Page 1: Table Of Contents
Dryer Models ..35 ® Amana ® Dryer Models ..36 Washers and Dryers Magic Chef ® Brands Dryer Models ....37 Washer and Dryer Hook-up Displays . -
Page 2: Maytag ® Key Features
Maytag ® Key Features & Benefits M AY TA G D E L I V E R S : ® SuperSize Capacity (3.3 cu. ft.) C A PA C I T Y Allows consumers to wash more clothes in a single load to save time. DependableClean ™... -
Page 3: Amana Key Features
Amana ® Key Features & Benefits A M A N A D E L I V E R S : ® Super Capacity Plus (3.3 cu. ft.) C A PA C I T Y Cleans more clothes in one load to save consumers time. -
Page 4: Maytag ® Nomenclature
Maytag ® Washer & Dryer Nomenclature Maytag Washers ® 4 7 5 5 Brand Product Type Model Number Marketing Voltage Color Code Code M = Maytag ® 4755 = Feature Package W = 120V-60hz AV = Automatic A= Alpha W = White Vertical Axis Maytag ®... -
Page 5: Amana Nomenclature
Washers ® 8 8 0 5 Brand Product Type Model Number Marketing Voltage Color Code Code N = Amana ® 8805 = Feature Package W = 120V-60hz AV = Automatic A= Alpha W = White Vertical Axis Amana ® Dryers... -
Page 6: Maytag Cleaning Performance
Maytag ® Cleaning Performance DependableClean ™ Wash System LOADFLEX ™ AGITATOR LOADFLEX ™ SPIRAL DESIGN FABRIC SOFTENER FLEXCARE ™ AGITATOR DISPENSER The spiral design drives clothes into the The LoadFlex agitator Used for adding fabric ™ cleaning zone for softener to the load utilizes a double-spiral design increased rollover. -
Page 7: Cleaning Performance
Amana ® Cleaning Performance Tri-Care ™ Agitator Tri-Wash System FABRIC SOFTENER DISPENSER TRI-CARE ™ AGITATOR Used for adding fabric SPIRAL DESIGN softener to the load before The Tri-Care agitator utilizes ™ the CleanDeep Rinse. The spiral design drives a spiral design to roll clothes clothes into the cleaning into the cleaning zone. -
Page 8: Consumer Insights
• Avoids complexity, particularly in laundry. She cares about the end product — clean clothes — but doesn’t want to think about the process. Amana ® • Wants something simple and straightforward to save her time, make her life easier and cut down on her workload. - Page 9 • Improved cleaning performance helps keep ¤ whites white and colors bright. Amana • New spiral agitator, FlexFins ™ and FixedFins are designed for • Spiral agitator is designed ® Tri-Care Agitator ™...
- Page 10 Washer Features FEATURE HOW IT WORKS BENEFIT C A R E Amana ® • Cycle provides extra-gentle, intermittent agitation and soak • Gentle wash motion for for delicates and knits. consumers’ most Ultra Handwash Cycle precious items. (select models) NAV8805 model only.
- Page 11 Washer Features FEATURE HOW IT WORKS BENEFIT C O N V E N I E N C E Quick Wash Cycle • Quick wash cycle for lightly-soiled or wrinkled garments that • Convenient cycle for (select models) are needed quickly. Quick wash cycle is 23 minutes. when consumers need their favorite outfit MAV5920E, NAV8805, NAV5805 and NAV3335...
- Page 12 Washer Features FEATURE HOW IT WORKS BENEFIT C O N V E N I E N C E Maytag ® • Adds an additional 12 minutes to the spin to remove more • Removing more water water from the load and reduce time in the dryer. from clothes reduces Extended Spin drying time.
- Page 13 MAV5920E, MAV4755, MAV3955E, MAV3905, ¤ MAV3855, NAV8805 and CAV4004 models only. • All Maytag ® and Amana ® washers meet new 2005 energy- • Conserves energy and 2005 Energy-Compliant efficiency standards. saves consumers money on utility bills.
- Page 14 • The washtub is designed with round holes pressed from the (select models) inside out for optimal water extraction and clothes care. • Resists corrosion, stains and damage from harsh Amana ® MAV5920E, MAV4755, NAV8805 and NAV5805 chemicals. Elustra ™...
- Page 15 • The single-phase design generates extra starting torque to bring the Maytag ® DependableClean ™ Wash and Amana ® • The washer is able to Tri-Wash systems into motion quickly. clean clothes while offering a level of clothes care acceptable to ¤...
- Page 16 Packages (select models) foam strip placed along the baseframe to seal sound within making installation more the cabinet of the washer. flexible. Amana ® MAV5920E, MAV4755, MAV3955E, MAV3905, SofSound ™ Quiet Packages MAV3855, NAV8805 and NAV5805 models only.
-
Page 17: Maytag Washer Control Panel
Maytag ® Washer Control Panel MAV5920E Washer control panel features: FEATURE FUNCTION Infinite Water Level Saves water and energy by allowing the consumer to use only the water they need by precisely matching water level to load size. Water usage is rated at 15.5 gallons minimum fill to 39.5 gallons maximum fill. Extra Rinse Extra rinse is added to the end of the cycle to more completely remove laundry additives, suds, perfumes, etc. -
Page 18: Amana Washer Control Panel
Amana ® Washer Control Panel NAV8805 Washer control panel features: FEATURE FUNCTION Infinite Water Level Saves water and energy by allowing the consumer to use only the water they need by precisely matching water level to load size. Water usage is rated at 15.5 gallons minimum fill to 39.5 gallons maximum fill. -
Page 19: Washer Control Panels
Independent Washer Control Panel CAV4004 Washer control panel features: FEATURE FUNCTION Infinite Water Level Saves water and energy by allowing the consumer to use only the water they need by precisely matching water level to load size. Water usage is rated at 15.5 gallons minimum fill to 39.5 gallons maximum fill. Wash/Rinse Temperature Select the desired water temperature. -
Page 20: Maytag Washer Cycle Charts
Maytag ® Washer Cycle Charts Cycle Times with Water Consumption Preset Options & Spin Soil Level Mini Fill Super Fill Settings Ex. Heavy Heavy Medium Light Wash Gallons 18-20 Regular Spin Spray Gallons Wrinkle Control Deep Rinse Gallons 18-20 Delicates 9 or 10 Extra Rinse Gallons 18-20... -
Page 21: Amana Washer Cycle Charts
Amana ® Washer Cycle Charts Water Consumption Cycle Times with Preset Options & Spin Soil Level Mini Fill Super Fill Settings Ex. Heavy Heavy Medium Light Wash Gallons 18-20 Regular Spin Spray Gallons Whites & Towels Deep Rinse Gallons 18-20... -
Page 22: Dryer Features
® Super Capacity Plus ¤ C A R E Maytag ® • Maytag ® and Amana ® dryers dry laundry quickly and • Powerful airflow and GentleBreeze ™ efficiently. The high-capacity blower produces a diagonal lower temperatures for Drying System airflow that swirls through the drum at 220 cubic feet per fast, gentle care. - Page 23 MDE/G5806, MDE/G4806, NDE/G8805, ¤ NDE/G5805, NDE/G2335 and CYE/G3005 models only. Amana • At the end of the cycle, the clothes are cooled for • Reduces wrinkles so ® approximately 20 minutes to reduce wrinkling. consumers spend less No-Iron Fabrics Cycle time ironing.
- Page 24 IntelliDial ™ Electronic cycle is being used and Controls (select models) MDE/G5806, MDE/G4806 and NDE/G8805 where the dryer is in the Amana ® models only. ¤ cycle. Electronic Controls (select models) • The big door opening makes it easy to get large, bulky items •...
- Page 25 Stainless Steel Dryer • Resists corrosion, stains and damage from harsh chemicals. Drum (select models) • Won’t scratch, even if MDE/G5806 and NDE/G8805 models only. consumers forget to check Amana ® ¤ a pocket for loose change. Elustra ™ Stainless...
- Page 26 Dryer Features FEATURE HOW IT WORKS BENEFIT C O N S T RU C T I O N High-Capacity Blower • The high-capacity blower produces a powerful diagonal • Delivers powerful airflow airflow of 220 cubic foot per minute. for faster drying. ¤...
- Page 27 Dryer Features FEATURE HOW IT WORKS BENEFIT C O N S T RU C T I O N Heavy-Duty Motor • The efficient 1/3-hp motor is thermal-protected with an • Protects itself from damage automatic reset. due to overheating. ¤ Heavy-Duty Baseframe •...
- Page 28 C O N S T RU C T I O N Maytag ® • Quiet performance makes the Maytag ® and Amana ® dryers • Allows for greater perfect for laundry areas that are just off the kitchen or flexibility in location and QuietSeries ™...
-
Page 29: Maytag Dryer Control Panel
Maytag ® Dryer Control Panel 9 10 MDE/G5806 and MDE/G4806 Dryer control panel features: FEATURE FUNCTION Temperature Allows consumers to choose from a complete range of temperature settings, making sure all fabrics come out looking their best. Air Fluff - Load tumbles with room temperature air. Used for items which need freshening. Low - For heat-sensitive items labeled Tumble Dry Low or Tumble Dry Medium (140°... -
Page 30: Amana Dryer Control Panel
Amana Dryer ® Control Panel NDE/G8805 Dryer control panel features: FEATURE FUNCTION Temperature Allows consumers to choose from a complete range of temperature settings, making sure all fabrics come out looking their best. Air Fluff - Load tumbles with room temperature air. Used for items which need freshening. -
Page 31: Control Panels
Independent Dryer Control Panel CYE3005 Dryer control panel features: FEATURE FUNCTION Temperature Allows consumers to choose from a complete range of temperature settings, making sure all fabrics come out looking their best. Delicate - For heat-sensitive items labeled Tumble Dry Low or Tumble Dry Medium. Regular - Sturdy cottons or labels marked Tumble Dry. -
Page 32: Maytag Washer Models
Maytag ® Washer Models MAV5920E MAV4755 MAV3955E MAV3905 MAV3855 MAV2755 Capacity 3.3 Cu. Ft. 3.3 Cu. Ft. 3.3 Cu. Ft. 3.3 Cu. Ft. 3.3 Cu. Ft. 3.3 Cu. Ft. Energy Star • • Controls IntelliDial ™ Rotary Rotary Rotary Rotary Rotary Quiet Cycle Select Timer •... -
Page 33: Amana Washer Models
Amana Washer ® Models NAV8805E NAV5805 NAV3335 NAV2335 Capacity 3.3 Cu. Ft. 3.3 Cu. Ft. 3.3 Cu. Ft. 3.3 Cu. Ft. Energy Star • Controls Electronic Rotary Rotary Rotary Quiet Cycle Select Timer • • • Cycle Status Lights Tri-Wash System •... -
Page 34: Magic Chef Brands Washer Models
Magic Chef ® Washer Models CAV4004 CAV2005 Capacity 3.3 Cu. Ft. 3.3 Cu. Ft. Controls Rotary Rotary MultiAction Wash System • ™ MultiAction Agitator • ™ Cycles Water Levels Infinite Wash/Rinse Temp. Combinations Timer Fabric Selections Regular Fabrics Cycle • •... -
Page 35: Maytag Dryer Models
Maytag ® Dryer Models MDE/G5806 MDE/G4806 MDE/G3706 MDE/G2706 Capacity 7.1 Cu. Ft. 7.1 Cu. Ft. 7.1 Cu. Ft. 7.1 Cu. Ft. Controls IntelliDial ™ IntelliDial ™ Rotary Rotary Cycle Status Lights Cycles GentleBreeze ™ Drying System • • • • Dryness Control Sensor Sensor... -
Page 36: Amana Dryer Models
Amana Dryer ® Models NDE/G8805 NDE/G5805 NDE/G2335 Capacity 7.1 Cu. Ft. 7.1 Cu. Ft. 7.1 Cu. Ft. Controls Electronic Rotary Rotary Cycle Status Lights Cycles FabriCare ™ Drying System • • • Dryness Control Sensor Auto Auto Adjustable Degrees of Drying... -
Page 37: Magic Chef Dryer Models
Magic Chef ® Dryer Models CYE/G3005 Capacity 7.1 Cu. Ft. Controls Rotary Cycles Drying System • Dryness Control Auto Adjustable Degrees of Drying Damp Dry Less Dry • Normal Dry • More Dry • Temperature Settings Adjustable Time Dry (minutes) Fabric Selections Regular Cycle •... -
Page 38: Hook-Up Displays
Washer & Dryer Hook-Up Displays Live Hook-Up Displays for Maytag ® and Amana ® Washers 1. Self-Demo Mode: Machine should go into ad mode immediately after being plugged in. If it does not go into ad mode: Turn the selector knob to Power Off. Push and hold selector knob. Cycle the lid very slowly three times. -
Page 39: Dimensions/Specifications
Dimensions/ Specifications Washer Dimensions Dryer Dimensions WASHER DIMENSIONS INCH (CM) DRYER DIMENSIONS INCH (CM) A. Height with washer lid open* ⁄ (135.9) A. Height – Overall* ⁄ ” (109.9) B. Height - Top of control panel* 44 (111.8) B. Height 36”... -
Page 40: Warranties
NUMBER TO BE USED BY Maytag ® Washer & Dryer Dealer Presenter 3428TM Dealers Maytag ® and Amana ® Washer & Dryer Sales Training Manual 3424T District Managers and Sales Associates Amana Washer & Dryer Dealer Presenter 3808TA Dealers ®... - Page 41 Maytag ® Dryer Warranty Maytag Dryer Warranty ® Full One Year Warranty For one (1) year from the date of original retail purchase, any part which fails in normal home use will be repaired or replaced free of charge. Limited Warranty After the first year from date of original retail purchase, through the time periods listed below, the parts designated below which fail in normal home use will be repaired or replaced free of charge for the part itself, with the owner paying all other costs, including labor, mileage, transportation, trip and diagnostic charges, if required.
- Page 42 Amana ® Washer Warranty Amana Washer Warranty ® Full One Year Warranty For one (1) year from the date of original retail purchase, any part which fails in normal home use will be repaired or replaced free of charge. Limited Warranty After the first year from date of original retail purchase, through the time periods listed below, the parts designated below which fail in normal home use will be repaired or replaced free of charge for the part itself, with the owner paying all other costs, including labor, mileage, transportation, trip and diagnostic charges, if required.
- Page 43 Amana ® Dryer Warranty Amana Dryer Warranty ® Full One Year Warranty For one (1) year from the date of original retail purchase, any part which fails in normal home use will be repaired or replaced free of charge. Limited Warranty Against Rust-Through Should an exterior cabinet, including the top and door, rust through during the one-year period starting from the date of retail purchase, repair or replacement will be made free of charge.
- Page 44 Form No. 3424T 2005 Maytag Appliances Printed in the U.S.A. 7/05 ® ©...
