Summary of Contents for Bell System CS106
- Page 1 C106 Coded Access Keypad Including: CS106 and BL106 Door Entry & Coded Entry PD-024 Issue 4...
-
Page 3: Features
Two Time Zones for Staff / Executive operation. Output for Fail-Safe and Fail-Secure locks. Exit button facility. Lock timer. Secure programming via the keypad. Non-volatile memory. Products CS106 Series combined coded access and door entry system. BL106 Series combined coded access and door entry system... -
Page 4: Table Of Contents
CS106/BL106 Combined Door Entry and Coded Access Contents Features ........................3 Products ........................3 General Description ....................6 Basic Operation ....................6 Other Features: ....................6 Installation ....................... 9 Wiring for the C106 Keypad ................9 Cable Requirements ..................10 Power Supply - Important Safety Information .......... - Page 5 CS106/BL106 Combined Door Entry and Coded Access Table 2 - Programming of Action Codes ............26 Table 3 - Summary of Action Numbers ............26 Table 4 - Programming of Other Functions ..........27 Commissioning ..................... 28 Testing the Lock Release Outputs..............28 Testing the controller with factory settings ...........
-
Page 6: General Description
CS106/BL106 Combined Door Entry and Coded Access General Description The C106 Coded Access Controller is a high quality, versatile security product, controlling access to a door by means of a keypad and an electric lock release mechanism. Basic Operation The C106 Keypad may be programmed with up to 10 unique access codes. If a valid code is entered on the keypad, the lock release will operate for a preset duration. - Page 7 CS106/BL106 Combined Door Entry and Coded Access time period only. This time period can be determined by a time-clock or manually via a key switch. For example, with factory settings, the operation of code 1 is unrestricted (Executive Code) whilst code 2 is restricted to when the time-clock input is closed (Zone 1 - Staff Code).
- Page 8 CS106/BL106 Combined Door Entry and Coded Access Programmable Options In addition to the 10 access codes the user may program the following other functions: Lock Duration (1-99 seconds) Lock Delay Time (0-99 seconds) Time-Restricted Access...
-
Page 9: Installation
CS106/BL106 Combined Door Entry and Coded Access Installation Read carefully all of the information presented in this chapter and then install the system in accordance with the wiring diagram below. Wiring for the C106 Keypad... -
Page 10: Cable Requirements
CS106/BL106 Combined Door Entry and Coded Access Cable Requirements Cable Types 0.5mm: Twisted pair, e.g. BT spec CW1308 or CAT5 UTP 1.0mm: 1.0mm ‘Twin mains flex’ Connections No. of cores Cable length Core diameter Power supply up to 15M 0.5mm up to 50M 1.0mm... -
Page 11: Power Supply - Important Safety Information
CS106/BL106 Combined Door Entry and Coded Access Power Supply - Important Safety Information The Model 340C Power Supply must be wall mounted on to plasterboard, wood or a similar non-conductive material, in a protected indoor environment and close to a 240V AC electrical supply e.g. an electrical cupboard. Connections... - Page 12 CS106/BL106 Combined Door Entry and Coded Access Mains Cables Use only mains cable to BS6004, BS6500, or equivalent, within the following specified limits: Minimum Maximum Conductor Diameter 1.0mm (0.75mm 2.25mm (4mm Cable Diameter 4.0mm 8.0mm When fitting the cables (both primary and secondary) ensure that the cable...
-
Page 13: Electric Lock Release
CS106/BL106 Combined Door Entry and Coded Access Electric Lock Release When installing lock releases please allow a little movement on the door as operation will be impaired if fitted too tightly. The C106 Keypad provides two alternative pairs of connections for direct connection of an electric lock releases:- ‘FAIL SECR’: Use these connections for ‘Fail-Secure’... -
Page 14: High Current Lock Releases
CS106/BL106 Combined Door Entry and Coded Access High Current Lock Releases For a lock release or a magnetic lock rated higher than 0.5A an additional power supply will be required. In addition a relay must be used to interface with the C106 Keypad. -
Page 15: Time Restricted Access
CS106/BL106 Combined Door Entry and Coded Access Time Restricted Access The C105 Keypad has a pair of terminals marked ‘TIME’ which can be connected to an external Time Clock or Key switch to control time-restricted access. Any switch contact must be fully isolated (i.e. voltage free), the TS2000-BST Time Clock is normally used. -
Page 16: Programming The C106 Keypad
CS106/BL106 Combined Door Entry and Coded Access Programming the C106 Keypad General The 10 access codes, lock time etc, are all programmed via the keypad. To prevent unauthorised use, a security key (1 - 8 digits) must be entered. The basic principle of programming is as follows: Procedure ■... -
Page 17: Programming A New Access Code (Functions 1 To 10)
CS106/BL106 Combined Door Entry and Coded Access Programming a New Access Code (Functions 1 to 10) The C106 Keypad has ten access codes. Each code may be between 1 to 8 digits long. Procedure Enter the current Security key (default 1212). Check... -
Page 18: Changing The Security Key (Function 91)
CS106/BL106 Combined Door Entry and Coded Access Changing the Security key (Function 91) The security key is the code that must be entered on the keypad to gain access to the settings. The security key is factory set to 1212, to maintain security we recommend that this be changed immediately. - Page 19 CS106/BL106 Combined Door Entry and Coded Access Choosing an access code To ensure an adequate level of security it is recommended that a minimum of 4 digits be used for each access code, giving 10,000 combinations. Codes should be chosen carefully to avoid obvious sequences and repetitions (e.g.
-
Page 20: Programming The Action Codes (Functions 51 To 60)
CS106/BL106 Combined Door Entry and Coded Access Programming the Action Codes (Functions 51 to 60) Each access code has an associated action number. This is a single digit from 0-3 which determines the action that occurs following the entry of that access code. - Page 21 CS106/BL106 Combined Door Entry and Coded Access Procedure Enter the current Security key (default 1212). Type : Example 52 + + + + 1 # <51 – 60> + + + + <Action No> # Code 2: Action No.=1 Both LEDs flash once...
-
Page 22: Programming The Lock Duration (Function 95)
CS106/BL106 Combined Door Entry and Coded Access Programming the Lock Duration (Function 95) This is the duration the lock release will operate for when triggered by an access code or by the ‘EXIT’ input. It is programmable in the range 1-99 seconds. -
Page 23: Programming A Lock Delay Time (Function 96)
CS106/BL106 Combined Door Entry and Coded Access Programming a Lock Delay Time (Function 96) This function causes a delay (0-99 seconds) to be introduced between the triggering of the lock release and its operation. Typically, this facility is used when the keypad is located some distance from the entrance. -
Page 24: Programming The Factory Settings (Function 99)
CS106/BL106 Combined Door Entry and Coded Access Programming the Factory Settings (Function 99) In the event of any problems, always return to Factory settings. Procedure Enter the Security key. If you have forgotten the Type : 99 + + + + # Security key see ‘Programming... -
Page 25: Summary Of Program Functions
CS106/BL106 Combined Door Entry and Coded Access Summary of Program Functions Table 1 - Programming Access Codes Function Key sequence Factory Setting 1 + + + + <1-8 digits> # Program Code 1 1 2 3 4 5 2 + + + + <1-8 digits> #... -
Page 26: Table 2 - Programming Of Action Codes
CS106/BL106 Combined Door Entry and Coded Access Table 2 - Programming of Action Codes Function Key Sequence Factory Setting 51 + + + + <0-3> # Code 1 Action Number 1 (Operate always) 2 (Operate when 52 + + + + <0-3> #... -
Page 27: Table 4 - Programming Of Other Functions
CS106/BL106 Combined Door Entry and Coded Access Table 4 - Programming of Other Functions Function Key Sequence Factory Setting 91 + + + + <1-8 digits> # Security key 1 2 12 95 + + + + <1-99 secs> #... -
Page 28: Commissioning
CS106/BL106 Combined Door Entry and Coded Access Commissioning After installation of the C106 unit, follow the two test procedures below; any problems can be diagnosed from the troubleshooting section. Finally program the required security and access codes (page 16). Testing the Lock Release Outputs Ensure that the lock release is connected to the correct output (as shown in the Wiring diagram on page 9). -
Page 29: Testing The Controller With Factory Settings
CS106/BL106 Combined Door Entry and Coded Access Testing the controller with factory settings Before proceeding with this test ensure that the lock release is working correctly by following the tests on page 28. Program to factory settings by following the instructions on page 24 or 32. -
Page 30: Troubleshooting
CS106/BL106 Combined Door Entry and Coded Access Troubleshooting Use the table below to determine the most probable cause of a fault condition. Symptom Possible Cause/Remedy Power Supply is overloaded. Remove externally connected components until the fault disappears. When power applied nothing Polarity not correct. - Page 31 CS106/BL106 Combined Door Entry and Coded Access Symptom Possible Cause/Remedy button is pressed. Test by applying a short-circuit directly Lock release does not operate to the ‘EXIT’ terminals; Check when Exit Button is pressed. connections to Exit button. Check C106 Keypad is correctly programmed;...
-
Page 32: Programming The Factory Settings With The Test Button
CS106/BL106 Combined Door Entry and Coded Access Programming the Factory Settings with the Test Button In the event of any problems, always return to Factory Settings. If the security key has been forgotten, the test button can be used to restore factory settings. -
Page 33: Specification For The C106 Controller
CS106/BL106 Combined Door Entry and Coded Access Specification for the C106 Controller Lock Output Voltage: Same as Input Voltage Load (maximum): 0.5A (load inductive or resistive) Note : Inductive loads such as Maglocks must have suitable transient voltage suppression fitted, e.g. a diode or MOV Power (C + &... - Page 34 CS106/BL106 Combined Door Entry and Coded Access...
-
Page 35: Cs106 / Bl106 Combined Series
CS106/BL106 Combined Door Entry and Coded Access CS106 / BL106 Combined Series Combined Door Entry and Coded Access Keypad... -
Page 36: General Description
CS106/BL106 Combined Door Entry and Coded Access General Description The CS106 / BL106 series systems are combined Door Entry Telephone and Coded Access Systems. The entrance panel incorporates a number of push buttons for each telephone, a speaker grill and an integral C106 keypad. -
Page 37: Installation Of The Door Entry Phone System
The Entrance Panel It should be mounted on an outside wall near the front door, and in a sheltered location. There is an option for CS106 systems to have a flush entrance panel. Extension Phones Each apartment can have up to 3 extension phones (4 phones in total). -
Page 38: Cable Planning
CS106/BL106 Combined Door Entry and Coded Access Cable Planning Cable Requirements... - Page 39 CS106/BL106 Combined Door Entry and Coded Access For optimum clarity of speech it is strongly recommended that this system is installed using twisted-pair telephone cable (e.g. type CW1308). Use one of the pairs for the R & O connection between the speech unit and the telephone.
-
Page 40: Installation Procedure
CS106/BL106 Combined Door Entry and Coded Access Installation Procedure Connect all items by following the wiring diagram, on page 44 or 45. It is strongly recommended that a single telephone be connected at a time and fully tested before proceeding to the next. -
Page 41: Troubleshooting
CS106/BL106 Combined Door Entry and Coded Access Troubleshooting Use the table below to determine the most probable cause of a fault condition. Refer also to page 28 for problems with the coded access system (C106 Keypad). Telephone Problems Symptom Possible Cause/Remedy Volume adjustment required on speech unit. - Page 42 CS106/BL106 Combined Door Entry and Coded Access Symptom Possible Cause/Remedy Volume adjustment required on the Speech Unit. Speech Unit is not tight against the panel grill. ‘O’ connection between Speech unit Constant tone/feedback and telephone is open circuit. when in use.
- Page 43 CS106/BL106 Combined Door Entry and Coded Access Miscellaneous Problems Symptom Possible Cause/Remedy Faulty 'O' or 'I' line between power Telephone will not buzz. supply and phone. Check 10.5V - 15V across ‘I’ and ‘O’ when called. Telephone ‘DOOR’ button Missing connection to C106 Keypad does not operate release;...
-
Page 44: Cs106-1/Bl106-1 Wiring (1 Way Combined)
CS106/BL106 Combined Door Entry and Coded Access CS106-1/BL106-1 Wiring (1 Way Combined) -
Page 45: Cs106-N/Bl106-N Wiring (Multi-Way Combined)
CS106/BL106 Combined Door Entry and Coded Access CS106-N/BL106-N Wiring (Multi-way Combined) -
Page 46: Wiring Diagram - 2 Door System With The C106
CS106/BL106 Combined Door Entry and Coded Access Wiring Diagram - 2 Door System with the C106... - Page 48 Bell System (Telephones) Ltd. Presley Way, Crown Hill, Milton Keynes MK8 0ET. Tel: 01908 261106 (Sales and Technical Support) FAX: 01908 261116 Local rate numbers Tel: 0845 121 4008 (Sales and Technical Support) FAX: 0845 121 4009 E-mail: sales@bellsystem.co.uk technical@bellsystem.co.uk Website: www.bellsystem.co.uk...
