PREPARATION

BACK PANEL INFORMATION

Image shown may differ from your TV.
19/22/26LE5300, 22/26LE5500,
11
DC-IN
Power Connection
CAUTION
Please be sure to connect the TV to the AC/DC power adapter before connecting the TV's
power plug to a wall power outlet.
16
1 2 3 4
1 2
RS-232C IN
(DVI)
(CONTROL&SERVICE)
OPTICAL
AV IN
AUDIO IN
DIGITAL
RGB/DVI AUDIO OUT
VIDEO L(MONO)
RGB IN (PC)
Y P P
B R
AUDIO
VIDEO
COMPONENT IN
7
DC IN
AC/DC Adaptor
19/22LE5300,
22LE5500
AUDIO R
5
L R
ANTENNA/
CABLE IN
6
Connect the AC/DC adapter plug to the
1
power input jack on the TV.
Connect the power cord to the AC/DC
2
adapter first, then plug the power cord into
the wall power outlet.
