Need Help? Please call the JVC Customer Service
TOLL FREE CUSTOMER CARE HOTLINE: 1(800)252-5722
Remote control
Connection : Antenna or Wall jack (Cable TV)
Antenna or cable
Connect
the arial.
After connections,
Power On.
DR-MV99BU
DVD VIDEO RECORDER
Basic Operation
http://www.jvc.com
Included Accessories
"AAA" battery x 2
(For remote control)
DR-MV99BU
ANTENNA IN
(FROM ANT.)
ANTENNA OUT
(TO TV)
Connect your TV
Video cable
DVD/VCR
OUT
INPUT
Video
Audio (L)
Audio (R)
Go to " Initial Setup Wizard"
(INSTRUCTIONS
QUICK
START
GUIDE
RF cable
Audio cable
INSTRUCTIONS
pg. 14
AC Outlet
Connect with
your TV
TV
pg. 18)
LPT1151-002A
0307MNH-OT-OT
Advertisement
Related Manuals for JVC DVD VIDEO RECORDER DR-MV99BU
Summary of Contents for JVC DVD VIDEO RECORDER DR-MV99BU
-
Page 1: Included Accessories
DR-MV99BU DVD VIDEO RECORDER Basic Operation Need Help? Please call the JVC Customer Service TOLL FREE CUSTOMER CARE HOTLINE: 1(800)252-5722 http://www.jvc.com Included Accessories "AAA" battery x 2 (For remote control) Remote control Connection : Antenna or Wall jack (Cable TV) - Page 2 Connection: With Cable Box Or DBS Receiver ANTENNA IN (RF. IN) ANTENNA OUT (RF. OUT) INPUT Video Audio (L) Audio (R) ANTENNA IN (RF. IN) After connections, Power On. When STEP When STEP DR-MV99BU DVD/VCR Antenna or cable ANTENNA IN (RF.
-
Page 3: Initial Setup Wizard
Initial Setup Wizard STANDBY/ON DVD VIDEO RECORDER RM-SDR108U Press "STANDBY/ON" STANDBY/ON Select Language Press "ENTER" Select "Tuning Band" Press "ENTER" Set the "Date, Year and Time" Moves the cursor to the previous or next column. Changes the setting at the current cursor position. -
Page 4: Basic Playback
BASIC PLAYBACK Select "DVD" Start Playback Stop Playback Playable Discs: DVD-Video, DVD-R, DVD+R, DVD-RW, DVD+RW, CD-R, Video CD, Audio CD BASIC RECORDING Select "DVD or VCR" Select Input (AV1, AV2, DV IN or Ch) Channel Select Mode DVD: XP, SP, LP or EP VCR: SP or SLP Recordable Discs: DVD-R, DVD+R, DVD-RW, DVD+RW STANDBY/ON... -
Page 5: Timer Recording
TIMER RECORDING (Munual Timer Programming) Select "HOME" STANDBY/ON DVD VIDEO RECORDER RM-SDR108U Select "Timer Record" Press "ENTER" Select "NEW" and Press "ENTER" Enter the necessary information for you timer recording(s). Moves the cursor left/right. Changes the setting at the current cursor position. Press "ENTER"... -
Page 6: Dubbing From Vcr To Dvd
Dubbing from VCR to DVD You can copy the contents of a VHS tape to a DVD using the DUBBING button. This allows you to archive your old VHS tapes to DVD. Preparation : Set the resolution to 480i using the OUTPUT STATUS button before dubbing. Press VCR button to set the VCR mode.
