Speed Control System

Throttle Stop Speed Control System

The speed control system has
two options for limiting speed.
Adjusting the speed limit screw
allows you to control vehicle
speed between 0 and 30 MPH
(48 km/h). This adjustment con-
trols how far the throttle opens.
To remove the speed limiting
entirely and allow operation up
to the maximum vehicle speed
of 38 MPH (61 km/h), the speed
limit bracket can be removed.
1. To adjust the speed limit
screw, loosen the jam nut.
2. Turn the screw inward to
reduce the speed. Turn the
screw outward to increase
speed up to the 30 MPH (48
km/h) maximum. The throt-
tle lever will stop against
the speed control bracket at
the maximum setting.
3. Tighten the jam nut after
adjusting.
4. To allow the vehicle to
operate to the maximum of
38 MPH (61 km/h), remove
the bracket fastener on the
throttle assembly and
remove the bracket.
ADJUSTMENTS
Bottom Views of
Throttle Assembly
Adjusted Below
Maximum
Limiting Screw
Adjusted at
Maximum
Bracket Fastener
Bracket
Removed
Jam Nut
91
