SERVICE MANUAL

MODEL
COMMANDER DEST.
KV-XS29M80
RM-954
KV-XS29M97
RM-953
(RM-953)
CHASSIS NO.
E
SCC-U13L-A
Hong Kong SCC-U17L-A
(RM-954)
BG-3S
MODEL
COMMANDER DEST. CHASSIS NO.
TRINITRON
CHASSIS
COLOR TV
®

Advertisement

Table of Contents
loading

Related Manuals for Sony TRINITRON KV-XS29M80

Summary of Contents for Sony TRINITRON KV-XS29M80

  • Page 1: Service Manual

    SERVICE MANUAL BG-3S CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KV-XS29M80 RM-954 SCC-U13L-A KV-XS29M97 RM-953 Hong Kong SCC-U17L-A (RM-953) (RM-954) TRINITRON COLOR TV ®...

  • Page 2: Rm-954 Rm

    PAR TS LIST ARE CRITICAL TO SAFE OPERA TION. REPLA CE ANODE. THESE COMPONENTS WITH SONY P AR TS WHOSE P AR T NUMBERS APPEAR AS SHO WN IN THIS MANU AL OR IN SUPPLEMENTS PUBLISHED BY SONY – 2 –...
  • Page 3 CARBON PAINTED ON THE CRT, AFTER REMOVING THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE ANODE. THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. – 3 –...

  • Page 4: Table Of Contents

    KV-XS29M80/XS29M97 RM-954 RM-953 TABLE OF CONTENTS Section Title Page Section Title Page SELF DIAGNOSIS FUNCTION 5. DIAGRAMS ........ 5 5-1. Block Diagram ............59 1. GENERAL ................ 9 5-2. Frame Schematic Diagram ........63 Circuit Boards Location .......... 67 2. DISASSEMBLY 5-4.

  • Page 5: Self Diagnosis Function

    KV-XS29M80/XS29M97 RM-954 RM-953 SELF DIAGNOSTIC FUNCTION The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER lamp will automatically begin to flash. The number of times the lamp flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER lamp flash indicators is listed in the instruction manual for the user’s knowledge and reference.
  • Page 6 KV-XS29M80/XS29M97 RM-954 RM-953 DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT 2 times 5 times Lamp ON 0.3 sec. Lamp OFF 3 sec. Lamp OFF 0.3 sec. STANDBY/SLEEP lamp Diagnostic Item Flash Count* +B overcurrent/overvoltage 2 times Vertical deflection stopped White balance failure 5 times * One flash count is not used for self-diagnostic.
  • Page 7 KV-XS29M80/XS29M97 RM-954 RM-953 SELF-DIAGNOSTIC SCREEN DISPLAY For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurances of failure for confirmation on the screen:...
  • Page 8 KV-XS29M80/XS29M97 RM-954 RM-953 SELF-DIAGNOSTIC CIRCUIT IC301 IC001 IC003 Y/CHROMA JUNGLE SYSTEM MEMORY FROM IK-IN IO-8DAT B-DAT FROM O-LED [+B] Q604 C PROTECT IO-SDAT [V] Q509/507 [+B overcurrent ªOCPº] Occurs when an overcurrent on the +B(135) line is detected by Q604. If Q604 go to ON and the voltage to pin 18 of IC301 should go down when V.SYNC is more than seven...
  • Page 9 The operating instructions mentioned here are partial abstracts from the Operating Instruction Manual. The page numbers of the Operating Instruction Manual remain as in the manual. AUDIO VIDEO L(MONO) VIDEO IN VIDEO OUT WOOFER AUDIO VIDEO L(MONO) VIDEO IN VIDEO OUT...
  • Page 10 (MONO) L(MONO)
  • Page 11 WOOFER L(MONO) LINE OUT R-AUDIO-L VIDEO L(MONO) LINE OUT R-AUDIO-L VIDEO L(MONO)
  • Page 12 SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER...
  • Page 13 SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER...
  • Page 14 SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER...
  • Page 15 SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER MENU AUTO PROGR...
  • Page 16 SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER...
  • Page 17 SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER...
  • Page 18 SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER...
  • Page 22 (MONO) MENU AUTO SOUND MODE SURROUND FAVORITE PROGR PIC MODE MENU ENTER...
  • Page 24 COMPONENT VIDEO OUT S VIDEO OUT LINE OUT R-AUDIO-L VIDEO (MONO) WOOFER LINE OUT R-AUDIO-L VIDEO L(MONO) L(MONO)
  • Page 25 MODE PIP PROGR ENTER FAVORITE PIP PROGR SOUND MODE SURROUND...
  • Page 26 ENTER ENTER ENTER ENTER ENTER...
  • Page 27 MODE MODE PIP PROGR ENTER FAVORITE PIP PROGR SOUND MODE SURROUND...
  • Page 28 MODE PIP PROGR ENTER FAVORITE PIP PROGR SOUND MODE SURROUND...
  • Page 29 MODE PIP PROGR ENTER FAVORITE PIP PROGR SOUND MODE SURROUND...
  • Page 31 PIP PROGR PIP PROGR ENTER ENTER FAVORITE FAVORITE PIP PROGR PIP PROGR ENTER ENTER ENTER ENTER ENTER ENTER ENTER MENU AUTO PROGR...
  • Page 32 PIP PROGR ENTER ENTER ENTER FAVORITE PIP PROGR SOUND MODE SURROUND ENTER ENTER ENTER ENTER ENTER ENTER...
  • Page 33 PIP PROGR ENTER ENTER ENTER FAVORITE PIP PROGR ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER...
  • Page 34 PIP PROGR ENTER FAVORITE PIP PROGR SOUND MODE SURROUND ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER...
  • Page 35 ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER...
  • Page 38 MODE (MONO) PIP PROGR MENU AUTO PROGR ENTER FAVORITE PIP PROGR SOUND MODE SURROUND...

  • Page 44: Set-Up Adjustments

    KV-XS29M80/XS29M97 SECTION 3 RM-954 RM-953 SET-UP ADJUSTMENTS • The following adjustments should be made when a complete Perform the adjustments in the following order : realignment is required or a new picture tube is installed. 1. Beam Landing • These adjustments should be performed with rated power 2.

  • Page 45: Convergence

    KV-XS29M80/XS29M97 RM-954 RM-953 3-2. CONVERGENCE Preparation : • Before starting this adjustment, adjust the focus, horizontal size and vertical size. • Minimize the brightness setting. Purity • Provide dot pattern. BMC (Hexapole) (1) Horizontal and Vertical Static Convergence Purity Center dot V.
  • Page 46 KV-XS29M80/XS29M97 RM-954 RM-953 BMC (Hexapole) Magnet. Blue Neck assy Neck assy If the red, green and blue dots are not balanced or aligned, then use the BMC magnet to adjust in the manner described below. Blue VM1 board VM1 board Note 1.

  • Page 47: Focus Adjustment

    KV-XS29M80/XS29M97 RM-954 RM-953 Rotate TLV-2 VOL (29”, 34”) on DY 3-3. FOCUS ADJUSTMENT Rotate TLV VOL (25”) on DY Adjust FOCUS control on the flyback transformer for the best XCV Rotate XCV Adj core on DY focus. YCH Rotate YCH VOL on DY...

  • Page 48: G2 (Screen) And White Balance Adjustments

    KV-XS29M80/XS29M97 RM-954 RM-953 2. WHITE BALANCE ADJUSTMENT 3-4. G2 (SCREEN) AND WHITE BALANCE 1) Set to Service Mode (Refer Section 4-1: ADJUSTMENTS ADJUSTMENTS WITH COMMANDER). 1. G2 (SCREEN) ADJUSTMENT 2) Input white raster signal. 1) Set the PICTURE to normal.

  • Page 49: Circuit Adjustment

    KV-XS29M80/XS29M97 SECTION 4 RM-954 RM-953 CIRCUIT ADJUSTMENTS 4-1. ADJUSTMENTS WITH COMMANDER Service adjustments are made with the RM-954 that comes with this unit. 1, 4 Select the adjustment item. ↓ a. ENTERING SERVICE MODE 3, 6 Raise/lower the data value.

  • Page 50: Adjustment Method

    KV-XS29M80/XS29M97 RM-954 RM-953 4-2. ADJUSTMENT METHOD Item Number 00 of device GEO Use the same method for all Items. Use 1 and 4 to select the This explanation uses H-Position as an example. 1. Select “GEO 00 HPS” with the 1 and 4 buttons.
  • Page 54 KV-XS29M80/XS29M97 RM-954 RM-953 ITEM INFORMATION. No. OPB0 OP1 XTAL 4.43 XTAL 3.58 SECAM 2nd. Lang Item KV-XS29M80 KV-XS29M97 No. OPB1 OP2 Item NICAM HDEV Thai Bil Dis. Fav DVD Input AV Input KV-XS29M80 KV-XS29M97 No. OPB2 OP3 Item PIC Rotate...

  • Page 55: Picture Quality Adjustments

    KV-XS29M80/XS29M97 RM-954 RM-953 4-3. PICTURE QUALITY ADJUSTMENTS BELL FILTER ADJUSTMENT SUB COLOR ADJUSTMENT 1. Input SECAM color-bar signal. 2. Connect the dual-trace oscilloscope to CN303 pin 9 1. Input a PAL color-bar. (not mounted). 2. Set to the following condition: 3.

  • Page 56: Picture Distortion Adjustment

    KV-XS29M80/XS29M97 RM-954 RM-953 4-5. PICTURE DISTORTION ADJUSTMENT (1) PICTURE DISTORTION ADJUSTMENT (2) Item Number 00 – 0B H-TRAPEZOID (Rotate RV1801) GEO 0 HPS (H POSITION) GEO 1 HSZ (H SIZE) GEO 2 PAP (PIN AMP) GEO 3 TLT (TRAPEZIUM) GEO 4...

  • Page 57: Diagrams

    KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 SECTION 5 RM-954 RM-953 RM-954 RM-953 RM-954 RM-953 RM-954 RM-953 DIAGRAM 5-1. BLOCK DIAGRAM Front Panel, DBFB(3D) AUDIO OUT AV, Headphone 3D SP BOX ASSY IC6201 Q6202 TDA7481 Q6206/6207 MAIN.TUVF with TV.V In AV SW STEREO...

  • Page 58: Frame Schematic Diagram

    NT/P AL APCN/SC DYD L DYD R DVD, 3D TERMINAL TO B5 BOARD CN1303 TO P2 BOARD CN4501 CN3451 * J4/P2 n for KV-XS29M97 only. 3D+IN :S-MICRO n for KV-XS29M80 only. GND/3D- – – – – – – – –...

  • Page 59: Circuit Boards Location

    C BUS 8-BIT PWM 8CH 14BIT PWM 1CH INTERFACE UNIT (6CH) P2 (KV-XS29M97) HSYNC COUNTER 1 8 (6) B5 (KV-XS29M80) 5-4. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS A BOARD WAVEFORMS Note: Reference information PAL/SECAM NTSC • All capacitors are in µF unless otherwise noted.
  • Page 60 KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 RM-954 RM-953 RM-954 RM-953 A BOARD NOTE: [POWER SUPPLY, HV, MICON, Y/C JUNGLE] The circuit indicated at left contains high voltage of over D004 D614 600 Vp-p. Please pay attention when inspecting or repair- D005 D615 IC001 B-10 ing it to prevent an electric shock.

  • Page 61: Schematic Diagram Of A (1/2) Board

    (1) Schematic Diagram of A (1/2) Board A BOARD MARK LIST KV-XS29M97 KV-XS29M80 C103 C115 C116 0.1 25V :CHIP C117 0.1 25V :CHIP C311 C314 1.0 16V C627 680p 500V C628 1000 35V CN302 CN604 CN605 D100 MA111-TX D315 1SS355TE-17 D316 RD7.5SB1-T1...

  • Page 62: Schematic Diagram Of A (1/2) Board

    (2) Schematic Diagram of A (2/2) Board Schematic diagram Schematic diagram (1/2) board – – (2/2) board – – – – – –...

  • Page 63: Schematic Diagram Of B3 Board

    KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 RM-954 RM-953 RM-954 RM-953 (5) Schematic Diagram of C Board – – – –...
  • Page 64 KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 RM-954 RM-953 RM-954 RM-953 C BOARD IC701 STV5112 [VIDEO AMP, ROTATION CIRCUIT] PRINTED WIRING BOARDS – C Board – BLUE FEEDBACK (RED FEEDBACK, GREEN FEEDBACK) BLUE OUTPUT (RED OUTPUT, GREEN OUTPUT) BLUE CATHODE CURRENT (RED CATHODE CURRENT, GREEN CATHODE CURRENT)
  • Page 65 (6) Schematic Diagram of P Board (KV-XS29M97 only) M(Y) S(Y) Y OUT M(B-Y) B-Y OUT SEL U R-Y OUT S(B-Y) SEL V CLAMP M(R-Y) S(R-Y) – – – – – – – –...
  • Page 66 KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 RM-954 RM-953 RM-954 RM-953 (7) Schematic Diagram of D Board [PICTURE IN PICTURE DVD SWITCH] [DF, DQP DRIVE] PRINTED WIRING BOARDS – P2 Board – (KV-XS29M97 only) – D Board – • : Pattern from the side which enables seeing.
  • Page 67 KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 RM-954 RM-953 RM-954 RM-953 (8) Schematic Diagram of H Board H5 BOARD MARK LIST KV-XS29M97 KV-XS29M80 C3907 CN3903 4P CN3906 3P L3903 0µH Note) The parts indicated as “#” in this circuit diagram are not listed here, as they are not used for these models.
  • Page 68 KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 RM-954 RM-953 RM-954 RM-953 [FRONT PANEL, AV, HEADPHONE] [VELOCITY MODULATION] PRINTED WIRING BOARDS – VM Board – – H Board – – – – –...

  • Page 69: Schematic Diagram Of P2 Board

    KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 RM-954 RM-953 RM-954 RM-953 (9) Schematic Diagram of VM Board – – – –...
  • Page 70 KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 RM-954 RM-953 RM-954 RM-953 (10) Schematic Diagrams of F and J Boards (KV-XS29M97 only) – – – –...

  • Page 71: Semiconductors

    KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 KV-XS29M80/XS29M97 RM-954 RM-953 RM-954 RM-953 RM-954 RM-953 5-5. SEMICONDUCTORS DIODE TRANSISTOR [CISPR] PRINTED WIRING BOARDS [3D TERMINAL] AK04V0 D5S6M SPB-26MVWF DTA114EKA-T146 IRF614 CXA1315P (16PIN) AU-01Z-V1 UN2211 CXA1855S (48PIN) EG20G UN2213 CXA2139S (48PIN) EL1Z UN2216 CXP750097-011S (64PIN) ERA22-08 2SA1162-G...

  • Page 75: Picture Tube

    7-685-648-79 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK 8-453-011-11 NA299-M X-4037-231-1 BEZNET,ASSY (KV-XS29M80) 102-108, 128 * A-1331-999-A C BOARD MOUNTED X-4036-803-1 BEZNET,ASSY (KV-XS29M97) 102-108, 128 ! 1-419-323-11 4-036-405-11 SPRING, COMPRESSION COIL, DEGAUSSING (HONG KONG)

  • Page 76: Speaker

    KV-XS29M80/XS29M97 RM-954 RM-953 6-4. 3D SPEAKER SCREW BVTP 4 × 12 4: 7-685-661-71 SCREW BVTP 4 × 16 p: 7-685-663-71 REF. NO. PART NO. DESCRIPTION REMARK A-1501-377-C BOX ASSY, SPEAKER (3D) * 4-065-515-01 BOX (TP), 3D SPEAKER 1-529-172-11 SPEAKER, LOUD (10CM)

  • Page 77: Electrical Parts List

    • MMH : mH, UH : µH noted. number, please include the board name. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1299-070-A A BOARD COMPLETE (KV-XS29M80) C306 1-163-233-11 CERAMIC CHIP 18PF ******************** C307 1-163-233-11 CERAMIC CHIP...
  • Page 78 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M80) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C533 1-126-941-11 ELECT 470MF C623 1-104-665-11...
  • Page 79 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M80) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <DIODE> D613 8-719-046-74 DIODE AU-01Z-V1 D614...
  • Page 80 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M80) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK JR005 1-216-295-91 SHORT Q003 8-729-424-08 TRANSISTOR UN2111...
  • Page 81 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M80) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R035 1-216-025-91 RES,CHIP 1/10W R338 1-216-037-00...
  • Page 82 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M80) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R543 1-216-437-00 METAL OXIDE 5.6K R615...
  • Page 83 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M80) (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C108 1-104-664-11 ELECT 47MF T603 ! 1-431-976-11...
  • Page 84 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C526 1-130-495-00 MYLAR 0.1MF C618 1-125-893-11...
  • Page 85 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK CN509 1-695-915-11 TAB (CONTACT) D605 8-719-510-53...
  • Page 86 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK IC502 8-759-700-07 IC NJM2903M L601 1-412-527-11...
  • Page 87 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R018 1-216-033-00 RES,CHIP 1/10W R310 1-216-025-91...
  • Page 88 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R523 1-249-411-11 CARBON 1/4W R594 1-260-288-11 CARBON 0.47...
  • Page 89 C3216 1-117-720-11 CERAMIC CHIP 4.7MF ****************************************************************** C3217 1-163-021-91 CERAMIC CHIP 0.01MF C3218 1-163-017-00 CERAMIC CHIP 0.0047MF * A-1136-055-A B3 BOARD COMPLETE (KV-XS29M80) ********************* C3219 1-163-017-00 CERAMIC CHIP 0.0047MF C3220 1-163-037-11 CERAMIC CHIP 0.022MF 4-382-854-11 SCREW (M3X10), P, SW (+) C3221...
  • Page 90 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 3 (KV-XS29M80) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3249 1-164-505-11 CERAMIC CHIP 2.2MF <CONNECTOR>...
  • Page 91 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 3 (KV-XS29M80) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CHIP CONDUCTOR> R1430 1-216-025-91 RES,CHIP...
  • Page 92 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 3 (KV-XS29M80) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3200 1-216-121-91 RES,CHIP 1/10W R3257...
  • Page 93 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 3 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1136-050-A B3 BOARD COMPLETE (KV-XS29M97)
  • Page 94 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 3 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3283 1-126-964-11 ELECT 10MF <CONNECTOR>...
  • Page 95 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 3 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK IC3206 8-759-496-02 IC NJM2150D Q1409...
  • Page 96 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 3 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R1448 1-216-043-91 RES,CHIP 1/10W R3209...
  • Page 97 R3289 1-216-073-00 RES,CHIP 1/10W R3290 1-216-081-00 RES,CHIP 1/10W ****************************************************************** R3291 1-216-079-00 RES,CHIP 1/10W R3294 1-216-073-00 RES,CHIP 1/10W * A-1131-506-A B5 BOARD MOUNTED (KV-XS29M80) R3295 1-216-065-91 RES,CHIP 4.7K 1/10W ******************** R3296 1-216-065-91 RES,CHIP 4.7K 1/10W R3297 1-216-069-00 RES,CHIP 6.8K 1/10W <CAPACITOR>...
  • Page 98 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 5 (KV-XS29M80) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK L1570 1-410-470-11 INDUCTOR 10UH R1593...
  • Page 99 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1131-500-A B7 BOARD MOUNTED R2310 1-216-295-91...
  • Page 100 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK D720 8-719-911-19 DIODE 1SS119-25 R1801 1-249-426-11 CARBON 5.6K...
  • Page 101 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 5 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK D2802 8-719-988-61 DIODE 1SS355TE-17 * A-1241-346-A F BOARD MOUNTED...
  • Page 102 8-719-070-16 DIODE NNCD9.1A-T1 S3907 1-692-431-21 SWITCH, TACTILE S3908 1-692-431-21 SWITCH, TACTILE <IC> IC3901 8-742-014-11 HYB IC SBX1981-51 ****************************************************************** * A-1372-755-A H5 BOARD MOUNTED (KV-XS29M80) <JACK> ********************* J3901 1-750-264-11 JACK J3902 1-784-646-11 TERMINAL, S * 4-055-304-01 HOLDER, LED J3903 1-770-329-11 JACK, PIN 3P <CAPACITOR>...
  • Page 103 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 5 (KV-XS29M80) 4 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK D3902 8-719-070-16 DIODE NNCD9.1A-T1...
  • Page 104 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 2 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1190-359-A P2 BOARD MOUNTED (KV-XS29M97)
  • Page 105 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 2 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK IC4501 8-752-057-18 IC CXA1315P Q4326...
  • Page 106 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 2 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R4319 1-216-045-00 RES,CHIP 1/10W R4382...
  • Page 107 KV-XS29M80/XS29M97 RM-954 RM-953 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 2 (KV-XS29M97) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R4560 1-216-041-00 RES,CHIP 1/10W C5907...
  • Page 108 DEFLECTION YOKE (Y29RSA-S) (RM-953) ! 8-735-057-05 PICTURE TUBE (M68LNH070X) 4-933-895-01 BATTERY COVER, REMOTE COMMANDER (RM-954) ****************************************************************** Sony Corporation English 99IM70177-1 SONY TV Industries (M) Sdn. Bhd. Printed in Malaysia  9-965-761-01 TV Business of General Area 1999. 9 – 144 –...
