Table of Contents
Related Manuals for Bissell 23A7 Series
Summary of Contents for Bissell 23A7 Series
- Page 1 USER'S GUIDE 23A7, 30Z8 SERIES 220-240V Thank You Safety Instructions Product View Assembly Operations Maintenance and Care 9-12 Troubleshooting Replacement Parts Warranty Consumer Services...
- Page 2 Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance. My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your BISSELL PowerForce Multi Cyclonic canister vacuum.
-
Page 3: Important Safety Instructions
(Spares may be obtained from Not intended for use by persons (including ■ your BISSELL supplier). If for any reason the children) with reduced physical, sensory or plug is cut off, it must be disposed of, as it is... -
Page 4: Product View
roduct view Handle Air Flow Regulator Flex Hose Telescoping Extension Wand Easy Empty™ Dirt Cotainer Multi-Surface Floor Nozzle Hose Connector Brush Switch CAUTION: Do not plug in your vacuum until you are familiar with all instructions and Upholstery Tool Crevice Tool Dusting Brush operating procedures. - Page 5 ssembly Connect the hose to the vacuum by WARNING: inserting the hose connector into the suction opening on the bottom front Plastic film can be of the vacuum. Push in until it clicks dangerous. To avoid danger into the locked position. of suffocation, keep away Connect the telescoping extension from babies and children.
-
Page 6: Power Cord
perations Power cord The power cord is located at the rear of the vacuum. Gently pull out the power cord, watching for the yellow line. Stop pulling the power cord once the yellow line is visible. There is also a red line, which indicates the end of the usable Automatic Cord cord. -
Page 7: Power Button
perations Power Power button Button Turn the power ON or OFF by pressing lightly downward on the power button Variable suction power control The variable suction power control is located on the back of the vacuum. Turn the control toward the larger dots for maximum suction. -
Page 8: Special Tools
Special tools Your BISSELL PowerForce Multi cyclonic is not only a powerful carpet and rug vacuum cleaner, Brush Up it’s also a versatile bare floor and above floor vacuum cleaner when you select one of the special tools. Floor nozzle: Use to vacuum carpets, rugs and bare floors. -
Page 9: Maintenance And Care
aintenance and care Emptying the dirt container WARNING: Empty the dirt container as soon as the dirt reaches the “FULL” lines on To reduce the risk of electric the sides of the dirt container. shock, turn power switch OFF and 1. - Page 10 Cleaning the inner cyclone & screen Filters protect the motor from dirt and dust particles. Use only BISSELL replacement filters in your PowerForce Multi Cyclonic 1. Unplug the vacuum from the electrical outlet. 2. Remove the dirt container from the vacuum.
-
Page 11: Cleaning The Pre-Motor Filter
This product is intended for household from dirt and dust particles. Use only use only and not for commercial or BISSELL replacement filters in your industrial use. Vacuuming of dust from PowerForce Multi Cyclonic. products like plaster, concrete or ashes will damage the motor and void the 1. - Page 12 Cleaning the Post-motor HEPA media filter* The post-motor HEPA media filter* assists in the filtration process to return clean air to the room. Use only BISSELL replacement filters in your PowerForce Multi Cyclonic. 1. Turn the power OFF. Unplug the vacuum from the electrical outlet.
-
Page 13: Troubleshooting
Other maintenance or service not included in the manual should be performed by an authorized service representative. Thank you for selecting a BISSELL product. Please do not return this product to the store. w w w . b i s s e l l . c o m... -
Page 14: Replacement Parts
eplacement parts - Item Part No. Part Name 203-1578 Hose 203-1579 Telescoping Extension Wand 203-1536 Multi-Surface Floor Nozzle 203-1583 Tool Holder 203-1581 Upholstery Tool 203-1580 Crevice Tool 203-1582 Dusting Brush 203-1575 Inner Cyclonic Assembly 203-1569 Pre-Motor Filter 203-1557 Post Motor HEPA Media Filter* *The filter, media, not the vacuum as a whole, complies with the IEST-RP-CC001.5 HEPA Standard w w w . -
Page 15: Limited One Year Warranty
Limited One Year Warranty Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, BISSELL Homecare, Inc., will replace (with new or remanufactured components), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for one year any defective or malfunctioning part do to manufacturers defect. - Page 16 ISSELL consumer services If your BISSELL product should require service: Call BISSELL Consumer Services at the numbers below and we will give you the location of a BISSELL Authorized Service Center in your area. For all other countries, contact your local in country distributor for questions, service, or repair.
