2-52

VTX Table Installation

The 2014 VTX comes equipped with the side-mounted table. To install:
1. Remove the table top from the transom storage and
the table support pole from under the port-side
pull-up cushion.
2. Slide the base of the pole into the mounted receiver.
3. Place the table receiver onto the top of the pole.
Reverse the process to stow the table away.
TABLE TOP
Figure 2-35. Table Top and Table
Support Pole
MOUNTED
RECEIVER
Figure 2-36. Mounted Receiver
TABLE
RECEIVER
Figure 2-37. Table Receiver
TABLE
SUPPORT
POLE
