B5S,FR-1,1L,A,1.6T,330X245,C GT502 AA60-40014A PIN-GT,ASSY;AUTO AA95-01822B ASSY SUB-PCB,MASTER;20P1,C17A,AA95-01615 SW811S 3403-001107 SWITCH-PUSH;250V,5A,DPST,-,KDC-A04 Samsung Electronics 7-33...
  • Page 88 QM313 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 IC902 1103-001177 IC-EEPROM;24WC16,2048x8Bit,DIP,8P,-,-,2. QM303 0504-000119 TR-DIGITAL;KSR1004,NPN,300MW,47K/47K,TO- SFT01 2904-001063 FILTER-SAW AV;38.9MHz,SIP5K,TP,18.5dB,B/ Q601 0504-000123 TR-DIGITAL;KSR1010,NPN,300mW,10K,TO-92,T SF101S 2904-001070 FILTER-SAW AV;38.9MHz,SIP5K,TP,14.6dB,B/ ICM603 1203-000642 IC-RESET;572,TO-92,3P,-,PLASTIC,2.35/2. JS701 3722-000183 JACK-SCART;21P,4mm,SN,BLK,NO RM638 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm IC201S AA09-00278A IC MICOM;TDA9361PS/N2/4/0717,SPM-744EW1 RM633 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 7-34 Samsung Electronics...
  • Page 89 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM R707 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM602 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM R601 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM363 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM R504 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM354 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM R907 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM R706 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM RC07 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM R227 2001-000531 R-CARBON;240KOHM,5%,1/8W,AA,TP,1.8X3.2M RC04 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM RM669 2001-000539 R-CARBON;24KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-35...
  • Page 90 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP R720 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM CM631 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP R222 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM CM607 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM CM327 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP R705 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM CM301 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP R708 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM C231 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP R713 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM C205 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 7-36 Samsung Electronics...
  • Page 91 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm CM332 2401-000426 C-AL;10uF,20%,16V,GP,TP,3.5x5,5 LM304 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm CM323 2401-000426 C-AL;10uF,20%,16V,GP,TP,3.5x5,5 LM309 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm CM304 2401-000426 C-AL;10uF,20%,16V,GP,TP,3.5x5,5 LM601 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm CM361 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 LM604 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm CM348 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 LM605 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm CM333 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 LJ702 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm Samsung Electronics 7-37...
  • Page 92 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J140 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J267 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J141 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J275 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J142 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) JA5V12 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J149 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 7-38 Samsung Electronics...
  • Page 93 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm J171 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C805 2401-000534 C-AL;150uF,20%,400V,GP,ST,25x30,10 J172 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) RL801S 3501-001040 RELAY-POWER;12VDC,500mW,10A,1FormA,15mS, J173 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) CN502A 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH J174 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) CN801B 3711-002645 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,STRAIGH Samsung Electronics 7-39...
  • Page 94 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5. DZ302 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D C305 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5. DZ806 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500mW,DO C303 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5. DZ802 0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500mW,D C814 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. DZ301 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D C408 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. DZ304 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D CR404S 2201-000639 C-CERAMIC,DISC;0.68nF,10%,2kV,Y5P,TP,9x5 DZ813 0403-001373 DIODE-ZENER;MTZJ5.1A,4.81V-5.07V,500mW,D C812 2201-000991 C-CERAMIC,DISC;0.56nF,10%,2kV,Y5P,TP,7.5 7-40 Samsung Electronics...
  • Page 95 AA39-10001M CBF POWER CORD;-,KJP-140,KLCE-2F,2.4m,HO EY802 AA60-40011A K EYELET;ID2.0,OD2.8,BST AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 EY803 AA60-40011A K EYELET;ID2.0,OD2.8,BST AA64-03106A DOOR-HOUSING;14P1DF,20P1DF(SEH),ABS HB,B EY804 AA60-40011A K EYELET;ID2.0,OD2.8,BST AA61-00050A SPRING ETC-DOOR;TVCR TVI,SUS304,-,-,-,-, EY805 AA60-40011A K EYELET;ID2.0,OD2.8,BST AA90-00947A ASSY-FULL DECK;2HD,SVTS-M2P/XEC EY806 AA60-40011A K EYELET;ID2.0,OD2.8,BST AA91-00741A ASSY-DECK;,SCORPIO TOSHIBA Samsung Electronics 7-41...
  • Page 96 3001-001186 SPEAKER;3W,8OHM,80°æ2DB,270HZ AA39-20501A LEAD CONNECTOR-ASSY;,3(2),67096-003,REC, AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, HA68-02177B LABEL-PQS;ALL,30MM,65MM,WHITE,AA68-02177 CF+KP 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW ASSY ACCESSORY AA92-06477A ASSY ACCESSORY;TX14N3DF4X/XET AA59-00221B REMOCON;,TM66,SAA5554PS,43,G6671B,S/S, 4301-000121 BATTERY-MN;1.5V,-,AAA,10.5x44.5m,HOLDER HA69-00276A BAG VINYL;HDPE,T0.025,L400,W240,-,W/O LO AA26-90001C TRANS MATCHING;-,300ohm/75ohm,PAL,40-890 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,- HA68-00336B CARD-WARRANTY;A/P100(G),A5,NEW VERSION,I AA68-50056Z LABEL-WARNING;A/P120(S),T0.2,-,-,BLK,-,T 7-42 Samsung Electronics...

  • Page 97: Block Diagram

    IC201S pin 42, where it outputs as RGB. 8-1-4 SYNCHRONOUS RECORDING: The viewer sees the signal from the 1st tuner , while the signal from the second tuner is recorded. Audio processing for the French system type is shown in the table. Samsung Electronics...
  • Page 98 Block Diagrams 8-2 C17A PCB Layout Samsung Electronics...

  • Page 99: Wiring Diagram

    Wiring Diagram 9. Wiring Diagram 9-1 C17A Wiring Diagram Samsung Electronics...

  • Page 100: Schematic Diagrams

    Schematic Diagrams 10. Schematic Diagrams 10-1 MAIN1 ( VCR SYSTEM BLOCK ) TP01 TP02 TP01 TP06 TP05 TP02 TP04 TP03 TP04 TP03 TP05 TP06 Samsung Electronics 10-1...
  • Page 101 Schematic Diagrams 10-2 MAIN2 ( VOC & TUNER BOX) 10-2 Samsung Electronics...
  • Page 102 Schematic Diagrams 10-3 MAIN3 ( VCR A/V BLOCK ) TP01 TP02 TP09 TP03 TP10 TP11 TP04 TP05 TP08 TP07 Samsung Electronics 10-3...
  • Page 103 Schematic Diagrams 10-4 MAIN4 ( SWITCHING BLOCK) 10-4 Samsung Electronics...
  • Page 104 Schematic Diagrams 10-5 MAIN5( OPTION-PAL HIFI BLOCK ) Samsung Electronics 10-5...
  • Page 105 Schematic Diagrams 10-6 MAIN6 ( OPTION-VCR SECAM BLOCK ) 10-6 Samsung Electronics...
  • Page 106 Schematic Diagrams 10-7 POWER & FBT Samsung Electronics 10-7...
  • Page 107 Schematic Diagrams 10-8 CRT 10-8 Samsung Electronics...
  • Page 108 Schematic Diagrams 10-9 FRONT A/V, MASTER SW FRONT A/V MASTER SW Samsung Electronics 10-9...
