Wolf PHORIZDIS30W Installation Instructions

W O L F P R O - S E R I E S W A L L H O O D H O R I Z O N T A L
D I S C H A R G E I N S T A L L A T I O N I N S T R U C T I O N S
Horizontal Discharge Kit Contains:
QTY
1
2
1
1
Horizontal Discharge Accessory Kits are designed for
use with Wolf Pro-Series Wall Hood Model Numbers:
24" DEEP
HOODS
PW302418(R)
PW362418(R)
PW422418(R)
PW482418(R)
PW542418(R)
PW602418(R)
PW662418(R)
Horizontal Discharge Kit Model Numbers
• PHORIZDIS30W (811088) – For use with PW302418
& PW302718
• PHORIZDIS36W (811089) – For use with PW362418
& PW362718
• PHORIZDIS42W (811090) – For use with PW422418
& PW422718
• PHORIZDIS48W (811091) – For use with PW482418
& PW482718
• PHORIZDIS54W (811092) – For use with PW542418
& PW542718
• PHORIZDIS60W (811093) – For use with PW602418
& PW602718
• PHORIZDIS66W (811094) – For use with PW662418
& PW662718
PROCEDURE
Hood must be anchored to wall framing to provide
proper support
1. First, ensure that there is adequate wall framing
available for the hood to mount securely to (See
Figure 1).
DESCRIPTION
Back Panel with PEM studs
Mounting Brackets
Installation Hardware (810555)
Instruction Sheet
27" DEEP
HOODS
PW302718(R)
PW362718(R)
PW422718(R)
PW482718(R)
PW542718(R)
PW602718(R)
PW662718(R)
2. Cut opening into wall. This opening must be large
enough for the supplied transition or custom duct
work to fit through when attached to the wall hood
(See Figure 2).
3. Install the mounting brackets onto the wall and
ensure that they are attached to wall framing studs.
These brackets will aid in mounting the hood onto
the wall by temporarily holding the hood in place for
you (See Figure 3).
4. Remove the factory installed back panel from the
hood by removing the screws on the top and back
sides of the wall hood (save the screws as they will
be used again). Then remove the electrical junction
box from the factory supplied back panel and save
the nuts holding the junction box on because they
will needed in order to transfer the junction box over
to the new horizontal discharge kit back panel (See
Figure 4).
5. Assemble the junction box removed in step 4 onto
the horizontal discharge back panel. If an internal
blower will be used with the hood, mount the blower
assembly to the horizontal discharge back panel
using the provided #10-24 KEPS nuts and the blow-
er installation instructions (See figure 5).
6. Next, assemble the new horizontal discharge back
panel (and internal blower assembly if applicable)
onto the hood using the screws removed in step 3.
7. Attach the transition or custom duct work to the out-
let of the ventilation hood.
8. Mount the hood onto the wall by utilizing the rectan-
gle cut outs in the back panel and hanging the hood
on the mounting brackets.
9. Use the rows of holes provided (shown in figure 3)
to drive mounting screws into the wall framing to
properly support the hood.
10. Connect electrical wiring per the ventilation hood
installation instructions.
