- Page 1 Professional Plasma Display with 3D Technology 85-inch 103-inch 152-inch...
- Page 2 Achieving the Ultimate Reality with Large-Screen FULL HD 3D Images. Opening New Business Possibilities. 4K2K Plasma Display TH-152UX1W 152” 85” 103” Full-HD Plasma Display TH-85VX200W Full-HD Plasma Display TH-103VX200W...
- Page 3 Images take on new dimensions of depth and texture.
- Page 4 • In the event that you experience dizziness, nausea, or other discomfort while viewing 3D images discontinue use and rest your eyes. • Parents/guardians should monitor children's viewing habits to avoid their prolonged use without rest periods. • Use only the 3D Eyewear recommended Panasonic 3D displays. 3D Eyewear...
- Page 5 3D images even on Blurred 3D image Right open Left open a large screen. Two pictures are overlapped * According to a Panasonic survey, as of June 9, 2010, for a FULL HD 3D-compatible flat-panel display. Time Right-eye images Luminescence time...
- Page 6 Achieving Large-Screen Displays with Naturally Colourful High-Resolution Images Newly developed Professional-quality engine doubles colour reproduction capability The new professional-quality engine raises the colour processing of each pixel from the conventional* 20-bit level to 30-bit processing. By faithfully reproducing all of the colour and luminance signals output by image sources, it produces smooth, vibrant colours across the entire screen.
- Page 7 A Wide colour gamut faithfully reproduces the colours and textures required by professionals Professional displays require a level of colour reproduction that portrays various materials in their natural colours for product designs and image applications. With the wide colour gamut of this panel, the natural colours and textures of materials can be faithfully reproduced, meeting versatile market needs.
- Page 8 A Wide Range of Applications Benefit from Large-Screen FULL HD 3D Images Ultra large-screen Panasonic plasma displays faithfully express colours with their meticulous image quality. The stereoscopic effect with 3D characteristics gives a realistic perception. These displays are extremely effective for professional applications that support business activities.
- Page 9 Application Examples for Ultra large-Screen 3D Displays Driving schools Showrooms • Can be used as a training device for piloting airplanes or driving cars. • Can be used to display the full colour variations of products in a space that is too small to display the actual products in all colours.
- Page 10 Museum highlights New museum services • Enables virtual display of invaluable artwork. • Display finely detailed items that are invisible to the naked eye. • Allows visitors to see details of artwork which they cannot see clearly through a showcase. •...
- Page 11 Application Examples for Ultra large-Screen 3D Displays Amusement facilities • Can be used to display content dynamically on the large screen. • Attracts customers during events by serving as a highlight of the facility. • Provide new services, such as encounters with life size characters.
- Page 12 Advanced PDP Development Centre Corporation (APDC). For 3D images filling the screen. images, the left and right images are each measured. * As a FULL HD 3D-compatible flat panel display, as of June 9, 2010. Panasonic studies.
-
Page 13: External Scaler Mode
The network function also uses the same Scaler VTR etc Provides CG-like colours for protocol as Panasonic projectors, so other • When using the network function, be sure to set CAD design of automobiles "Control I/F Select" in "Network Setup" to "LAN.“... -
Page 14: Specification
TH-152UX1W 4K2K Plasma Display 152” TH-103VX200W Full-HD Plasma Display TH-85VX200W Full-HD Plasma Display 103” 85” Specification Product Fiche 4K2K Plasma Display TH-152UX1W Manufacturer Panasonic Corporation TH-103VX200W TH-85VX200W Model No. DISPLAY Energy efficiency class Screen Size (Diagonal) 152-inch (3,862 mm) Visible screen size (diagonal) -
Page 15: Optional Accessories
Dimensions Cautions: This drawing is not a scale Units: mm TH-152UX1W 3600 TH-103VX200W 3416 (Effective Display Area) 2412 TH-85VX200W 2015 2269 (Effective Display Area) 1889 (Effective Display Area) Infrared transmitter for 3D Eyewear Infrared transmitter for 3D Eyewear Optional Accessories... - Page 16 The Panasonic 3D Innovation Center was established to accelerate the development and expansion of 3D businesses. By taking full advantage of the collective strengths of the Panasonic Group to spur the evelopment of its 3D-related technologies and services, we are thus committed to creating new business models and strengthening total solutions to meet customer needs ahead of the times.
