Barrel Chair

The barrel chair has controls on the bottom right and left sides under the chair skirt that controls
the swivel and side to side action of the chair.

Euro Recline with Ottoman

To recline, sit down, grasp the armrest's and lean back to recline. Since a seat belt is not
provided, do not use the euro recliner while in transit.

Dinette

Booth
The dinette will seat four people. Storage and/or various systems components can be accessed
from above by removing the seat cushions and lifting the seat supports.
Free Standing
Since the free standing dinette chairs are not secured to the floor, and not equipped with seat belts,
they should not be occupied while the recreation vehicle is in motion. These chairs should be
stored securely while the vehicle is in motion.
Pedestal
The dinette can also be converted into an additional bed if required. To convert, lift the table top off
of the two support posts. Remove the support posts from the floor and lay them down between the
seats. Insert the table top between the seats on the ledges provided. Loosen the seat cushion from
the Velcro fasteners and slide each together to form the bed. Reverse this process when
reconverting to the dinette configuration.
Wall Mounted
This dinette can also be converted into an additional bed. Lift the aisle side of the table and and
pinch in the pins on the table leg to collapse the leg. Unhook from side wall and swing into place.
The table supports on the dinette base. Loosen the seat cushion from the Velcro fasteners and
slide each together to form the bed. Reverse this process when reconverting to the dinette
configuration.

Lounge Table

This table is stored in a folded position next to the barrel chair. To raise for use, pull out on the
bottom to release it from its securing catch, and swing up. When raised, reach under the table and
swing the supporting leg down until it locks into position. Adjust the length of the support leg, so
that the table will be level when resting on it. To adjust the support leg length, pull back on the
spring clip, releasing the detent from the adjustment hole it is presently in. While holding the spring
clip back, slide the leg to the desired length, then release the spring, allowing the detent to lock
into the new hole.
To fold back for storage, reverse the previous procedure; shortening the support leg, and folding
the leg up against the bottom of the table top. Lower the table top, and push in on the bottom to
secure it into the catch that keeps the table from moving while traveling.
