  • Page 2 CP190i - GPS Chart Plotters CPF190i - GPS Chart Plotters/Fish Finder Owner's Manual CP190i CPF190i...
  • Page 3 Consult an authorized STANDARD HORIZON dealer or other qualified service technician if the problem cannot be corrected. Operation is subject to the following...
  • Page 4 - The GPS Chart Plotter contains dangerous high-voltage circuits which only experienced technicians can handle. - STANDARD HORIZON will not be liable for errors contained herein, or for incidental or consequential damages in connection with the performance or use of this material.
  • Page 5 Page CP190i and CPF190i...

  • Page 6: Table Of Contents

    BATTERY CONNECTIONS ................... 25 NMEA CONNECTIONS ..................25 GPS POSITION ON A VHF RADIO ............... 25 CP190i: OPTIONAL BLACK BOX FISH FINDER ..........25 RADAR ANTENNA (USA ONLY) ................26 2.10 PERSONAL COMPUTER CONNECTIONS ............26 2.11 NMEA DATA PAGE ....................27 2.12 DEMO MODE (For DEALER USE) ................
  • Page 7 MAKING ADDITIONAL ROUTES ................75 CREATING A ROUTE USING MARKS ON THE CHART PAGE ......75 INSERTING A WAYPOINT INTO A ROUTE ............76 GOTO A ROUTE ....................77 9.6.0 Using [GOTO] to select Route ..............77 Page CP190i and CPF190i...

  • Page 8: Cp190I And Cpf190I Page

    Changing the NMEA Page Windows ..............100 12.7 NMEA DATA PAGE ....................100 12.8 NMEA TREND PAGES ..................101 12.9 VHF DIGITAL SELECTIVE CALLING ..............102 12.9.0 Interfacing ....................102 12.9.1 Distress Call ..................... 102 12.9.2 Position Request ..................103 CP190i and CPF190i Page 9...
  • Page 9 17.2.2 200 kHz and 50 kHz Zoom Pages ............127 17.2.3 200 kHz and 50 kHz Fish/Chart Pages ........... 128 17.3 SETUP MENU ...................... 128 17.4 PRESETS ......................128 17.5 FREQUENCY ....................... 129 17.6 GAIN MODE ......................129 Page 10 CP190i and CPF190i...

  • Page 10: Cp190I And Cpf190I Page

    20.0 CP190i/CPF190i SPECIFICATIONS ..............143 20.1 CPF190i FISH FINDER SPECIFICATIONS ............143 20.2 CP190i/CPF190i DIMENSIONS ................144 20.3 OPTIONAL FF525 FISH FINDER SPECIFICATIONS (use with CP190i) ... 144 20.4 OPTIONAL WAAS GPS RECEIVER SPECIFICATIONS ........145 CP190i and CPF190i Page 11...
  • Page 11 21. APPENDIX: TERMS ....................... 147 ANALYTICAL INDEX ......................151 Page 12 CP190i and CPF190i...

  • Page 12: Introduction

    800/767-2450 or marinetech@vxstdusa.com. GENERAL INFORMATION The CP190i (with internal GPS antenna) and CPF190i (with internal GPS antenna and Fish Finder) are precision-crafted high-performance receivers for the Global Positioning System (WAAS GPS) constellation of satellites that provide precise location data with a host of navigation features and are ideal for nautical use and sealed against water ingress.

  • Page 13: Packing List

    When the package containing the Navigation device is first opened, please check for the following contents. If any parts are missing contact the dealer this Navigation device was purchased from. Accessories and replacement parts may be ordered from STANDARD HORIZON’s Parts Department at 741/827-7600 extension 6800 or e-mail at yaesuparts@vxstdusa.com. 1.1.0...

  • Page 14: Optional Accessories

    600W 2" Bronze Thru-hull depth temp Transducer DST525 600W In-hull Transducer DST526 600W 2" Bronze Thru-hull depth, speed temp Transducer (FF525 ONLY) DST527 1000W In-hull depth Transducer (FF525 ONLY) DST528A 1000W Bronze long stem depth temp Transducer CP190i and CPF190i Page 15...
  • Page 15 Page 16 CP190i and CPF190i...

  • Page 16: Installation

    The CP190i and CPF190i are designed to be bracket and flush mounted. However when bracket mounting the CP190i and CPF190i in an area where satellite reception is not possible with the internal antenna or when flush mounted, the optional GPS antenna must be installed.

  • Page 17: Flush Mounting

    Figure 2.1 - Example of Bracket installation on CPF190i FLUSH MOUNTING The CP190i and CPF190i are supplied with a flush mount template for the cutout hole and screw holes required to install the GPS Chart Plotter. NOTE Before drilling holes make sure there is enough room to mount the GPS Chart Plotter and there are no obstructions.

  • Page 18: Mounting The Optional External Gps Antenna

    MOUNTING THE OPTIONAL EXTERNAL GPS ANTENNA An external WAAS GPS antenna is available when the CP190i or CPF190i is flush mounted or mounted in an area where satellite reception is not possible with the internal antenna.This antenna is designed to be mounted on a base, installed on an extension or flush mounted.

  • Page 19: Connections

    Battery Ground CONNECTIONS The CP190i and CPF190i have connectors that allow them to be connected to a Power supply, optional WAAS GPS antenna, optional FF525 50/200kHz BLACK BOX FISH FINDER (only for CP190i) and NMEA Devices* such as VHFs, AIS Receiver, Digital Instruments and autopilots.

  • Page 20: Cp190I Connection Table

    If you have connected devices as shown in the table on the next page and need to feed NMEA to other devices (Autopilot, RADAR…) you can parallel wires from the yellow, brown or white wires to other devices. 2.4.0 CP190i Connection Table Power Data Cable Pin Wire Color Description Connection Example...
  • Page 21 2.4.1.2 AIS Setup The CP190i has to be set up to be able to receive NMEA information from the AIS receiver. The GPS Chart Plotter reads the AIS NMEA message VMD, type 1, 2, 3 and 5 for AIS Class A and type 18, 19, 24 for AIS Class B.

  • Page 22: Cpf190I Connection Table

    Port1 (Brown) and change the sentences to APA, APB, BOD, GGA, GLL, RMC and XTE. 2.4.3 CPF190i Connections 2.4.3.0 DC Power Connection Optional WAAS GPS ntenna CPF190i Switch Black Battery Fuse PWR & ACC 1 Cable 10-35Vdc Transducer CP190i and CPF190i Page 23...
  • Page 23 The Input and Output baud rate for each port is set using the Advanced Setup>In/Out Connections menu. For example if Port1 is set for AIS 38400, the Input and Output both operate at 38400 baud. Page 24 CP190i and CPF190i...

  • Page 24: Battery Connections

    * Connect to NMEA Output (if available) * Some manufacturers of DSC VHF’s are not capable of outputting NMEA DSC and DSE sentences to the CP190i or CPF190i. Refer to the Owner’s Manual and confirm the VHF can output NMEA DSC and DSE sentences.

  • Page 25: Radar Antenna (Usa Only)

    Please refer to Par. “1.3 Radar Unit supplied by SI-TEX USA”. The Radar antenna includes the necessary electronics to deliver Radar information to a compatible STANDARD HORIZON GPS Chart Plotter, and is supplied with mounting hardware kit, interconnection cable and a Radar Junction Box.

  • Page 26: Nmea Data Page

    Full page, Radar page, Navigation page, Highway Page, Celestial page, NMEA Display page. NOTE This mode is used by dealers to promote the features of the CP190i or CPF190i when on a retail shelf. The Demo mode can be selected from the Simulation Menu following the procedure: 1.
  • Page 27 GPS Chart Plotter normal operation. If a key in not touched for 30 seconds the Demo Mode will re-start. To disable the Demo Mode follow the procedure above selecting OFF at point 5. Page 28 CP190i and CPF190i...

  • Page 28: Controls And Indicators

    CONTROLS AND CONNECTIONS The CP190i or CPF190i is controlled by using the keys located on the front panel. These labeled keys are dedicated to specific functions. As you press a key, a single audio beep confirms the key action; every time a key press is not valid, three rapid beeps sound to indicate that the key action is not valid.

  • Page 29: Getting Started

    GPS Chart Plotter Fish Finder Software V16.30 00R Figure 3.1.0 - Example of Start-Up page on CPF190i 2. When the power is first turned on two pages the Start-Up page and the Caution pages are Page 30 CP190i and CPF190i...
  • Page 30 After a fix is received the GPS Chart Plotter will automatically switch to the Chart Page with the ship icon centered on the screen. WAAS Ship Cursor Cursor Icon window Figure 3.1.0c - GPS Status and Chart pages CP190i and CPF190i Page 31...

  • Page 31: Cursor Vs. Home Mode

    To change from Cursor Mode to Home Mode press [CLR]. 3.1.2 Cursor and Menu selection speed The CP190i and CPF190i allow you to control the speed the Cursor moves when the ShuttlePoint knob is pressed. To change the speed: Figure 3.1.2 - Cursor Speed menu 1.

  • Page 32: Changing The Ship Icons

    3.1.4 Changing the Backlight and Contrast With the CP190i and CPF190i turned on, briefly press [PWR] to show the backlight and contrast popup window. Move the ShuttlePoint knob to the left or right to adjust the LCD backlight intensity or up or down to change the LCD contrast. Press [ENT] to set.

  • Page 33: Automatic Time

    5. Press [CLR] or move the ShuttlePoint knob to the left to exit the menu and show the Chart page. NOTE When the CP190i and CPF190i are in Course Up mode a small arrow icon will be shown on the Chart page indicating North.

  • Page 34: Selecting Loran Td Or Other Coordinate System

    The GPS Fix coordinates can be changed to show Latitude/Longitude, Loran TDs or UTM. Below is the window that will appear when customizing the Coordinate System. CHART DATUM CHART ORIENTATION RES Figure 3.3 - Coordinate System menu CP190i and CPF190i Page 35...

  • Page 35: Changing The Chart Color

    Example: Y/Z change to Z/Y. CHANGING THE CHART COLOR The CP190i and CPF190i have preprogrammed settings allowing you to customize the look of the Chart page. The default is Sunlight, however there are other settings: Classic, NOAA, Night and Normal. Night is very useful during evening hours so not to impair night vision.
  • Page 36 Press [MENU] two times, move the Shuttlepoint knob to highlight the first (top) selection in the menu and press [ENT]. c. Move the Shuttlepoint knob to highlight the LANGUAGE item and press [ENT]. d. A language window will be shown, select your language and press [ENT]. CP190i and CPF190i Page 37...

  • Page 37: Settings In General Setup Menu

    (Off is the default). Finish point START point WINDOWS SETUP This menu selection allows the data windows to be customized on the CHART PAGE and NAVIGATION PAGE (refer to section 12.0.0). Page 38 CP190i and CPF190i...

  • Page 38: About Page

    1. Press [MENU], move the ShuttlePoint knob to highlight SETUP MENU and press [ENT]. 2. Move the ShuttlePoint knob to highlight About... and press [ENT] or move the ShuttlePoint knob to the right. 3. The Information page appears on the screen (see the following picture). CP190i and CPF190i Page 39...
  • Page 39 : M-NA-M632.00 L. ANGELES and S. PEDRO BAYS Designed for 3 Storage Capacity Figure 3.7 - Example of About page 4. Press [CLR] or move the ShuttlePoint knob to the left to exit and show the Chart Page. Page 40 CP190i and CPF190i...

  • Page 40: Find Services

    FIND SERVICES USING FIND SERVICES & MORE FUNCTIONS The CP190i and CPF190i have a dedicated [FIND] key that allows searching the optional C-MAP B /MAX C-CARD for Port Services, Ports, Tide Stations, Wrecks, EPPESEN Obstructions, Points Of Interest, Lakes, User Points, GPS Coordinates or Information on any point on the Chart.

  • Page 41: Port

    2. Move the ShuttlePoint knob to highlight TIDE STATIONS and press [ENT] or move the ShuttlePoint knob to the right. 3. A popup window will be shown with a list of nearest Tide Stations. 4. Move the ShuttlePoint knob to highlight the desired Tide Station and press [ENT]. Page 42 CP190i and CPF190i...

  • Page 42: Wrecks

    See the following table: ICON DESCRIPTION non-dangerous wreck dangerous wreck distributed remains of wreck F o u l wreck showing mast/masts Masts wreck showing any portion of hull or superstructure Figure 4.0.3 - Wreck icons Table CP190i and CPF190i Page 43...

  • Page 43: Obstructions

    5. Another window will be shown detailing the Obstruction information. 6. Press [CLR] to show the actual position of the Obstruction on the Chart Page. 7. Press [CLR] again at any time to return your cursor to your vessel’s position. Page 44 CP190i and CPF190i...

  • Page 44: Lakes Information

    4.0.5.0 Quick Info On Lakes Upon viewing the chart of a lake, you can click on the Lake Info icon to query the available information immediately displayed with many details. For example, see the following picture: CP190i and CPF190i Page 45...
  • Page 45 The following is an example of Full Info on Lakes: Figure 4.0.5.1 - Example of Full Info page To see the "Fishing" object press [MENU] (when the "Fishing" object is highlighted). On the screen appears: Page 46 CP190i and CPF190i...

  • Page 46: Lakes By Name

    6. Move the ShuttlePoint knob to highlight the desired Type and press [ENT]. 7. A popup window will be shown with a list of nearest Points Of Interest that fall into the Category and Type you have selected. CP190i and CPF190i Page 47...

  • Page 47: User Points

    6. Press [CLR] at any time to return your cursor to your vessel’s position. WAAS 3D INFORM Figure 4.0.8 - Find User Points (Marks and Waypoints) 4.0.9 Coordinates This feature allows you to enter Coordinates (Latitude/Longitude) and view the entered position on the Chart Page. Page 48 CP190i and CPF190i...

  • Page 48: Information

    ShuttlePoint knob through the Info Tree, all the relevant information of the selected object is shown on the lower part of the page. 4. Press [CLR] again at any time to return your cursor to your vessel’s position. Figure 4.0.10 - Find Information CP190i and CPF190i Page 49...
  • Page 49 Page 50 CP190i and CPF190i...

  • Page 50: Max Cartography Overview

    5.0.0 Coverage areas and details Figure 5.0.1 - Coverage Area The CP190i and CPF190i have Built-In Charts for coastal navigation of USA including Alaska, Hawaii and Great Lakes, Canada, Bahamas, Caribbean, Cuba, Puerto Rico, and Central America which include: a. Depth contours and spot soundings to 66 feet (20 meter) on lower scale charts and 33 feet (10 meters) on higher scale charts b.

  • Page 51: Inserting The Optional Max C-Card

    . n se r . n cl a ss cl a ss Figure 5.1a - Inserting C-CARD (details) NOTE The small connector below the C-CARD is only used by Standard Horizon repair technicians. Page 52 CP190i and CPF190i...
  • Page 52 · Safety Status Bar (a status bar with six boxes to show the status of certain functions. Any warning or alarm condition is identified by the red color to indicate possible risk) CP190i and CPF190i Page 53...
  • Page 53 MAX data cover different areas, the GPS Chart Plotter receives data from both charts (depending on the current position). · When NT data and MAX data cover the same area, the GPS Chart Plotter receives data only from MAX chart. Page 54 CP190i and CPF190i...

  • Page 54: Map Functions

    [ZOOM IN]/[ZOOM OUT] push (press and hold) causes an expansion or compression of the chart image, without a chart level change. CHART: US,NOS,GRAPH,11472H SCALE: 1:40000 ACQUIRING CHART: US,NOS,GRAPH,11472H SCALE: 1:40000 ACQUIRING CHART: US,NOS,GRAPH,11474 SCALE: 1:80000 ACQUIRING Figure 6.0.0 - Zoom Type CP190i and CPF190i Page 55...

  • Page 55: Icon Size

    6.0.2 Place Name Size On MAX charts it is possible to set the size of all names drawn on the charts, selecting between Standard (default), Medium and Large size. Page 56 CP190i and CPF190i...

  • Page 56: Perspective View

    5. Move the ShuttlePoint knob to select the selection and press [ENT]. 6. Press [CLR] until the menu disappears or an easier method is to move the ShuttlePoint knob to the left until the Chart Page is shown. CP190i and CPF190i Page 57...

  • Page 57: Dynamic Nav-Aids

    5. Move the ShuttlePoint knob to select the selection and press [ENT]. 6. Press [CLR] until the menu disappears or an easier method is to press the ShuttlePoint knob to the left a few times. Page 58 CP190i and CPF190i...

  • Page 58: Satellite Imagery

    5. Move the ShuttlePoint knob to select the selection and press [ENT]. 6. Press [CLR] until the menu disappears or an easier method is to move the ShuttlePoint knob to the left until the Chart Page is shown. CP190i and CPF190i Page 59...

  • Page 59: Currents Prediction

    2. Move the ShuttlePoint knob to highlight MAX FUNCTIONS and press [ENT] or move the ShuttlePoint knob to the right. 3. Move the ShuttlePoint knob to highlight CURRENTS PREDICTION and press [ENT] or move the ShuttlePoint knob to the right. Page 60 CP190i and CPF190i...

  • Page 60: Chart Language

    [GOTO]/[MENU] to increase/decrease time; press [CLR] to exit. 6.0.8 Chart Language The CP190i and CPF190i may be customized to show the local language of the chart. To select the Chart Language you want: 1. Press [MENU], move the ShuttlePoint knob to highlight SETUP MENU and press [ENT].

  • Page 61: How To Show The Pictures Or Diagrams Of A Object

    Otherwise press [ENT] to open the Full Info on the object. Note that on the Full Info there is the small camera icon on a corner of the square containing the object icon. To see the picture press [MENU] when the object with a picture is highlighted. Page 62 CP190i and CPF190i...

  • Page 62: Enhanced Port Info

    Additional attributes of Port Areas and Port Marinas have been included as Location, Country, Region, State, Harbour master telephone number etc., see the following figure. WAAS 3D PORT icon Figure 6.0.10 - Example of enhanced Port Info CP190i and CPF190i Page 63...
  • Page 63 Page 64 CP190i and CPF190i...

  • Page 64: Creating Marks

    If a Mark has previously been created and you wish to Edit it, move Cursor over the top of the Mark. 1. After a Mark is created press [ENT], move the ShuttlePoint knob to highlight EDIT and press [ENT]. CP190i and CPF190i Page 65...

  • Page 65: Deleting A Mark Or Waypoint

    2. Press [ENT], move the ShuttlePoint knob to highlight MOVE and press [ENT]. 3. Use the ShuttlePoint knob to move the cursor. A dotted line, connecting the previous Waypoint position to the new position, is shown: Page 66 CP190i and CPF190i...

  • Page 66: Marks/Waypoints List

    A-Z ASCENDING - Sorts the name of the Mark or Waypoint in ascending order b. Z-A DESCENDING - Sorts the name of the Mark or Waypoint in descending order SEND* Sends the stored points to a external device (PC) capable of listening to NMEA WPL and RTE sentences. CP190i and CPF190i Page 67...

  • Page 67: Creating A New Mark With The User Points List

    Mark or HIDE to hide on the Chart Page the created Mark. Press [ENT]. 17. Press [CLR] to save the created Mark. 18. Press [CLR] again and the new Mark appears on the Chart Page. Page 68 CP190i and CPF190i...

  • Page 68: Goto Cursor, Route And Mark

    After entering in all the Marks it is a good practice to backup the points to a User C-CARD. Refer to Section 11. GOTO CURSOR, ROUTE AND MARK The CP190i and CPF190i can easily be set to start navigating to the Cursor on the Chart Page, a saved Mark or a Route that was created. GOTO CURSOR 1.
  • Page 69 5. You will notice a circle is drawn around the Icon Symbol. This means the GPS Chart Plotter is now navigating to the point. 6. Press [CLR] to switch to the Chart page or Highway page to start navigating to the point. Page 70 CP190i and CPF190i...

  • Page 70: Man Over Board (Mob) Function

    During navigation, the “MOB” feature provides a one-touch method of storing a location, such as a point were a crew member fell overboard. In this mode, the CP190i or CPF190i places a MOB point on the Chart page and all the navigation data shown is related to navigating back to this point, allowing you to retrace your path to the MOB point efficiently.
  • Page 71 Page 72 CP190i and CPF190i...

  • Page 72: Routes

    ROUTES The CP190i and the CPF190i have the capability to store 50 Routes with 100 Waypoints or Marks in each Route. A Route can consist of Waypoints or Marks. The difference is when a Route is made using Waypoints and the Route is deleted the Waypoints are also deleted.

  • Page 73: Changing The Name Of A Route

    4. Press [ROUTE]. Another Waypoint is shown under the cursor and a line joins the Starting Waypoint to the second Waypoint. 5. Repeat steps 3 and 4 until all Waypoints are entered into the Route. Page 74 CP190i and CPF190i...

  • Page 74: Making Additional Routes

    1. Move the ShuttlePoint knob over the top of a Mark that you wish to be the starting point in the Route and press [ROUTE]. 2. Next move the ShuttlePoint knob until the cursor is over the Mark that you want to be the next leg in the Route. CP190i and CPF190i Page 75...

  • Page 75: Inserting A Waypoint Into A Route

    Waypoint (see the left side of the above picture). Once you have positioned the cursor at the location you want, press [ENT] (see the right side of the above picture). Figure 9.5a - Inserting Waypoint procedure (2) Page 76 CP190i and CPF190i...

  • Page 76: Goto A Route

    2. Press [GOTO] to start following the Route. 3. Press [CLR] twice to revert to Home mode. DELETING A ROUTE To delete a Route follow the procedure below: 1. Press [MENU], move the ShuttlePoint knob to highlight USER POINTS and press [ENT]. CP190i and CPF190i Page 77...

  • Page 77: Other Settings In Route Menu

    The Route Check function is used after you have created a Route to ensure you and your vessel will not have problems while navigating. This is done by the CP190i and CPF190i by reviewing the Route and looking for the following hazards that may effect safe navigation.

  • Page 78: Cp190I And Cpf190I Page

    The default setting is Medium. ROUTE CHECK REPORT Shows the list of the dangerous objects found on the charts crossed by the Route. A-B = Width C-D = Depth E-F = Accuracy Figure 9.8.0a - Route Check parameters CP190i and CPF190i Page 79...
  • Page 79 (like DSC, MOB, Mark). In the case of checking a single point towards which the navigation is started, the leg for which the Route Check is executed is defined by the current position (the leg’s starting point) and the destination point (the leg’s ending point). Page 80 CP190i and CPF190i...

  • Page 80: Tracks

    The Track function can be setup to lay down a Track for a predetermined time or distance interval. If you have a fast moving boat you may want to setup the CP190i and the CPF190i to record a Track point every 0.5NM or if you have a sail boat you may want to setup to lay down a Track point once every 1 minute.

  • Page 81: Saving And Starting A New Track

    Shows or hides a Track shown in ACTIVE TRACK menu LINE COLOR Selects the color of the Track line DELETE Deletes a Track selected in the ACTIVE TRACK menu STEP UNIT Allowable selection are Distance or Time Page 82 CP190i and CPF190i...

  • Page 82: Trip Log

    5. A warning popup window will be shown to confirm if you want to reset the Trip Log. Move the ShuttlePoint knob to highlight YES and press [ENT].The Trip Log is now reset. 6. Press [CLR] to store and exit the editing mode Figure 10.1. 1 - Trip Log Reset CP190i and CPF190i Page 83...
  • Page 83 Page 84 CP190i and CPF190i...

  • Page 84: User C-Card

    Formatting permanently erases all files previously saved on the User C-CARD. 11.0.1 Transferring files to the optional User C-CARD 1. Remove a C-CARD if present and insert the optional C-MAP B J /MAX EPPESEN User C-CARD into the slot. CP190i and CPF190i Page 85...

  • Page 85: Loading A File From The Optional User C-Card

    3. Open the door, remove the User C-CARD from the slot and insert another User C-CARD into the same slot. 4. Move the ShuttlePoint knob to highlight REFRESH and press [ENT]. This "new" User C-CARD is now ready to receive and store information. Page 86 CP190i and CPF190i...

  • Page 86: Pages

    12. PAGES The CP190i and CPF190i have many pages that are designed to ease your navigation. CHART NAVIGATION HIGHWAY CELESTIAL WAAS WAAS GPS STATUS NMEA DISPLAY Display example with RADAR connected Chart and Fish Finder WAAS Figure 12 - Example of screen display pages The pages can be selected in the following way: 1.

  • Page 87: Change Focus On Dual Chart Page

    Bearing from Fix to Destination (If plotter is not navigating to a 9 Cursor Coordinates point BRG will show --- ) Chart Scale Distance & Bearings from Fix to Cursor Figure 12.0.1 - Example of single Chart Page Page 88 CP190i and CPF190i...

  • Page 88: Window Selections

    12.0.2 Window Selections The default is the Two Line Small window. The CP190i and CPF190i windows may be changed by the procedure below. FULL CHART (None) 1 LINE SMALL GENERAL 1 LINE LARGE WAAS WAAS 2 LINES SMALL HIGHWAY COMPASS Figure 12.0.2 - Data window layout...

  • Page 89: Additional Functions On Chart Page

    When on the Chart page you will notice icons of Buoys, Towers, Lights, Wrecks, Tide Stations and Port Icons. If the cursor is moved over the top of these icons a popup window will be shown with information about the icon. Page 90 CP190i and CPF190i...

  • Page 90: Turning Off Information On Icon Points

    4. Move the ShuttlePoint knob up or down to select the preset and press [ENT]. 5. Press [CLR] or move the ShuttlePoint knob to the right until the Chart Page is shown. CHART Figure 12.0.6 - Display Mode settings CP190i and CPF190i Page 91...

  • Page 91: Marine Settings

    : Turns the Ports and Service icons On of Off. Areas along the shore with facilities for mooring, downloading and uploading of ships, generally sheltered from waves and winds. Port installations are piers, wharves, pontoons, dry docks, cranes..Page 92 CP190i and CPF190i...

  • Page 92: Depth Settings

    POINT OF INTEREST (LIBRARY) Figure 12.0.9 - Example of Roads and Points Of Interest 12.0.10 Chart Settings Settings that control how the chart features will be shown on the Chart Page of the GPS Chart Plotter. CP190i and CPF190i Page 93...
  • Page 93 Plotter draws the rest of the chart using charts from above and below the current scale. When this function is turned on you will notice the display may redraw 2 to 3 times to show all the details. Page 94 CP190i and CPF190i...

  • Page 94: Underwater Objects Settings

    1. To change to show the Compass Tape, select the Chart Page, press [MENU]. Move the ShuttlePoint knob to highlight SETUP MENU and press [ENT]. 2. Move the ShuttlePoint knob to highlight GENERAL SETUP and press [ENT] or move the ShuttlePoint knob to the right. CP190i and CPF190i Page 95...

  • Page 95: Highway Page

    HIGHWAY PAGE Shows a 3D view of the vessel travelling through the water when Navigating to a destination point, Mark or following a Route. Press [ZOOM IN] or [ZOOM OUT] to change the highway scale. Page 96 CP190i and CPF190i...

  • Page 96: Celestial Page

    ShuttlePoint knob is pressed up to move the cursor to the top of the Tide Graph this is the High Water Level and if the cursor is moved to the bottom of the Tide Graph the draught will show the Low Water Level. CP190i and CPF190i Page 97...

  • Page 97: Gps Status Page

    4. Move the ShuttlePoint knob to highlight None (to disable) and press [ENT]. 5. Press [CLR] until the menu disappears or an easier method is to move the ShuttlePoint knob to the left until the menu disappears. Page 98 CP190i and CPF190i...

  • Page 98: Setup Menu

    Figure 12.6 - NMEA Display page The NMEA sentences read from external devices are: BWC, DSC, DSE, GGA, GLL, GSA, GSV, HDG, HDM, HDT, RMC, VHW, VTG, DPT, DBT, MTW, VWR, VWT, TLL, WPL, RTE. CP190i and CPF190i Page 99...

  • Page 99: Changing The Nmea Page Windows

    2. Move the ShuttlePoint knob to highlight DATA and press [ENT]. 3. Connect the BLUE Wire on the GPS Chart Plotter to the junction of the Brown wire and the VHF wire. The display should look similar to the following picture. Page 100 CP190i and CPF190i...

  • Page 100: Nmea Trend

    Wind trend information the CP190i and CPF190i must be connected to the NMEA output of a external Wind instrument. NOTE* The CP190i must be connected to the Optional FF525 (or FF520) 50/200kHz BLACK BOX FISH FINDER. To select a NMEA Trend Page: 1.

  • Page 101: Vhf Digital Selective Calling

    For additional information refer to Par. 2.4 Connections. 12.9.1 Distress Call STANDARD HORIZON GPS chart plotters are able to display the location of a vessel in distress when interfaced to a compatible DSC VHF with NMEA 0183 output and the radio...

  • Page 102: Position Request

    Figure 12.9.1 - DSC Log - Distress Call 12.9.2 Position Request STANDARD HORIZON GPS chart plotters are able to display the location of a vessel when connected DSC VHF radio and when a Position Request or Report call is received.
  • Page 103 Page 104 CP190i and CPF190i...

  • Page 104: Advanced Settings

    13.0 INPUT/OUTPUT (NMEA, AIS, RADAR) 13.0.0 Input The CP190i has 2 Inputs and 3 Outputs connections. The CPF190i has 1 Input and 2 Outputs connections. These ports may be set up to receive and output the following. · NMEA-0183 - NMEA devices* set to 4800 Baud (default setting) ·...

  • Page 105: Navigate

    WGS84 Datum. A datum is a mathematical model of the Earth which approximates the shape of the Earth, and enables calculations such as position and area to be carried out in a consistent and accurate manner. Page 106 CP190i and CPF190i...

  • Page 106: Loran Td

    This offset is useful for cruising vessels or vessels that travel internationally often. Figure 13.2 - Compass Table 13.3 ALARMS The Alarms menu is used to select and setup audible and visual Alarms. Available alarms are Arrival, XTE, Depth,Anchor and Grounding Alarm. CP190i and CPF190i Page 107...

  • Page 107: Simulation

    Off - turn the simulation mode Off b. On - enable the simulator mode, where the speed and course are adjusted by entering in values in the Course and Speed selection discussed later in this table. Page 108 CP190i and CPF190i...

  • Page 108: Navigating A Route In Simulation Mode

    Manual. If Auto Info is set to On, when receiving the Position Request it is possible to center the cursor over the top of the Position Request icon and show the Position Request popup window CP190i and CPF190i Page 109...
  • Page 109 Page 110 CP190i and CPF190i...

  • Page 110: Ais

    · Receive details from other vessels or navigation aids within VHF range. STANDARD HORIZON GPS Chart Plotters are able to display AIS target (for collision avoidance) on the Chart Page and AIS list pages when connected to a AIS receiver (GX2100 or GX2150 STANDARD HORIZON VHF/AIS transceiver) or transponders which output NMEA 0183 VDM sentence at 38400 or 4800 baud.

  • Page 111: Menu

    By placing the cursor over a AIS Target icon using the ShuttlePoint knob, the following information is displayed (see the following picture): · Vessel Name · MMSI number · Radio Call Sign · SOG · COG · CPA and TCPA values Page 112 CP190i and CPF190i...

  • Page 112: List

    3. Move the ShuttlePoint knob up or down to select the Target and scroll the page up or down. Press [ENTER] exits the page and shows the Target ship on the Chart page along with the current position of the GPS Chart Plotter. CP190i and CPF190i Page 113...

  • Page 113: Ais Target Colors

    Vessels with antipollution facilities or equipment (light blu) Low enforcement vessels (light red) Medical transport (dark green) Vessels according to Resolution N 18 (Mob-83) (cyan) (red) Passenger ship (magenta) Cargo ship (dark gray) Figure 14.5 - Color AIS Targets Page 114 CP190i and CPF190i...

  • Page 114: C-Weather Service

    15. C-WEATHER SERVICE C-Weather is a free service available on the CP190i and CPF190i. C-Weather service gives excellent coverage for the whole World. Weather forecasts are based on data received from the leading meteorological centers. This data is processed by Jeppesen server and made...

  • Page 115: Copy From User C-Card

    · Real Time View Off: the Weather data is not displayed. The layer displayed is the one selected into the previous menu item. 15.0.4 Type of Data Allows selecting the type of data, refer to the table in the Figure 15. Page 116 CP190i and CPF190i...

  • Page 116: Mobilarm

    16.0 MOBILARM-GPS CHART PLOTTER CONNECTION Connect the MOBILARM system to one of the Ports on the Standard Horizon GPS Chart Plotter. Refer to Par. 2.4.0 “Connection Table” for CP190i, Par. 2.4.2 “Connection Table” for CPF190i and MOBILARM Owner’s Manuals for connections.

  • Page 117: Software Setup

    NOTE Note the CP190i and CPF190i have only one NMEA Input so Port1 will have to be set to MOBILARM. Port 1 Example Chart Plotter MOBILARM Blue NMEA Out Brown NMEA In GPS V+ Black GPS V- NOTE Refer to the Figure 16.0, the Blue and Brown wires are from Port1. If these wires are being used to connect to another NMEA device, choose another wire pair and configure the port associated with the wires.

  • Page 118: Mobilarm Ptx

    On the GPS Chart Plotter all menus and/or pages are closed and the chart is centered on the PTX MOB received position. A Audible Alarm is heard and a pop-up warning window appears to notify that a PTX has been received: CP190i and CPF190i Page 119...

  • Page 119: Placing Cursor On The Ptx Icon

    Select YES and press [ENT]. 16.4.1 Goto PTX When Goto is selected on the GPS Chart Plotter, navigation will start to the PTX icon location. After the GPS Chart Plotter has received a PTX MOB alarm, using the ShuttlePoint Page 120 CP190i and CPF190i...

  • Page 120: The Mobilarm Alarm Status List

    4. Move the ShuttlePoint knob to highlight MOBILARM and press [ENT]. PTX number Recovered 213°22.120W 20°01.022N Recovered 03:45:14 PM 10:31:24 PM 305°04.015W 79°56.320N Recovered Time the PTX alarm was received PTX position PTX status Figure 16.4.2 - Example of MOBilarm PTX List page CP190i and CPF190i Page 121...
  • Page 121 (if open) and center the chart selected PTX. DELETE Deletes the selected PTX. SHOW Centers the chart on the selected PTX. SHOW ALL Selects the best chart scale to see al PTX icons on the chart at the same time. Page 122 CP190i and CPF190i...

  • Page 122: Fish Finder For Cpf190I

    3. Move the ShuttlePoint knob to highlight IN/OUT CONNECTIONS and press [ENT] or move the ShuttlePoint knob to the right. 4. Move the ShuttlePoint knob to highlight FISH FINDER and press [ENT] or move the ShuttlePoint knob to the right. CP190i and CPF190i Page 123...

  • Page 123: Understanding The Fish Finder Page

    Fish Finder page allows retrieving useful information about what is under the boat. Digital Depth Readout of the current bottom depth. Water Temperature Readout of the current water temperature returned by the temperature sensor included in DST520, DST521, DST523, DST525, DST526, DST527, DST528A. Page 124 CP190i and CPF190i...

  • Page 124: Understanding The Fish Finder Display

    Thermo- clines are represented as horizontal stripes of noise. They are very important for fishing since often many species of game fish like to suspend in, just above, or just below the thermoclines. CP190i and CPF190i Page 125...

  • Page 125: Displaying The Fish Finder Page

    1. From all pages (except the Fish Finder page), press [MENU]. From Fish Finder page, press [MENU] two times. Figure 17.2 - Main Menu 2. Move the ShuttlePoint knob to highlight RADAR/FISH and press [ENT]. Figure 17.2a - Fish Finder page selection menu Page 126 CP190i and CPF190i...

  • Page 126: Auto Full Page

    To select the area to be zoomed in move the ShuttlePoint knob Up or Down which moves the VRM line. To zoom In or Out, press [ZOOM IN] or [ZOOM OUT]. The zoom ranges are 2x and 4x the normal Fish Finder display. 30.0Ft Figure 17.2.2 - Zoom Full page CP190i and CPF190i Page 127...

  • Page 127: 200 Khz And 50 Khz Fish/Chart

    1. From the Full Fish Finder page, press [MENU]. The following menu appears: Figure 17.3 - Fish Finder Setup menu 17.4 PRESETS To simply menu selections, the Fish Finder has two presets that can be easily selected for Fishing or Cruising: Page 128 CP190i and CPF190i...

  • Page 128: Frequency

    Allows you to choose the frequency among Auto, 50 kHz, 200 kHz or 50&200 kHz when single frequency page is selected. Figure 17.5 - Frequency menu 17.6 GAIN MODE Figure 17.6 - Gain Mode menu CP190i and CPF190i Page 129...

  • Page 129: Auto Mode

    Example: Your vessel is in about 57FT of water, however there is fish suspended in 35FT of water. You want to display to 10FT area around the fish. Shift would be set to 30FT and Depth would be set to 40FT shown in example below. Page 130 CP190i and CPF190i...

  • Page 130: Interference Rejection

    Allows you to control the Sensitivity of the unit’s receiver from 0 to 100%. To see more detail, increase the receiver Sensitivity by selecting a higher Gain percentage. If there is too much detail or if the screen is cluttered, lowering the Sensitivity may increase the clarity of the display. CP190i and CPF190i Page 131...

  • Page 131: Stc (Sensitivity Time Control)

    In custom mode it can be varied from 0% to 100%. The STC effect is maximum near the surface, to mitigate the Surface Clutter and it progressively diminishes to 0 at the selected STC depth. Page 132 CP190i and CPF190i...

  • Page 132: Surface Noise Filter

    8 the attenuation is maximum and is applied from surface level down to a depth of 255 Ft, as shown in the Surface Noise Filter Table reported below: Surface Noise Filter Depth Preset Depth (Ft) Figure 17.9.2 - Surface Noise Filter Depth table CP190i and CPF190i Page 133...

  • Page 133: Display Setup

    : shown as arches with the Fish icon Icon + Echo + Depth : shown as arches with the Fish icon and relative depth values Echo + Depth : shown depth values Icon : shown as Fish icons without the arches Page 134 CP190i and CPF190i...

  • Page 134: A-Scope

    Used to calibration on the Water Temperature sensor in the transducer. 17.11.3 Set Defaults Restores the factory settings. 17.12 ALARMS The Alarms menu allows you to define alarm settings for Shallow Alarm, Depth Alarm and Temperature Upper/Lower/Rate. CP190i and CPF190i Page 135...

  • Page 135: Shallow Water

    This option saves the complete set of Fish Finder settings to an optional User C-CARD. This is useful to avoid the user having to retune up Fish Finder after a RAM Clear operation or a software update. Page 136 CP190i and CPF190i...

  • Page 136: Load Settings From User C-Card

    Figure 17.14 - C-CARD - Load settings 17.15 RESTORE CURRENT PRESET DEFAULTS This option restores the default values only for the current presets and does not affect the other presets. Figure 17.15 - C-Card - Restore settings CP190i and CPF190i Page 137...
  • Page 137 Page 138 CP190i and CPF190i...

  • Page 138: Troubleshooting

    Internal RAM memory to become corrupted. To solve this issue, perform a RAM clear (refer to Section 19). NOTE After performing a RAM Clear all Marks, Routes and tracks will be erased. To back up these points refer to Section 11 for details. CP190i and CPF190i Page 139...
  • Page 139 Page 140 CP190i and CPF190i...

  • Page 140: Technical Tests

    Each time you move the ShuttlePoint knob to right, the screen will decrease brightness, move it to the left to increase brightness. Backlight The second option allows to set the backlight. Operates in similar mode as Contrast. CP190i and CPF190i Page 141...

  • Page 141: Cartridges

    ASCII mode (normal or small) and [CLR] to exit. Loop-Back Test This is a special test done during the production phase to check the serial ports integrity. This function is only required by Standard Horizon. Page 142 CP190i and CPF190i...

  • Page 142: Specifications

    : 5Feet at 50kHz, 2.5Feet at 200kHz Maximum Depth : 1500Feet at 50kHz, 700Feet at 200kHz Airmar X-DUCER ID : Must use Standard Horizon transducers Advanced Digital Signal Processing Speed & Temperature Sensor (if available on transducer) Alarms (shallow water, depth, Fish, temp)

  • Page 143: Cp190I/Cpf190I Dimensions

    3.9" [98.6mm] 1.5" 1.5" [37mm] [37mm] 7.1" [181mm] 0.2" [4.1mm] Figure 20.2 - CP190i/CPF190i Dimensions [inch/mm] 20.3 OPTIONAL FF525 FISH FINDER SPECIFICATIONS (USE WITH CP190i) Power Output : 600W or 1kW depending on connected transducer Frequency : 50 and 200kHz Minimum Depth : 5Feet at 50kHz, 2.5Feet at 200kHz...

  • Page 144: Optional Waas Gps Receiver Specifications

    Reacquisition < 1 second Hot Start 1 second outdoor, 10 seconds indoor Warm Start 29 seconds Cold Start 29 seconds Accuracy < 2.5m with SBAS < 2.0m NMEA Output Messages GGA, RMC, GSA, GSV, TXT CP190i and CPF190i Page 145...
  • Page 145 Page 146 CP190i and CPF190i...
  • Page 146 HDG (Heading) – Shows heading from a External Flux Gate Compass when connected. HDOP/VDOP – Horizontal/Vertical Dilution of Precision. It is a parameter indicating the precision of the positioning system (GPS). The smaller the HDOP/VDOP value, the more CP190i and CPF190i Page 147...
  • Page 147 70 metres (230FT) in Height and up to 600 metres (2.000 FT) in diameter. Position Request – Marine DSC VHF Function of transmitting a GPS position to another Marine DSC VHF. When GPS Chart Plotter is connected to STANDARD HORIZON GPS the position of another vessel is shown on the Chart page.
  • Page 148 WATER TEMP – Shows the sea water temperature for when a Digital Speed Log/Temp instrument with NMEA is connected. XTE (Cross Track Error) – The distance your vessel is off course (left or right) to a Destination point. CP190i and CPF190i Page 149...
  • Page 149 Page 150 CP190i and CPF190i...

  • Page 150: Analytical Index

    C-CARD Test ........142 ASF ........... 36 C-COM ........105, 115 ASF1/2 ..........107 C-Weather ....105, 115, 116 assistance ......... 13 C-Weather menu ......115 Attention Areas ......... 92 Calibrate Water Speed ....135 CP190i and CPF190i Page 151...
  • Page 151 Category ........... 47 Course Up ......... 33 CAUTION ..........5 Coverage areas ........ 51 Caution page ........30 CP190i Connection Table ....21 CELESTIAL PAGE ......97 CP190i Connections ......21 Central America ....13, 51, 87 CPA ........111, 112 Chain ........
  • Page 152 Find GPS Coordinates ...... 49 Distance ........38, 69 Find Information ........ 49 Distance to Destination ..... 89 Find Lakes By Name ......47 Distance Units and Time Units ..81 Find Lakes Information ..... 45 CP190i and CPF190i Page 153...
  • Page 153 Information ......... 30, 49 GOTO CURSOR ....... 69 Input ..........105 GOTO MARK ........70 Input Data Display ......142 GOTO menu ........69 INPUT/OUTPUT ......105 Goto PTX ........120 INSERTING A WAYPOINT ....76 Page 154 CP190i and CPF190i...
  • Page 154 LOCATE ..........67 locate Points Of Interest ....47 Name Tags ........92 locate Port ......... 42 NAME TO A ROUTE ......74 locate Port Services ......41 Nav Aids & Light Sectors ....92 CP190i and CPF190i Page 155...
  • Page 155 ..........14 Quick Info .......... 53 Packing List ........14 QUICK INFO ON AIS ...... 112 PAGES ..........87 Quick Info on AIS ......113 Pair ........... 36, 107 Quick Info On Lakes ......45 Page 156 CP190i and CPF190i...
  • Page 156 Spot Soundings ......... 53 Satellite Imagery ....... 59 spot soundings ........51 satellite reception ......98 start a new Track ......82 SAVE ..........86 start navigating ......30, 69 Save settings ........137 Start-Up page ........30 CP190i and CPF190i Page 157...
  • Page 157 Value Added Data ...... 92, 94 TIME ......... 83, 90, 148 Variable Depth Marker ....125 Time ......... 81, 109 Variation .......... 107 Time Format ........38 VDM ..........125 TIME SETUP ........38 VDOP ........ 90, 98, 147 Page 158 CP190i and CPF190i...
  • Page 158 Warranty ........... 13 Zoom Full page ....... 127 Water Resistance ......143 ZOOM IN ........... 29 water resistent ........13 ZOOM OUT ........29 WATER TEMP ........ 149 Zoom Type ........55 WATER TEMP RATE ..... 124 CP190i and CPF190i Page 159...
  • Page 159 Products shall be limited solely to repair or replacement, at its option, of the Product or part(s) therein which, upon examination by STANDARD HORIZON, appear to be defective or not up to factory specifications. STANDARD HORIZON may, at its option, repair or replace parts or subassemblies with or reconditioned parts and subassemblies.

This manual is also suitable for:

Cpf190i

Table of Contents
