ViewSonic VG2021m-1 Service Manual page 9

ELECTRICAL REQUIREMENT
Horizontal / Vertical Frequency
Horizontal Frequency
Vertical Refresh Rate
Maximum Pixel Clock
Sync Polarity
Timing Table
Item
1. 640 x 400 @ 70Hz, 31.5kHz
2. 640 x 480 @ 60Hz, 31.5kHz
3. 640 x 480 @ 67Hz, 35.0kHz
4. 640 x 480 @ 72Hz, 37.9kHz
5. 640 x 480 @ 75Hz, 37.5kHz
6. 720 x 400 @ 70Hz, 31.5kHz
7. 800 x 600 @ 56Hz, 35.1kHz
8. 800 x 600 @ 60Hz, 37.9kHz
9. 800 x 600 @ 75Hz, 46.9kHz
10. 800 x 600 @ 72Hz, 48.1kHz
11. 832 x 624 @ 75Hz, 49.7kHz
12. 1024 x 768 @ 60Hz, 48.4kHz
13. 1024 x 768 @ 70Hz, 56.5kHz
14. 1152X 864 @75Hz,
15. 1152X 870 @75Hz, 70.8
16. 1024 x 768 @ 75Hz, 60.0kHz
17. 1280 x 1024 @ 60Hz, 63.4kHz
18. 1280 x 1024 @ 75Hz, 79.97kHz
19. 1400x 1050 @ 60Hz, 65.3kHz
Primary Presets
"1400 x 1050" @ 60Hz
User Presets
Number of User Presets (recognized timings) Available: 10 presets total in FIFO configuration
Changing Modes
l Maximum Mode Change Blank Time for image stability : 3 seconds (Max), excluding
"Auto Adjust" time
l Under DOS mode (640 x 350, 720 x 400 & 640 x 400), it should recall factory setting
when execute "Auto Adjust"
l The monitor needs to do "Auto Adjust" the first time a new mode is detected
l (see section "0-Touch™ Function Actions")
l While running Change Mode, Auto Adjust or Memory Recall, the image shall blank
ViewSonic Corporation
30 – 82 KHZ
56– 76 HZ.
156 MHz
Independent of sync polarity.
Timing
67.5kHz
kHz
6
Analog Digital
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Confidential - Do Not Copy
VG2021m-1
