NETWORK CAMERA

SND-6084R/

User Manual

SNO-6084R/SNV-6084R

Advertisement

Table of Contents
loading

Related Manuals for Samsung SND-6084R

Summary of Contents for Samsung SND-6084R

  • Page 1: Network Camera

    NETWORK CAMERA SND-6084R/ User Manual SNO-6084R/SNV-6084R...
  • Page 2 Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.

  • Page 3: Important Safety Instructions

    overview important Safety inStructionS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.

  • Page 4: Explanation Of Graphical Symbols

    overview warninG TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT. Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
  • Page 5 class construction An apparatus with CLASS construction shall be connected to a MAINS socket outlet with a protective earthing connection. Battery Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. Disconnection Device Disconnect the main plug from the apparatus, if it’s defected.
  • Page 6 overview Please read the following recommended safety precautions carefully. y Do not place this apparatus on an uneven surface. y Do not install on a surface where it is exposed to direct sunlight, near heating equipment or heavy cold area. y Do not place this apparatus near conductive material.

  • Page 7: Table Of Contents

    Important Safety Instructions Product Features Recommended PC Specifications Recommended Micro SD/ SDHC/SDXC Memory Card Specifications NAS recommended specs What’s Included At a Glance (SND-6084R) At a Glance (SNO-6084R) At a Glance (SNV-6084R) iNSTALLATioN & Installation (SND-6084R) CoNNeCTioN Installation (SNO-6084R) Installation (SNV-6084R)

  • Page 8: Web Viewer

    overview web vieweR Connecting to the Camera Password setting Login Installing STW WebViewer Plugin Using the Live Screen Playing the recorded video SeTup SCReeN Setup Basic Setup Video & Audio setup Network Setup Event Setup NAS (Network Attached Storage) guide System Setup Viewing profile information AppeNDix...

  • Page 9: Product Features

    If the IR indicator turns on, the product switches to the IR mode for preventing an object from being too bright, which helps you identify the object in near distance. • visibility: 15m (SnD-6084r/Snv-6084r) In B/W mode, the IR indicator turns on with the effective visibility of 15m at 0 Lux.

  • Page 10: Recommended Pc Specifications

    overview • Smart codec Adaptively applies codecs for a portion of the camera’s field of view to improve the quality of such area specified by user. • auto Detection of Disconnected network Detects network disconnection before triggering an event. • onvif compliance This product supports ONVIF Profile-S.

  • Page 11: Recommended Micro Sd

    recommenDeD micro SD/SDHc/SDXc memory carD SpecificationS • Recommended capacity : 4GB ~ 64GB • For your camera, we recommend you use a memory card from the following manufacturers: Micro SD/SDHC/SDXC Memory Card : Sandisk, Transcend • For the framerate below 30 fps, it is recommended to use the specification memory card of Class 6 or higher.

  • Page 12: What's Included

    Please check if your camera and accessories are all included in the product package. Appearance Item Name Quantity Description Model Name SND-6084R or Camera SNO-6084R or SNV-6084R SND-6084R/ Instruction book, SNO-6084R/ Installer S/W CD SNV-6084R SND-6084R/ Quick Guide...
  • Page 13 SNO-6084R/ L Wrench the camera / Used to remove and SNV-6084R replace the dome cover Alarm Cable Useful for alarm connection SND-6084R Useful for installation on the Screw SND-6084R ceiling, wall, etc. Used for installation on the wall Tapping Screw...
  • Page 14 Used for assembling the dome case when installing the product Machine Screws SNV-6084R on the pipe, wall mount, etc. or blocking a hole. Options (not included) Housing for installing indoor SND-6084R/ Indoor Buried Housing buried type cameras SNV-6084R 14_ overview...

  • Page 15: At A Glance (Snd-6084R)

    GLance (SnD-6084r) appearance Item Description Dome cover Case cover used to protect the lens and the main unit. Camera Case Housing part that covers the camera body. English _15...
  • Page 16 overview components b cd k l m 16_ overview...
  • Page 17 Item Description Internal Cover It is a cover to protect the main body. Illumination Sensor Detects incoming light to control the IR LED. Lens Lens for the camera. IR LED These infrared LED’s are controlled by the illumination sensor. Zoom in (Tele) Zoom out (Wide) Zoom/Focus Control Focusing on a near object (Near)
  • Page 18 overview Item Description Micro SD Memory Compartment for the Micro SD memory card. Card Compartment Audio Out Jack Used to connect to speakers. Audio In Jack Used to connect to a microphone. Network Port Used to connect the PoE or Ethernet cable for network connection. Microphone hole A microphone is embedded.

  • Page 19: At A Glance (Sno-6084R)

    at a GLance (Sno-6084r) appearance Item Description Sunshield It protects the camera from the direct sunlight. Sunshield Hold It fixes the sunshield with the camera. The button restores all camera settings to the factory default. Press and hold for about 5 seconds to reboot the system. If you reset the camera, the network settings will be adjusted so that Reset Button DHCP can be enabled.
  • Page 20 overview Item Description Zoom in (Tele) Zoom out (Wide) Zoom/Focus Control Focusing on a near object (Near) Button Focusing on a far object (Far) Focus Control Press this button for automatic focus control. Output port for test monitoring the video output. Use the test monitor cable Test Monitor Out to connect to a mobile display and check the test video.
  • Page 21 components CAUTION: Be ware of the Rated Voltage and Polarity of the power connection. ARM-IN ARM-OUT Item Description Power Port Used to plug the power cable. Used to connect the alarm input sensor or external day/ ARM-IN night sensor. Alarm I/O Port Common port for alarm output signal.
  • Page 22 overview Item Description Audio Out Jack Used to connect to speakers. Audio In Jack Used to connect to a microphone. IR LED These infrared LED’s are controlled by the illumination sensor. Illumination Sensor Detects incoming light to control the IR LED. 22_ overview...

  • Page 23: At A Glance (Snv-6084R)

    at a GLance (Snv-6084r) appearance Item Description Dome cover Case cover used to protect the lens and the main unit. Camera Case Housing part that covers the camera body. English _23...
  • Page 24 overview components 24_ overview...
  • Page 25 Item Description Internal Cover It is a cover to protect the main body. Illumination Sensor Detects incoming light to control the IR LED. Lens Lens for the camera. IR LED These infrared LED’s are controlled by the illumination sensor. Power Port Port for power terminal block.

  • Page 26: Installation & Connection

    • Stuck-in or peeled-off cables can cause damage to the product or a fire. • For safety purposes, keep anyone else away from the installation site. And put aside personal belongings from the site, just in case. inStaLLation (SnD-6084r) Disassembling 1. Use one hand to hold the camera’s bottom part and turn the cover counterclockwise with another hand to separate it.
  • Page 27 installation 1. Attach the installation template to the selected area and punch 3 holes as shown in the figure. 2. Use the 2 supplied screws to fix the camera to the 2 punched holes. Set the <FRONT TOP> mark imprinted on the camera to face the direction of camera monitoring.

  • Page 28: Installation (Sno-6084R)

    installation & connection inStaLLation (Sno-6084r) This camera is waterproof and in compliance with the IP66 spec, but the jack connected to the external cable is not. You are recommended to install this product below the edge of eaves to prevent the cable from being externally exposed. installation 1.

  • Page 29: Installation (Snv-6084R)

    inStaLLation (Snv-6084r) This camera is waterproof and in compliance with the IP66 spec, but the jack connected to the external cable is not. You are recommended to install this product below the edge of eaves to prevent the cable from being externally exposed. Disassembling 1.
  • Page 30 installation & connection installation 1. Drill a hole (diameter : 6mm, depth : min 55mm) of the case bottom and insert the provided plastic anchor to the end. 2. Fit the bottom hole to the anchor hole and insert and fix the taping screw (M4.5xL50). 3.
  • Page 31 connecting waterproof power cable and Lan cable 1. Remove the dome cover and the case. 2. Pull out the long projected part of the rubber plug on the bottom and remove it as shown in the figure. Use an appropriate cable bush for the LAN cable to be connected.
  • Page 32 installation & connection 5. Insert the LAN cable into the large hole made by removing the projected part of the rubber plug in step 2 above. 6. Remove the sheath with a cable cutter, and align the cables. 7. Connect the LAN cable with a LAN connector, and insert it into the LAN tool.
  • Page 33 connecting alarm cable 1. Remove the dome cover and the case. 2. Pull out the rubber plug on the bottom as shown in the figure. 3. Insert the alarm cable into the hole made by removing the rubber plug in step 2, and connect the cable with the PCB alarm terminal.

  • Page 34: Outdoor Installation

    installation & connection attaching to the unbundled adapter Choose and purchase a necessary one of the following options (unbundled) that is suitable to the installation site or for your convenience. 1. Remove the dome cover from the case by referring to the “Disassembling”...

  • Page 35: Optional Accessories For Installation

    SBP-301HM3 : SNV-6084R) This adaptor is used when installing the dome camera onto a wall. 2. CEILING MOUNT ADAPTOR(SBP-300CM)/ HANGING MOUNT(SBP-301HM2 : SND-6084R, SBP-301HM3 : SNV-6084R) This adaptor is used when installing the dome camera on a concrete ceiling. English _35...
  • Page 36 installation & connection 3. POLE MOUNT ADAPTOR(SBP-300PM) This is an adaptor for WALL MOUNT ADAPTOR (SBP-300WM or SBP-300WM1) installation on a pole whose diameter is bigger than 80mm. 4. CORNER MOUNT ADAPTOR (SBP-300KM) This is an adaptor for WALL MOUNT ADAPTOR (SBP-300WM or SBP-300WM1) installation on the corner of wall joint.

  • Page 37: Snv-6084R)

    2. Set the horizontal angle so that the image is not reversed. In case of the SND-6084R model, rotate the lens with the cover on the rear of the lens unit. 3. Adjust the tilt angle so that the camera faces toward the monitoring object.
  • Page 38 & connection inSertinG/removinG a micro SD memory carD (SnD-6084r/Snv-6084r) Disconnect the power cable from the camera before inserting the Micro SD memory card. Do not insert the Micro SD memory card while it’s upside down by force. Otherwise, it may damage the Micro SD memory card.

  • Page 39: Removing A Micro Sd Memory Card

    Gently press down on the exposed end of the memory card as shown in the diagram to eject the memory card from the slot. <SND-6084R> <SNV-6084R> Pressing too hard on the Micro SD memory card can cause the card to shoot out uncontrollably from the slot when released.

  • Page 40: Memory Card Information

    installation & connection memory carD information (not incLuDeD) what is a memory card? The memory card is an external data storage device that has been developed to offer an entirely new way to record and share video, audio, and text data using digital devices. Selecting a memory card that’s suitable for you Your camera supports Micro SD/SDHC/SDXC memory cards.

  • Page 41: Connecting With Other Device

    Device Monitor to install Ethernet Power <SND-6084R> Power CAUTION: Be ware of the Rated Voltage and Polarity of the power connection. ARM-IN ARM-OUT Ethernet Monitor to install <SNO-6084R> English _41...
  • Page 42 installation & connection Monitor to install Ethernet Power <SNV-6084R> The CVBS out terminal of the product is provided for easier installation, and is not recommended for monitoring purposes. 42_ installation & connection...

  • Page 43: Ethernet Connection

    Connect the Ethernet cable to the local network or to the Internet. power Supply (SnD-6084r) Use the screwdriver to connect each line (+, –) of the power cable to the corresponding power port of the camera. If both PoE and DC 12V are applied simultaneously, the product will be supplied with power from PoE.

  • Page 44: Power Cable Specification For Each Model

    & connection power cable Specification for each model in case of Dc 12v input: Wire Type (AWG) SND-6084R Cable Length (Max.) SNO-6084R SNV-6084R in case of ac 24v input: Wire Type (AWG) SNO-6084R Cable Length (Max.) SNV-6084R network cable Specification...

  • Page 45: Connecting To Audio Input/Output

    connecting to audio input/output Speaker Microphone Network Speaker Amp Microphone Microphone CAUTION: Be ware of the Rated Voltage and Polarity of the power connection. ARM-IN Speaker ARM-OUT Microphone Microphone Speaker Speaker English _45...
  • Page 46 As a microphone is built in, you can use the built-in microphone instead of an external one. (It is applicable only to the SND-6084R model.) 2. Connect the AUDIO OUT port of the camera with the speaker or LINE IN port of the amplifier that the speaker is connected to.
  • Page 47 Connect the Alarm I/O cable to the corresponding port of the port box. Sensor Alarm (Warning lamp) <SND-6084R> CAUTION: Be ware of the Rated Voltage and Polarity of the power connection. ARM-IN ARM-OUT Sensor...
  • Page 48 installation & connection Sensor Alarm (Warning lamp) <SNV-6084R> • ALARM-IN : Used to connect the alarm input sensor or external day/night sensor. • ALARM-OUT : Used to connect the alarm output signal. • GND : Common port for alarm output signal If devices (e.g., flashing light and siren) that exceed the voltage and current specifications are connected by using the open collector method, it may cause malfunction.
  • Page 49 to connect the external sensor Connect one strand of each signal line (2-strand) of the sensors to the [aLarm in] port, and connect the other strand to the [GnD] port. alarm in wiring Diagram External Inside of the camera VCC_3.3V connection RESISTOR RESISTOR...

  • Page 50: Network Connection And Setup

    network connection and setup You can set up the network settings according to your network configurations. connectinG tHe camera DirectLy to LocaL area networKinG connecting to the camera from a local pc in the Lan 1. Launch an Internet browser on the local PC. 2.

  • Page 51: Connecting The Camera Directly To A Dhcp

    connectinG tHe camera DirectLy to a DHcp BaSeD DSL/caBLe moDem INTERNET DSL/Cable Modem Camera External Remote PC DDNS Server (Data Center, KOREA) 1. Connect the user PC directly with the network camera. 2. Run the IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet.

  • Page 52: Modem

    network connection and setup connectinG tHe camera DirectLy to a pppoe moDem INTERNET PPPoE Modem Camera External Remote PC DDNS Server (Data Center, KOREA) 1. Connect the user PC directly with the network camera. 2. Run the IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet.

  • Page 53: Connecting The Camera To A Broadband Router With The

    connectinG tHe camera to a BroaDBanD router witH tHe pppoe/caBLe moDem This is for a small network environment such as homes, SOHO and ordinary shops. Camera INTERNET PPPoE or PPPoE or Broadband Cable Modem Cable Modem Camera Router External Remote PC DDNS Server (Data Center, KOREA) Local PC...

  • Page 54: Buttons Used In Ip Installer

    network connection and setup ButtonS uSeD in ip inStaLLer e f g Item Description Model name of the connected camera. Device Name Click the column to sort the list by model name. However, search will be stopped if clicked during the search. Alias This function is not currently implemented.

  • Page 55: Static Ip Setup

    Exits the IP Installer program. For the IP installer, use only the installer version provided in the installation CD or use the latest one if available. You can download the latest version from the Samsung web site (www.samsungcctv.com). Static ip Setup manual network Setup Run <ip installer_v2.XX.exe>...
  • Page 56 network connection and setup 3. In the <address> pane, provide the necessary information. • MAC (Ethernet) Address : The MAC address imprinted on the camera label is automatically displayed and requires no user setting. IP related parameters can be set only when DHCP is not checked.
  • Page 57 if using a Broadband router • IP Address : Enter an address falling in the IP range provided by the Broadband Router. ex) 192.168.1.2~254, 192.168.0.2~254, 192.168.XXX.2~254 • Subnet Mask : The <Subnet mask> of the Broadband Router will be the <Subnet mask>...

  • Page 58: Auto Network Setup

    network connection and setup auto network Setup Run <ip installer_v2.XX.exe> to display the camera search list. At the initial startup, both [auto Set] and [manual Set] will be grayed out. For cameras found with the IPv6 setting, these buttons will be grayed out as the cameras do not support this function.

  • Page 59: Dynamic Ip Setup

    Dynamic ip Setup Dynamic ip environment Setup • Example of the Dynamic IP environment - If a Broadband Router, with cameras connected, is assigned an IP address by the DHCP server - If connecting the camera directly to modem using the DHCP protocols - If IPs are assigned by the internal DHCP server via the LAN checking the Dynamic ip 1.

  • Page 60: Port Range Forward (Port Mapping)

    network connection and setup port ranGe forwarD (port mappinG) Setup If you have installed a Broadband Router with a camera connected, you must set the port range forwarding on the Broadband Router so that a remote PC can access the camera in it. manual port range forwarding 1.
  • Page 61 Port forwarding can be done without additional router setup if the router supports the UPnP (Universal Plug and Play) function. After connecting the network camera, set <Quick connect> of <Samsung DDNS> to <On> in the “Setup  Network  DDNS” menu.

  • Page 62: Connecting To The Camera From A Shared Local Pc

    network connection and setup connectinG to tHe camera from a SHareD LocaL pc 1. Run the IP Installer. It will scan for connected cameras and display them as a list. 2. Double-click a camera to access. The Internet browser starts and connects to the camera.

  • Page 63: Connecting Web Viewer To Product

    web viewer connectinG to tHe camera normally, you would 1. Launch the Internet browser. 2. Type the IP address of the camera in the address bar. ex) • IP address (IPv4) : 192.168.1.100  http://192.168.1.100 - the Login dialog should appear. •...

  • Page 64: Web Viewer Connection Via Upnp/Bonjour

    To register your device to the <DDnS> server, visit www.samsungipolis.com and register your device first, and then set the Web Viewer’s <network> - <DDnS> to <Samsung DDnS>, as well as providing <product iD> that had been used for DDNS registration.

  • Page 65: Password Setting

    paSSworD SettinG When you access the product for the first time, you must register the login password. When the “password change” window appears, enter the new password. For a new password with 8 to 9 digits, you must use at least 3 of the following: uppercase/lowercase letters, numbers and special characters.
  • Page 66 web viewer inStaLLinG Stw webviewer pLuGin If connecting to a camera for the first time, you will see the installation message. Then, install the required WebViewer Plugin to access the camera and control the video from it in real time. 1.
  • Page 67 5. Click [oK]. The old version of Web Viewer Plug-in is deleted. 6. Click [install] to begin installation of the Web Viewer Plug-in. 7. Click [finish]. STW Web Viewer Plug-in installation is completed. In your internet explorer, if you need to move to the installation screen after installing the STW webviewer plugin, check whether webviewer_...

  • Page 68: Using The Live Screen

    web viewer uSinG tHe Live Screen Item Description Monitoring Move to the monitoring screen. Move to the screen where you can search for the video recording saved in your Micro Playback SD memory card or NAS. Setup Move to the Setup screen. Profile access You can read the profile information.
  • Page 69 Item Description Regardless of the resolution setup configured in the camera, it sets the resolution to Fix the resolution 640x480. Press it again to switch back to the default resolution. Full Screen Switch the current video to the maximum size of the monitor. Capture Saves the snapshot as an image file in the .jpg format.

  • Page 70: To Capture The Snapshot

    web viewer to capture the snapshot 1. Click [capture ( )] on the scene to capture. 2. When a captured video is saved, a notification message appears. When using Internet Explorer, the captured video is saved in My Computer / My Documents / Pictures.
  • Page 71 to use audio 1. Click [audio ( )] icon to activate audio communication. 2. Use [ ] bar to control the volume. If there is no sound from pulling in and out the audio jack while it is in operation, click the [Audio ( )] icon to enable it again.
  • Page 72 web viewer pLayinG tHe recorDeD viDeo Before you can play the video, you must configure the record settings. For details on record settings, refer to “Storage”. (page 114) name of event search screen and its function Item Description Set the search date and time range for data saved in your Micro SD memory Search range setting card or NAS.

  • Page 73: To Play The Content After Searching By Event

    to play the content after searching by event 1. Click the [playback ( )] button. 2. Specify the start time and end time of your search. 3. Select an event type for your search within the specified period. 4. Click the [event search] button. The search results will be displayed in the list.
  • Page 74 web viewer name of time search screen and its function Item Description Time bar The section in the specific period is played by moving the time bar. Set the search date using the calendar. Search date setting If there is data saved in your Micro SD memory card or NAS on the day, it is marked as a box on the calendar.

  • Page 75: To Play After Searching By Time

    Item Description Video information Time data of the replayed video is displayed on the screen. Set the desired date to make a backup copy of video data saved in your Backup Micro SD memory card or NAS. Can be set as up to 5 minutes. to play after searching by time 1.
  • Page 76 web viewer 6. Move [time bar ( )] to a desired time point of the video before playing it. The time containing a normal recoding file will be highlighted in blue; the time with the event recording will be highlighted in red. to back up the searched video 1.
  • Page 77 to play an avi file (1) micro SD memory card 1. Separate the Micro SD memory card from the camera. Before separating the Micro SD memory card, set the <Device> to <Off> in the “Setup  Event  Storage” menu. 2.
  • Page 78 web viewer (2) naS (network-attached Storage) 1. In Windows browser, use \\<ip address>\ to access. ex)\\192.168.20.31\defaultfolder\ch01\ img\2013_07_02\AVI 2. Go to <computer>  <network drive connection>  Enter 1. 3. Connected to the NAS. The directory structure is same as the directory structure for a Micro SD memory card.

  • Page 79: Basic Setup

    setup screen Setup On the network, you can set up basic information on the camera, video and audio, network events and system. 1. In the Live screen, click [ Setup ( ) ] . 2. The Setup screen appears. The setting page for preview video requires the STW web viewer plug-in to be installed on the PC. If not installed already, automatically moves to the Silverlight setup.
  • Page 80 setup screen 4. Select each profile properties. For more details, refer to “to add/change the video profile”. (Page 82) 5. Click the input box of each item and enter / select a desired value. The context menu may differ depending on the selected codec type. •...
  • Page 81 • ATC sensitivity : Affect the transfer rate according to the variance in the network bandwidth. The transfer rate will be adjusted to the fastest if the bandwidth is <very high>, and adjusted to the latest if the bandwidth is <very low>. •...

  • Page 82: To Add/Change The Video Profile

    setup screen to add/change the video profile The profile setup can be added or modified to accommodate various profiles depending on the recording conditions. 1. Select one from the <video profile> options. 2. Provide the name and select a codec. 3.
  • Page 83 • Encoding priority : You can set the priority of video transmission to frame rate or compression. • GOV length : It specifies the distance (in terms of number of frames) between two consecutive I-Frames in a video sequence when H.264 codec was selected. (One I-Frame + 0~Several P-Frames) •...
  • Page 84 setup screen to use crop encoding 1. Select <use>. 2. Click <Set area>. The Crop Encoding Area Setup window will pop up. 3. Select <ratio>. • Ratio: It sets up the aspect ratio of the user specified area. - 16:9 : The aspect ratio shall be set to 16:9 as close as to the user specified area.
  • Page 85 user 1. From the Setup menu, select the <Basic ( )> tab. 2. Click <user>. 3. Provide the necessary user information. • Administrator password change : Change the password for the administrator. For the security purposes, you are recommended to use a combination of numbers, alphabets uppercase and lowercase and special characters for your password.
  • Page 86 setup screen If the existing password is not matched, when you change the admin password, you cannot change the password. After changing your password, if there is a camera connected to a CMS or NVR client, then you need to re-register it with the newly changed password. If the camera is still connected with the same password, then the account may be locked because a client uses the previous password.

  • Page 87: Date & Time

    Date & time 1. From the Setup menu, select the <Basic ( )> tab. 2. Click <Date & time>. 3. Specify the time and date that will be applied to the camera. • Current system time : Displays the current time settings of your system. •...
  • Page 88 setup screen ip & port 1. From the Setup menu, select the <Basic ( )> tab. 2. Click <ip & port>. 3. Set the <ipv4 setup>. • IP type : Select an IP connection type. - Manual : Specify the IP address, Subnet mask, Gateway, DNS1, and DNS2.

  • Page 89: Event Setup

    • Use timeout : When connecting to RTSP, this function resets the connection if there’s no response for a certain time. • Device port : Set a port used to transfer video signals with the Samsung protocols. If changed the HTTP port, the browser exits.

  • Page 90: Video Setup

    setup screen viDeo & auDio Setup video setup 1. From the Setup menu, select the <video & audio ( )> tab. 2. Click <video setup>. 3. Select a <video source> mode. • Flip mode : Turn upside down the image that is captured by the camera.

  • Page 91: Audio Setup

    - Internal microphone : Microphone that is built-in in the camera. (It is applicable only to the SND-6084R model.) - External microphone : 3.5 pi(¢) jack type external MIC. • Apply power to Ext. Mic. : If the external microphone connected has no separate power supply, check this option to set camera to supply power to the connected external microphone.

  • Page 92: Camera Setup

    setup screen camera setup You can change the camera settings according to the environment where the camera is located. 1. From the Setup menu, select the <video & audio ( )> tab. 2. Click <camera setup>. 3. Configure the settings as necessary of : Image preset, Sensor, SSDR, White balance, Back light, Exposure, Day/ Night, Special, OSD, IR...
  • Page 93 • Reduced noise : Select this when you need a video with low noise in the low illumination environment. • Bright video : This makes the dark area in a full video brighter. Video contracts effects are reduced. • Motion focus&Reduced noise : Use this when there are many moving objects, such as on a road or in a crowded place like a museum, or when you need a video with low noise in a low illumination environment.
  • Page 94 setup screen initial setting for each image preset mode Minimum Maximum Image preset SSDR SSNR shutter shutter Definition focus (Default) When you change the Default (1/5) 1/12000 Default (High) Default (12) Default (12) profile Motion focus 1/30 1/12000 Default (High) Default (12) Reduced noise 1/15...
  • Page 95 If the sensor mode is set to 50 fps or 60 fps, the <Back light> mode cannot be set to <WDR>. to Set SSDr (Samsung Super Dynamic range) In a scene where the difference between bright and dark is severe, you can increase the brightness of the dark area alone to regulate the overall brightness.
  • Page 96 setup screen to Set white Balance You can correct the image colors based on white under any lighting conditions. 1. Select <white balance>. 2. Select <mode>. • ATW : Corrects the colors of the camera video automatically. • Manual : You can adjust the red and blue gains of the camera video manually. •...
  • Page 97 to Set BLc You can specify a desired area on the video manually and set the area to be displayed more clearly. 1. Select <Back light>. 2. Set <mode> to <BLc>. 3. Set <BLc level>. You can change the level to adjust the brightness of the monitoring area.
  • Page 98 setup screen to Set exposure You can adjust the exposure level of the camera. 1. Select <exposure>. 2. Select each item and set it properly. • Brightness : Adjust the screen brightness. • Minimum shutter : The limit of the longest exposure time.
  • Page 99 to Set Day/night 1. Select <Day/night>. 2. Select each item and set it properly. • Mode: Mode is used to adjust the color of Color or Black and White. - Color : The video is always output in color. - B/W : The video is always output in black and white.
  • Page 100 setup screen to Setup Special 1. Select <Special>. 2. Select each item and set it properly. • DIS : Compensates the image automatically when it is seen to shake for stable image output. • Sharpness mode : Adjust the overall sharpness of the image.
  • Page 101 to Set oSD 1. Select <oSD>. 2. Select each item and set it properly. • Camera title : It specifies the name of the camera to be displayed on the screen. • Camera title X, Y : It specifies the position of the camera name on the screen.
  • Page 102 setup screen Smart codec Set a desired area of the video incoming from the camera as ROI area and specify the detection sensitivity for the area. 1. From the Setup menu, select the <video & audio ( )> tab. 2. Click <Smart codec>. 3.

  • Page 103: Focus Setup

    focus setup You can adjust the focus and zoom ratio of video image. 1. From the Setup menu, select the <video & audio ( )> tab. 2. Click <focus setup>. 3. Set the focus and zoom. • Focus : Manually adjusts the lens focus (Far ...

  • Page 104: Network Setup

    - User name : Enter the user name for the DDNS service. - Password : Enter the password for the DDNS service. 5. When done, click [apply ( If selected <Quick connect>, be sure to select Samsung DDNS service. 104_ setup screen...

  • Page 105: Registering With Ddns

    DDnS to register your product with the Samsung DDnS 1. Visit the iPOLiS web site (www.samsungipolis.com) and sign in with a registered account. 2. From the top menu bar, select <DDnS Service> - <my DDnS>. 3. Click [proDuct reGiStration].
  • Page 106 Samsung DDnS in camera setup 1. From the DDNS setup page, set <DDnS> to <Samsung DDnS>. 2. Provide the <product iD> that you registered product ID with the DDNS site. 3. Click [apply (...
  • Page 107 ip filtering You can create a list of IPs that you want to grant or deny access to them. 1. From the Setup menu, select the <network ( )> tab. 2. Click <ip filtering>. 3. Select <filtering type>. • Deny : If selecting this, access from those IPs that are added to the filtering will be restricted.
  • Page 108 setup screen You can select a secure connection system or install the public certificate for this purpose. 1. From the Setup menu, select the <network ( )> tab. 2. Click <SSL>. 3. Select a secure connection system. To access the camera using HTTPS mode, you have to type the IP address for the camera in the form of “https://<Camera_IP>”.
  • Page 109 802.1x When connecting network, you can choose whether using 802.1x protocol, and then install the certification. 1. From the Setup menu, select the <network ( )> tab. 2. Click <802.1x>. 3. Set the <ieee 802.1x setting(eapoL using eap-tLS)>. • IEEE 802.1x : Specify the use of the 802.1x protocol.
  • Page 110 setup screen You can specify the priority to secure a stable transfer rate for a specific IP. 1. From the Setup menu, select the <network ( )> tab. 2. Click <QoS>. 3. Click the [add ( )] button. The IP list will be created. 4.
  • Page 111 • Enable SNMP Trap : SNMP trap is used to send important events and conditions to the Admin. - Community : Enter the trap community name to receive messages. - IP address : Enter the IP address to which messages will be sent. - Authentication failure : It specifies whether an event shall be generated when the community information is invalid.
  • Page 112 • UPnP discovery : It specifies Able or Disable for UPnP Discovery. • Friendly name : Display the camera name. Friendly name is displayed in the format of SAMSUNG-<Model Name>-<MAC Address>. In the Windows operating system which basically supports UPnP, the cameras connected to the network are displayed.
  • Page 113 event Setup ftp / e-mail You can configure the FTP/E-mail server settings so that you can transfer the images taken with camera to your PC if an event occurs. 1. From the Setup menu, select the <event ( )> tab. 2.
  • Page 114 setup screen • E-mail configuration - Server address : Enter the IP address of the email server that you transfer the alarm or event images to. - Use authentication : Select whether to use authorization. - Use SSL : Specify the use of SSL. - ID : Enter the user ID for logging into the email server.
  • Page 115 If you insert a Micro SD card saved in another saving file type (AVI/STW), you will need to format it before use. - STW : It is Samsung Techwin’s unique file format. - AVI : It is the conventional avi format.
  • Page 116 setup screen 4. Specify the <normal record setup>. • Always : Always save recorded video in the Micro SD memory card. If set to Always, the activation time cannot be changed. • Only scheduled time : Records only on the specified time of the specified day of week. •...
  • Page 117 Confirm that the NAS IP address and the camera IP address are in the same format. ex) The NAS & camera subnet mask initial value is 255.255.255.0. If the IP address is 192.168.20.32 then the NAS IP address should be in the range of 192.168.20.1~192.168.20.255.
  • Page 118 setup screen naS (network attached Storage) guide When you use the NAS, you might be unable to save data due to temporary network disconnections. If the setting allows a Micro SD memory card and the NAS to be simultaneously connected for use, the higher priority for recording goes to the NAS.
  • Page 119 3. Click the <Shared folder> in the file sharing and privilege menu. 4. Click the [create] button. 5. After entering the shared folder name(ID), click the [oK] button to create a shared folder. In this example, the shared folder name is [testDirectory].
  • Page 120 setup screen 8. After clicking the [create] button, enter name(ID) and password. In this example, name(ID) is set to [testiD] and password is also set to [testiD]. According to the NAS recommendations, when you use Netgear’s NAS equipment, do not allocate the capacity for use. 9.

  • Page 121: Alarm Output

    alarm output 1. From the Setup menu, select the <event ( )> tab. 2. Click <alarm output>. 3. Set the camera’s type of alarm output. If you change the alarm output type, the alarm out button on the monitoring page and alarm output type displayed on Event Setup page will be changed accordingly.

  • Page 122: Alarm Input

    setup screen alarm input You can set the alarm input type, activation time, and operation mode. 1. From the Setup menu, select the <event ( )> tab. 2. Click <alarm input>. 3. Set whether or not to <enable>. 4. Select the type. •...
  • Page 123 6. Specify an operation that will perform if an alarm occurs. • FTP : Specify the use of FTP transfer in the alarm input setup. Refer to “FTP / E-mail” for more details. (page 113) • E-mail : Specify the use of email transfer in the alarm input setup. Refer to “FTP / E-mail”...

  • Page 124: Time Schedule

    setup screen time schedule You can set to save the video data at a certain interval as scheduled regardless of the actual occurrence of the event. 1. From the Setup menu, select the <event ( )> tab. 2. Click <time schedule>. 3.

  • Page 125: Tampering Detection

    tampering detection You can set to detect tampering attempts and trigger events, such as sudden change of camera’s framing direction, blocked lens and other overall change of scenes from the video. 1. From the Setup menu, select the <event ( )>...
  • Page 126 setup screen mD / va Events of motion detection and video analysis can be set to trigger event signal output. 1. From the Setup menu, select the <event ( )> tab. 2. Click <mD / va>. 3. Set whether or not to <enable>. 4.
  • Page 127 Before using, set the minimum and maximum motion sizes to suit desired motion range to be detected. Detected size of an object may have difference with the actual size according to its shape. Up to 16 objects from the top side of the screen can be displayed. If camera is capturing a close object, the video analysis capability may degrade.

  • Page 128: To Use Motion Detection

    setup screen to use motion detection It detects a motion that meets all conditions specified by sensitivity, size and area. 1. Select a motion detection mode. 2. Select <Sensitivity> tab to set the sensitivity level. You can set the sensor’s sensitivity to detect a motion out of the background from the monitoring video.
  • Page 129 4. Select <area> tab. You can specify an area on the screen to include or exclude the area to/from detection. You can specify up to 4 areas. • Detection area : Sets the entire screen as excluded from detection, and adds specified area as motion detection area.
  • Page 130 setup screen to use video analytics It detects event that meets all conditions specified by sensitivity, size and area and the event condition rules. 1. Select the video analysis mode. 2. Set <Sensitivity>, <Size> and <area>. For further details on settings, refer to “to use motion detection”.
  • Page 131 to set the video analysis rules ` passing 1. Set the type to <passing>. 2. On the screen, click on preferred starting and ending point of the virtual line, then a popup window appears. 3. Select the desired rule: • Right: Detects motions of moving from the left to the right, over the virtual line.
  • Page 132 setup screen ` appearing (Disappearing) 1. Set the analysis type to <appearing (Disappearing)>. 2. Select the desired event rule: • Defined area based rules : It detects event of appearing object that appears in the area and remaining for a certain time period while not passing through the area borders, and opposite case of disappearing of objects existed in the area.

  • Page 133: Face Detection

    face detection You can set to detect recognized face and trigger an event accordingly. 1. From the Setup menu, select the <event ( )> tab. 2. Click <face detection>. 3. Set whether or not to <enable>. 4. Select <Sensitivity> tab to set the sensitivity level.

  • Page 134: Audio Detection

    setup screen audio detection You can set to detect sound over the specified level and trigger an event accordingly. 1. From the Setup menu, select the <event ( )> tab. 2. Click <audio detection>. 3. Set whether or not to <enable> . 4.
  • Page 135 network disconnection When the network is physically disconnected, it is considered as an event to be saved. 1. From the Setup menu, select the <event ( )> tab. 2. Click <network disconnection>. 3. Set whether or not to <enable> . 4.

  • Page 136: System Setup

    setup screen SyStem Setup product information 1. From the Setup menu, select the <System ( )> tab. 2. Click <product information>. 3. Check the camera information, or provide details according to your network environment. • Model : Model name of the product. •...
  • Page 137 upgrade / reboot 1. From the Setup menu, select the <System ( )> tab. 2. Click <upgrade / reboot>. 3. Select a desired item and set it appropriately. • Upgrade : Performs upgrading the system. • Factory default : Resets the system to the factory default.
  • Page 138 If you forcibly terminate the upgrade process, upgrade will not be completed properly. During restarting the system, accessing with web viewer will not be made. You can download the latest version from the Samsung web site (www.samsungcctv.com). 138_ setup screen...
  • Page 139 to back up the current settings 1. Click [Backup]. The Save As dialog should appear. 2. Specify the backup path with a proper file name, and click [Save]. The backup file will be saved to the specified path in the format of “.bin”. to restore the backup settings 1.
  • Page 140 setup screen You can check the system log or event log. 1. From the Setup menu, select the <System ( )> tab. 2. Click <Log>. 3. Select a log type. • System : You can check the system logs where any system changes are recorded including the time information.
  • Page 141 open SDK A user can install an application on their camera to execute additional functions. 1. From the Setup menu, select the <System ( )> tab. 2. Click <open SDK>. 3. Click the [Browse ( button to select the *.cap file from the user folder.
  • Page 142 setup screen viewinG profiLe information profile access You can check the profile information. 1. Click [Status ( )] on the live screen. 2. The profile information screen is displayed. • Profile access : Show the information of the newly added profile. - Profile : Show the information of the newly added codec.
  • Page 143 Specification Description Items SND-6084R SNO-6084R SNV-6084R Imaging Device 1/2.8” PS Exmor 2.38M CMOS (IMX136) Total Pixels 1952(H) x 1116(V) Effective Pixels 1944(H) x 1104(V) Scanning System Progressive Video Color : 0.1 Lux (1/30sec, F1.2, 50IRE), 0.0017Lux (2sec, F1.2, 50IRE) Min.
  • Page 144 Auto (ICR) / Color / B/W / External / Schedule Backlight Off / BLC Compensation Wide Dynamic Range 100dB Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On) Digital Noise SSNRIII (2D+3D Noise Filter) (Off / On) Reduction Defog...
  • Page 145 Description Items SND-6084R SNO-6084R SNV-6084R Selectable (Mic IN/Line IN), Max output level: 1 Vrms Audio In Supply voltage: 2.5VDC(4mA), Input impedance: approx. 2K Ohm Audio out Line out (3.5mm stereo mini jack) Motion detection, Tampering, Audio Detection, Face Detection, Video...
  • Page 146 Description Items SND-6084R SNO-6084R SNV-6084R IPv4, IPv6 TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, Protocol SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour HTTPS(SSL) Login Authentication Digest Login Authentication Security...
  • Page 147 Description Items SND-6084R SNO-6084R SNV-6084R AC24V : -50°C ~ +55°C AC24V : -40°C ~ +55°C (-58°F ~ +131°F) / Less (-40°F ~ +131°F) / Less -10°C ~ +55°C than 90% RH than 90% RH Operating Temperature (+14°F ~ +131°F) / DC12V, PoE (IEEE 802.3af) :...

  • Page 148: Product Overview

    SnD-6084r Unit : mm (inch) Ø 132.1 (5.2") Ø 97 (3.82") 148_ appendix...
  • Page 149 Sno-6084r Unit : mm (inch) 333.2 (13.12") 200 (7.87") 178 (7.01") 134.6 (5.30") 321.6 (12.31") Ø 82 (3.23") (BoDy) 3- Ø 5.5 HoLeS Ø 70 (2.76") 82.2 90.4 (3.56") English _149...
  • Page 150 appendix Snv-6084r Unit : mm (inch) Ø 160 (6.3") Ø 100 (3.94") 150_ appendix...

  • Page 151: Troubleshooting

    trouBLeSHootinG PROBLEM SOLUTION y Check to make sure that the camera’s Network settings are appropriate. y Check to make sure that all network cables have been connected properly. I can’t access the camera from a y If connected using DHCP, verify that the camera is able to acquire web browser.
  • Page 152 appendix PROBLEM SOLUTION Can I define event rules even y Yes, it can be. You can set rules for events despite of the intelligent when I don’t use <MD / VA>? video analysis setting. No signal is found at the Alarm Output port even when an y Check alarm output port settings.
  • Page 153 Corresponding Source code from us for a period of three years after our last shipment of this product by sending email to help.cctv@samsung.com If you want to obtain the complete Corresponding Source code in the physical medium such as CD-ROM, the cost of physically performing source distribution might be charged.
  • Page 154 Gnu GeneraL puBLic LicenSe The “Program”, below, refers to any such program or work, and a “work based on the Program” means either Version 2, June 1991 the Program or any derivative work under copyright law : that is to say, a work containing the Program or a portion Copyright (C)1989, 1991 Free Software Foundation, Inc.
  • Page 155 3. You may copy and distribute the Program (or a work 7. If, as a consequence of a court judgment or allegation of based on it, under Section 2)in object code or executable patent infringement or for any other reason (not limited to form under the terms of Sections 1 and 2 above provided patent issues), conditions are imposed on you (whether that you also do one of the following :...

  • Page 156: Gnu General Public License

    no warranty You should also get your employer (if you work as a programmer)or your school, if any, to sign a “copyright 11. BECAUSE THE PROGRAM IS LICENSED FREE OF disclaimer” for the program,if necessary. Here is a sample ; CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, alter the names: TO THE EXTENT PERMITTED BY APPLICABLE LAW.
  • Page 157 Finally, every program is threatened constantly by software The “Corresponding Source” for a work in object code form patents. States should not allow patents to restrict means all the source code needed to generate, install, and development and use of software on general-purpose (for an executable work) run the object code and to modify omputers, but in those that do, we wish to avoid the special the work, including scripts to control those activities.
  • Page 158 5. conveying modified Source versions. d) Convey the object code by offering access from a designated place (gratis or for a charge), and offer You may convey a work based on the Program, or the equivalent access to the Corresponding Source in modifications to produce it from the Program, in the form of the same way through the same place at no further source code under the terms of section 4, provided that you...
  • Page 159 7. additional terms. However, if you cease all violation of this License, then your license from a particular copyright holder is reinstated (a) “Additional permissions” are terms that supplement the provisionally, unless and until the copyright holder explicitly terms of this License by making exceptions from one or more and finally terminates your license, and (b) permanently, if of its conditions.
  • Page 160 14. revised versions of this License. In the following three paragraphs, a “patent license” is any express agreement or commitment, however denominated, The Free Software Foundation may publish revised and/ not to enforce a patent (such as an express permission or new versions of the GNU General Public License from to practice a patent or covenant not to sue for patent time to time.
  • Page 161 openSSL combined License The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and the original SSLeay license apply to the toolkit. See below for the actual license texts. Actually both licenses are BSD-style Open Source licenses. In case of any license issues related to OpenSSL please contact openssl-core@openssl.org.
  • Page 162 SNMP v3 using both IPv4 and IPv6. For more additional This product includes software developed by the information, send email to help.cctv@samsung.com. Computer Science Department at University College Copyright (C) 2004, Kneschke, incremental London.
  • Page 163 3. Neither the name of the Regents of the University of 3. Neither the name of Thomas BERNARD nor the names California nor the names of its contributors may be used of its contributors may be used to endorse or promote to endorse or promote products derived from this software products derived from this software without specific prior without specific prior written permission.
  • Page 164 THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR MERCHANTABILITY AND FITNESS FOR A PARTICULAR...
  • Page 165 THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT THIS SOFTWARE IS PROVIDED BY APPLE AND ITS HOLDERS AND CONTRIBUTORS “AS IS” AND ANY CONTRIBUTORS “AS IS” AND ANY EXPRESS OR EXPRESS OR IMPLIED WARRANTIES, INCLUDING, IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY MERCHANTABILITY AND FITNESS FOR A PARTICULAR...
  • Page 166 Copyright (c) 2006 Free Software Foundation, Inc. mozilla public License Since we, at Samsung Techwin, used the Mozilla Firefox component without modifying the source code according to the MOZILLA Public license 1.1, we are not obliged to provide the source code of the corresponding component.
  • Page 167 1.11. "Source Code" means the preferred form of the Covered (d) Notwithstanding Section 2.2(b) above, no patent license is Code for making modifications to it, including all modules it granted: 1) for any code that Contributor has deleted from contains, plus any associated interface definition files, scripts the Contributor Version;...

  • Page 168: Disclaimer Of Warranty

    3.5. Required Notices. You must duplicate the notice in Exhibit 6.2. Effect of New Versions. Once Covered Code has been A in each file of the Source Code. If it is not possible to put such published under a particular version of the License, You may notice in a particular Source Code file due to its structure, then always continue to use it under the terms of that version.

  • Page 169: Limitation Of Liability

    8.3. If You assert a patent infringement claim against Participant 13. muLtipLe-LicenSeD coDe. alleging that such Participant’s Contributor Version directly or Initial Developer may designate portions of the Covered Code indirectly infringes any patent where such claim is resolved as Multiple-Licensed. Multiple-Licensedmeans that the Initial (such as by license or settlement) prior to the initiation of patent Developer permits you to utilize portions of the Covered Code infringement litigation, then the reasonable value of the licenses...
  • Page 170 the independent JpeG Group’s JpeG Software The software included in this product contains copyrighted software that is licensed under the JPEG license. • JPEG license - Code project . Generating Outline OpenGL, Libjpeg This distribution contains the sixth public release of the Permission is NOT granted for the use of any IJG author’s Independent JPEG Group’s free JPEG software.
  • Page 171 t-Kernel License - This Product uses the Source Code of T-Kernel under T-License granted by the T-Engine Forum(www.t-engine.org) t-License [License agreement for Source code of t-Kernel] established by T-Engine Forum on January 23, 2004 revised on June 17, 2004 revised on December 21, 2006 revised on March 24, 2009 article 1.
  • Page 172 article 4. License of Source code 4. The Distributor of Modification shall determine the name of the Modified Source Code subject to the rules separately 1. As provided for in this Article, T-Engine Forum shall established by T-Engine Forum and publish an appropriate notice as required by the rules on the Patch for Modification provide, and grant a license to use, the Source Code free and the Modified Source Code.
  • Page 173 article 9. indemnity distribute the Ported Source Code as the Source Code for T-Kernel. Provided, however, that the Ported Source Code 1. Neither T-Engine Forum nor the copyright holder of the may be treated in the same way as the Modified Source Code until the time of registration hereunder.

  • Page 174: End Of Terms And Conditions

    5. Submission of Contributions. Unless You explicitly state any form of electronic, verbal, or written communication sent to the Licensor or its representatives, including but otherwise, any Contribution intentionally submitted for not limited to communication on electronic mailing lists, inclusion in the Work by You to the Licensor shall be under source code control systems, and issue tracking systems the terms and conditions of this License, without any that are managed by, or on behalf of, the Licensor for...
  • Page 175 BZip2 License This program, "bzip2", the associated library "libbzip2", and all documentation, are copyright (C) 1996-2007 Julian R Seward. All rights reserved. component name License bzip2-1.0.5 Bzip2 http://www.bzip.org/ Redistribution and use in source and binary forms, with THIS SOFTWARE IS PROVIDED BY THE AUTHOR ``AS or without modification, are permitted provided that the IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, following conditions are met:...
  • Page 176 pHp 3.01 License The PHP License, version 3.01 Copyright (c) 1999 - 2010 The PHP Group. All rights reserved. component name License php-5.2.17 PHP 3.01 http://www.php.net/distributions 6. Redistributions of any form whatsoever must retain the Redistribution and use in source and binary forms, with or without modification, is permitted provided that the following following acknowledgment: "This product includes PHP conditions are met:...
  • Page 177 Samsung Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products.
  • Page 178 SALES NETWORK SAMSUNG TECHWIN CO., LTD. Samsung Techwin R&D Center, 6, Pangyo-ro 319beon-gil, Bundang-gu, Songnam-si, Gyeonggi-do 463-400, Korea TEL : +82-70-7147-8740~60 FAX : +82-31-8018-3745 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660...

This manual is also suitable for:

Sno-6084rSnv-6084r

Table of Contents
