- Page 1 PRO DJ LINK Setup Guide...
-
Page 2: Table Of Contents
(iOS/Android) simultaneously, as well as when referring to rekordbox func- tions directly. Before start Purpose of this guide .......................3 General description of PRO DJ LINK ................3 To make connections .......................3 About trademarks and registered trademarks ..............3 Connecting the CDJ-2000nexus and DJM-2000nexus/ DJM-2000 Connecting rekordbox by wireless LAN ................4... -
Page 3: Before Start
! The quantize function makes it possible to apply beat effects in tempo with the music. Even more functions are available when used in combination with other DJ players and DJ mixers supporting the PRO DJ LINK function. For details, see the respective play- ers’... -
Page 4: Connecting The Cdj-2000Nexus And Djm-2000Nexus/Djm-2000
Connecting the CDJ-2000nexus and DJM-2000nexus/DJM-2000 Connecting rekordbox by wireless LAN Equipment used ! CDJ-2000nexus (1 – 4 units) ! Wireless router with internal switching hub or access point ! Mobile device (iOS/Android) or computer (Mac/Windows) on which rekordbox is installed ! DJM-2000nexus or DJM-2000 ! Audio cable ! LAN cables (one for each DJ player + one more) - Page 5 Connecting the cables (LAN cable and audio cables) Connect the LAN cable and audio cables. Connect in such a way that the DJ player’s [PLAYER No.], the channel number of the DJ mixer’s LAN cable insertion port and the channel number of the terminals to which the audio cables are connected are all the same number.
- Page 6 Checking the device(s) connected by wireless connection 1 Press the [rekordbox] button. TAG TRACK LINK INFO UTILITY BACK / REMOVE BROWSE TAG LIST INFO MENU rekordbox LINK DISC QUANTIZE TIME MODE AUTO CUE 2 Tap the [LOAD] icon, or click the [LINK] button to establish the link connection. The devices that have been recognized are indicated on the DJ player’s screen.
-
Page 7: Connecting Rekordbox By Wired Connection/Connecting A Usb Device Or Sd Memory Card
Connecting rekordbox by wired connection/Connecting a USB device or SD memory card Equipment used ! CDJ-2000nexus (1 – 4 units) ! USB cable (for the iPod cable, use the iPod cable included with the CDJ-2000nexus.) ! Mobile device (iOS/Android) or computer (Mac/Windows) on which rekordbox is installed ! USB device or SD memory card on which music files analyzed with rekordbox are stored ! DJM-2000nexus or DJM-2000 ! Audio cable... - Page 8 Connecting the cables (LAN cable and audio cables) Connect the LAN cable and audio cables. Connect in such a way that the DJ player’s [PLAYER No.], the channel number of the DJ mixer’s LAN cable insertion port and the channel number of the terminals to which the audio cables are connected are all the same number.
- Page 9 Checking the connected device(s) 1 Press one of the medium select buttons to check the connection with the respective device. — To use a computer (Mac/Windows) connected by wired LAN: Press the [rekordbox] button. — To use a USB device or SD memory card connected to another player that is connected by link: Press the [LINK] button. —...
-
Page 10: Connecting The Cdj-2000Nexus And Djm-900Nexus
Connecting the CDJ-2000nexus and DJM-900nexus Connecting rekordbox by wireless LAN Equipment used ! CDJ-2000nexus (1 – 4 units) ! Wireless router with internal switching hub ! Mobile device (iOS/Android) or computer (Mac/Windows) on which rekordbox is installed ! DJM-900nexus ! Audio cable ! LAN cables (one for each DJ player + one more) Connections diagram (when connecting two DJ players) POWER... - Page 11 Connecting the cables (LAN cable and audio cables) 1 Connect the wireless router and DJM-900nexus by LAN cable. 2 Connect the LAN cable and audio cables. Connect in such a way that the DJ player’s player number and the channel number of the terminals to which the DJ mixer’s audio cables are connected are the same number. Ex.: When player 2 is connected to [CH2], player 3 is connected to [CH3] and the wireless router is connected to the DJ mixer CH 3 CH 2...
- Page 12 Checking the device(s) connected by wireless connection 1 Press the [rekordbox] button. TAG TRACK LINK INFO UTILITY BACK / REMOVE BROWSE TAG LIST INFO MENU rekordbox LINK DISC QUANTIZE TIME MODE AUTO CUE 2 Tap the [LOAD] icon, or click the [LINK] button to establish the link connection. The devices that have been recognized are indicated on the DJ player’s screen.
-
Page 13: Connecting Rekordbox By Wired Connection/Connecting A Usb Device Or Sd Memory Card
Connecting rekordbox by wired connection/Connecting a USB device or SD memory card Equipment used ! CDJ-2000nexus (1 – 4 units) ! Switching hub ! USB cable (for the iPod cable, use the iPod cable included with the CDJ-2000nexus.) ! Mobile device (iOS/Android) or computer (Mac/Windows) on which rekordbox is installed ! USB device or SD memory card on which music files analyzed with rekordbox are stored ! DJM-900nexus ! Audio cable... - Page 14 Connecting the cables (LAN cable and audio cables) 1 Connect the switching hub and DJM-900nexus by LAN cable. 2 Connect the LAN cable and audio cables. Connect in such a way that the DJ player’s player number and the channel number of the terminals to which the DJ mixer’s audio cables are connected are the same number. Ex.: When player 2 is connected to [CH2], player 3 is connected to [CH3] and the switching hub is connected to the DJ mixer CH 3 CH 2...
- Page 15 Checking the connected device(s) 1 Press one of the medium select buttons to check the connection with the respective device. — To use a computer (Mac/Windows) connected by wired LAN: Press the [rekordbox] button. — To use a USB device or SD memory card connected to another player that is connected by link: Press the [LINK] button. —...
-
Page 16: Connecting The Cdj-2000Nexus And Another Mixer
Connecting the CDJ-2000nexus and another mixer Connecting rekordbox by wireless LAN Equipment used ! CDJ-2000nexus (1 – 4 units) ! Wireless router with internal switching hub ! Mobile device (iOS/Android) or computer (Mac/Windows) on which rekordbox is installed ! Another DJ mixer (DJ mixer other than the DJM-2000nexus/DJM-2000/DJM-900nexus) ! Audio cable ! LAN cables (one for each DJ player) Connections diagram (when connecting two DJ players) - Page 17 Checking the connections Checking the DJ player’s link established by LAN connection Check that the player number indicated on the DJ player’s screen is lit in white. LINK OK LINK NG ! If the player number indicated on the DJ player’s screen is lit in gray, the link is not established. If there is a DJ player for which the player number is lit in gray, redo the connection procedure.
-
Page 18: Connecting Rekordbox By Wired Connection/Connecting A Usb Device Or Sd Memory Card
Connecting rekordbox by wired connection/Connecting a USB device or SD memory card Equipment used ! CDJ-2000nexus (1 – 4 units) ! Switching hub ! USB cable (for the iPod cable, use the iPod cable included with the CDJ-2000nexus.) ! Mobile device (iOS/Android) or computer (Mac/Windows) on which rekordbox is installed ! USB device or SD memory card on which music files analyzed with rekordbox are stored ! Another DJ mixer (DJ mixer other than the DJM-2000nexus/DJM-2000/DJM-900nexus) ! Audio cable... - Page 19 Checking the connections Checking the DJ player’s link established by LAN connection Check that the player number indicated on the DJ player’s screen is lit in white. LINK OK LINK NG ! If the player number indicated on the DJ player’s screen is lit in gray, the link is not established. If there is a DJ player for which the player number is lit in gray, redo the connection procedure.
-
Page 20: Connecting The Cdj-2000/Cdj-900 And Djm-2000Nexus
Connecting the CDJ-2000/CDJ-900 and DJM-2000nexus/DJM-2000 Connecting rekordbox by wired connection/Connecting a USB device or SD memory card Equipment used ! CDJ-2000 (1 – 4 units) or CDJ-900 (1 – 4 units) ! Computer (Mac/Windows) on which rekordbox is installed ! USB device or SD memory card on which music files analyzed with rekordbox are stored ! DJM-2000nexus or DJM-2000 ! Audio cable ! LAN cables (one for each DJ player + one more) - Page 21 Connecting the cables (LAN cable and audio cables) Connect the LAN cable and audio cables. Connect in such a way that the channel number of the DJ mixer’s LAN cable insertion port and the channel number of the terminals to which the audio cables are connected are the same number.
- Page 22 Checking the connected device(s) 1 Press one of the medium select buttons to check the connection with the respective device. — To use a computer (Mac/Windows) connected by wired LAN: Press the [LINK] button. — To use a USB device or SD memory card connected to another player that is connected by link: Press the [LINK] button. —...
-
Page 23: Connecting The Cdj-2000/Cdj-900 And Djm-900Nexus
Connecting the CDJ-2000/CDJ-900 and DJM-900nexus Connecting rekordbox by wired connection/Connecting a USB device or SD memory card Equipment used ! CDJ-2000 (1 – 4 units) or CDJ-900 (1 – 4 units) ! Switching hub ! Computer (Mac/Windows) on which rekordbox is installed ! USB device or SD memory card on which music files analyzed with rekordbox are stored ! DJM-900nexus ! Audio cable... - Page 24 Connecting the cables (LAN cable and audio cables) 1 Connect the switching hub and DJM-900nexus by LAN cable. 2 Connect the LAN cable and audio cables. Connect in such a way that the DJ player’s player number and the channel number of the terminals to which the DJ mixer’s audio cables are connected are the same number. Ex.: When player 2 is connected to [CH2], player 3 is connected to [CH3] and the computer (Mac/Windows) is connected to the DJ mixer CH 3 CH 2...
- Page 25 Checking the connected device(s) 1 Press one of the medium select buttons to check the connection with the respective device. — To use a computer (Mac/Windows) connected by wired LAN: Press the [LINK] button. — To use a USB device or SD memory card connected to another player that is connected by link: Press the [LINK] button. —...
-
Page 26: Connecting The Cdj-2000/Cdj-900 And Another Mixer
Connecting the CDJ-2000/CDJ-900 and another mixer Connecting rekordbox by wired connection/Connecting a USB device or SD memory card Equipment used ! CDJ-2000 (1 – 4 units) or CDJ-900 (1 – 4 units) ! Switching hub ! Computer (Mac/Windows) on which rekordbox is installed ! USB device or SD memory card on which music files analyzed with rekordbox are stored ! Another DJ mixer (DJ mixer other than the DJM-2000nexus/DJM-2000/DJM-900nexus) ! Audio cable... - Page 27 Checking the connections Checking the DJ player’s link established by LAN connection (for the CDJ-2000) Check that the player number indicated on the DJ player’s screen is lit in white. LINK OK LINK NG ! If the player number indicated on the DJ player’s screen is lit in gray, the link is not established. If there is a DJ player for which the player number is lit in gray, redo the connection procedure.
- Page 28 The files, folders and lists loaded into the respective devices are displayed on the DJ player’s screen. Ex.: When connecting a computer (Mac/Windows) rekordbox (Mac/Windows) This completes checking the connections. © 2012 PIONEER CORPORATION. All rights reserved. PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan...
