Page 1: Table Of Contents
Audio Dubbing ... 68 Insert Editing ... 69 TROUBLESHOOTING AFTER USE CONTROLS, INDICATIONS AND CONNECTORS LCD Monitor/Viewfinder Indications During Recording ... 79 LCD Monitor/Viewfinder Indications During Playback ... 80 Warning Indications ... 81 CAUTIONS SPECIFICATIONS GLOSSARY OF TERMS INDEX LYT0216-001B...
Page 2: Safety Precautions
76 – 81) and familiarize yourself with button locations, etc. before use..read thoroughly the Safety Precautions that follow. They contain extremely important information regarding the safe use of your new camcorder. You are recommended to carefully read the cautions on pages 82 and 83 before use.
Page 3 Charger other than the one provided with this camcorder. If you lose the provided AC Power Adapter/ Battery Charger or if it malfunctions, please consult your nearest JVC service dealer. NOTES: The rating plate (serial number plate) and safety caution are on the bottom and/or the back of the main unit.
Page 4 If this happens, place the battery pack in your pocket or other warm, protected place for a short time, then re- attach it to the camcorder. As long as the battery pack itself is not cold, it should not affect perform- ance.
Page 5: About Dv
Lens Colour Difference Signal (R-Y/B-Y) Chrominance (C) AUDIO This camcorder separates the data into blocks, writing one block of each data type on each track of the tape. Head tracking direction Sub-Code Area The Time Code and Date/Time data are written here, separate from the video data.
Page 6: Provided Accessories
PROVIDED ACCESSORIES AC Power Remote control unit Adapter/Charger AA-V80EK RM-V711U MiniDV Cassette Tape 30 min Lithium battery CR2025 for remote (DVM-30) M-DV30ME control unit (For function confirmation) Battery pack BN-V814U (x2) Battery pack BN-V856U Shoulder Strap Cable adapter...
Page 7 Editing cable VIDEO/AUDIO cable (ø 3.5 mini-plug, 2 poles) (camcorder to TV or VCR, ø 3.5 mini-plug 4 RCA plug) S-VIDEO cable DC cord Cleaning cloth CD-ROM The CD ROM contains the following 3 software programmes: power pack •JLIP Video Capture •JLIP Video Producer...
Page 8: Getting Started
See the Additional Reference Manual for more information on charging the Battery Pack BN-V856U. NOTES: If you connect the camcorder’s DC cord to the adapter during battery charging, power is supplied to the camcorder and charging stops. When using the AC Power Adapter/Charger, be sure to use the supplied power cord only.
Page 9: Installing The Battery Pack
BN-V856U * Using one battery installed in the camcorder ** Using two batteries; one in the camcorder and one in the provided Power Pack attached to the camcorder Installing The Battery Pack The battery pack does not charge while in the camcorder. Before installation, make sure the battery pack has been charged fully.
Page 10: Indoor Use
Indoor Use When using the camcorder indoors, you can use the AC Power Adapter/Charger instead of a battery. To AC outlet Power lamp When power is supplied, the power lamp lights. To DC OUT jack SUPPLY POWER TO ADAPTER Plug the AC Power Adapter/Charger’s power cord in to an AC outlet.
Page 11: Date/Time Settings
24 hours to charge the clock lithium battery. Then perform the date/time setting before using the camcorder. It is also possible to use the camcorder without the date/time setting. NOTE: If you don’t exit the Date/Time Menu, the clock display will not move but the camcorder’s internal...
Page 12: Loading/Unloading A Cassette
Loading/Unloading A Cassette The camcorder needs to be powered up to load or eject a cassette. PUSH-OPEN button OPEN LCD MONITOR Press the PUSH-OPEN button and open the LCD monitor up to an angle of 90 degrees. OPEN CASSETTE COVER Turn on the power, then slide the OPEN/EJECT switch in the direction of the arrow.
Page 13: Recording Mode Setting
It is recommended that tapes recorded in the LP mode on this camcorder be played back on this camcorder. During playback of a tape recorded on another camcorder, blocks of noise may appear or there may be momentary pauses in the sound.
Page 14: Grip Strap Attachment
GETTING STARTED Tripod Mounting Align the tripod’s screw with the mounting socket on the bottom of the camcorder. The camcorder can be mounted on a tripod even with the Power Pack attached. Bottom of the camcorder (Cont.)
Page 15: Shoulder Strap Attachment
Shoulder Strap Attachment When transporting the camcorder, it is convenient to use the shoulder strap. Dioptre Adjustment Adjust the viewfinder display for best viewing. Lock button SELECT OPERATION MODE Set the Power Dial to “ ” or “ ”. TURN ON CAMCORDER Pull out the viewfinder fully.
Page 16: Remote Control Unit
Remote Control Unit You can use the RM-V711U to control the camcorder. When using the remote control, be sure to point it at the remote sensor. The transmitted beam effective area for indoor use is approx. 5 m. The transmitted beam may not be effective or may cause incorrect operation if the remote sensor is directly exposed to sunlight or powerful lighting.
Page 17: Operation Mode
White Balance Adjustment settings are effective. Allows you (camcorder operator) to become part of the scene once the camcorder is set. This mode is similar to the Self-Timer on film cameras. Allows you to play back a recording, Allows you to switch off the camcorder.
Page 18: Recording
You should already have performed the necessary preparations ( and try recording that way before attempting to use more advanced features. NOTE: Before starting recording, make sure you set the date and time ( recording, you can display them during playback ( ON/OFF Power Dial Power lamp...
Page 19: Start Recording
If 5 minutes elapse in the Record-Standby mode, power shuts off automatically to conserve energy and protect the heads. To turn the camcorder on again, push back and pull out the viewfinder again or close and re-open the LCD monitor. As long as you don’t take out the tape you were...
Page 20 Recording From The Middle Of A Tape When removing a tape on which you were recording, or when you resume recording on a tape after playing back the recording previously made (without taking the tape out between recordings), perform this proce- dure.
Page 21 When recording is resumed, the time code starts counting up again from “00:00:00”. This means the camcorder may record the same time codes as those existing in a previously recorded scene. To prevent leaving a blank portion on a tape, perform the procedure in “Recording From The Middle of A Tape”...
Page 22: Adjust Brightness
Tape Remaining Indicator The time remaining on the tape is automatically monitored and displayed ( “TAPE END” appears. If the indications are turned off, the tape remaining indicator appears when remaining time reaches 2 minutes. Display – – – – – – – – – – BRIGHT Brightness Control You can adjust the brightness of the LCD monitor by...
Page 23 Journalistic shooting In some situations different angles of shooting may be required for more dramatic results. Interface Shooting The person you are shooting can view himself/ herself in the LCD monitor, and you can even shoot yourself while viewing your own image in the LCD monitor.
Page 24 Zoom Select any one of the three powers of magnification and get “closer” to the subject ( Simply set the zoom switch to either zoom in (towards “T”) or zoom out (towards “W”). The zoom speed is variable — the quicker you set the zoom switch, the quicker the zoom action. NOTES: Zoom magnification of over 10X is done through Digital image processing, and is therefore called Digital Zoom.
Page 25: Advanced Features
MENU button/ Select Dial ON/OFF button NOTES: Connect the camcorder to a TV and set “ON SCREEN” to “ON” in the Date/Time Menu. The display appears on the connected TV . The Indicator/Display function overrides these settings. Even if you have set “ON SCREEN” to “ON”, pressing the ON/OFF button for longer...
Page 26 ENGAGE 5S MODE Then press START/STOP. The tally lamp lights and beep sounds to indicate the start of recording, and after 5 seconds the camcorder enters Record-Standby mode. •If you press and hold START/STOP within 5 seconds after recording starts, Record- Standby mode is not engaged.
Page 27 Self-Timer Once the camcorder is set, the camcorder operator can become part of the scene in a more natural way adding the final touch to a memorable picture. When the START/ STOP button is pressed, the tally lamp changes as...
Page 28: Colour Bar
Pro Snapshot Use your camcorder like a regular camera and take a snapshot, or several of them in succession. SELECT OPERATION MODE First turn the Power Dial to “ ”, “ ”, “5S” or “ ” while pressing down the lock button located on the dial.
Page 29 Pro Snapshot mode with no frame* Multi-Analyzer 4** : There is a momentary camera shutter-type blackout together with the sound effect of a shutter closing, which is recorded together with the image. ** : This will be disabled when P.AE/Effects other than “SHUTTER” are activated. : Recorded with Progressive mode.
Page 30 Description of Progressive Scan CCD Progressive Scan is a special image sensing method which, unlike conventional interlace scanning, is able to pick up all the lines of picture information in one Scan. Since the Progressive Scan CCD is capable of outputting 50 full Frames* per second —...
Page 31 Menus The Recording Menu allows you to set these functions: Recording Mode, Wide Mode, Zoom Magnification, Digital Image Stabilizer, Gain Up, Date/Time Menu, System Menu . The following selection procedure applies to Recording Mode, Wide Mode, Zoom Magnifica- tion, Stabilization and Gain Up . Please refer to pages 32, 33 for details.
Page 32 REC MODE WIDE MODE ZOOM GAIN UP TO DATE / TIME MENU TO SYSTEM MENU REC MODE (Recording mode) You can change the tape recording speed. LP tape speed is slower than SP, allowing LP to record 1.5 times longer than SP. If you have shot in SP mode Audio Dubbing and Insert Editing will be possible later. NOTE: Tapes shot in LP mode are recommended to be played back on this unit.
Page 33 During Full-Auto mode, 40X is selected automatically. DIS (Digital Image Stabilizer) When recording while holding the camcorder in your hand, or when shooting a subject with little or no contrast, subtle hand movements will cause shakiness in the recorded image.
Page 34 System Menu The System Menu allows you to set the following functions: Scene, Beep/Tally, Wind Cut, Sound Mode and ID numbers. Power Dial Lock button SELECT OPERATION MODE First turn the Power Dial to “ ”, “5S” or “ ” while pressing down the lock button located on the dial, make sure the LCD monitor is open fully or the viewfinder is pulled out.
Page 35: Wind Cut
Even though not heard while shooting, shutter sound is recorded on the tape. 32kHz 32kHz This number is necessary when connecting the camcorder to a computer [01 to 99]. pg. 26) WIND CUT When activated, this mode helps cut down on noise created by wind.
Page 36 FADE/WIPE Effects IMPORTANT: When the Digital Image Stabilizer is activated, the Fade/Wipe Effects are not available. If certain P.AE/Effects ( Wipe Effects cannot be used. If you select a Fade/Wipe Effect that is unusable in the current situation, the indication blinks. Use these to spice up the transition from one scene to the next.
Page 37 Press START/STOP to start recording, and the Fade In or Wipe In occurs automatically. ACTIVATE FADE OUT OR WIPE OUT When you want to stop recording the scene, press START/STOP. Before the camcorder enters the Record-Standby mode, the Fade Out or Wipe Out occurs automatically. Example...
Page 38 RESUME RECORDING If you start recording a new scene within 5 minutes of the end of the previous recording (without having turned the camcorder’s power off), the previous scene wipes out, revealing the new scene. RECORDING Previous scene end...
Page 39 Random Variations When is selected, the camcorder chooses one of the fades/wipes at random. START/STOP button START RECORDING Press START/STOP. The camcorder does the rest, selecting an effect at random. •The recording starts with a Fade In or Wipe In. If you press START/STOP during record- ing, Record-Standby mode is preceded by a Fade Out or Wipe Out;...
Page 40 FADER AND WIPE MENU MENU FADER — WHITE FADER — BLACK FADER — B.W WIPE — CORNER WIPE — WINDOW WIPE — SLIDE WIPE — DOOR WIPE — SCROLL WIPE — SHUTTER RECORDING EFFECT Fade in or out with a white screen. Fade in or out with a black screen.
Page 41 The new scene wipes in over the previous one from the centre toward the top and bottom of the screen. When this function is activated, the camcorder randomly selects the effect used in scene transition (from the Fade and Wipe effects).
Page 42 P.AE/Effects IMPORTANT: When the Digital Image Stabilizer is activated, the P. AE/Effects other than "SHUTTER" are not available. If certain Fades or Wipes ( P.AE/Effects cannot be used. If you select a P.AE/Effect that is unusable in the current situation, the effect’s symbol begins flashing.
Page 43 SHUTTER (Variable Shutter (Speed) 1/50–The shutter speed is fixed at 1/50th of a second. Black bands that usually appear when shooting a TV screen become narrower. 1/100–The shutter speed is fixed at 1/100th of a second. The flickering that occurs when shooting under a fluorescent light or mercury-vapour lamp is reduced.
Page 44 Record-Standby; it cannot be activated during recording. If START/STOP is pressed instead of the Progres- sive Button, the camcorder starts recording using the operation mode to which the Power Dial is set at that moment ( pg. 17). “PS” disappears.
Page 45 Manual Focus Adjustment The camcorder, in most cases, adjusts the focus from approx. 1.5 cm to infinity automatically. However, when focusing is difficult or when the subject is not in the middle of the LCD monitor or the viewfinder, adjust the focus manually. Factory preset is “AUTO”.
Page 46 Exposure Control Usually this is adjusted automatically. However, when the background is too bright or too dark in compari- son with the subject, the exposure could be corrected manually. Factory preset is “AUTO”. Power Dial Lock button Select Dial SELECT OPERATION MODE First turn the Power Dial to “...
Page 47 Iris Lock Use this function when shooting a moving subject, when zooming, when the subject changes its distance (thus its size in the LCD monitor or the viewfinder), or when you want to lock the brightness level. When the subject is close, keep the iris locked. Even when the subject moves away from you, the image will not darken.
Page 48 A term that refers to the correctness of colour reproduction under various lighting. If the white balance is correct, all other colours will be accurately reproduced. The white balance is usually adjusted automatically. However, the more advanced camcorder operator would prefer to control this function manually and achieve a more professional colour/tint reproduction.
Page 49 Manual White Balance Operation If the camera is operating in manual mode, perform a Manual White Balance when shooting under various types of lighting Power Dial Lock button SELECT OPERATION MODE Follow steps 1 through 4 of the white balance adjustment ( pg.
Page 50: Playback
You can watch what you’ve recorded in the LCD monitor. Tape running indicator LCD monitor SELECT OPERATION MODE Turn the Power Dial to “PLAY” while pressing down the lock button located on the dial. The Power lamp comes on. OPEN LCD MONITOR Open the LCD monitor.
Page 51 To temporarily stop playback, press 6/4. Press again to resume playback. If still playback contin- ues for more than about 3 minutes, the camcorder’s Stop mode is automatically engaged. After 5 minutes in the stop mode, the camcorder’s power is automatically turned off.
Page 52: Advanced Features
Press the Play button to start playback. ACTIVATE ZOOM Press the zoom buttons (T/W) on the remote control. Make sure the remote control is pointed at the camcorder's remote sensor. •Pressing T zooms in. LOCATE PORTION OF MAGNIFIED SCENE You can move the image on screen around to find a particular portion of the picture.
Page 53 VIDEO ECHO START PLAYBACK Press the Play button (4). ACCESS P.AE/EFFECT SELECT MENU Point the remote control at the camcorder’s remote sensor and press EFFECT. The P.AE/ EFFECT Select Menu appears. SELECT P.AE/EFFECT Move the pointer and highlight bar to the desired effect by pressing EFFECT.
Page 54: Playback Menu
Playback Menu The Playback Menu allows you to set the following functions: Playback Sound (32 kHz, 48 kHz), Synchro Comp, Display and Time Code . The following procedure applies to all except Synchro Comp ( Display 48kHz MODE FULL SOUND 32kHz MODE SOUND1 SYNCHRO...
Page 55 Playback Sound During playback, the camcorder detects the sound mode in which the recording was made, and plays the sound back. Select the type of sound to accompany your playback picture. (32 kHz is preset to “SOUND 1” and 48 kHz is preset to “FULL SOUND”.)
Page 56: Basic Connections
VCR/TV Connection Please refer to your VCR and/or TV instruction manual(s) when connecting. Connector is under the cover. To AV OUT connector VIDEO/AUDIO cable (provided) To DC IN jack Core filter DC cord Connector is under the cover. VIDEO/AUDIO cable (provided) To AV OUT connector To S-VIDEO OUT connector...
Page 57 To DC IN jack Core filter DC cord CONFIRM POWER-OFF STATUS Make sure the camcorder’s power is off. CONNECT CAMCORDER TO TV OR VCR Pull out the connector cover and open it. Connect as shown in the illustration pg. 56, 57).
Page 58: Advanced Connections
Connection To A Personal Computer This camcorder can transfer still images to a personal computer by using the provided software when connected as shown in the illustration below. It is also possible to transfer still images to a personal compu- ter with a DV connector-equipped capture board installed.
Page 59 Connection to the Digital Printer GV-DT1 (optional) allows you to print out the images or to transfer the captured image from the Digital Printer to a personal computer. It is also possible to copy recorded scenes from the camcorder onto another video unit equipped with a DV connector. This function is called Digital Dubbing ( pg.
Page 60: Editing
Dubbing You can copy recorded scenes from the camcorder onto a videotape. Refer to your VCR’s instruction manual for details. Play button Stop button Lock button Power Dial MAKE CONNECTIONS Connect the camcorder to your VCR as shown in the illustration on pages 56, 57.
Page 61: Digital Dubbing
Digital Dubbing It is also possible to copy recorded scenes from the camcorder onto other video unit equipped with a DV connector. Since digital signal is sent, there is little if any image or sound deterioration. Connector is under the cover.
Page 62: Brand Setting
RM-V711U (provided) VCR BRAND BUTTONS NAME (A) (B) PHILIPS IMPORTANT Although the MBR is compatible with JVC VCRs and those of many other makers, it may not work with yours or may offer limited functions. NOTES: SANYO SELECO, SHARP SONY...
Page 63: Random Assemble Editing
56, the VCR’s remote pause terminal using an editing cable. If you use a JVC VCR not equipped with a remote pause terminal or a non-JVC VCR, connect the camcorder's EDIT jack to the remote control's remote pause connector using an editing cable.
Page 64 Since time codes register time only as accurately as seconds, the time code total time may not match the total program time exactly. Turning off the camcorder’s power erases all registered Edit-In and Edit-Out points. If you use Sepia or Monotone P.AE/Effects, you can’t use the Dissolve or Black &...
Page 65 When the editing cable is connected to the Pause terminal during dubbing, make sure the remote control is pointed at the VCR’s sensor, and that the path between the two is unobstructed. If, during Random Assemble Editing, you press any button on the camcorder, its Record-Standby mode is automatically engaged.
Page 66: For More Accurate Editing
Some VCRs make the transition from Record-Standby to Record mode faster than others. Even if you begin editing for the camcorder and the VCR at exactly the same time, you may lose scenes you wanted, or find that you’ve recorded scenes you didn’t want. For a cleanly edited tape, confirm and adjust the timing of the camcorder against your VCR.
Page 67 0 . 0 DISPLAY TIMECODE ACCESS PLAYBACK MENU Point the remote control at the camcorder’s remote sensor and press R.A. EDIT ON/OFF to make the Random Assemble Editing menu disappear, then press MENU. The Playback Menu appears on the TV screen.
Page 68: Audio Dubbing
If you dub onto a blank space on the tape, the sound may be disrupted. Make sure you only edit recorded areas. If feedback or howling occurs during TV Playback, move the camcorder’s microphone away from the TV, or turn down the TV’s volume.
Page 69: Insert Editing
Insert Pause mode. Press again to resume editing. RM-V711U (provided) Lock button Power Dial STOP EDITING Press STOP while the camcorder is in the Insert-Pause mode. NOTES: P.AE/Effects ( pg. 42) can be used to spice up the scenes being edited during Insert Editing.
Page 70: Troubleshooting
If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer. SYMPTOM 1. No power is supplied. 2. “SET DATE/TIME!” appears. 3. Recording cannot be performed. 4. There is no playback picture.
Page 71 SYMPTOM 10. The tape is moving, but there’s no picture. 11. In the 5-Second mode, recording ends before 5 seconds have elapsed. 12. Pro Snapshot mode cannot be used. 13. Digital Zoom doesn’t work. 14. P.AE/Effects and Fade/ Wipe Effects don’t work. 15.
Page 72 Dissolve before beginning recording. The effects are then automatically activated ( pg. 38). •Do not turn off the camcorder’s power after setting Edit-In and Edit-Out points, as they will all be erased ( pg. 38). •The camcorder automatically shuts off...
Page 73 •When the LCD monitor's fluorescent light reaches the end of its service life, images on the LCD monitor become dark. Consult your nearest JVC dealer. 31. •The light used to illuminate the LCD monitor causes it to become hot.
Page 74 If the indication remains even though you repeat the above two or three times, please consult your nearest JVC dealer. 40. •To protect the battery, it is recommended to charge it in places with a tempera- ture of 10°C to 30°C pg.
Page 75: After Use
AFTER USE Cleaning The Camcorder Hook LCD monitor REMOVE POWER SUPPLY Remove the battery pack or disconnect the AC Power Adapter/Charger ( CLEAN EXTERIOR Wipe gently with a soft cloth. •Put cloth in diluted mild soap and wring it well to wipe off heavy dirt. Then wipe again with a dry cloth.
Page 76: Controls, Indications And Connectors
CONTROLS, INDICATIONS AND CONNECTORS Connector cover Pull this out to open. q w e &...
Page 77 Progressive Dial (PROGRESSIVE) Turn for Progressive Video Recording or Pro Snapshot Recording. & Progressive Button ( When this button is pressed, the camcorder starts Progressive Mode Recording (high resolution). When pressed during playback, a playback snapshot is taken. OPEN/EJECT switch ( Slide the switch down when loading/unloading a tape.
Page 78 However, headphones equipped with volume control cannot be used. pg. 58, 59, 61) Bottom of the camcorder DC IN jack ( pg. 10) The DC cord of an AC Power Adapter can be connected.
Page 79: Lcd Monitor/Viewfinder Indications During Recording
Appears when the wind cut mode is engaged to cut down on noise created by wind. ( Displays the 5 second mode recording or animation recording mode. Displays the sound mode for approx. 5 seconds after turning on the camcorder. Displays the date/time.
Page 80: Lcd Monitor/Viewfinder Indications During Playback
CONTROLS, INDICATIONS AND CONNECTORS LCD Monitor/Viewfinder Indications During Playback Displays the sound mode. Displays the recording mode of the tape being played back. Appears during playback of scenes recorded in the Progressive Mode. Appears while a tape is running. : Playback : Fast-Forward/High-speed search : Rewind/High-speed search : Forward slow-motion...
Page 81: Warning Indications
Press the reset button after removing the power supply (battery, etc.), and wait a few minutes for the indication to clear. When it does, you can resume using the camcorder. If the indication remains, consult your nearest JVC dealer.
Page 82: Cautions
... vertically, in their original cases. Main Unit 1. For safety, DO NOT ..open the camcorder’s chassis..disassemble or modify the unit..short-circuit the terminals of the battery pack. Keep it away from metallic objects when not in use.
Page 83 20 seconds, it stops automatically. Also refer to the Cleaning Cassette’s instructions. If, after using the Cleaning Cassette, the problems still exist, consult your nearest JVC dealer. Mechanical moving parts used to move the video heads and video tape tend to become dirty and worn out over time.
Page 84: Specifications
CAMCORDER General Power Power consumption Format Signal format Video signal recording format Cassette Tape Speed Maximum recording time Pickup Lens LCD monitor Viewfinder Operating temperature Operating humidity Storage temperature Dimensions Weight Video Output S VIDEO output DV output Digital still output...
Page 85: Glossary Of Terms
(See “White Balance”.) AC Power Adapter/Charger Used when charging the battery. Or, when connected directly to the camcorder, it can be used as a power supply. Auto focus Focus can be set for automatic adjustment, for beginners who find the adjustment difficult.
Page 86: Index
Audio Dubbing ... Auto Focus ... Auto Shut off ... Battery ... Battery Low ... Beep/Tally ... Charging ... Cleaning The Camcorder ... Colour bar (BAR) ... Connections ... Date/Time Display ... Date/Time Settings ... Digital Dubbing ... Digital Image Stabilizer ...
