Page 5: Introduction
Introduction CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 6 Drive your new vehicle at least 1,000 miles (1,600 km) before towing a trailer. For more detailed information about towing a trailer, refer to Trailer towing in the Tires, Wheels and Loading chapter. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 7 Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. 2010 Transit Connect (tst) Owners Guide, 3rd Printing...
Page 8 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
Page 9 Introduction may seek to access the information independently of Ford Motor Company and Ford of Canada. To the extent that any law pertaining to Event Data Recording applies to SYNC or its features, please note the following: Once 911 Assist (if equipped)
Page 10 WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 11 Parking Aid System Non-Petroleum Based Stability Control System Speed Control Master Lighting Switch Hazard Warning Flasher Fog Lamps-Front Fuse Compartment Fuel Pump Reset Windshield Wash/Wipe Windshield Rear Window Defrost/Demist Defrost/Demist 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 12 Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Service Engine Soon Engine Air Filter Passenger Compartment Jack Air Filter Low Tire Pressure Check Fuel Cap Warning 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 13: Instrument Cluster
If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately by your authorized dealer. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 14 A chime will sound when there is a malfunction in the indicator light. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 15 Speed control (if equipped): Illuminates when the speed control is activated. Turns off when the speed control system is deactivated, refer to the Driver Controls chapter for more information. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 16 If the indicators stay on or flash faster, check for a burned out bulb. High beams: Illuminates when the high-beam headlamps are turned on. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 17 Door ajar warning chime: The door ajar reminder chime informs the driver that one or more doors are open while the ignition is in the run position. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 18: Gauges
Speedometer: Indicates the current vehicle speed. Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 19 Refer to Filling the tank in the Maintenance and Specifications chapter for more information. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 20 Note: The information display will remain on for several minutes after you switch off the ignition. If SHON or SHIP ON is displayed, the vehicle shipping mode is switched on. Have your dealer switch off the vehicle shipping mode. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 21: Entertainment Systems
AM/FM stereo (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 22: Am/Fm Stereo With Cd
AM/FM stereo with single CD (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 23 SCAN: Press for a brief sampling of all tracks on the current disc. Sound Adjustments BASS/TRE: Press to toggle between bass and treble adjustments. Once the desired selection appears in the display, press to adjust the levels. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 24 • VEHICLE ID: Press to view the vehicle’s VIN number. • BT ON/OFF: Press to turn Bluetooth ON/OFF (if equipped). Refer to Bluetooth hands free system later in this chapter for more information 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 25: Auxiliary Input Jack (Line In)
Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 26: Bluetooth System
Your primary responsibility is the safe operation of the vehicle. Only use non-essential features and devices when it is safe to do so. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 27 Bluetooth discovery mode. 6. Select FORD AUDIO when it appears in your phone’s display. 7. Enter the code number shown on the vehicle display using the phone keypad. If no code number is shown on the display, enter the Bluetooth PIN number 0000 or any number using the phone keypad.
Page 28 • External device • Help External device: Auxiliary input jack Note: This system is language specific. If you would like the system to operate in another language, please contact your authorized dealer. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 29 You can store up to 20 name tags per function. Note: There are some voice command ’short cuts’ available which allow you to speak those commands directly without having to follow the complete command menu. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 30 Store name: When you say, “Store name”, the system will ask you for the name. Say the name when prompted. Delete name: Allows you to delete a stored station. Delete directory: Allows you to delete all stored stations at once. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 31 Bluetooth system. Depending on your phone book entry, different categories may be displayed in the audio display, such as: • or Phone • or Mobile or M 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 32 The call will be transferred to hands-free mode. Ignore the call by doing nothing. Reject the call by pressing CD, AM/FM or VOL ON/OFF on the audio system. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 33 2. Press MENU repeatedly until ACTIVE appears in the display. 3. Press < or > on the audio system to scroll through the list of paired (bonded) phones. 4. When the desired selection appears in the display, press MENU. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 34 • Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 35 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch protection film attached.
Page 36 Audio system warranty and service Refer to the Warranty Guide/Customer Information Guide for audio system warranty information. If service is necessary, see your dealer or qualified technician. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 37: Climate Controls
: Distributes outside air through the windshield defroster and demister vents. Can be used to clear thin ice or fog from the windshield. To exit select another mode. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 38 3. Set the fan to the highest speed initially. As the interior starts to cool down, adjust the fan speed to maintain comfort and/or switch from recirculated air to outside air mode. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 39: Rear Window Defroster
This may cause damage to the heated grid lines and will not be covered by your warranty. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 40: Lights
(DRL) system does not activate the tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 41: Headlamps
The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident, the alignment of your headlamps should be checked by your authorized dealer. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 42 #2 screwdriver or 10 mm wrench/socket to adjust the headlamp up or down. 6. Close the hood and turn off the lamps. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS NON-ADJUSTABLE. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 43: Turn Signal Control
Reading lamps (if equipped) The reading lamps are operated by separate on/off controls. Theater dimming: The dome lamp dims about 20 seconds after the doors are closed. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 44: Bulb Replacement
The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 45 1. Make sure the headlamp switch is in the off position. 2. Switch off the interior lamps. 3. Pry out the light assembly with a flat screwdriver. Install in reverse order. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 46 Check the operation of all bulbs frequently. Replacing headlamp bulbs 1. Make sure the headlamp control is in the off position and open the hood. 2. Pull off the bulb cap. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 47 Note: If the bulb is accidentally touched, it should be cleaned with rubbing alcohol before being used. Replacing front parking lamp bulbs 1. Make sure the headlamp control is in the off position. 2. Turn the cover counterclockwise and remove it. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 48 2. Remove the bulb socket from the lamp assembly by turning it counterclockwise. 3. Pull the bulb straight out of the socket. Install in reverse order. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 49 2. Remove the two wing nuts and gently pull the lamp assembly away from the vehicle. 3. Remove the bulb socket from the lamp assembly by turning it counterclockwise. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 50 3. Remove the bulb socket from the lamp assembly by turning it counterclockwise. 4. Pull the bulb straight out of the socket. Install in reverse order. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 51 Replacing license plate lamp bulbs 1. Make sure the headlamp control is in the off position. 2. Remove the lens assembly. 3. Pull the bulb straight out. Install in reverse order. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 52: Driver Controls
Reverse gear wipe The rear wiper will be activated automatically when shifting into R (Reverse) if the front wiper is activated. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 53: Steering Wheel Adjustment
Your vehicle has a variety of console features. These include: • Cupholders • Storage area • Power window switches (if equipped) WARNING: Use only soft cups in the cupholder. Hard objects can injure you in a collision. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 54 12 VDC/180W. If the power point or cigar lighter socket is not working, a fuse may have blown. Refer to Fuses and relays in the Roadside Emergencies chapter for information on checking and replacing fuses. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 55: Power Windows
Allows the driver’s window to open fully without holding the control down. Press the switch down and release quickly. The window will open fully. Press it again to stop the window. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 56: Mirrors
Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place. These actions could cause damage to the glass and mirrors. Fold-away mirrors Pull/push the mirrors in to fold/unfold them. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 57: Speed Control
Disengaging speed control To disengage the speed control, depress the brake pedal. Disengaging the speed control will not erase previous set speed. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 58 You can also use the – control to operate the Tap-Down function. Press and release – to decrease the vehicle set speed in small amounts by 1 mph (1.6 km/h). 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 59 Volume • Volume up: Press the top button on the back of the remote control. • Volume down: Press the bottom button on the back of the remote control. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 60 • In all modes to abort a traffic message during broadcasting Voice To select or deselect voice control, press the button on the top. For further information see the supplemental information on the Bluetooth feature. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 61 Open the right hand door first from either the outside (1) or inside (2) the vehicle. Open the left hand door second by squeezing the handle to unlatch the door and pulling it open. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 62 The left door must be closed first. Opening the doors fully Push the yellow button located on the door and swing it open. The check arms will automatically re-engage when the doors are closed. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 63: Locks And Security
• Insert the key and turn to the lock position to engage the childproof locks. • Insert the key and turn to the unlock position to disengage the childproof locks. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 64 If there are problems with the remote entry system, make sure to take ALL remote entry transmitters with you to the authorized dealer in order to aid in troubleshooting the problem. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 65 If all doors are closed the turn signal lamps will flash twice. Replacing the battery The remote entry transmitter uses one coin type three-volt lithium battery CR2032 or equivalent. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 66 6. Insert the new battery. The positive + terminal should face upwards. Press the battery down to ensure that the battery is fully seated in the battery housing cavity. 7. Snap the two halves back together. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 67 8. Repeat Step 6 to program each additional remote entry transmitter. 9. The programming mode will exit automatically after 10 seconds of inactivity or by turning the ignition II. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 68: Anti-Theft System
Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 69 Replacing coded keys can be very costly. Store an extra programmed key away from the vehicle in a safe place to help prevent any inconveniences. Please visit an authorized dealer to purchase additional spare or replacement keys. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 70 Keep the ignition in the II (on) position for at least one second but not more than 10 seconds. 7. Turn the ignition to the O (off) position. 8. Remove the previously programmed coded key from the ignition. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 71 If failure repeats, bring your vehicle to your authorized dealer to have the new key(s) programmed. To program additional new unprogrammed key(s), repeat this procedure from Step 1 for each additional key. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 72: Seating And Safety Restraints
• a trimmed energy absorbing foam and structure (1), • two steel stems (2), • a guide sleeve adjust/release button (3), • and a guide sleeve unlock/remove button (4). 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 73 WARNING: The adjustable head restraint is a safety device. Whenever possible it should be installed and properly adjusted when the seat is occupied. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 74 For occupants of extremely tall stature, adjust the head restraint to its full up position. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 75 WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Lift handle to move seat forward or backward. Rotate the control to adjust seatback. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 76 Using the armrest (if equipped) Move the armrest up or down. You can also move it all the way up to stow it on the side of the seatback. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 77 (4). To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 78 Whenever possible it should be installed and properly adjusted when the seat is occupied. To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 79 For occupants of extremely tall stature, adjust the head restraint to its full up position. WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 80 To place the seat in the tumble position: 4. Pull the release straps up. 5. Fold the seat forwards until the lever is automatically locked and you hear a click. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 81 1. Pull down on the locking lever. 2. Fold the seat down. 3. Raise the seatback. 4. Install all head restraints. 5. Ensure that the red indicator is in the locked position. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 82: Safety Restraints
• Two front crash severity sensors. • Front passenger sensing system • “Passenger airbag off” or “pass airbag off” indicator lamp • Restraints Control Module (RCM) with impact and safing sensors. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 83 The system is designed to help protect smaller drivers sitting close to the driver airbag by providing a lower airbag output level. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 84 The front safety belt usage sensors detect whether or not the driver and front outboard passenger safety belts are fastened. This information allows your Personal Safety System™ to tailor the airbag deployment and safety belt pretensioner activation depending upon safety belt usage. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 85 If any of these things happen, even intermittently, have the Personal Safety System™ serviced at an authorized dealer immediately. Unless serviced, the system may not function properly in the event of a collision. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 86 3) Never use a single belt for more than one person. WARNING: When possible, all children 12 years old and under should be properly restrained in a rear seating position. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 87 Make sure the tongue is securely fastened in the buckle. • Front and rear seats 2. To unfasten, push the release button and remove the tongue from the buckle. • Front and rear seats 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 88 Refer to Safety restraints for children or Safety seats for children later in this chapter. How to use the automatic locking mode • Buckle the combination lap and shoulder belt. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 89 Your vehicle is equipped with safety belt pretensioners at the driver and front outboard passenger seating positions. The safety belt pretensioner tightens the safety belts firmly against the occupant’s body at the start of the crash. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 90 Safety belt warning light and indicator chime The safety belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 91 If the Belt-Minder warnings have expired (warnings for approximately five minutes) for one occupant (driver or front passenger), the other occupant can still activate the Belt-Minder feature. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 92 1 in 4 of us will be seriously injured in a crash during our lifetime. “I’m not going far” 3 of 4 fatal crashes occur within 25 miles (40 km) of home. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 93 “I’d rather be thrown clear” Not a good idea. People who are ejected are 40 times more likely to DIE. Safety belts help prevent ejection, WE CAN’T “PICK OUR CRASH”. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 94 • This will disable the Belt-Minder feature if it is currently enabled or enable the Belt-Minder feature if it is currently disabled. As confirmation, the safety belt warning light will flash three times. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 95: Airbags
Never place a rear-facing child seat in front of an active airbag. If you must transport a forward-facing child in the front seat, move the seat all the way back and use appropriate restraints. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 96 WARNING: Additional equipment may affect the performance of the airbag sensors increasing the risk of injury. Please refer to the Body Builders Layout Book for instructions about the appropriate installation of additional equipment. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 97 Airbags are designed to inflate in frontal and near-frontal collisions, not rollover, side-impact, or rear-impacts unless the collision causes sufficient longitudinal deceleration. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 98 WARNING: If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 99 When the front passenger seat is not occupied (empty seat) or in the event that the front passenger frontal airbag is enabled (may inflate), the indicator lamp will be unlit. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 100 Occupant Passenger Airbag Indicator Lamp Empty seat Unlit Disabled Small child in child safety Disabled seat or booster Small child with safety belt Disabled buckled or unbuckled Adult Unlit Enabled 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 101 Small (i.e. three-ring Unlit Disabled binder, small purse, bottled water) Medium (i.e. heavy Disabled briefcase, fully packed luggage) Empty seat, or small Disabled to medium object with safety belt buckled 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 102 If the airbag readiness lamp is lit, do the following: The driver and/or adult passengers should check for any objects that may be lodged underneath the front passenger seat or cargo interfering with the seat. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 103 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Guide.
Page 104 SRS, its fuses or the seat cover on a seat containing an airbag. Contact your authorized dealer as soon as possible. WARNING: All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 105 Side airbags are designed to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 106: Child Restraints
See the following sections for directions on how to properly use safety restraints for children. Also see Airbag supplemental restraint system (SRS) in this chapter for special instructions about using airbags. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 107 Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consult your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
Page 108 Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in a front seating position. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 109 If all children cannot be seated and restrained properly in a rear seating position, properly restrain the largest child in the front seat. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 110 All children are shaped differently. The child height, age and weight thresholds provided are recommendations or the minimum requirements of law. The National Highway Traffic Safety Administration (NHTSA) provides education and 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 111 Seating and Safety Restraints training to ensure that all children ages 0 to 16 are properly restrained in the correct restraint system. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your seat is appropriate for your child and properly installed in the vehicle.
Page 112 Perform the following steps when installing the child seat with combination lap/shoulder belts: Note: Although the child seat illustrated is a forward facing child seat, the steps are the same for installing a rear facing child seat. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 113 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 114 It also helps to achieve the proper snugness of the child seat to the vehicle. Sometimes, a slight lean 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 115 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching safety restraints for children in this chapter for more information.
Page 116 Keep the tether strap just snug without lifting the front of the child seat. Keeping the child seat just touching the vehicle seat gives the best protection in a severe crash. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 117 The tether strap anchors in your vehicle are in the following positions (shown from top view): • Four-passenger vehicle 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 118 The tether can be attached directly to the rear of the second row center seat. 1. Route the tether strap under the head restraint and between the head restraint posts. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 119 2. Locate the correct anchor for the selected seating position. • On five-passenger vehicles, anchors are located on the passenger-side and driver-side upper rear door frame area close to the roof. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 120 If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. Child booster seats The belt-positioning booster (booster seat) is used to improve the fit of the vehicle safety belt.
Page 121 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that vehicle lap/shoulder safety belts fit better.
Page 122 • High back booster seats If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 123 Move a child to a different seating location if the shoulder belt does not stay positioned on the shoulder during use. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 124 Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 125: Tires, Wheels And Loading
Study your owner’s guide and any supplements for specific information about equipment features, instructions for safe driving and additional precautions to reduce the risk of an accident or serious injury. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 126 These differences that make your vehicle so versatile also make it handle differently than an ordinary passenger car. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 127: Tire Information
Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 128 • Standard load: A class of P-metric or Metric tires designed to carry a maximum load at 35 psi [37 psi (2.5 bar) for Metric tires]. Increasing the inflation pressure beyond this pressure will not increase the tire’s load carrying capability. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 129: Tire Inflation
Ford Motor Company. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 130 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 131 For your safety, tires that are damaged or show signs of excessive wear should not be used because they are more likely to blow out or fail. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 132 You should replace your spare tire when you replace the road tires or after six years due to aging even if it has not been used. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 133 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
Page 134 The tire pressure sensors mounted in the wheels are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your Tire Pressure Monitoring System (if equipped).
Page 135 Rotating your tires at the recommended interval (as indicated in the scheduled maintenance information that comes with your vehicle) will help your tires wear more evenly, providing better tire performance and longer tire life. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 136 This information identifies and describes the fundamental characteristics of the tire and also provides a U.S. DOT Tire Identification Number for safety standard certification and in case of a recall. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 137 These speed ratings may need to be adjusted for the difference in conditions. The ratings range from 81 mph (130 km/h) to 186 mph (299 km/h). These ratings are listed in the following chart. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 138 Refer to the Safety Compliance Certification Label, which is located on the B-Pillar or the edge of the driver’s door, for the correct tire pressure for your vehicle. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 139 The cold inflation pressure should never be set lower than the recommended pressure on the vehicle label. The tire suppliers may have additional markings, notes or warnings such as standard load, radial tubeless, etc. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 140 4. Maximum Load Single lb (kg) at psi (kPa) cold: Indicates the maximum load and tire pressure when the tire is used as a single; defined as two tires (total) on the rear axle. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 141: Tire Pressure Monitoring System (Tpms)
TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 142 RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 143 To restore the full functionality of the Tire Pressure Monitoring System, have the damaged road wheel/tire repaired and remounted on your vehicle. For additional information, refer to Changing tires with TPMS in this section. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 144 TPMS If your tires are properly inflated and malfunction your spare tire is not in use and the light remains ON, contact your authorized dealer as soon as possible. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 145 Check air pressure in the road tires. If any tire is under-inflated, carefully drive the vehicle to the nearest location where air can be added to the tires. Inflate all the tires to the recommended inflation pressure. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 146 • To reduce the chances of interference from another vehicle, the TPMS reset procedure should be performed at least 3 feet (1 meter) away from another Ford Motor Company vehicle undergoing the TPMS reset procedure at the same time. • Do not wait more than two (2) minutes between resetting each tire sensor or the system will timeout and the entire procedure will have to be repeated on all four wheels.
Page 147 Decrease the air pressure until the horn sounds. 8. Remove the valve cap from the valve stem on the right rear tire. Decrease the air pressure until the horn sounds. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 148 SNOW TIRES AND CHAINS WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 149: Vehicle Loading
Tire Label in order to determine the new payload. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 150 Once you have reached the maximum payload of your vehicle, do not add more cargo, even if there is space available. Overloading or improperly loading your vehicle can contribute to loss of vehicle control and vehicle rollover. Example only: 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 151 The GVWR is shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The GVW must never exceed the GVWR. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 152 WARNING: Do not exceed the GVWR or the GAWR specified on the Safety Compliance Certification Label. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 153 In metric units, the calculation would be: 635 kg - (5 x 99 kg) - (5 x 13.5 kg) = 635 - 495 - 67.5 = 72.5 kg. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 154 Your vehicle can haul more cargo and people than most passenger cars. Depending upon the type and placement of the load, hauling cargo and people may raise the center of gravity of the vehicle. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 155: Trailer Towing
N (Neutral) or with all four (4) wheels off the ground on a car-hauling trailer. In case of a roadside emergency with a disabled vehicle, see Wrecker towing in the Roadside Emergencies chapter. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 156: Driving
WARNING: Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 157 Safety Restraints chapter. 2. Make sure the headlamps and electrical accessories are off. • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 158 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 159 Outdoor Appliances.” Never use an indoor extension cord outdoors; it could result in an electric shock or fire hazard. • Use a 16 gauge outdoor extension cord, minimum. • Use as short an extension cord as possible. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 160 Make sure system is unplugged and properly stowed before driving the vehicle. While not in use, make sure the protective cover seals the prongs of the engine block heater cord plug. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 161: Brakes
Even when the ABS is disabled, normal braking is still effective. If your BRAKE warning lamp BRAKE illuminates with the parking brake released, have your brake system serviced immediately by an authorized dealer. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 162 WARNING: If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized dealer as soon as possible. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 163: Advancetrac
Operating your vehicle with the “sliding car” icon illuminated could lead to an increased risk of loss of vehicle control, vehicle rollover, personal injury and death. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 164 Traction Control is a driver aid feature that helps your vehicle maintain traction of the wheels, typically when driving on slippery and/or hilly road surfaces, by detecting and controlling wheel spin. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 165 • Entering a paved road from a gravel road, or vice versa • Cornering while towing a heavily loaded trailer (refer to Trailer towing in the Tires, Wheels and Loading chapter). 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 166 • loose or worn suspension components • loose or worn steering components • improper steering alignment A high crown in the road or high crosswinds may also make the steering seem to wander/pull. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 167 Placing any load on the roof also raises the center of gravity and increases the potential for rollover. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 168 • If the vehicle goes from one type of surface to another (i.e., from concrete to gravel) there will be a change in the way the vehicle responds to a maneuver (steering, acceleration or braking). Again, avoid these abrupt inputs. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 169 WARNING: Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the off position and remove the key whenever you leave your vehicle. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 170: Transmission Operation
WARNING: Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the off position and remove the key whenever you leave your vehicle. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 171 • O/D (overdrive) is automatically returned each time the key is turned off. 2 (Second) This position allows for second gear only. • Provides engine braking. • Use to start-up on slippery roads. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 172: Reverse Sensing System
The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle. The system may not detect smaller objects, particularly those close to the ground. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 173 RSS. If your vehicle sustains damage to the rear bumper/fascia, leaving it misaligned or bent, the sensing zone may be altered causing inaccurate measurement of obstacles or false alarms. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 174 Once through the water, always dry the brakes by moving your vehicle slowly while applying light pressure on the brake pedal. Wet brakes do not stop the vehicle as quickly as dry brakes. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 175: Roadside Emergencies
Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 176: Hazard Flasher Control
Motorhome customers in the U.S and Canada should contact 1-800-444-3311. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles. To obtain reimbursement information, U.S.
Page 177: Fuel Pump Shut-Off Switch
Note: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 178 — Brown — — Natural Black Black Passenger compartment fuse panel The fuse panel and relay box are located below the instrument panel to the left of the steering wheel. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 179 Rear window defroster relay — Heater blower relay — Interior lamps relay — Windshield wipers relay — Rear unlock relay Hazard flashers Power mirrors Light switch, Exterior lighting — Not used 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 180 A/C switch, Park aid module 7.5A Interior lamps, Battery saver — Not used — Not used 7.5A Right parking lamp/tail lamps 7.5A License plate lamps Light switch — Not used — Not used 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 181 Not used Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 182 Not used 40A** Passenger compartment fuse panel 20A** Ignition switch 20A** Fuel pump 10A* Powertrain control module (PCM) keep alive power, Canister solenoid 15A* PCM, Data link connector 10A* Backup lamps 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 183 10A* Left low beam headlamp 10A* Mass air flow sensor, Brake switch, Backup lamps relay, EGR stepper motor, EVAP canister purge valve, Heated oxygen sensors, Floor shifter, Transmission range sensor 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 184: Changing Tires
(TPMS) in the Tires, Wheels and Loading chapter. Replace the spare tire with a road tire as soon as possible. During repairing or replacing of the flat tire, have the authorized dealer inspect the TPMS sensor for damage. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 185 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 186 • Driving vehicles equipped with a camper body • Driving vehicles with a load on the cargo rack Drive cautiously when using a full-size dissimilar spare tire/wheel and seek service as soon as possible. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 187 2. Turn the handle counterclockwise and lower the spare tire until it rests on the ground and the cable is slack. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 188 Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel. Note: Passengers should not remain in the vehicle when the vehicle is being jacked. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 189 3. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 190 Tap it with the palm of your hand to lock it into place. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 191 (every six months, per scheduled maintenance information), or at any time that the spare tire is disturbed through service of other components. Return the jack and tools to the storage position in the cargo area. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 192: Wheel Lug Nut Torque
M12 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 193: Jump Starting
Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect from any electrical surges. Turn all other accessories off. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 194 Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 195 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 196 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 197 After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 198: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If your vehicle is to be towed from the rear using wheel lift equipment, the front wheels (drive wheels) must be placed on a dolly to prevent damage to the transmission.
Page 199 Driving chapter for specific instructions if you cannot move the gear shift lever into N (Neutral). • Maximum speed is not to exceed 35 mph (56 km/h). • Maximum distance is 50 miles (80 km). 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 200: Customer Assistance
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 201 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 202 In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Ford Motor Company 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 203 THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step procedure outlined on the first page of the Customer Assistance section, you may be eligible to participate in the BBB AUTO LINE program.
Page 204 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 205 If you are in another foreign country, contact the nearest authorized dealer. If the authorized dealer employees cannot help you, they can direct you to the nearest Ford affiliate office. If you buy your vehicle in North America and then relocate outside of the U.S.
Page 206: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 207: Cleaning
• Never use abrasive materials such as steel wool or plastic pads as they can scratch the chrome surface. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 208 • Do not use hydrofluoric acid-based or high caustic-based wheel cleaners, steel wool, fuels or strong household detergent. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 209 PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3-A). 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 210 • Avoid cleaners or polishes that increase the gloss of the upper portion of the instrument panel. The dull finish in this area helps protect the driver from undesirable windshield reflection. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 211 (but do not oversaturate) or the ring will set. • Do not use household cleaning products or glass cleaners, which can stain and discolor the fabric and affect the flame retardant abilities of the seat materials. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 212 FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 213: Maintenance And Specifications
WARNING: To reduce the risk of vehicle damage and/or personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 214 Note: To prevent damage to, or loss of the key, remove the key immediately after opening the hood and swivel the badge back. 3. Lift the hood and support it with the prop rod. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 215: Engine Compartment
3. Brake fluid reservoir 4. Battery 5. Power distribution box 6. Windshield washer fluid reservoir 7. Air filter assembly 8. Automatic transmission fluid dipstick 9. Engine oil dipstick 10. Power steering fluid reservoir 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 216 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 217: Engine Oil
If the engine is overfilled, some oil must be removed from the engine by an authorized dealer. 7. Put the dipstick back in and ensure it is fully seated. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 218 Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine and engine’s warranty, use Motorcraft SAE 5W-20 or an equivalent SAE 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 219: Battery
Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance information. Ford production and Motorcraft replacement oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 220 6. Release the parking brake. With your foot on the brake pedal and with the A/C on, put the vehicle in D (Drive) and allow the engine to idle for at least one minute. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 221: Engine Coolant
50/50 mixture of coolant and water provides the following: • Freeze protection down to -34°F (-36°C). • Boiling protection up to 265°F (129°C). • Protection against rust and other forms of corrosion. • Proper function of calibrated gauges. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 222 WARNING: Do not put engine coolant in the windshield washer fluid container. If sprayed on the windshield, engine coolant could make it difficult to see through the windshield. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 223 2. When the engine is cool, wrap a thick cloth around the coolant pressure relief cap on the coolant reservoir (a translucent plastic bottle). Slowly turn cap counterclockwise (left) until pressure begins to release. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 224 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant since a Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner.
Page 225 How fail-safe cooling works If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation. Each disabled cylinder acts as an air pump and cools the engine. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 226 FUEL FILTER Your vehicle is equipped with a lifetime fuel filter that is integrated with the fuel tank. Regular maintenance or replacement is not needed. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 227: Fuel Information
• Avoid inhaling fuel vapors. Inhaling too much fuel vapor of any kind can lead to eye and respiratory tract irritation. In severe cases, excessive or prolonged breathing of fuel vapor can cause serious illness and permanent injury. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 228 • Stay outside your vehicle and do not leave the fuel pump unattended when refueling your vehicle — this is against the law in some places; • Keep children away from the fuel pump; never let children pump fuel. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 229 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford, Motorcraft or other certified fuel filler cap is not used. WARNING: The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 230 Do not be concerned if your engine sometimes knocks lightly. However, if it knocks heavily under most driving conditions while you are using fuel with the recommended octane rating, see your authorized dealer to prevent any engine damage. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 231 Ask your fuel supplier about gasolines that meet the World-Wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the right fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 232 • Have the vehicle loading and distribution the same every time. Your results will be most accurate if your filling method is consistent. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 233 65 mph [105 km/h]). • Revving the engine before turning it off may reduce fuel economy. • Using the air conditioner or defroster may reduce fuel economy. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 234 • Transmissions give their best fuel economy when operated in the top cruise gear and with steady pressure on the gas pedal. • Close windows for high speed driving. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 235 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 236 A driving cycle consists of a cold engine startup followed by mixed city/highway driving. No additional vehicle service is required. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 237 If the vehicle is still not ready for I/M testing, the above driving cycle will have to be repeated. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 238 Brake fluid should not be allowed to contact the eyes and skin. If this happens, promptly wash the area thoroughly with soap and water. Consult a physician immediately if you experience an adverse reaction. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 239 Do not drive the vehicle if the fluid level is at the bottom of the dipstick. If the fluid level is below the MIN mark, add fluid in 1/2 pint (250 ml) increments. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 240 Do not use supplemental transmission fluid additives, treatments or cleaning agents. The use of these materials may affect transmission operation and result in damage to internal transmission components. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 241: Air Filter(S)
Note: Failure to use the correct air filter element may result in severe engine damage. The customer warranty may be void for any damage to the engine if the correct air filter element is not used. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 242: Part Numbers
Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used.
Page 243: Maintenance Product Specifications And Capacities
Maintenance and Specifications 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 244 Maintenance and Specifications 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 245 Maintenance and Specifications 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 246: Engine Data
2.0L I4 engine Cubic inches Required fuel 87 octane Firing order 1–3–4–2 Ignition system C.O.P Compression ratio 10.0:1 Spark plug gap .051 inch +/- .002 (1.3 mm +/- .05) Engine drivebelt routing 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 247 Vehicle identification number (VIN) The vehicle identification number is located on the driver side instrument panel. XXXXXXXXXXXXXXXXX Please note that in the graphic, XXXX is representative of your vehicle identification number. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 248 TRANSMISSION CODE DESIGNATIONS You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Code Four-speed automatic (4F27E) 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 249: Accessories
GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 250 • Electrical or electronic accessories or components that are added to the vehicle by the authorized dealer or the owner may adversely affect battery performance and durability. 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 251: Ford Extended Service Plan
FORD ESP EXTENDED SERVICE PLANS More than 30 million Ford, Lincoln, and Mercury owners have discovered the powerful protection of Ford ESP. It is the only extended service plan backed by Ford Motor Company, and provides “peace of mind” protection beyond the New Vehicle Limited Warranty coverage.
Page 252 Ford ESP Can Quickly Pay for Itself One service bill – the cost of parts and labor – can easily exceed the price of your Ford ESP Service Contract. With Ford ESP, you minimize your risk for unexpected repair bills and rising repair costs.
Page 253 Ford Extended Service Plan 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 254: Index
....108 Auxiliary power point ....53 Child safety seats - booster Axle seats ...........120 refill capacities ......242 Cleaning your vehicle engine compartment ....208 instrument panel ....209 Battery ........218 interior ........210 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 255 Fluid capacities ......242 Daytime running lamps (see Lamps) .........39 Four-Wheel Drive vehicles preparing to drive your Dipstick vehicle ........166 automatic transmission fluid ..........238 Fuel ..........226 engine oil .........216 calculating fuel economy ..231 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 256 ..40 replacing bulbs ......45 interior lamps .....42, 44 turning on and off ....39 replacing bulbs ......45 Heating LATCH anchors ......114 heating and air conditioning system ........36 Liftgate ........60 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 257 Power distribution box Belt-Minder ......90 (see Fuses) .......180 for adults ......86–88 for children ......105 Power mirrors ......55 Occupant Classification Power point .........53 Sensor ........83 warning light and chime ..89–90 Power steering ......165 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 258 Tires, Wheels and Loading ..140 Tires ......126–127, 183 alignment ........134 Warning lights (see Lights) ..12 care ..........130 Washer fluid ......215 changing ......183, 187 Water, Driving through .....173 checking the pressure ....130 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)
Page 259 Index Windows checking and adding fluid ..215 power .........54 operation ........51 rear wiper/washer .....51 replacing wiper blades ...215–216 Windshield washer fluid and Wrecker towing ......197 wipers 2010 Transit Connect (tst) Owners Guide, 3rd Printing USA (fus)

Ford 2010 Transit Connect Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Ford Extended Service Plan

Index

Quick Links

Related Manuals for Ford 2010 Transit Connect

Summary of Contents for Ford 2010 Transit Connect

Table of Contents
