Summary of Contents for Gulf Stream Travel Trailer
-
Page 1: Fifth Wheel
TRAVEL TRAILER FIFTH WHEEL OWNER’S MANUAL Nappanee, Indiana GULF STREAMERS INTERNATIONAL RV CLUB APPLICATION – PAGE 43... - Page 2 Please read over this manual and all the other owner’s manuals included in your packet. It will make your initial trips in your new GULF STREAM much more pleasurable and save time in the long haul.
-
Page 3: Table Of Contents
TIRE MARKINGS………………………………………………………………………………………………………………. 16 TIRE LOAD RATINGS…………………………………………………………………………………………………………. 17 TIRE AIR PRESSURE…………………………………………………………………………………………………………. 17 TIRE MAINTENANCE…………………………………………………………………………………………………………. 17 WHEEL NUT TORQUE……………………………………………………………………………………………………….. 17 ELECTRIC BRAKE SYSTEM………………………………………………………………………………………………… 18 TRAVEL TRAILER “HOUSE” SYSTEMS………………………………………………………………………………..… 18 SAFETY…………………………………………………………………………………………………………………………..18 ELECTRICAL…………………………………………………………………………………………………………………….19 12-VOLT/110-VOLT……………………………………………………………………………………………………………. 19 30-AMP AND 50-AMP 110-VOLT SERVICE……………………………………………………………………………….. 19 POWER CONVERTER………………………………………………………………………………………………………... 20 GROUND FAULT INTERRUPTER……………………………………………………………………………………………... - Page 4 OPERATION……………………………………………………………………………………………………………………. 24 FILLING THE LP TANK……………………………………………………………………………………………………….. 24 GAS LINE CHECK……………………………………………………………………………………………………………… 24 REGULATOR PRESSURE……………………………………………………………………………………………………. 25 GAS TANK AND REGULATOR FREEZE UP………………………………………………………………………………. 25 HOSE REPLACEMENT……………………………………………………………………………………………………….. 25 REGULATOR VENT MAINTENANCE……………………………………………………………………………………….. 25 PLUMBING…………………………………………………………………………………………………………………….. 25 FRESH WATER………………………………………………………………………………………………………………… 25 CITY WATER…………………………………………………………………………………………………………………… 26 WATER TANK………………………………………………………………………………………………………………….. 26 WATER SYSTEMS CONVENIENCE CENTER…………………………………………………………………………….. 26 SANITIZING THE WATER TANK…………………………………………………………………………………………….
-
Page 5: Gulf Stream Warranty
Such notice must be addressed to the National Retail Service Manager, Gulf Stream Coach, Inc., P.O. Box 1005, Nappanee, Indiana 46550, and must be received by Gulf Stream within the earlier of 30 days after the issue is known to the initial retail purchaser or 10 days subsequent to the expiration of this Limited Warranty. - Page 6 The Purchaser must inspect the recreational vehicle at the time of delivery to ensure that it is acceptable as delivered. This recreational vehicle has been sold to an independent dealer, and not an agent of Gulf Stream, for resale in the ordinary course of the dealer's business, on terms and conditions and equipped as the dealer and the initial retail purchaser determine, and the initial retail purchaser’s agreement is solely with the dealer, not Gulf Stream.
-
Page 7: Component Warranty Coverage And Service
This Limited Warranty gives Purchaser specific legal rights and the Purchaser may also have other rights that may vary from state to state. Gulf Stream is not responsible for any representation or warranty that is not herein stated unless required by applicable state or federal law. -
Page 8: Lp Gas Heating System And Lp Gas Appliance Safety Regulations
LP GAS HEATING SYSTEM AND LP GAS APPLIANCE SAFETY REGULATIONS The United States Government requires that the manufacturer of this recreational vehicle provide the following safety information that has been provided by the National Fire Prevention Association (NFPA) and the American National Standards Institute (ANSI). -
Page 9: General Safety
Carbon Monoxide. Under normal conditions your coach should be free from Carbon Monoxide at any given time. Due to the safety hazards of Carbon Monoxide (CO), each Gulf Stream motor home is equipped with a CO Detector. Carefully read the instructions included with your CO detector to ensure proper use and maintenance. Most CO detectors require only occasional dusting and weekly testing. -
Page 10: Tow Vehicle Requirements
TOW VEHICLE REQUIREMENTS Prior to hitching and pulling your travel trailer or fifth wheel, make sure your tow vehicle is properly suited and equipped for such use. Read your tow vehicle’s owner’s manual sections on trailer towing, Gross Combined Weight Rating, hitch requirements, sway control requirements, braking requirements, and all related areas for proper towing. -
Page 11: Sway Control
EQUALIZING HITCH LOAD COMPARISON SWAY CONTROL Except for the very light folding tent campers, most trailers should employ some type of sway control device. There are several types of these devices available, operating on different principles such as friction, cam action, and computer operated braking of the trailer wheels. -
Page 12: Hitch Height Adjustment
HITCH HEIGHT ADJUSTMENT If the spring bars on the equalizer hitch are fitted with chains for fastening to the trailer “A” frame, the selection of the proper link to be used at the connecting point can best be chosen by “hitching up” on a level road or driveway. After hitching up the trailer visually inspect how level the tow vehicle/trailer combination is and adjust the chain link selection accordingly. -
Page 13: Electrical Connection
ELECTRICAL CONNECTION Plug the pigtail on the fifth wheel or travel trailer into the electrical harness on the truck. Be sure there is enough slack to allow the vehicle to turn without disconnecting the pigtail. Make sure all lights and the brakes work prior to moving the fifth wheel or travel trailer. -
Page 14: Vehicle Loading
Refer to the manufacturer’s labels posted inside and outside of the unit for unit weight information (See Fig. 1 & Fig. 2). -
Page 15: Weighing Your Trailer
Please review the following guidelines for weighing your trailer. TRAVEL TRAILERS Pull your fully loaded travel trailer onto the scale and leave it hitched to the vehicle as shown in diagram A. This will give you the actual Gross Axle Weight (GAW) as pulled down the road. -
Page 16: Fifth Wheels - Weighing
FIFTH WHEELS Pull your fully loaded fifth wheel onto the scale per Diagram D. This will give you the actual Gross Axle Weight (GAW) as pulled down the road. Check your Federal ID label (FIG. 2) to see what the maximum rating for your axles is and make sure they are not overloaded. -
Page 17: Vehicle Weight Information Label
The tires installed on your vehicle have been pre-selected as the proper size and weight by the chassis manufacturer for the type and weight of the travel trailer built. The Tire and Loading Information label (Fig. 4) located on the side of the trailer will show the proper tire size for your coach and the recommended air pressures. -
Page 18: Tire Load Ratings
WHEEL NUT TORQUE Wheel nut torque is a very important safety measure that should be checked often. Travel trailer tires may carry higher loads than typical passenger car tires. Further, travel trailer tires on tandem axle trailers are subject to high side-to-side load stress when making slow or tight turns. -
Page 19: Electric Brake System
ELECTRIC BRAKE SYSTEM The electric brakes on your travel trailer of fifth wheel are similar to those on your automobile; the difference being that they are activated by 12 volt electrical impulse as opposed to a hydraulic system. The impulse comes from a brake controller, which in affect regulates the flow of electrical current to the trailer brakes. -
Page 20: Electrical
This equipment is available only on models that have generator preparation. ELECTRICAL Your GULF STREAM is equipped with two (2) separate electrical systems that provide your vehicle with power on the road and in camp. A chassis 12 volt DC system and a 110 volt AC system are installed. -
Page 21: Power Converter
Listed below are components that might be used in Gulf Stream vehicles and the maximum amperage draw each one has. Whether your power supply is 30-amps or 50-amps this chart may help you decide which components you can safely use for an extended period without damage. -
Page 22: Ground Fault Interrupter
replace it with a new fuse of the proper rating. If the fuse continues to fail, contact your nearest dealer. NEVER REPLACE A FUSE WITH A HIGHER RATED FUSE THAN WHAT IS DESIGNATED! Look through here Good fuse Blown fuse (FIG. -
Page 23: Battery Types And Charging
BATTERY TYPES AND CHARGING Only similar batteries should be connected together in one bank. Do not connect old and new batteries, or wet and gel cell batteries together. Deep-cycle batteries are usually rated in Amp-hours, which is based on a 20-hour discharge rate. -
Page 24: Raising And Lowering Tv Antenna
RAISING AND LOWERING YOUR ANTENNA RAISING: ROTATING: LOWERING: Crank clockwise until some Pull down with both hands and Rotate plate until arrows align. resistance is felt on handle. rotate plate for better signal. Crank counter-clockwise until down. If you have bad or no reception, perform the following checks: •... -
Page 25: Climate Differences
CLIMATE DIFFERENCES The appliances in your vehicle will not function if the LP gas does not vaporize. Propane will continue to vaporize down to –44 degrees F. Propane has become the main type of LP gas used in RVs in recent years. Butane should never be used. The LP gas dealer will have the correct type or blend for his locale. -
Page 26: Regulator Pressure
REGULATOR PRESSURE Have the gas regulator checked at the beginning of each season and whenever a problem occurs. Proper line pressure is 11 inches of water column. Your RV dealer or gas supplier can perform this needed check. GAS TANK AND REGULATOR FREEZE-UP LP gas regulator freeze-up can be prevented if owners are aware of its causes. -
Page 27: City Water
CITY WATER Open the CITY WATER INLET DOOR and connect a hose to a city pressurized water faucet and to the vehicle’s CITY WATER INLET. Some models have a separate water fill for the FRESH WATER TANK. Others have a selector switch to select either LOCAL SUPPLY or FRESH WATER TANK. -
Page 28: Water Pump
1. Prepare a chlorine solution using 1 gallon of water and ¼ cup of household bleach (sodium hypochlorite solution). With tank empty, pour chlorine solution into the tank. use 1 gallon solution for each 15 gallons of tank capacity. This procedure will result in a residual chlorine concentration of 50 PPM in the water system. -
Page 29: Drainage P-Traps
separate BLACK WATER HOLDING TANK. Some models may have a second GRAY WATER HOLDING TANK to accommodate various floorplans and features. Which tank each sink drains into may vary from one model to another. The drainage system also includes vents that carry odors caused by drain water and waste out of the RV, while also equalizing air pressure. -
Page 30: Holding Tank Maintenance
clean the drain hose. Repeat as necessary. Follow the same procedure for the GRAY WATER HOLDING TANK. A repeat flush is not necessary. When the tank is empty, push the dump valve handle in until it seats. Remove the hose, wash and replace it in its storage location. Replace termination outlet cap. HOLDING TANK MAINTENANCE Keep your tanks well flushed out when the vehicle is not in use. -
Page 31: Appliances
3. Turn ON all faucets and OPEN the HOT and COLD WATER PIPE DRAIN VALVES. Leave these valves in the OPEN position. These valves are located either under the galley sink or in an exterior compartment, and permit the water to drain onto the ground below the RV. 4. -
Page 32: Range
RANGE Also operated with LP gas are the range burners and the oven (optional). The basic operation is the same as the units in your home except that extra care must be taken to provide adequate ventilation in your RV. Unlike your home, the RV has limited air space, thus, a limited amount of oxygen available for combustion. -
Page 33: Air Conditioner
Your furnace is designed to sustain a desired temperature in the vehicle at most times. Due to varying weather conditions, the furnace may not be able to keep up with sub-freezing temperatures. The amount of vehicle occupants and the position the vehicle is parked may help or hinder the furnace’s ability to keep up with freeze conditions. Consult the furnace owner’s manual for more information. -
Page 34: Effects Of Long Term Occupancy
FORMALDEHYDE If you notice an odor in your recreational vehicle – it could be formaldehyde Gulf Stream is an industry leader in reducing emissions of formaldehyde from the products used in constructing its RV’s. Formaldehyde is commonly found in nearly all homes and buildings. It is a colorless gas that is released into the home from a variety of indoor sources. -
Page 35: Condensation And Mold
SLIDE OUT SYSTEMS OWNER’S MANUALS AND TROUBLESHOOTING GUIDES Gulf Stream products carry a variety of electrically operated slide out products. The electrical slide out product installed in your particular RV is accompanied by an owner’s manual from the slide out system manufacturer. For troubleshooting, maintenance and proper use of your particular slide out, please refer to the slide out owner’s manual... -
Page 36: Slide Out Weather Seals
The failure of paint or decals to line up after slide out adjustments does not require attention and repainting or applying new decals is not necessary or covered under the Gulf Stream Coach, Inc. Limited Warranty. AWNINGS Electric awnings installed on your RV are optional and/or may have been added by your dealer. -
Page 37: Maintenance
MAINTENANCE ROOF If you decide to access the roof via the rear mounted ladder, we recommend that you stay low and/or near the middle of the roof. When accessing the roof, use extreme caution and avoid movement on areas near the roof air conditioner ducting (some models) and/or between the rafters on light (lite) models. -
Page 38: Paint, Fiberglass And Sidewall Care
Some components used by Gulf Stream and the chassis manufacturer, by nature, will appear to be “rusty” or corroded on the surface. These components are not required to be rust free for normal operation. These components may include axle housings, brake caliper housings, LP black pipe fittings, etc. -
Page 39: Pre-Trip Checklist
PRE-TRIP CHECK LIST (AT HOME) EXTERIOR All objects secure………………….……. Awnings locked…………………………. Tires at proper pressure (spare)………. Wheel lug nuts at proper torque………. (Check for wear and damage) Hitch and hitch ball secure…………….. All exterior lights operational………….. Stabilizers raised………………… Batteries charged, fluid level okay…… Brakes checked for operation…………... -
Page 42: Index
GAS TANK AND REGULATOR FREEZE UP (LP)………… 25 GROUND FAULT INTERRUPTER……………………………. 21 GULF STREAMERS INTERNATIONAL RV CLUB…………. 43 HITCH – FIFTH WHEEL HEIGHT ADJUSTMENT…………. 12 HITCH – TRAVEL TRAILER HEIGHT ADJUSTMENT……… 11 HITCH LOCKING DEVICES…………………………………… 10 HITCHING – FIFTH WHEELS……………………………..11 HITCHING – TRAVEL TRAILERS…………………………… 9 HOLDING TANK FLUSH SYSTEM……………………………... - Page 43 TIRE MARKINGS………………………………………………. 14 TIRES……………………………………………………………. 14 TOW VEHICLE REQUIREMENTS…………………………….. 9 TRAILER LIGHT SCHEMATIC…………………………………. 40 VEHICLE LOADING……………………………………………. 13 VEHICLE WEIGHT INFORMATION LABEL………………… 16 WARRANTY – GULF STREAM……………………………….. 4 WATER HEATER……………………………………………… WATER SYSTEMS CONVENIENCE CENTER………….. WATER PUMP…………………………………………………. 27 WATER SYSTEM WINTERIZING……………………………. 29 WATER TANK………………………………………………….. 26 WEIGHING –...
