3°C. Specified accuracy will 5.0 Characteristics be restored when the interference is removed. The design of this instrument has been assessed and tested assuming maximum connecting lead lengths of 3.0 metres. Page SPS5.1 Manual SPS5.1 Manual Page 11...
A typical firing sequence is illustrated below:- In the event of an error contact the supplier quoting the error number. Soak time soak temperature energy=100% ramp 1 rate variable ambient Delay Ramp 1 Ramp 2 Cooling Time Page SPS5.1 Manual SPS5.1 Manual Page 3...
Pressing this key when READY is displayed has no effect. Suitable proprietary RC filter networks fitted with insulated wire leads are:- RS Components Part No. 210-364 RS Components (tab fixing) Part No. 210-370 Farnell Electronic Components Part No. 218-893 Page SPS5.1 Manual SPS5.1 Manual Page 9...
Page 5
SK2 is the thermocouple connector. The positive terminal is clearly marked. SK1 is the mains/control connector:- K1 is the switched Mains Live output to the heater contactor K2 & K3 are not used (not connected) on the SPS5.1 K4 is Mains Live input K5 is Mains Neutral input...
This shows that the load has cooled to less than 40°C & firing is COVER 230V ~ 50HZ 1.0A READY complete. Fuse: 1.0A Anti-surge Wickmann type TR5 T1A 250V WARNING ISOLATE FROM ELECTRICAL SUPPLY BEFORE OPENING THIS INSTRUMENT FOR INSTALLATION, CONFIGURATION OR REPAIR PURPOSES Page SPS5.1 Manual SPS5.1 Manual Page 7...
