- Page 1 MANUFACTURING NUMBERS: 9700501 9700505 9700508 9700512 WATER FILTRATION SYSTEM Model SE-4200/4400 P/N 1010852 Rev. C 04/06 Owner s Manual ’...
-
Page 2: Table Of Contents
Programming ...11 Operating the Unit ... 15 Checking the Controller Program ... 16 Changing the Cartridges ... 16 Maintenance ...16 Troubleshooting ...17 Replacement Parts - SE-4200/4400 ...19 Wiring Diagram ...21 Notes...22 Notes...23 LIMITED WARRANTY ...Back Cover OWNER INFORMATION Warranty Information Please read the full text of the Limited Warranty in this manual. -
Page 3: Service/Technical Assistance
Failure to observe may result in damage to the equipment and/or severe bodily injury or death. P/N 1010852 Rev. C 04/06 SE-4200/4400 WATER FILTRATION SYSTEM Purchased From: Date of Purchase: Model No.: Serial No.: Mfg. - Page 4 SE-4200/4400 WATER FILTRATION SYSTEM IMPORTANT SAFETY INFORMATION (continued) The following warnings and cautions appear throughout this manual and should be carefully observed. • Turn the unit off, disconnect the power source, and allow unit to cool down before performing any service or maintenance on the unit.
-
Page 5: Operating Specifications
1-13 Trans Membrane Pressure 0.5-3 Bar (7.25-43.5 psi) MWCO 100 kd P/N 1010852 Rev. C 04/06 SE-4200/4400 WATER FILTRATION SYSTEM SPECIFICATIONS ELECTRICAL SHOCK HAZARD. FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL COULD RESULT IN SERIOUS INJURY OR DEATH. 1.25 50/60 •... -
Page 6: Dimensions
SE-4200/4400 WATER FILTRATION SYSTEM SPECIFICATIONS (continued) Dimensions Control Box Drain Permeate (use water) Inlet P/N 1010852 Rev. C 04/06... -
Page 7: Installation
• Water Inlet (Feed Water) • Permeate (Product Water) • Drain P/N 1010852 Rev. C 04/06 SE-4200/4400 WATER FILTRATION SYSTEM INSTALLATION When making a plumbing connection to the system, remember to use a back-up wrench on the support plumbing. Always use a good quality and approved pipe sealant or Teflon tape on pipe threads. -
Page 8: Locating And Mounting The System
SE-4200/4400 WATER FILTRATION SYSTEM Locating and Mounting the system Consider these points before mounting the system: • Note the location of the water supply, drain, and an appropriate electrical outlet when choosing a mounting location. • Remember to allow for access to the Control Box. - Page 9 5 minutes to allow any trapped air to be flushed out. 9. Close the tap. The flushing is complete. P/N 1010852 Rev. C 04/06 SE-4200/4400 WATER FILTRATION SYSTEM INSTALLATION (continued) SANITIZING THE SYSTEM AND LINES The plumbing must also be sanitized to eliminate pos- sible contamination that may have occurred during the installation process.
-
Page 10: Filtration Process
SE-4200/4400 WATER FILTRATION SYSTEM Filtration Process The filtration process includes a Filtration Cycle and a Backwash Cycle. During the Filtration Cycle, water enters the system inlet port and passes through the filter elements before exiting via the Permeate outlet. This system is designed so that no valves are powered during the Filtration Cycle. -
Page 11: Programming
SET PASSWORD to SET DATE/TIME and press the Enter button. 4. The system displays the SET DATE message. P/N 1010852 Rev. C 04/06 SE-4200/4400 WATER FILTRATION SYSTEM OPERATION (continued) Using the Up and Down arrow buttons, enter the correct date in mm/dd/yy format. After each entry, press the Enter button. - Page 12 SE-4200/4400 WATER FILTRATION SYSTEM SET QUICKFLUSH MODE NOTE: The Quick Flush function allows the sys- tem to be used for water systems containing a high quantity of air. Air does not pass through the filtration membranes. Performing a quick flush at pre-set times allows the accumulated air to be released.
- Page 13 Menu button to return to the STOP MODE display. 13. Press the Run button to return to FILTER MODE. P/N 1010852 Rev. C 04/06 SE-4200/4400 WATER FILTRATION SYSTEM OPERATION (continued) RESET DEFAULTS MODE 1. From the FILTER MODE display, press the Stop button.
- Page 14 SE-4200/4400 WATER FILTRATION SYSTEM NOTE: The REVIEW HISTORY mode displays infor- mation about the most recent operation first. 5. When finished reviewing history, press the Enter button. The system will display the REVIEW OF CYCLES display. Press Menu to return to STOP MODE.
-
Page 15: Operating The Unit
Stop Mode. Press the Menu button to enter the password again. If you have forgotten your password, contact the manufacturer. P/N 1010852 Rev. C 04/06 SE-4200/4400 WATER FILTRATION SYSTEM OPERATION (continued) Operating the Unit After all of the menus have been programed, the sys- tem can be activated. -
Page 16: Checking The Controller Program
SE-4200/4400 WATER FILTRATION SYSTEM The SE-4200/4400 Filtration system is designed to require very little maintenance. To ensure that the water is of the highest quality, occasionally some ser- vice is required. Checking the Controller Program The program features and setting should be checked occasionally to confirm that the system is operating under the proper settings. -
Page 17: Troubleshooting
Cartridge end connections not tight. cartridge after changing O-rings not lubricated. cartridge. O-rings split, cut, or twisted. P/N 1010852 Rev. C 04/06 SE-4200/4400 WATER FILTRATION SYSTEM TROUBLESHOOTING Possible Cause Plug power cord in correctly. Plug power cord in correctly. Contact your maintenance person or Authorized Service agency. - Page 18 SE-4200/4400 WATER FILTRATION SYSTEM TROUBLESHOOTING (continued) Problem Water leaks from Permeate Port not tight. Permeate Port. O-rings not lubricated. O-rings split, cut, or twisted. Water leaks from system Not enough pipe thread sealant used. fitting or connection. Fitting loose or broken.
-
Page 19: Replacement Parts - Se-4200/4400
SE-4200/4400 WATER FILTRATION SYSTEM REPLACEMENT PARTS - SE-4200/4400 See Inset A Inset A P/N 1010852 Rev. C 04/06... - Page 20 SE-4200/4400 WATER FILTRATION SYSTEM REPLACEMENT PARTS - SE-4200/4400 (continued) Item Part Description 1001073 Label Control Panel 5550100 Enclosure Control-upper 7000434 SE Series 3 Board Controller Replacement Kit 6* 304P113 Screw, FLTHD #4-40 x 1 15/16” 8* 308P151 Sems Screw #8-32 X 5/16...
-
Page 21: Wiring Diagram
SE-4200/4400 WATER FILTRATION SYSTEM WIRING DIAGRAM P/N 1010852 Rev. C 04/06... -
Page 22: Notes
SE-4200/4400 WATER FILTRATION SYSTEM NOTES P/N 1010852 Rev. C 04/06... -
Page 23: Notes
SE-4200/4400 WATER FILTRATION SYSTEM NOTES P/N 1010852 Rev. C 04/06... -
Page 24: Limited Warranty
Equipment manufactured by Antunes Filtration Technologies, Division of A.J. Antunes & Co. has been constructed of the finest materials available and manufactured to high quality standards. These units are warranted to be free from mechanical and electrical defects for a period of one year from date of purchase or 18 months from shipment from factory, whichever occurs first, under normal use and ser- vice, and when installed in accordance with manufacturer’s recommendations.
