DIGITAL VIDEO RECORDER

VR-616
Thank you for purchasing this JVC product.
Before operating this unit, please read the
instructions carefully to ensure the best
possible performance.
INSTRUCTIONS
For Customer Use:
Enter below the serial No. which is
located on the bottom of cabinet. Retain
this information for future reference.
Model No:
VR-616
Serial No:
LLT0063-001A
