JVC KD-S901R Instructions Manual

Jvc cd-receiver instructions
Hide thumbs Also See for KD-S901R:
Table of Contents

Advertisement

Quick Links

CD RECEIVER
CD-RECEIVER
RECEPTEUR CD
CD-RECEIVER
KD-SC800R/KD-S901R
COMPACT
DIGITAL AUDIO
For installation and connections, refer to the separate manual.
Für den Einbau und die Anschlüsse siehe das eigenständige Handbuch.
Pour l'installation et les raccordements, se référer au manuel séparé.
Bijzonderheden over de installatie en aansluiting van het apparaat vindt u in de
desbetreffende handleiding.
KD-SC800R
KD-S901R
INSTRUCTIONS
BEDIENUNGSANLEITUNG
MANUEL D'INSTRUCTIONS
GEBRUIKSAANWIJZING
GET0146-001A
[E/EX]

Advertisement

Table of Contents
loading

Related Manuals for JVC KD-S901R

Summary of Contents for JVC KD-S901R

  • Page 1 CD RECEIVER CD-RECEIVER RECEPTEUR CD CD-RECEIVER KD-SC800R/KD-S901R COMPACT DIGITAL AUDIO For installation and connections, refer to the separate manual. Für den Einbau und die Anschlüsse siehe das eigenständige Handbuch. Pour l’installation et les raccordements, se référer au manuel séparé. Bijzonderheden over de installatie en aansluiting van het apparaat vindt u in de desbetreffende handleiding.

  • Page 2: How To Reset Your Unit

    3.CAUTION: Do not open the top cover. There are no user-serviceable parts inside. Leave all servicing to qualified service personnel. 4.CAUTION: This CD player uses invisible laser radiation and is equipped with safety switches to prevent radiation emission when unloading CDs. It is dangerous to defeat the safety switches.

  • Page 3: Table Of Contents

    Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS How to reset your unit ... How to use the M (MODE) button ...

  • Page 4: Location Of The Buttons

    LOCATION OF THE BUTTONS Control panel Display window 1 Remote sensor 2 Control dial (standby/on/attenuator) button 4 SEL (select) button 5 Screws—M2 × 5 mm (only for KD-SC800R) 6 Plate cover and standard plate (only for KD-SC800R) 7 FM/AM button 8 5 (up) button +10 button 9 0 (eject) button...

  • Page 5: Basic Operations

    Turning on the power Turn on the power. Note on One-Touch Operation: When you select a source in step 2 below, the power automatically comes on. You do not have to press this button to turn on the power. Select the source. To operate the tuner (FM or AM), see pages 7 –...

  • Page 6: Setting The Clock

    Setting the clock You can also set the clock system to either 24 hours or 12 hours. Press and hold SEL (select) for more than 2 seconds so that one of the PSM items appears on the display. (PSM: see page 23.) Set the hour.

  • Page 7: Radio Operations

    Listening to the radio You can use either automatic searching or manual searching to tune in to a particular station. Searching a station automatically: Auto search Select the band (FM1 – 3, AM). Each time you press the button, the band changes as follows: Selected band appears.

  • Page 8: Storing Stations In Memory

    Tune in to a station you want while “M” (manual) is flashing. To tune in to stations of higher frequencies To tune in to stations of lower frequencies • If you release your finger from the button, the manual mode will automatically turns off after 5 seconds.

  • Page 9: Tuning In To A Preset Station

    Manual preset You can preset up to 6 stations in each band (FM1, FM2, FM3, and AM) manually. Ex.: Storing FM station of 88.3 MHz into the preset number 1 of the FM1 band. Select the band (FM1 – 3, AM) you want to store stations into (in this example, FM1).

  • Page 10: Rds Operations

    RDS OPERATIONS What you can do with RDS RDS (Radio Data System) allows FM stations to send an additional signal along with their regular programme signals. For example, the stations send their station names, as well as information about what type of programme they broadcast, such as sports or music, etc.
  • Page 11 Press and hold SEL (select) for more than 2 seconds so that one of the PSM items appears on the display. (PSM: see page 23.) Select “AF-REG” (alternative frequency/regionalization reception) if not shown on the display. Select the desired mode—“AF,” “AF REG,”...
  • Page 12 Using PTY Standby Reception PTY Standby Reception allows the unit to switch temporarily to your favorite programme (PTY: Programme Type) from the current source (another FM station or CD). • PTY Standby Reception will not work if you are listening to an AM station. You can select your favorite programme type for PTY Standby Reception.
  • Page 13 Searching your favorite programme You can search any one of the PTY codes. In addition, you can store your 6 favorite programme types in the number buttons. When shipped from the factory, the following 6 programme types have been stored in the number buttons (1 to 6).

  • Page 14: Other Convenient Rds Functions And Adjustments

    To search your favorite programme type Press and hold T (TP/PTY) for more than 2 seconds while listening to an FM station. The last selected PTY code appears. To select one of your favorite programme type To select any one of the twenty-nine PTY codes Ex.: When “ROCK M”...

  • Page 15: Automatic Clock Adjustment

    Changing the display mode while listening to an FM station You can change the initial indication on the display to station name (PS NAME), station frequency (FREQ), or clock time (CLOCK) while listening to an FM RDS station. • See also “Changing the general settings (PSM)”...
  • Page 16 PTY codes NEWS: News AFFAIRS: Topical programmes expanding on current news or affairs INFO: Programmes which impart advice on a wide variety of topics SPORT: Sport events EDUCATE: Educational programmes DRAMA: Radio plays CULTURE: Programmes on national or regional culture SCIENCE: Programmes on natural science and technology...

  • Page 17: Cd Operations

    Playing a CD Open the control panel. Note on One-Touch Operation: When a CD is already in the loading slot, pressing CD turns on the unit and starts playback automatically. Insert a CD into the loading slot. The unit turns on, draws the CD and starts playback automatically.

  • Page 18: Locating A Track Or A Particular Portion On A Cd

    To stop play and eject the CD Press 0. CD play stops and the control panel flips down. The CD automatically ejects from the loading slot. The source changes to the tuner (you will hear the last received station). • If you change the source, the CD play also stops (without ejecting the CD).

  • Page 19: Selecting Cd Playback Modes

    How to use the +10 and –10 buttons • Ex. 1: To select track number 32 while playing track number 6 (Three times) \ 10 \ 20 \ 30 Track 6 • Ex. 2: To select track number 8 while playing track number 36 (Three times) \ 30 \ 20 \ 10...

  • Page 20: Sound Adjustments

    SOUND ADJUSTMENTS Selecting preset sound modes (C-EQ: custom equalizer) You can select a preset sound mode (C-EQ: custom equalizer) suitable to the music genre. • There is a time limit in doing the following procedure. If the setting is canceled before you finish, start from step 1 again.

  • Page 21: Adjusting The Sound

    Adjusting the sound You can adjust the sound characteristics to your preference. Select the item you want to adjust. Each time you press the button, the adjustable items change as follows: (bass) (treble) LOUD (volume) (loudness) Indication To do: BAS* Adjust the bass.

  • Page 22: Other Main Functions

    OTHER MAIN FUNCTIONS Changing the general settings (PSM) You can change the items listed on the next page by using the PSM (Preferred Setting Mode) control. Basic Procedure Press and hold SEL (select) for more than 2 seconds so that one of the PSM items appears on the display.
  • Page 23 Preferred Setting Mode (PSM) items • For detailed operations of each PSM items, refer to the pages listed in the table. Indications CLOCK H Hour adjustment CLOCK M Minute adjustment 24H/12H 24/12-hour time display AUTO ADJ Automatic clock setting DISPMODE Display mode AF-REG Alternative frequency/...

  • Page 24: Selecting The Display Color (Only For Kd-Sc800R)

    You can change the standard plate with another plate supplied with your unit. You can also download them by visiting <http://www.jvc.co.jp/jvccar>. • When changing the plate, be careful not to leave your fingerprints on the plate or cover. Loosen the screws with the supplied hex screwdriver.
  • Page 25 Replace with another plate (a standard, cutout, or downloaded plate) of your preference. • When attaching a standard plate Standard plate • When attaching a cutout or downloaded plate Add the transparent plate (supplied) between the cutout or downloaded plate and the plate cover in order to attach the plate cover in place.

  • Page 26: Detaching The Control Panel

    Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. Detaching the control panel Before detaching the control panel, be sure to turn off the power.

  • Page 27: Using The Remote Controller

    USING THE REMOTE CONTROLLER This unit can be remotely controlled as instructed here (with an optionally purchased remote controller). We recommend that you use remote controller RM-RK50 or RM-RK60 with your unit. (Ex.: When you are using RM-RK60) Before using the remote controller: •...

  • Page 28: Location Of The Buttons

    Location of the buttons RM-RK60 1 • Turns on the unit if pressed when the unit is turned off. • Turns off the unit if pressed and held until “SEE YOU” appears on the display. • Drops the volume level in a moment if pressed briefly.

  • Page 29: Troubleshooting

    What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms • Sound cannot be heard from the speakers. • This unit does not work at all. • SSM (Strong-station Sequential Memory) automatic preset does not work.

  • Page 30: Maintenance

    • After starting the heater in the car. • If it becomes very humid inside the car. Should this occur, the CD player may malfunction. In this case, eject the disc and leave the unit turned on for a few hours until the moisture evaporates.

  • Page 31: Specifications

    Panel Size (approx.): 188 mm × 58 mm × 12 mm Mass (approx.): 1.4 kg (excluding accessories) Design and specifications are subject to change without notice. If you want some additional downloaded plates, you can download them by visiting <http://www.jvc.co.jp/jvccar>.
  • Page 32 Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit Haben Sie PROBLEME mit dem Betrieb? Bitte setzen Sie Ihr Gerät zurück Siehe Seite Zurücksetzen des Geräts Vous avez des PROBLÈMES de fonctionnement? Réinitialisez votre appareil Référez-vous à...

  • Page 33: Problemen Oplossen

    Neem bij vragen of voor meer bijzonderheden over inbouwpakketten contact op met uw JVC car audio dealer of een dealer of een bedrijf dat inbouwpakketten levert. (déblocage Voordat u aan de montage van het apparaat...
  • Page 34 • When using the optional stay • Beim Verwenden der Anker-Option • Lors de l’utilisation du hauban en option • Wanneer u de steun gebruikt (facultatief) Fire wall Feuerwand Cloison Washer Brandscherm Unterlegscheibe Rondelle Sluitring Dashboard Armaturenbrett Tableau de bord Dashboard Screw (option) Schraube (Option)

  • Page 35: Electrical Connections

    • If noise is a problem... Nennleistung ersetzen. Brennt die Sicherung häufig This unit incorporates a noise filter in the power circuit. durch, wenden Sie sich an ihren JVC Autoradiohändler. However, with some vehicles, clicking or other unwanted • Sind Störgeräusche ein Problem...
  • Page 36 If your car is equipped with the steering wheel remote controller, you can operate this receiver using the controller. To do it, a JVC’s OE remote adapter (not supplied) which matches with your car is required. Consult your JVC IN-CAR ENTERTAINMENT dealer for details.
