Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfill your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality, and high quality.
These are key characteristics of all our products and the reason they are greatly
appreciated throughout the world.
To get the most out of your new dishwasher, we recommend that you read the
operating instructions before using it. The operating instructions also include
information on how you can help protect the environment.
Do you need this Use&Care Guide in spanish? Log onto
www.askona.com/customer-care to download.
¿Necesita esta Instrucciones de uso y cuidado en español? Entre en
www.askona.com/customer-care y descárguesela.
Operating Instructions
Dishwasher
ASKO D5628XXLS
Advertisement
Table of Contents
Related Manuals for Asko D5628XXLS
Summary of Contents for Asko D5628XXLS
-
Page 1: Operating Instructions
Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfill your needs for many years to come. Scandinavian design combines clean lines, everyday functionality, and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world. -
Page 2: Table Of Contents
CONTENTS FRONT PANEL CARE AND MAINTENANCE INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS TROUBLESHOOTING BEFORE WASHING FOR THE FIRST TIME TECHNICAL INFORMATION LOADING THE DISHWASHER SERVICE USING THE DISHWASHER PROGRAM CHART SETTINGS FRONT PANEL The panel is fitted with touch buttons with audible feedback (see the chapter Settings). On/Left-on mode Display High temperature... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE • Should a child swallow dishwasher detergent or rinse aid, give plenty to drink immediately, i.e., one or two glasses of milk or WARNING! water. Do not try to induce vomiting. Seek medical advice immediately: Call the National Capital Poison Center at This manual does not cover all possible conditions and situations 1-800-222-1222. -
Page 4: Before Washing For The First Time
BEFORE WASHING FOR THE FIRST TIME WATER SUPPLY REFILL RINSE AID INDICATOR The machine can be connected to either a hot (max. 160 °F, 70 °C) or cold water supply. We recommend a cold water supply. When the rinse aid needs topping up, the above symbol lights on The water pressure should be 4.2-140 psi. -
Page 5: Loading The Dishwasher
LOADING THE DISHWASHER ECONOMIC DISHWASHING Wood Wooden items should only be washed in a dishwasher if marked Run programs only with a full load dishwasher safe. Wait until the dishwasher is fully loaded before running a program, this way you save energy. Use the Rinse & Hold program to rinse Aluminum the dishes if there are any unpleasant odors while you wait for the Aluminum can lose its shine if washed in a dishwasher. - Page 6 UPPER BASKET LOWER BASKET Place glasses, cups, bowls, side plates, and saucers in the upper Place plates, side plates, serving dishes, pots, and cutlery (in the basket. Wine glasses are placed on the wine glass shelf and knives cutlery basket) in the lower basket. are placed in the knife stand on the right (if equipped).
-
Page 7: Using The Dishwasher
USING THE DISHWASHER CUTLERY BASKET ADD DETERGENT Place cutlery with the handles facing down, except for knives, and spread them out as much as possible. Ensure that spoons do not stack inside each other. The cutlery basket is best placed in the middle at the front of the lower basket to best utilize dishwashing performance from the unique spray nozzle (Power Zone™... -
Page 8: Program Selection
Recommended detergent amounts based on water Daily wash hardness A program suitable for day-to-day dishwashing. This program can Water hardness Detergent amounts also clean dried leftovers, but is not intended for burnt food, such Soft Prewash 1 teaspoon as on oven dishes. (0-3 grains per gallon) Main wash 1 to 1-1/2 tablespoons Medium... -
Page 9: Once The Program Has Finished
You can vary the temperature as shown below: The time counts down while the program is running and the remainder of the program is displayed. The remaining time is Heavy wash: 130 °F (55 °C) / 160 °F (70 °C) displayed, e.g., 1:15, meaning that 1 minute 15 seconds of the Normal wash: 130 °F (55 °C) / 150 °F (65 °C) -
Page 10: Settings
SETTINGS DO AS FOLLOWS TO OPEN THE SETTINGS MENU: First, open the door. Turn off the dishwasher using the On/Left-on mode button (press and hold). Release the button. Press and hold the On/Left-on mode button until the display lights up. Within five seconds, press and hold the Program selector and the Long dry button. - Page 11 Button press Options Settings Description Operation volume This sound is used to confirm each button press. (Off) (Low) (High) Press Start/Stop to save the setting value and continue to the next setting. LCD contrast For adjusting the contrast of the display on the front (Display on the front of the door) door.
-
Page 12: Care And Maintenance Instructions
CARE AND MAINTENANCE INSTRUCTIONS COARSE FILTER NOTE! The coarse filter traps larger food particles, which cannot get past the drain pump. Empty the coarse filter as necessary. The dishwasher must not be used without the filters in place! 1 Lift the coarse filter by the handle. Dishwashing results may be affected if the coarse filter is incorrectly fitted. - Page 13 2 Remove any debris using a needle, toothpick, or some other DOOR similar pointed device. The spray arms also have holes When cleaning the edge around the door, use only a slightly damp underneath. cloth (with a little cleaner if necessary). WARNING! Do not use a spray bottle or the like around the door lock.
-
Page 14: Troubleshooting
TROUBLESHOOTING Display Type of fault Action Overfilling Call the Customer Care Center. Water outlet fault See "Water remains in the dishwasher above the filters" in the table below. Water inlet fault Check that the water supply valve is on. Inlet valve leakage Turn off the water supply valve and call the Customer Care Center. - Page 15 Problem Possible causes Action The dishwasher does not start. The Start/Stop start button has been pressed Press and hold Start/Stop until the display for too short a time. shows (the door open symbol). This indicates that the dishwasher is ready to start. The door is not properly closed.
- Page 16 Problem Possible causes Action The touch buttons do not react when pressed. You have pressed the touch buttons too soon Wait a moment then try again. after opening the door. Dirt on the touch buttons. Clean with a dry or slightly damp cloth. Open the door until the display lights up.
-
Page 17: Technical Information
TECHNICAL INFORMATION TECHNICAL DATA Height: 34-3/8" - 36-1/2" (873-927 mm) Width: 24" (610 mm) Depth: 22-7/8" (581 mm) Weight: 110 lb (50 kg) Water pressure: 4.2–140 psi Electrical connection: See serial number tag and rating plate. Rated power: See serial number tag and rating plate. Weight can vary due to different specifications. -
Page 18: Service
“Trouble Shooting” additional help can be found by calling used commercially or used in marine, mobile, or aeronautical ASKO Customer Care at 1-800-898-1879 application must be filed with ASKO within One (1) year from date of purchase. Read chapter Troubleshooting before contacting the Customer Care Center. -
Page 19: Program Chart
PROGRAM CHART Customer Care Center 1-800-898-1879 www.askona.com... -
Page 20: Quick Guide
QUICK GUIDE LOAD THE BASKETS (SEE PAGE 5) Do not rinse dishes under running water before loading them in the dishwasher. Simply scrape off large food particles before loading the dishwasher. CHECK THAT THE SPRAY ARMS CAN ROTATE FREELY Check also that the water supply valve is on. ADD DETERGENT (SEE PAGE 7) The detergent compartment has one smaller compartment for the prewash and one for the main wash.
