Operating Instructions
Optional Function
• WIRELESS REMOTE CONTROLLER (Optional)
This air-conditioner is equipped with wired remote controller basically. But if you want to have the wireless
remote controller, you pay for it.
Signal transmitter
Transmits the signals to the signal receptor.
1
4
3
5
6
CAUTION : for handling the Remote Controller
• Aim at the signal receptor on the wired remote controller so as to operate.
• The remote control signal can be received at a distance of up to about 7m.
• Be sure that there are no obstructions between the remote controller and the signal
receptor.
• Do not drop or throw the remote controller.
• Do not place the remote controller in a location exposed to direct sunlight, or near the
heating unit, or any other heat source.
• Block a strong light over the signal receptor with a curtain or etc. so as to prevent the
abnormal operation. (ex:electronic quick start, ELBA, inverter type fluorescent lamp)
10 Multi-Type Air Conditioner
11
A/CL
10
9
2
7
8
1. FAN Operation Button
Used to circulate room air without cooling or
heating.
2. Cooling Operation Button
3. Soft Dry Operation Button
Used to dehumidify without overcooling.
4. Heating Operation Button
(Heat pump model only)
5. Timer Set Button
Used to set the timer when the desired time is
obtained.
Then the wired remote controller is set up to 24
hours by an hour but the wireless remote
controller is set up to 7 hours by an hour.
Therefore, if you want to set over 7 hours, use the
wired remote controller.
6. Fan Speed Button
Used to set the desired fan speed.
7. On/Off Button
Operation starts when this button is pressed, and
stops when the button is pressed again.
8. Set Temperature Button
Used to set the temperature when the desired
temperature is obtained
9. Auto Operation Button
10. Plasma Air Clean Button(Optional)
11. Electric Heater Button (Optional)
Used to set the Electric Heater.
