Replacing the light bulbs.

Setting the controls to OFF does not remove power to the light circuit.
(appearance may vary)
14
Raise the grille panel, set the master power
switch to the O (off) position and allow
lamps to cool.
To remove the light shield, press on
the sides of the shield and pull down.
This light is located above the top drawer.
Raise the grille panel, set the master power
switch to the O (off) position
and allow lamps to cool.
Remove items from the shelf above
the light shield. Remove the shelf.
Use both hands to grasp each end
of the light shield. Press in on the bottom of
the shield with your thumbs while rotating
the cover up and out.
Freezer Compartment
Raise the grille panel, set the master power
switch to the O (off) position and allow
lamps to cool.
Remove the items from the shelf just below
the light shield. Remove the shelf.
To remove the light shield, press down
on the top of the shield and pull the tabs
out of the slots. Tilt the shield forward and
out.
Dispenser
Raise the grille panel, set the master power
switch to the O (off) position
and allow lamps to cool.
The bulb is located in the dispenser under
the control panel. Remove
the two screws from the light shield.
Slide the light shield toward the dispenser
to disengage the tabs, then remove the
light shield. Remove the light bulb by
turning it counterclockwise.
Replace the bulbs with appliance bulbs
of the same or lower wattage. Replace the
shield by engaging the bottom tab into the
slot and applying light forward pressure
until the shield snaps in place.
Set the master power switch to the I (on)
position and close the grille panel.
Replace the bulb with an appliance bulb of
the same or lower wattage. Replace the
shield by engaging the bottom tab into the
slot and applying light forward pressure
until the shield snaps in place.
Set the master power switch to the I (on)
position and close the grille panel.
Replace the bulb with an appliance
bulb of the same or lower wattage,
and reinstall the light shield. Replace
the shield by engaging the bottom tab into
the slot and applying light forward pressure
until the shield snaps in place.
Set the master power switch to the I (on)
position and close the grille panel.
Replace the bulb with a bulb
of the same size and wattage. Replace
the light shield by sliding the tabs into
the slots in the front of the dispenser.
Replace the two screws.
Set the master power switch to the I (on)
position and close the grille panel.
