Videocon VKB50QA-XSA User Manual

Videocon lcd/led screen user manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

SOUTH ZONE
HYDERABAD: 040-32449623 WARANGAL: 0870-3293311/22
KURNOOL: 08518-275859 NIZAMABAD:08462-245666 VIJAYAWADA: 0866-3248833/55
VISHAKHAPATNAM : 0891-3260033/44/55 RAJAHMUNDRY : 9000990236
TIRUPATI: 0877-2270013/14 BANGALORE: 080-324491144/66/77
HUBLI : 0836-3246633/44/55 MANGALORE : 0824-3257994/96 DAVANGERE: 0819-2261337
MYSORE: 0821-2372616 COCHIN: 0484-3113155 / 66 / 77 CALICUT : 0495-3233511 / 22 / 33
CHENNAI: 044 – 26209378 MADURAI: 0452 - 3268877 /55/66
COIMBATORE: 0422 - 2333145/146 SALEM: 0427 - 2403199 TRICHY: 0431 – 2411045
CENTRAL ZONE
MUMBAI: 022 – 42324545 THANE: 022 – 32162709 PUNE: 020 – 24260489, 020 – 24260329
NAGPUR: 0712-254307079 SANGLI: 0233 – 2276266 NASIK: 0253 – 2582703,0251 – 2582704
AURANGABAD: 0240 - 2471201 SOLAPUR: 0217 – 2357057 JALGAON: 0257 – 2020002
GOA: 0283-2462554 AHMEDABAD: 079 – 26400418, 079 – 40268555 SURAT: 0261 – 2461569
RAJKOT: 0281 – 2465041 INDORE: 0731 – 2544536, 0731 – 2544537 BHOPAL: 0755 – 4097500
JABALPUR: 0761 – 4218460,0761 – 4218472 RAIPUR: 0771 – 2445196
KOLKATA: 033 – 44031403 GUWAHATI: 0 9954746944 ASANSOL: 0341 – 2221017
BHUBNESHWAR: 0674 – 2597281
HINDI ZONE
AGRA: 0562-4051151 CHANDIGARH: 0124-5042140 DEHRADUN: 0135-3243553
DELHI: 011-32062775 GHAZIABAD: 0120-4162000 JAIPUR: 0141-4085001
JALANDHAR: 0181-5020297 JAMMU: 0191-2434959 JODHPUR: 0291-2741661
KARNAL: 9254304822 LUCKNOW: 0522-4017315 LUDHIANA: 0161-5092741 / 50292752
VARANASI : 0542-2363383/6541202 GURGAON: 0124-4094358 RANCHI: 0651 – 2340362
PATNA: 0612-2200048 GWALIOR: 9009799125

Advertisement

Table of Contents
loading

Related Manuals for Videocon VKB50QA-XSA

Summary of Contents for Videocon VKB50QA-XSA

  • Page 1 SOUTH ZONE HYDERABAD: 040-32449623 WARANGAL: 0870-3293311/22 KURNOOL: 08518-275859 NIZAMABAD:08462-245666 VIJAYAWADA: 0866-3248833/55 VISHAKHAPATNAM : 0891-3260033/44/55 RAJAHMUNDRY : 9000990236 TIRUPATI: 0877-2270013/14 BANGALORE: 080-324491144/66/77 HUBLI : 0836-3246633/44/55 MANGALORE : 0824-3257994/96 DAVANGERE: 0819-2261337 MYSORE: 0821-2372616 COCHIN: 0484-3113155 / 66 / 77 CALICUT : 0495-3233511 / 22 / 33 CHENNAI: 044 –...
  • Page 2 One that stands the test of time to grow stronger with our every interaction. At Videocon, we have set ourselves a goal to continuously challenge ourselves and contribute towards good health, happiness and a bigger cause - a greener tomorrow.

  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION ..................2 WARNINGS AND SAFETY PRECAUTIONS..........2 ANTENNA AND EXTERNAL EQUIPMENT CONNECTION....... 4 NAMES AND FUNCTION OF CONTROLS ON SET ......... 6 NAMES AND FUNCTION OF CONTROLS ON REMOTE......7 5.1. RF QWERTY REMOTE..............11 BATTERY INSTALLATION ............... 11 VIDEO MENU ...................

  • Page 4: Introduction

    and keep it somewhere you have quick access to, if required. Do not touch any pa ating manual. The LCD/LED Screen is a high-te moisture. Do not rub or strike the Active matrix LCD/LED wit or damage the active matrix LCD/LED per g water, on or near the TV.

  • Page 5: Product Disposal Guidelines

    Cleaning For safety, remove the Power plug from the power socket before cleaning the set. the dust on set by wiping the screen and the Clean enzol, petroleum or chemicals. here the power cord is subject to damage. Remove the Power plug from the power socket when the TV set is not used for a prolonged Period of the Aerial socket.

  • Page 6: Antenna And External Equipment Connection

    You can connect Antenna,external equipm Reflector A) RF Antenna Connection RF Antenna Connect Antenna cable to the RF IN / ANT IN socket on rear of the TV For good operation of the set, good signal is required. In the Strong area with the strong signal an indoor Antenna could be used but otherwise an outdoor Antenna RF IN/ANT IN...
  • Page 7 3. Switch on the PC and PC screen appears on the set. The set can be operated as PC monitor. HDMI HDMI socket on the TV. AV OUT VIDEO This connection is used for connecting the TV/AV, signal from TV SET 1 to TV SET 2. Note- AV OUT functionality is not applicable for DTH source.

  • Page 8: Names And Function Of Controls On Set

    4. NAMES AND FUNCTION OF CONTROLS ON SET A) Front Panel Control/Keys B) connecting your Unit:- (Optional) Note : 1) Point 10 is Optional. 2) Above sketch and connectivity are just for representation actual product may look different as per model selection.

  • Page 9: Names And Function Of Controls On Remote

    SOURCE SOURCE POWER RADIO FAVOURITE ACTIVE MOSAIC RADIO ACTIVE MOSAIC NET CONNECT EXIT HELP BACK DTV MENU ATV MENU MENU INFO MUTE SWAP STOP REPEAT ANGLE STOP REPEAT ANGLE PQRS WXYZ PQRS WXYZ SHIFT SHIFT LANGUAGE S-LINK SLEEP S-LINK HELP NOTE : Above Sketch is just for representation.
  • Page 10 RF QWERTY REMOTE : NOTE : Above Sketch is just for representation. Actual Remote set may differ than this sketch.
  • Page 11 POWER Turns TV into STANDBY ON / OFF mode. DTV MENU MENU This key is used to display DTH menu. MUTE Turns sound OFF or ON SOURCE Press SOURCE key on remote or key on front panel keypad A source OSD will appear to select a source press OK. ATV MENU This key is used to display the analog menu.
  • Page 12 Navigates vertically up/down through the Menu/Sub menu. - Used to set Program name - Used to sorting purpose in Program edit menu - To enter into displayed Menu / Sub menu parameters. - Select submenu from displayed menu - Select Up/Down Text page in USB mode - Increase / Decrease the value of selected items - To Navigate BBCL channel list only in DTH source.

  • Page 13: Rf Qwerty Remote

    5.1 RF QWERTY REMOTE (OPTIONAL) : · Remote can be used as a keyboard and mouse as well. · To access the Qwerty remote first you have to connect the dongle of remote provided with the remote. · The Qwerty Remote keypad works in Net Connect applications which is indicated at mouse symbol (RF Qwerty remote dongle is inserted in USB port).

  • Page 14: Video Menu

    7. Video Menu This function is used to select the presetted picture settings’ Picture Mode (Vivid,Hi-Bright,User,Cinema,Sports) Use this function to adjust picture size of the image/video to MOVIE - ZOOM,PANORAMA ZOOM / 16:9 (only for HDMI,D2H,Component), Picture Size SUPER ZOOM,SMART ZOOM,THEATRE ZOOM,NORMAL / Full (only VGA, multimedia), 4:3.

  • Page 15: Audio Menu

    8. Audio Menu This function is used to select the preset sound modes Audio Mode (User,Speech,Standard/Strata(optional), Music,) The Equalizer 100Hz,200Hz, 300Hz,400Hz,900Hz,1.5KHz, 3KHz, Equalizer 6KHz,9kHz,12kHz can be changed by the user The loudness function is used to on/off the Loudness level of Loudness Speaker User can select the left/right speaker intensity by changing...

  • Page 16: Installation Menu

    10. Installation Menu (For TV Input Only) Favourite channels group can be selected with (Red,Green,Yellow,Blue) keys on remote navigate to a channel to be included in favorite list press a color key, the color box same as key pressed appear in front of channel and the channel is included in list to remove the channel from favourite list press same key again Favourite Exit menu and press same color key, the favorite OSD appear with selected...

  • Page 17: Wireless And Internet Settings

    Lock This feature enable to handle the overall Locking of Source Channel e.t.c. Switch Press left/Right Navigation keys for ON/OFF of this feature. This feature allow to Lock the front panel key which is Front Present on TV set. Panel Press left/Right Navigation keys for ON/OFF of this feature.
  • Page 18 · Select desired Wireless Connection by pressing Green Color key “ ” · Press Yellow key to enter the password of the wireless device. · Now press green key to connect the wireless device. · If it does not get connected automatically; press back“ ”...

  • Page 19: Internet Features (Optional)

    Scroll down the source list and select “Net Connect”. c. Then press “OK” key to use the internet features. This function is used to access the Videocon applications. V Apps Ex. : Facebook, Twitter, Nivio, Weather, You Tube, Games, Radio and Currency Converter.
  • Page 20 12. INTERNET FEATURES (OPTIONAL) > To access this feature, enter the IP address of Desktop/Laptop in given window of HOST IP. > Press OK key to access the shared folder. Procedure to Share Folder in PC: > Create a share in Windows PC. Net Connect >...

  • Page 21: Multimedia Format Support

    13. MULTIMEDIA FORMAT SUPPORT File Type File Format File suffix Picture: JPEG\ BMP\ PNG .jpg/ .bmp/ .png .avi/.mpg.mov/.mkv/.mp4/.wmv/.flv/.vob Video: MPEG1\ MPEG2\ MPEG4/MOV/FLV/VOB .wma/.mp3 Audio WMA\ MP3 Picture Formats Details File Format Resolution Compressed Format Support Range Progressive JPEG Only Support 1024x768 1920X1080 JPEG Baseline(Standard)
  • Page 22 4. The reading speed will be variable due to different connected devices & different storage capacities. 5. Videocon is not responsible if USB device is not supported, nor it is responsible for damage or loss of data. 6. Due to difference of equipment & storage capacity the time need to read information also differ.The speed of reading information may slow down temporarily, note that this is not...
  • Page 23 Resolution support Component 480i (60Hz), 480p (60Hz), 576i(50Hz), 576p(50Hz), 720p,(50Hz, 60Hz),1080i, (50hz, 60Hz) mode VGA mode 640 x 480 (60Hz, 72Hz, 75Hz), 800 x 600 (56Hz, 60Hz, 72Hz, 75Hz), 1280 x 1024 (60Hz), 1600 x 1200 (60Hz), HDMI 480i(60Hz), 480P (60Hz), 576i (50Hz), 576p (50Hz) 720p (60Hz), 1080i(50Hz,60Hz), 1080P (50Hz,60Hz)

  • Page 24: Technical Specifications

    14. TECHNICAL SPECIFICATIONS...

  • Page 25: Troubleshooting

    15. TROUBLESHOOTING Manually trail to adjust HV position. Auto Adjust, try to adjust clock manually.

  • Page 26: Stand Assy. & Wall Mounting Instruction

    16. STAND ASSY. & WALL MOUNTING INSTRUCTIONS Stand Assembly of 32” LED 1. Place the set, face down on the table(as shown in figure). 2. To avoid damage / scratches on panel / set, use soft and STAND BASE clean surface. M 4X12 3.
  • Page 31 2. In case the customer chooses to subscribe to the services, customer may call the customer care numbers provided by company. 3. Videocon d2h person will come and explain the Service feature to the customer before installation. 4. On purchase of the product subscription to the Videocon d2h services is not mandatory.
