- Page 1 Moov V Series Hardware Manual...
-
Page 2: Important Safety Information
On main roads, the distance to an exit calculated by your Mio may be further than the distance shown on road signs. Road signs show the distance to the start of an exit while your Mio shows the distance to the next intersection, i.e., the end of the exit ramp or road. To prepare to exit a road, always follow distance information on road signs. -
Page 3: Home Charger-Specific Safety Information
Home charger-specific safety information To charge your Mio from the mains power, use the home charger supplied by Mio as an accessory (may be sold separately). Using other home chargers with your Mio could result in serious injury or property damage. -
Page 4: Table Of Contents
Getting to know your Mio ........................11 V500 Series ............................11 V700 Series ............................12 How do I turn on my Mio? ........................13 Using the power switch ........................13 How do I charge the battery? .......................14 How do I charge the battery in a vehicle? ..................14 How do I charge the battery via my computer? (V500 Series only) ..........14... -
Page 5: Welcome
Welcome Thank you for purchasing this Mio. Please read this manual carefully before using your Mio for the first time. Keep this manual in a safe place and use as your first point of reference. Important information for using the manual It is important to understand the terms and typographical conventions used in this manual. -
Page 6: Mounting Your Mio In A Vehicle
If the windscreen is tinted with a reflective coating, it may be athermic and impact the GPS reception. In this instance, please mount your Mio where there is a “clear area” - usually just beneath the rear-view mirror. To protect your Mio against sudden surges in current, connect the in-car charger only after the car engine has been started. -
Page 7: V700 Series
V700 Series... -
Page 8: Mounting On The Dashboard
Mounting on the dashboard V700 Series If you transfer the suction cup between vehicles, the adhesion could be reduced. To restore adhesion, please clean with water. -
Page 9: Installing The External Antenna
Installing the external antenna An external antenna may be supplied with your Mio for better signal reception. Connect the external antenna to the connector for external antenna on your Mio, then attach the antenna to the windshield (as shown in the diagram). -
Page 10: Installing The Optional Digital Tv Card
Installing the optional digital TV card Open the TV card compartment cover as shown below. Insert the digital TV card into the socket ( ), and then press down to lock the card into place ( If you need to remove the digital TV card, press the locking clips ( ) to release the card and then remove it Replace the compartment cover. -
Page 11: Getting To Know Your Mio
Getting to know your Mio V500 Series Power switch Connector for in-car charger, USB cable, home charger (sold separately) and TMC accessory kit (may be sold separately) Antenna Slot for microSD™ memory card Slot for digital TV card (may be sold... -
Page 12: V700 Series
V700 Series Power switch Microphone Antenna Battery indicator Slot for digital TV card (may be sold Main Menu button separately) Speaker Connector for in-car charger and home charger (sold separately) Cradle slot Connector for headphones and TMC accessory kit (may be sold separately) Connector for external antenna Slot for microSD™... -
Page 13: How Do I Turn On My Mio
To turn on your Mio, slide the power switch to the ON position. To turn off your Mio, slide the power switch to the OFF position, then tap Sleep. Your Mio will enter a suspended state. When you next turn it on, your Mio will return to the last screen that you used. -
Page 14: How Do I Charge The Battery
How do I charge the battery? Your Mio has an internal battery that when fully charged, should provide power for up to 2 hours. The battery can take up to 4 hours to fully charge. The battery may not be fully charged when you use your Mio for the first time. -
Page 15: How Do I Insert A Memory Card
V700 Series Hold the microSD™ card by the edges and gently insert it into the slot as shown in the above diagrams of your Mio. To remove a card, gently push the top edge of the card inwards to release it, then pull it out of the slot. -
Page 16: How Do I Use The Remote Control
How do I use the remote control? Installing the battery for the remote control Remove the plastic film from the remote control. Insert a small rod, such as a straightened paperclip, into the eject hole and push firmly ( ) and pull out the battery holder ( Place the battery in the battery holder. - Page 17 Name Description Switches to the previous or next channel. ／ RETURN Returns to the previous channel. Mute button Mutes or unmutes the sound. ENTER Press to confirm channel number choice. Adjusts the volume. ／ Main Menu Returns to the Main Manu. button...
-
Page 18: Other Features
Media playback is not available on all models and is only available in selected countries. Using Media you can play music or video files that you have downloaded to your Mio or from your microSD™ card. WARNING: The TV and video player features MUST NOT be used when driving. Using the features may cause an accident. -
Page 19: Reference
Your Mio receives GPS signals via the internal GPS antenna. To guarantee the optimum GPS signal strength, ensure your Mio is outdoors, or in a vehicle outdoors, and has an unobstructed view of the sky. GPS reception is not usually affected by weather, however, very heavy rain or snow may have a negative effect on your reception. -
Page 20: Troubleshooting
(sold separately) or USB cable, then try again. Screen responds slowly. The remaining battery power may be too low to operate your Mio. If the problem still persists, reset your Mio. Screen freezes. -
Page 21: For More Information
Register your Mio with MioClub If you have a faulty product or you would like to speak to a member of our Technical Support team, register your Mio on MioClub to obtain the Technical Support phone numbers for your region. -
Page 22: Copyright
CE Marking. Declaration of conformity Hereby, Mio Technology declares that this N236/N248 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The FM transmitter function is not allowed to use in Cyprus, France and Greece. Please turn off the function in those areas. (For models...
