VACUUM CLEANER SERVICE MANUAL CAUTION BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS" IN THIS MANUAL. MODEL : V-C9352WA V-C9363WA V-C9364WAU V-WA266ND... -
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS..................3 CAUTIONS......................3 DESCRIPTION ....................4 SPECIFICATIONS ....................5 DISASSEMBLY ....................5~8 TROUBLESHOOTING ...................9~11 BLOCK DIAGRAM .....................12 SCHEMATIC DIAGRAM..................12 EXPLODED VIEW ..................13~16 REPLACEMENT PARTS LIST ..............17~18 APPENDIX......................19... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS BEFORE OPERATING THIS VACUUM CLEANER, READ THIS SERVICE MANUAL THOROUGHLY, AND OBSERVE EACH POINT CAREFULLY. 1. Empty the dust tank, when the dust thank is full. 4. Attachments • Main spray nozzle: Shampoo cleaning for carpet 1) If the dust thank is full, intake power will be and floor. -
Page 4: Description
DESCRIPTION Handle Cover Shampoo Hose Clamp Lever Dust Tank Hose Handle Shampoo Tank Cap Pipe Shampoo Tank Cord Reel Button Inlet Dust Yellow Mark Red Mark Switch Button Shampoo Button Pipe Power Cord Optional Carpet Master Carpet/Floor Nozzle Window Master Spray Nozzle Spray Nozzle Shampoo Bottle... -
Page 5: Specifications
SPECIFICATIONS • MODEL : REFER TO THE COVER PAGE • ATTACHMENTS • POWER SOURCE : ON RATING PLATE F/HOSE ASSY .............1EA • POWER CONSUMPTION : ON RATING PLATE STAINLESS PIPE ............2EA • CAPACITY : WATER 5.0 , DRY 6.0 CARPET MASTER............1EA •... - Page 6 3) Separate Dust Tank and Shampoo Tank. 2) Remove seven screws fastening the Body Cover Assy on the Body Base Assy. Dust Tank Shampoo Tank 2. Body Base Assy Replacement 3) Separate Body Cover Assy by lifting. 1) Separate Exhaust Cover Assy.
- Page 7 3. Motor Assy Replacement 5. Pump Assy Replacement 1) Take out the Snap Ring and pull out the pump • Lift the motor assembly in direction of the arrow. tube. • Stripe off lead wires. Snap Snap Ring Ring 4. Cord Reel Assy Replacement 2) Take out buttons on button setting.
- Page 8 3) Remove two screws fastening Button Setting and 5) Separate E-ring using pump nipple. separate the button setting on body base. Button Setting 4) Remove four screws fastening the Pump on the Body Base.
-
Page 9: Troubleshooting
TROUBLESHOOTING 1. SWITCH ON BUT MOTOR DOES NOT RUN Checking Cause Solution Check the power Insert again Poor plug insertion source. Power cord cut Repair or exchange Interior lead wire cut Exchange the lead wire Motor(stator armature) Exchange the motor coil cut or damaged Poor contact carbon Exchange or repair... - Page 10 3. SWITCH OFF BUT MOTOR RUNS Poor connection Repair Poor switch Exchange the switch 4. WEAK SUCTION POWER Exchange the carbon Carbon brush defaced brush or the motor Exchange the motor Motor armature cut Low rotation speed Foreign matters attached Remove the foreign to the impeller matters...
- Page 11 6. VIBRATION NOISES Loose parts Secure firmly Unbalanced motor Exchange or repair assembly the motor Foreign matters are attach Remove the foreign to the impeller matters Poor carbon brush Exchange the carbon rectification brush or the motor Armature is cut or foreign Exchange motor matters attached Remove foreign matters...
-
Page 12: Block Diagram
SCHEMATIC DIAGRAM MOTOR S/W1 PWB ASM MOTOR MOTOR S/W2 CORD REEL ASSY PUMP S/W1 PUMP PUMP S/W2 SCHEMATIC DIAGRAM PUMP S/W MOTOR S/W THERMAL CUTOUT PUMP 0.47∝F MOTOR 250V -12-... -
Page 13: Exploded View
EXPLODED VIEW BASE ASS'Y, BODY 130411 146871 168711 139202 250204 250203 146811 249701 COVER ASS'Y, 139205 EXHAUST 266011 252302 235514 139204 450203 452112 343501 239401 243501 158591 239202 444801 737001 239402 C43501 236601 140362 130401 146611 144411 158591 168771 158592 247891 -13-... - Page 14 TANK ASS'Y, DUST TANK ASS'Y, SHAMPOO 748395 748391 333003 750062 333002 750061 140361 136501 748394 340365 748382 748381 COVER ASS'Y, BODY 235511 231121 250202 135502 249702 349011 139201 152301 235501 -14-...
- Page 15 COVER ASS'Y, TOP 335511 336501 336502 348601 335504 339203 348602 335505 139203 347691 349742 135515 152313 -15-...
- Page 16 452151 449401 449321 452111 552492 652011 652032 652491 652031 552500 552498 552496 552497 650581 650771 552491 552501 552499 -16-...
-
Page 17: Replacement Parts List
REPLACEMENT PARTS LIST LOCATION No. DESCRIPTION P/No REMARK C43501 E-RING 4O80070C 130401 BASE, BODY 3040FI1518D 130411 BASE ASSY, BODY 3041FI1519D 135502 COVER, FRONT 3550FI1742D 135515 GUIDE, FILTER 4974FI2403A 136501 HANDLE, CARRIER 3650FI3339A 139201 PACKING, DUST SEAL 3920FI3543T 139202 PACKING, MOTOR MOUNTING 3920FI3847A 139203 PACKING, DUST SEAL... - Page 18 REPLACEMENT PARTS LIST LOCATION No. DESCRIPTION P/No REMARK 335505 COVER, INNER 3550FI1744D 335511 COVER ASSY, TOP 3551FI1657A 336501 HANDLE, UPPER 3850FI2424A 336502 HANDLE, LOWER 3850FI2425A BLACK 339203 PACKING, DUST SEAL 3920FI3534U 340365 PACKING, DUST SEAL 3920FI4718V 343501 PACKING, DUST SEAL 3920FI3524W 347691 FLOAT...
- Page 19 REPLACEMENT PARTS LIST • COLOR & PARTS NUMBER LOCATION NO. DESCRITION DEEP GRAY BLACK TITAN SILVER PETER RED REMARK 130401 BASE, BODY 3040FI1518D 3040FI1518C 3040FI1518B 3040FI1519D 3040FI1519C 3040FI1519B C-2 TYPE 130411 BASE ASSY, BODY 3040FI1519F B-3 TYPE 3040FI1519G C-1 TYPE 135502 COVER, FRONT 3550FI1742D...
-
Page 20: Appendix
APPENDIX • THE TYPE OF POWER CORD & PARTS NUMBER Cord Reel ASS'Y P/No. Type Type of plug (L/No. : 146871) A - 1 12.7 S - 1 C - 2 4687FI1482K C - 1 3040FI1519G Color identification of fuse 4687FI1482Q Brown B - 3... - Page 21 Memo -21-...
- Page 22 Memo -22-...
- Page 23 May, 2004 P/No.: 3828FI3854A Printed in Korea...
