Summary of Contents for Whirlpool Refrigarator

  • Page 1 Gebrauchsanweisung Brugsanvisning Instructions for use Bruksanvisning Mode d’emploi Käyttöohje Gebruiksaanwijzing Manual de utilização Istruzioni per l’uso Instrucciones para el uso Návod k použití Instrukcje użytkowania Návod na použitie Használati utasítás Instrucţiuni de utilizare Инструкци за употреба Инструкции по эксплуатации Я...

  • Page 2: Table Of Contents

    INSTRUCTIONS FOR USE BEFORE USING THE APPLIANCE SAFEGUARDING THE ENVIRONMENT PRECAUTIONS AND GENERAL RECOMMENDATIONS HOW TO INCREASE FREEZER STORAGE CAPACITY FUNCTIONS STORE FOOD IN THE APPLIANCE TWIST ICE MAKER RECOMANDATION IN CASE OF NO USE OF THE APPLIANCE ENERGY-SAVING TIPS MAINTENANCE AND CLEANING LED LIGHT SYSTEM TROUBLESHOOTING GUIDE...

  • Page 3: Before Using The Appliance

    BEFORE USING THE APPLIANCE • This appliance is intended to be used in 1. After unpacking the appliance, make sure it is household and similar applications such as not damaged and that the door closes properly. - staff kitchen areas in shops, offices and other Any damage must be reported to the dealer working environments; within 24 hours of delivery of the appliance. - farm houses and by clients in hotels, motels 2. Wait at least two hours before switching the and other residential type environments; appliance on, to ensure that the refrigerant - bed and breakfast type environments; circuit is fully efficient. 3. Installation and the electrical connection must be carried out by a qualified technician To ensure best use of your appliance, carefully read the operating instructions according to the manufacturer’s instructions which contain a description of the product and in compliance with the local safety and useful advice.

  • Page 4: Precautions And General Recommendations

    PRECAUTIONS AND GENERAL RECOMMENDATIONS INSTALLATION SAFETY • The appliance must be handled and installed • Do not store explosive substances such as by two or more persons. aerosol cans with a flammable propellant in this • Be careful not to damage the floors (e.g. appliance. parquet) when moving the appliance. • Do not store or use petrol, flammable liquids • During installation, make sure the appliance or gas in the vicinity of this or other electrical does not damage the power cable. appliances. The fumes can cause fires or • Make sure the appliance is not near a heat explosions. source. • Do not use mechanical, electric or chemical • To guarantee adequate ventilation, leave a means other than those recommended by the space on both sides and above the appliance. Manufacturer to speed up the defrost process. The distance between the rear of the appliance • Do not use or place electrical devices inside the and the wall behind the appliance should be appliance compartments if they are not of the 50mm. A reduction of this space will increase type expressly authorised by the Manufacturer.

  • Page 5: How To Increase Freezer Storage Capacity

    Notes: frequency of door opening, as well as location • Do not block the air outlet area (on the back of the appliance. Temperature setting should wall) with food products take into consideration these factors. • If the freezer is provided with a flap, it is • Unless otherwise specified the appliance possible to maximize the storage volume by accessories are not dishwasher safe. removing the flap (by bending it). • The bigger distance at the backside of • All shelves, flaps and pull-out baskets are appliance to the wall, the higher is energy- removable. saving. • The internal temperatures of the appliance may be affected by the ambient temperature, HOW TO INCREASE FREEZER STORAGE CAPACITY You can increase storage capacity in the freezer • placing the food products directly on the freezer compartment by: shelves. • removing the baskets / flaps (by bending it) to • removing the Twist Ice Maker (separately) or allow the storage of big products. together with the docking station.
  • Page 6 KEY LOCK BLACK OUT ALARM This function prevents anyone from inadvertently After a power blackout, your product is designed changing settings or switching off the appliance. to automatically monitor the temperature in To lock the keys, press Stop Alarm button for the freezer when electricity is resupplied. If the temperature in the freezer rises above freezing 3 seconds until the display shows the Key Lock level, the Black Out indicator turns on, the indicator and an acoustic signal confirms the Alarm indicator blinks and the acoustical alarm function has been selected. After 3s. indicator sounds when electricity is resupplied. To reset the goes off. When activated, pressing the other buttons (except Stop Alarm button) activates an alarm press the Stop Alarm button just once. audible signal and on display flashes the Key Lock In case of Black Out Alarm, the following actions indicator . Any alarm can be deactivated when are recommended: Key Lock function is active. • If the food in the freezer is unfrozen but still cold, all the food in the freezer should be eaten To unlock the keys, follow the same procedure within the next 24 hours. until the display shows the Key Lock indicator • If the food in the freezer is frozen, this indicates and an acoustic signal confirms the function has the food was thawed and then refrozen when been disengaged. After 1s. indicator...
  • Page 7 7. The “Shock Freeze” function is automatically • Incompatibility with the “Shock Freeze” deactivated 4-5 hours after its activation: the function indicator switches off and the fans are To guarantee optimal performance, the “Shock deactivated. Freeze” and “Fast Freeze” functions cannot be The “Shock Freeze” function may nevertheless used at the same time. Therefore, if the “Fast be switched off at any time as desired, by Freeze” function has been already engaged, it briefly pressing the button on the control has to be disengaged first to activate the “Shock panel: the indicator switches off and the Freeze” function (and vice-versa). fans are deactivated. ECO NIGHT FUNCTION Attention: (NIGHT TIME RATE) • Incompatibility with the “Fast Freeze” The Eco Night function enables appliance energy function consumption to be concentrated in the reduced To guarantee optimal performance, the “Shock rate hours (generally at night), when electricity is...

  • Page 8: Store Food In The Appliance

    STORE FOOD IN THE APPLIANCE TIPS FOR FREEZING AND STORING FRESH • Always observe the storage information on the FOOD package. • Before freezing, wrap and seal fresh food in: aluminium foil, cling film, air and water-tight plastic bags, polythene containers with lids or freezer containers suitable for freezing fresh food. • Food must be fresh, mature and of prime quality in order to obtain high quality frozen food. • Fresh vegetables and fruit should preferably be frozen as soon as they are picked to maintain the full original nutritional value, consistency, colour and flavour. Some meat, especially game, should be hung before it is frozen. NOTE: • Always leave hot food to cool before placing in the freezer. • Eat fully or partially defrosted foods immediately. Do not refreeze unless the food is cooked after it has thawed. Once cooked, the thawed food can be refrozen.

  • Page 9: Twist Ice Maker

    TWIST ICE MAKER HOW TO MAKE ICE CUBES HOW TO TAKE ICE CUBES You can remove the complete Twist Ice Maker 1. Make sure that the storage bin is in place under (press and hold (1) the leveler on the left and push the ice tray. If not, slide into place. it (2) towards you) or you can just remove the ice 2. Twist one of levers firmly in the clockwise cube tray by pulling it (3) towards you. direction until the tray twists slightly. The ice cubes fall into the storage bin. or Fill the tray with potable water (maximum level = 2/3 of the overall capacity). 3. Repeat Step 2 for the other half of the tray, if necessary. You can make ice cubes (see the chapter “HOW TO MAKE ICE CUBES”) and store them in the storage bin and pull it towards you. 4. To get ice, slightly lift up the storage bin and pull it towards you. NOTE: if you prefer, you can remove the entire Twist Ice Maker from the appliance, to take the or ice cubes wherever is convenient for you (for example: directly on the table). Place again the Twist Ice Maker in its seat, or reinsert the ice cube tray within the Twist Ice Maker. Take care not to spill water.

  • Page 10: Recomandation In Case Of No Use Of The Appliance

    RECOMANDATION IN CASE OF NO USE OF THE APPLIANCE Short vacation Power failure There is no need to disconnect the appliance from In the event of a power failure, call the local office the power supply if you will be away for less than of your electricity supply company and ask how three weeks. Use up perishable food, freeze other long it is going to last. food. Note: Bear in mind that a full appliance will stay cold longer than a partially filled one. Long vacation If ice crystals are still visible on the food, it may be Remove all the food if you are going away for three frozen again, although flavour and aroma may be weeks or more. affected. 1. Empty the ice bucket. Fix some wooden or plastic wedges to the upper If food is found to be in a poor condition, it is best part of both doors with adhesive tape and leave to throw it away. the doors open enough for air to circulate inside For power failures lasting up to 24 hours. both compartments. This will prevent odour and 1. Keep both doors of the appliance closed. This mould from setting in. will allow the stored food to stay cold as long as possible.

  • Page 11: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Before any cleaning or maintenance operation, unplug the appliance from the mains or disconnect the electrical power supply. Periodically clean the appliance with a cloth and a solution of lukewarm water and neutral detergent specifically for refrigerator interiors. Never use detergents or abrasives. Never clean refrigerator parts with flammable fluids. The fumes can create a fire hazard or explosion. Clean the outside of the appliance and the door seal with a damp cloth and dry with a soft cloth. Do not use steam cleaners. Clean the condenser (back the appliance) using a vacuum cleaner, proceeding as follows: remove the front plinth and proceed to clean the condenser. Important: • The buttons and control panel display must not be cleaned with alcohol or alcohol-derived substances, but with a dry cloth. • The refrigeration system pipes are located near the defrost pan and can become hot. Periodically clean them with a vacuum cleaner. • To remove or insert the glass shelf, move up the front part of the shelf to pass the stopper.. LED LIGHT SYSTEM The light system inside the freezer compartment uses LEDs light, allowing a better lightning as well as very low energy consumption. If the LED light system does not work, please contact the Service to replace it.

  • Page 12: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Before contacting After-sales Service… Performance problems often result from little things you can find and fix yourself without tools of any kind. Noises coming from your Some of the functional noises you might hear: appliances are normal A hissing sound when switching on the appliance for the first since it has a number time or after a long pause. of fans and engines to A gurgling sound when refrigerant fluid enters into the pipes.
  • Page 13 If the appliance • Are the appliance controls correctly set? temperature is too high: • Has a large amount of food been added to the appliance? • Check that the door is not opened too often. • Check that the door close properly. • Make sure that air flow vents inside the compartment are not blocked, as this prevents the circulation of cold air. If there is moisture • Make sure that air flow vents inside the compartment are not build-up: blocked, as this prevents the circulation of air. • Make sure that the food is properly packaged. Dry any dampness on food containers before placing them in the appliance. • Check that the doors are not opened too often. When the door is opened, humidity from the room air enters the appliance. The more often the door is opened, the faster humidity builds up, especially when the room itself is very humid. • If the room is very humid, it is normal for moisture to build up inside the refrigerator. If the doors do not open • Check that food packages are not blocking the door.

  • Page 14: After-Sales Service

    AFTER-SALES SERVICE Before contacting After-Sales Service: • the Service number (the number after the word Switch the appliance on again to see if the SERVICE on the data plate on the inside of the problem has been solved. If it has not, disconnect appliance), the appliance from the power supply and wait for • your full address, about an hour before switching on again. • your telephone number and area code. If, after performing the checks described in the Troubleshooting Guide and switching the appliance on again, your appliance still does not work properly, contact the After-sales Service, explain the problem. Specify: Note: • the model and appliance serial number (stated The direction of door opening can be changed. If on the rating plate), this operation is performed by After-sales Service • the nature of the problem, it is not covered by the warranty. ELECTRICAL CONNECTION FOR GREAT BRITAIN AND IRELAND ONLY Warning - this appliance must be earthed Fuse replacement If the mains lead of this appliance is fitted with a BS 1363A...
  • Page 21 5019 300 02992 05/14...
