Ramsey Electronics BULLSHOOTER ENDLESS LOOP BS2C Assembly And Instruction Manual page 22

To change the sample rate of the BS2C, power it down, then press and hold the
PAUSE button while powering the unit on. The display will show three dashes
to indicate sample rate selection. Now press the UP DOWN keys to select from
one of four sample rates.
When finished, press the STOP button to save changes and get back into nor-
mal operation at the new rate.
Sample Mode
1
2
3
4
Here is a cool thing you can do! Record your messages at a slow sample rate,
then change to a new, faster sample rate, and your messages can play back
funny-fast! You can also go the other way to make your messages sound
really slow.
Recording
You can record up to three different ways with the BS2C, the first being the
internal microphone located on the front panel. The second way to record is
by using an external microphone (which assumes you are using an external
electret microphone) though J5, and the third way is to record RCA levels
through J9. By default the BS2C is set up to select the microphone. This is
indicated by the LACK of a decimal point on the display. If you plug in an ex-
ternal microphone the BS2C automatically switches off the front microphone in
favor of the external microphone.
To switch to the RCA line level input, press both of the UP and DOWN keys at
the same time. The decimal point on the display will come on indicating that
the line input is selected. To switch back to the microphone, click both
switches again.
To begin recording, select the message location by pressing the UP DOWN
buttons, then press both PLAY and RECORD switches. The record LED will
blink several times to indicate a pause to eliminate switch noise. Then the nu-
meric display will rotate to indicate that a recording is in progress. Once you
are finished recording, press the STOP button. The internal microphone will
pick up the slight click of the button, but that should not detract from the kit
and is unavoidable.
Playback
Playback is pretty straightforward. You select the message you want to play
using the UP DOWN keys, and then hit the PLAY button. If you hit the PLAY
Sample Rate
4kHz
5kHz
6kHz
8kHz
Recording Time
8 minutes
6.4 minutes
5.3 minutes
4 minutes
BS2 • 22
Passband
1.7kHz
2.3kHz
2.7kHz
3.4kHz
