Summary of Contents for Konica Minolta PMT
- Page 1 Konica Minolta Kit ~ Bizhub for PMT Installation Manual | Konica Minolta Kit ~ Bizhub for Product Version: 7.2 Version of this manual: 7.2.28 © 2014 Inepro B.V. All rights reserved...
-
Page 3: Table Of Contents
Table of Contents Introduction Part List Hardware Setup Set up the PTM 1 PTM GUI ................................ 12 2 Behaviour ................................ 13 3 Network ................................ 13 4 General Settings ................................ 14 Version 7.2.28 http://www.inepro.com... -
Page 5: Introduction
Introduction Part... - Page 6 1. Check the part list, read more on page 2. Prepare and construct the hardware. To read more go to page 3. Set up the PTM, you will find more information on page Konica Minolta Kit ~ Bizhub for PMT...
-
Page 7: Part List
Part List Part... - Page 8 Part List PartList Before the PTM is installed make sure all the parts needed are present. 321000 - PTM MFP Multi RFID parts Konica Minolta Kit ~ Bizhub for PMT...
- Page 9 321000 - PTM MFP Multi RFID part list 1 x P120650 - PTM Desktop Foil 4 x P273930 - Rubber Foot, adhesive 1 x P275732 - Multi ISO RFID 13,56 MHz Antenne Board 1 x P321160 - PTM LCD Display 1 x P321161 - Touchscreen M4702A 1 x P321180 - PTM Housing back-side 2 x P500007 - Pan-head cross recess screw ISO 7045 - M4 x 20 - Z...
-
Page 11: Hardware Setup
Hardware Setup Part... - Page 12 Additional requirements: · Pair of wire cutters · No. 2 cross head screwdriver · No. 1 PosiDriv head screwdriver · PTM MFP · 2x CAT-5 Network cables (one 90 degree angled cable included) Konica Minolta Kit ~ Bizhub for PMT...
- Page 13 Attach the PTM bracket to the copier 2. Attach the PTM to the bracket with the M4 x20 screws and their hooded washers. Make 1. Attach the bracket to the copier with the sure the network cable and power supply cable foam tape and screws.
- Page 14 Hardware Setup Attach the PTM to the PTM bracket 3. Use the ty-raps to feed the cable to the back of the machine. Konica Minolta Kit ~ Bizhub for PMT...
-
Page 15: Set Up The Ptm
Set up the PTM Part... -
Page 16: Ptm Gui
3. If not, the display will be filled with white. Use the PayCon Config Tool to enter the menu and go to the "hardware\User Interface" menu. 4. From the Hardware menu, go to "../Customer Interface", "..\Employee Interface" and "..\Menu Interface" and set all these to "Touchscreen". Konica Minolta Kit ~ Bizhub for PMT... -
Page 17: Behaviour
Behaviour Behaviour 1. Where is the credit value kept? a. On the card (SVC), you will need to use cards of the chipcard or Mifare card type and the ECOS 'KM - PTM Payment Option', continue with step 2. b. On the server (SVS), go to step 3. c. - Page 18 To edit it's properties, go to 'Main Menu' => 'Products' => 'Product List', select it and press c. Check the price and if the index number corresponds with the copy product index number in the table. Konica Minolta Kit ~ Bizhub for PMT...
-
Page 19: General Settings
General Settings 11. Purse Selection, manage the way the purse is selected. , Go to 'Main Menu' => 'Card/ID' => 'Generic Settings' => 'Purse Selection'. b. Select the selection behaviour in the list (look for a description in the table) confirm with Purse Selection Description All Purses...
