Microwave / Combination
DSG Retail Limited is responsible for after sales service.
If you have a query about the product please contact our product support line
0844 561 6263 (Currys) and 08700 118 117 (Pixmania).
Oven
clock/
pre-set
defrost by
weight
defrost by
time
start
micro/grill
auto menu
/combi
stop/clear
KGJAL31
Advertisement
Table of Contents
Related Manuals for Kenwood Storage Server
Summary of Contents for Kenwood Storage Server
- Page 1 Microwave / Combination Oven clock/ pre-set defrost by weight defrost by time start micro/grill auto menu /combi stop/clear KGJAL31 DSG Retail Limited is responsible for after sales service. If you have a query about the product please contact our product support line 0844 561 6263 (Currys) and 08700 118 117 (Pixmania).
-
Page 2: Table Of Contents
2 - 3 know your Kenwood microwave safety information 4 - 8 using aluminium foil in your microwave unpacking and getting ready introducing microwave cooking 11 - 16 cooking with a microwave 11 - 12... - Page 3 steam condensation product overview 14 - 15 control panel overview checking your microwave clock setting setting the child lock...
-
Page 4: Know Your Kenwood Microwave
Kenwood microwave before using your Kenwood microwave ● Read these instructions carefully and retain for future reference. ● Remove all packaging labels. Please dispose of them properly. before calling for service ● Review the section on Troubleshooting. This will help you to solve some general problems by yourself and reduce the need to ask for the help of professional technicians. -
Page 5: Microwave Use
safety information please read carefully and keep for future reference maintenance of your microwave WARNING : It is hazardous for anyone other than a quali- fied technician to carry out any service or repair operation which involves the removal of a cover that gives protection against exposure to microwave energy. - Page 6 safety information cooking use As the power of different microwave ovens can vary consider- ably, care must be taken when first using this appliance as it may cook faster than expected. ● Do not leave the appliance unattended during use. WARNING : Only allow children to use the oven without supervision when adequate instructions have...
- Page 7 safety information do not use these in your microwave ● Never use equipment made of metal, except foil in your microwave oven. The microwave energy cannot pass through the metal so it bounces off and sparks against the inside of the oven.
-
Page 8: Safety Information 4
safety information earthing instructions ● WARNING: THIS APPLIANCE MUST BE EARTHED. ● This appliance is equipped with a cord having an equipment-earthing conductor and an earthing plug. ● The plug must be plugged into an appropriate outlet that is installed and earthed in accordance with all local standards and requirements. -
Page 9: Using Aluminium Foil In Your Microwave
using aluminium foil in your microwave It is safe to use aluminium foil in your microwave oven as long as you follow these safety guidelines. As with all metal, microwave energy cannot pass through foil, but provided that you keep the foil away from the side of the oven it will not cause sparks and there will not be any damage to your oven. -
Page 10: Unpacking And Getting Ready
unpacking and getting ready This microwave oven is designed for home use. It should not be used for commercial catering. 1. After unpacking your oven, check that it has not been damaged whilst in the box. Make sure there are no dents on the oven, and the door closes properly. -
Page 11: Introducing Microwave Cooking
introducing microwave cooking Always remember the basic safeguards you would follow when using any cooking equipment or handling hot food. See below for basic guidelines in microwave cooking. If you are unfamiliar with using a microwave, refer to the back of this instruction booklet for more information. -
Page 12: Checking Your Cooking Utensils
● Microwave ovens cook food using microwave energy that is similar to naturally occurring radio waves. Normally, these “waves” would fade as they dispersed into the atmosphere but in a mi- crowave oven they are concentrated onto food causing it to heat up. ●... -
Page 13: Microwave Heating Categories
microwave heating categories Your oven has been tested and labelled to meet the government’s voluntary agreement on the reheating of pre-cooked food. The heating characteristics and output power levels of microwave ovens are usually calculated using a relatively large portion of food (a 1000 gram load, IEC 705) but many packs of pre-cooked food are sold in smaller packs, often about 350 grams. -
Page 14: Steam
steam When you microwave food, steam is created as water in the food heats up and evaporates. clock/ pre-set The steam formed during microwave cooking is defrost by weight entirely safe. It has to escape from the micro- defrost by time wave to prevent pressure from building up start... -
Page 15: Control Panel Overview
control panel overview clock/pre-set button Use this button to set the clock and to preset cooking time. clock/ pre-set LED display defrost by weight button Shows the clock , cooking Use this button to defrost the time and setting. food by weight. defrost by weight defrost by... -
Page 16: Checking Your Microwave
checking your microwave Check your microwave after unpacking. NOTE: For your safety, the microwave stops if the oven door is opened during cooking. Close the door and press the start but- ton to continue the cooking cycle. 1. Pull handle to open the door. Put the turntable ring inside the oven and place the glass turntable on top of the ring. -
Page 17: Clock Setting
clock setting When the microwave oven is connected to the mains power, the oven will display 0:00, and the microwave will sound once. Please ensure you have set the clock prior to use. Please follow the steps below to set the clock. 1. -
Page 18: Setting The Child Lock
setting the child lock This feature prevents the electronic operation of the oven by locking the operation of the control panel until you have cancelled it. Please follow the steps below to set the child lock. 1. Press the stop/clear button for 3 sec- onds and a long tone will sound and the child lock indicator will illuminate to indicate the microwave has set the... -
Page 19: Microwave Cooking
microwave cooking For simple Microwave Cooking, follow the steps below. For instance if you want to use 80% microwave power to cook for 20 minutes. 1. Press the micro/grill/combi button once and the LED display will show P100. Press the button again to change the microwave power level to P80. -
Page 20: Grill Or Combination Cooking
grill or combination cooking For Grilling, follow the steps below. 1. Press the micro/grill/combi button once and the LED display will show G. 2. Press the up/down buttons to adjust the cooking time. The time setting is be- clock/ pre-set tween 0:05 - 95:00. - Page 21 Grill/Combi. Button Control Order Microwave Grill Display Power Power 100% Please note that there are only 2 modes of Combination Cooking and their Microwave, Grill clock/ Powers are indicated as per above table. pre-set For instance if you want to do 55% microwave power and 45% grill power cooking (C-1) for 10 minutes, please follow the steps below.
-
Page 22: Two-Stage Cooking
two-stage cooking For Two-Stage Cooking, please follow the steps below. For instance if you want to defrost your food for 5 minutes and then to cook it with 80% microwave power for 7 minutes. NOTE: You can set a maximum of 2 stages for Two-Stage Cooking. -
Page 23: Delay Start Cooking (Program Set In Advance)
delay start cooking (program set in advance) For Delay Start Cooking, set the clock first and follow the steps below. For instance: The current time is 12 o’clock (noon) and you want to cook with 80% micro- wave power for 5 minutes after 1 hour 30 minutes. NOTE: You can set a maximum of 2 stages for Delay Start Cooking. -
Page 24: Auto Cooking
auto cooking This feature allows you to cook most of your food based on the food category and the weight. Select the category and choose the default weight of the food. For quick reference of the cooking time and the default weight, please refer to the Auto Menu table. auto menu 1. - Page 25 NOTE: The density and thickness of food can affect its cooking time. Ensure all food is piping hot and cooked thoroughly before serving. It is essential that food is checked during and after the recommended cooking time, even if Auto Menu was used. Auto Menu table Menu Weight...
-
Page 26: Quick Start Cooking
quick start cooking This feature allows you to quickly cook your food for 30 seconds with 100% microwave power. Please follow the steps below. 1. Press the start button to start the quick start cooking. Press the button again to increase by another 30 seconds, you may increase the cooking time up to 95 minutes. -
Page 27: Defrosting
defrosting This feature allows you to defrost your frozen foods simply by entering the weight or time. You may wish to place the frozen food on a microwave safe plate or dish before placing it on the defrost rack. This is to ensure that any liquids released during defrosting will not spill and dirty the interior of the oven. -
Page 28: Querying The Cooking Function
querying the cooking function This feature allows you to check and view the current power, time, and pre-set time of your selected cooking program. to find out the current cooking power 2 , 3 1. Press the stop/clear button, open the door then press the micro/grill/com- bi button once and the LED display will clock/... -
Page 30: Cleaning Your Microwave
Cleaning your Cleaning your oven each time you use it will help to prevent Unplug your microwave from the mains and wait for the On the right hand side wall of the cavity is the wave guide cover, It is important that this wave guide cover is kept clean at all times. Make sure you keep the outlet grids clean. - Page 31 microwave a build up of stubborn marks that can be difficult to clean. oven to cool down completely before cleaning. microwaves are passed through this to enable your food to cook. Wipe it with mild detergent and water and leave to dry. Be careful not to spill water into the vents.
-
Page 32: Troubleshooting
troubleshooting If you have a problem that cannot be answered by these points, please contact your near- est store. Please note: If you call a Mastercare engineer out to your home and the product is found not to be faulty, or the instruction book has not been followed, our product guarantee is not applicable and a call-out fee will be charged. - Page 33 questions and answers Q. What happens if the microwave is switched on while the oven is empty? A. The microwave will be damaged. Do not switch the microwave on when there is noth- ing inside the oven. It is a good idea to keep a cup of water in the oven just in case some- one accidentally starts the microwave.
-
Page 34: Specification
specification Input 230 - 240V ~50Hz Ouput 950 - 1000 Watts Microwave Frequency 2450MHz Outside Dimensions 520mm x 440mm x 335mm (width x deep x height) Power consumption Microwave 1550 - 1650 Watts Grill 1150 - 1250 Watts Complies with EEC directives 89/336/EEC and 92/31/EEC. Because we continually strive to improve our products, we may change specifications without prior notice.
