- Page 1 QUANTUM Q6 Edge Series Including Models: Quantum Q6 Edge 3S, Quantum Q6 Edge 3SP, and Quantum Q6 Edge 3MP...
- Page 2 The latest/current version of this manual is available on our website. Copyright © 2011 Pride Mobility Products Corp. INFMANU4037/Rev D/August 2011...
-
Page 3: Table Of Contents
C O N T E N T S INTRODUCTION ..........................4 SAFETY ..............................5 III. YOUR POWER CHAIR ........................17 IV. ASSEMBLY ............................21 COMFORT ADJUSTMENTS ......................24 VI. BATTERIES AND CHARGING .....................31 VII. CARE AND MAINTENANCE ......................35 Q6 Edge Series www.pridemobility.com... -
Page 4: Introduction
I . I N T R O D U C T I O N SAFETY WELCOME to Quantum Rehab, a division of Pride Mobility Products (Pride). The power chair you have pur- chased combines state-of-the-art components with safety, comfort, and styling in mind. We are confident that these design features will provide you with the conveniences you expect during your daily activities. - Page 5 I I . S A F E T Y PRODUCT SAFETY SYMBOLS The symbols below are used on the power chair to identify warnings, mandatory actions, and prohibited actions. It is very important for you to read and understand them completely. Read and follow the information in the owner’s manual.
- Page 6 I I . S A F E T Y Keep tools and other metal objects away from battery terminals. Contact with tools can cause electric shock. Do not connect an extension cord to the AC/DC converter or the battery charger. Removal of grounding prong can create electrical hazard.
- Page 7 I I . S A F E T Y EMI/RFI — This product has been tested and passed at an immunity level of 20 V/ Indicates electrical shock hazard. Locked and in drive mode. Place unit on level ground and stand to one side when changing from drive mode to freewheel mode or freewheel mode to drive mode.
- Page 8 I I . S A F E T Y Disposal and recycling – Contact your Quantum Rehab Provider for information on proper disposal and recycling of your Pride product and its packaging. Class II Equipment Manufactured in MAIN FRAME Power chair information label Indicates power chair securement points.
-
Page 9: General Guidelines
I I . S A F E T Y GENERAL GUIDELINES MANDATORY! Do not operate your new power chair for the first time without completely reading and understanding this owner’s manual. Your power chair is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an extensive variety of products to best fit the individual needs of the power chair user. -
Page 10: Your Power Chair
I I . S A F E T Y Weight Limitations Your power chair is rated for a maximum weight capacity. Please refer to the specifications table for this limit. Keep in mind that the maximum weight capacity includes the combined weight of the user and any accessories mounted to the power chair. - Page 11 I I . S A F E T Y WARNING! If your power chair is equipped with a reclining seatback, do not attempt to negotiate inclines with the seat in a reclined position. Do not attempt to negotiate obstacles with the seat in a reclined position unless an attendant is present to help stabilize the chair.
- Page 12 I I . S A F E T Y Public Streets and Roadways WARNING! You should not operate your power chair on public streets and roadways. Be aware that it may be difficult for traffic to see you when you are seated on your power chair. Obey all local pedestrian traffic rules.
-
Page 13: Stairs And Escalators
I I . S A F E T Y Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach Stairs and Escalators Power chairs are not designed to travel up or down stairs or escalators. Always use an elevator. WARNING! Never use your power chair to negotiate steps or escalators. Doors Determine if the door opens toward or away from you. -
Page 14: Positioning Belts
I I . S A F E T Y WARNING! Pride does not recommend using the power chair as a seat in a motor vehicle. The power chair user should transfer into the vehicle seat and use the vehicle-installed belt restraint system if and whenever feasible. -
Page 15: Reaching And Bending
I I . S A F E T Y Preventing Unintended Movement WARNING! If you anticipate being seated in a stationary position for an extended period of time, turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources. - Page 16 I I . S A F E T Y Prescription Drugs/Physical Limitations Users must exercise care and common sense when operating a power chair. This includes awareness of safety issues when taking prescribed or over-the-counter drugs or when the user has specific physical limitations. WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or if you have certain physical limitations.
-
Page 17: Assembly
I I I . Y O U R P O W E R C H A I R THE Q6 EDGE SERIES POWER CHAIR Your power chair has two main assemblies: the seat assembly and the power base assembly. See figure 5. Typically, the seat assembly includes the armrests, seatback, and seat base. - Page 18 I I I . Y O U R P O W E R C H A I R TRAPEZE BARS REAR SHROUD FRONT COVER MANUAL FREEWHEEL LEVER SUSPENSION SPRING Figure 6. The Q6 Edge Power Base PROHIBITED! The spring tension on your power chair was factory set to meet the needs of the demographic majority of users.
- Page 19 I I I . Y O U R P O W E R C H A I R Main Circuit Breaker (located on the rear main frame): The main circuit breaker is a safety feature built into your power chair. When the batteries and the motors are heavily strained (e.g., from excessive loads), the main circuit breaker trips to prevent damage to the motors and the electronics.
- Page 20 I I I . Y O U R P O W E R C H A I R Manual Freewheel Levers For your convenience, your power chair is equipped with a manual freewheel lever mounted on each motor. The levers allow you to disengage the drive motors and maneuver the chair manually. WARNING! Do not use the power chair while the drive motors are disengaged! Do not disengage the drive motors when the power chair is on an incline, as the unit could roll on its own! Only engage the freewheel mode when on a level surface.
-
Page 21: Initial Assembly
I V . A S S E M B L Y INITIAL ASSEMBLY Your power chair may require some assembly either before initial use or after transportation. It may also require disassembly to make some comfort adjustments. Figure 10 details those parts of the power chair that are designed to be disassembled and assembled by an end user or by a qualified caregiver before using the product or making comfort adjustments. -
Page 22: Seat Installation
I V . A S S E M B L Y Seat Installation SEAT LATCH SAFETY It may be necessary to install the seat either prior to initial operation or after transporting your power chair. Contour seats are attached to the power base with the Universal Mounting System (UMS). - Page 23 I V . A S S E M B L Y Power Elevating Seat Option Your power chair may be equipped with a power ele- vating seat option. While the seat itself may be any one of the styles offered for this model, the way the seat base attaches to the power base is different.
-
Page 24: Comfort Adjustments
Your Quantum Rehab Provider has evaluated your power chair and made any necessary adjustments to suit your specific requirements. Do not change your seating configuration without first contacting Pride Mobility Products or your Quantum Rehab Provider. -
Page 25: Seat Position
V . C O M F O R T A D J U S T M E N T S 7. Remove the hardware that attaches the trapeze bars to the seat interface weldments. See figure 16. 8. Move the trapeze bars up or down to the desired height. -
Page 26: Armrest Width Adjustment
V . C O M F O R T A D J U S T M E N T S Seatback Angle Adjustment If your power chair is equipped with an adjustable seat- back, you can adjust it to four (4) different angles: 90°, JAM NUT 102°, 105°, or 107°. -
Page 27: Controller Position
V . C O M F O R T A D J U S T M E N T S Controller Position You can move the controller in toward or out away from the armrest, or change the position of the control- ler for either left-hand or right-hand use. - Page 28 V . C O M F O R T A D J U S T M E N T S Foot Platform Height Adjustment The foot platform height is easily adjusted to several different heights. To raise or lower the foot platform: 1.
- Page 29 V . C O M F O R T A D J U S T M E N T S Power Elevating Seat (Optional) If your power chair is equipped with a power elevating seat, you can change the seat height either through the controller or through a toggle switch mounted to one of the armrests.
-
Page 30: Positioning Belt
V . C O M F O R T A D J U S T M E N T S Positioning Belt Your power chair may be equipped with a positioning belt that can be adjusted for operator comfort. See fig- ure 22. -
Page 31: Batteries And Charging
V I . B A T T E R I E S A N D C H A R G I N G BATTERIES AND CHARGING The Q6 Edge uses two long-lasting, 12-volt, deep-cycle batteries. These batteries are sealed and maintenance free. Since they are sealed, there is no need to check the electrolyte (fluid) level. - Page 32 V I . B A T T E R I E S A N D C H A R G I N G To charge the batteries using the off-board charger: 1. Position your power chair next to a standard electrical outlet.
- Page 33 V I . B A T T E R I E S A N D C H A R G I N G Daily Use If you use your power chair on a daily basis, charge the batteries as soon as you are finished using your power chair.
- Page 34 V I . B A T T E R I E S A N D C H A R G I N G How can I ensure maximum battery life? A fully charged deep-cycle battery will provide reliable performance and extended battery life. Keep your power chair’s batteries fully charged whenever possible.
-
Page 35: Care And Maintenance
V I I . C A R E A N D M A I N T E N A N C E CARE AND MAINTENANCE Your Q6 Edge is a sophisticated power chair. Like any motorized vehicle, it requires routine maintenance checks. You can perform some of these checks, but others require assistance from your Quantum Rehab Provider. -
Page 36: Daily Checks
V I I . C A R E A N D M A I N T E N A N C E The body shroud has been sprayed with a clear sealant coating. You can apply a light coat of car wax to help it retain its high-gloss appearance. -
Page 37: Cleaning And Disinfection
V I I . C A R E A N D M A I N T E N A N C E Storage Your power chair should be stored in a dry place, free from temperature extremes. When storing, disconnect the batteries from the power chair. -
Page 38: Battery Replacement
V I I . C A R E A N D M A I N T E N A N C E TIRE TUBE FRONT RIM HALF SCREWS WHEEL REAR RIM HALF LUG NUTS Figure 24. Q6 Edge Drive Wheel Figure 25. - Page 39 V I I . C A R E A N D M A I N T E N A N C E To replace the batteries: 1. Turn off the power to the controller. 2. Make sure that the power chair is in drive mode. See III. “Your Power Chair.” 3.
-
Page 40: Corrective Maintenance
V I I . C A R E A N D M A I N T E N A N C E When to See Your Quantum Rehab Provider for Service The following symptoms could indicate a serious problem with your power chair. If necessary, contact your Quantum Rehab Provider. - Page 41 N O T E S Q6 Edge Series www.pridemobility.com...
- Page 42 N O T E S www.pridemobility.com Q6 Edge Series...
- Page 43 Quality Control – Q6 Edge Series Inclusion of all Parts Joystick Serial Number Controller Serial Number Left Motor Serial Number Right Motor Serial Number Fit and Finish Performance Pride keeps a more detailed report on file at the factory. Date Inspected Inspector *INFMANU4037* Product Serial #...
