JVC AV-28R370KE Instructions Manual

Interiart natural vision t-v link
Hide thumbs
Table of Contents

Advertisement

Quick Links

Specifications
Model
AV-32R370KE
Item
Broadcasting systems
CCIR I
Colour systems
PAL
• The EXT terminals also support the NTSC 3.58/4.43 MHz system.
Channels and frequencies E21-E69
Sound-multiplex systems
NICAM (I) system
Teletext systems
FLOF (Fastext), WST (World Standard Text)
Power requirements
220 - 240 V AC, 50 Hz
Power consumption
Maximum: 200 W, Average: 127 W,
Standby: 3 W
Picture tube size
Viewable area 76 cm (measured
diagonally)
Audio output
Rated Power output: 10 W + 10 W + 10 W, 18 W (woofer)
(13 cm × 6.5 cm) oval × 2, (16 cm × 4 cm) oval × 1, 13 cm round woofer ×1
Speakers
EXT-1 terminal
Euroconnector (21-pin, SCART)
• Video input, Audio L/R inputs and RGB inputs are available.
• TV broadcast outputs (Video and Audio L/R) are available.
EXT-2 terminal
Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
• Video and Audio L/R outputs are available.
• T-V LINK functions are available.
EXT-3 terminal
Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
RCA connectors × 3
EXT-4 terminal
S-VIDEO connector × 1
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
AUDIO OUT terminal
RCA connectors × 2
• Variable audio L/R outputs are available.
• Variable out 0-1 Vrms, low impedance.
SURROUND REAR
SPEAKER terminals for external surround speakers.
terminal
• Surround rear sounds are output to the speakers.
• For impedance 8-ohm speakers only.
• Rated power output: 7.5 W + 7.5 W
Headphone jack
Stereo mini-jack (3.5 mm in diameter)
Dimensions (W × H × D)
946 mm × 562 mm × 551 mm
Weight
57.5 kg
Accessories
Remote control unit × 1 (RM-C1504)
AA/R6 dry cell battery × 2
We may change the design and specifications without notice.
Pictures displayed on the screen using this TV's ZOOM functions should not be shown for any
commercial or demonstration purpose in public places (cafes, hotels, etc.) without the consent of the
owners of copyright of the original picture sources, as this would be an infringement of copyright.
© 2003 VICTOR COMPANY OF JAPAN, LIMITED
AV-28R370KE
Maximum: 200 W, Average: 125 W,
Standby: 3 W
Viewable area 66 cm (measured
diagonally)
854 mm × 507 mm × 494 mm
43.0 kg
LCT1354-001A-U
0203-MK-CR-JMUK

Colour Television

AV-32R370KE
AV-28R370KE
INSTRUCTIONS
Contents
Setting up your TV . . . . . . . . . . . . . . . . . 5
TV buttons and functions . . . . . . . . . . . 10
Remote control buttons and functions . . .11
Teletext function . . . . . . . . . . . . . . . . . 16
Using the TV's menu . . . . . . . . . . . . . . 18
Additional menu operations . . . . . . . . . 35
Additional preparation . . . . . . . . . . . . . 39
Troubleshooting . . . . . . . . . . . . . . . . . . 42
Specifications . . . . . . . . . . . . Back cover
