Operating Instructions
<Basics>
Installation Instructions provided
HD Communication Camera
GP‑VD130CH
Model No.
Before operating this product, please read the instructions carefully and save this manual for future use.
For instructions on how to operate this HD Communication Camera and
how to establish its settings, refer to the operating instructions of the HD
Visual Communication Unit to be connected.
Advertisement
Table of Contents
Related Manuals for Panasonic GP-VD130CH
Summary of Contents for Panasonic GP-VD130CH
-
Page 1: Operating Instructions
Operating Instructions <Basics> Installation Instructions provided HD Communication Camera GP‑VD130CH Model No. Before operating this product, please read the instructions carefully and save this manual for future use. For instructions on how to operate this HD Communication Camera and how to establish its settings, refer to the operating instructions of the HD Visual Communication Unit to be connected. - Page 2 “dangerous voltage” within For use only with power supply Panasonic, PNLV6506. the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
-
Page 3: Safety Precautions
Safety precautions DO NOT REMOVE PANEL COVERS BY CAUTION: UNSCREWING. In order to maintain adequate ventilation, do not To reduce the risk of electric shock, do not remove install or place this unit in a bookcase, built-in the covers. No user serviceable parts inside. cabinet or any other confined space. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 5: Table Of Contents
Contents Safety precautions ............3 Connections ..............16 Connections to the HD Visual Communication Unit and IMPORTANT SAFETY INSTRUCTIONS ......4 AC adapter ..............16 Before use ................. 6 Connecting the IR system cable (sold separately) ..16 Overview ................ 6 Installation precautions for the IR system cable ... -
Page 6: Before Use
Panasonic HD Visual Communication Units. Compatible HD Visual Communication Units: Disclaimer of warranty KX-VC300CN, KX-VC600CN IN NO EVENT SHALL Panasonic Corporation BE LIABLE Concerning HD Visual TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF... -
Page 7: Characteristics
Characteristics 1/2.8-type MOS sensor and high-performance 3 zoom Easy operation of unit enabled by its integration with a lens featured high-performance pan-tilt head unit A 1/2.8-type full HD MOS sensor and DSP (digital signal Operations at the high speed of 90°/s or more ... -
Page 8: Accessories
Accessories Check that the following accessories are present and accounted for. Getting Started ..............1 AC adapter ................. 1 Power cable (1.9 m) ............1... -
Page 9: Installation Precautions
Installation precautions In addition to heeding the points presented in the “Safety precautions”, observe the following precautions as well. Do not install or use the unit in the following kinds of Ensure that the installation work complies with the locations. technical standards governing electrical equipment. - Page 10 Installation precautions Use the dedicated AC adapter and power cable provided If there is a possibility of noise interference with the unit. Either wire the cables so that the power cable (ceiling light Connect the AC adapter and power cable to the power inlet cord) of AC 220 V or more, and the signal cable are placed securely.
-
Page 11: Operating Precautions
Operating precautions Shoot under the proper lighting conditions. Operating temperature range To produce pictures with eye‑pleasing colours, shoot under Avoid using the unit in cold locations where the temperature the proper lighting conditions. drops below 0 °C or hot locations where the temperature The pictures may not appear with their proper colours when rises above 40 °C since these temperatures downgrade the picture quality and adversely affect the internal parts. - Page 12 Operating precautions Handle the unit carefully. When using the automatic functions Do not drop the unit or subject it to strong impact or p p When using the automatic white balance setting (auto vibration. Doing so may cause the unit to malfunction. tracking white adjustment) function under fluorescent lights, the white balance may vary.
-
Page 13: Concerning The Ir Repeater Function
Concerning the IR repeater function The IR repeater function enables operations to be performed in response to the signals from the remote controller which are received by the receivers of the camera (this unit) in cases where the camera and HD Visual Communication Unit have been installed at a distance from each other. -
Page 14: Parts And Their Functions
Parts and their functions 1 Remote controller signal receiver Light sensors are located in two places at the front of the camera pedestal. These sensors are used when the IR repeater function (page 13) is used. 2 Status display lamp This lights in the following way depending on the status of the unit. -
Page 15: Installation
Installation When installing the unit on a desk Place the unit flat on the surface. Notes p p Install the unit in a stable location which will not be susceptible to shaking. If the unit is installed in a location which is susceptible to shaking, this will cause the unit’s images to shake in turn. -
Page 16: Connections
Connections Connections to the HD Visual Communication Unit and AC adapter This unit HD Visual Communication Unit KX-VC300CN, KX-VC600CN HDMI cable (sold separately) AC adapter Power cable p p For details on how to operate the unit and select its settings, refer to the operating instructions of the HD Visual Communication Unit to be connected. -
Page 17: Installation Precautions For The Ir System Cable
Connections Installation precautions for the IR system cable p p Place the HD Visual Communication Unit behind the doors of a system rack, for example, to ensure that the signals of the remote controller will not be received directly. If these signals are received directly, they will interfere with the signals of the IR system cable, and the operations concerned will not be performed properly. -
Page 18: How To Turn The Power On And Off
How to turn the power on and off Turning the power on p p This unit does not have a power switch. Its power is turned on when power is supplied to the unit. Unit’s power OFF Status display lamp: Off Power is supplied. -
Page 19: Factory Setting
Factory setting Factory settings for the setting items Item Factory setting Brightness Auto White Balance Auto Focus Focus Position: Center, Focus Mode: Auto Backlight Digital Zoom Pan/Tilt Position: Center Brightness: Auto Preset number 1‑9 White Balance: Auto Focus: Auto Home Position* Fixed at preset number 5 * The camera moves to this position first when its power is turned on. -
Page 20: Troubleshooting
Troubleshooting q Operation Symptom Cause and remedial action Reference pages p p Is the power plug securely connected to the AC outlet? ––– No power p p Are the AC adapter and the power cable connected properly? P.16 p p Is the power on? Cannot operate ... - Page 21 Troubleshooting q Video Symptom Cause and remedial action Reference pages p p Has the unit been connected properly to the HD Visual P.16 Communication Unit? No pictures are Operating instructions displayed or the p p Has the camera been selected correctly from the HD Visual of the HD Visual Communication Unit? pictures are disturbed...
- Page 22 Troubleshooting Symptom Cause and remedial action Reference pages Operating instructions The pictures are too p p Adjust the brightness manually. of the HD Visual light or too dark Communication Unit p p If a subject has suddenly crossed in front of the camera, it may appear slightly distorted because this camera uses a MOS –––...
-
Page 23: Appearance
Appearance Unit: mm... -
Page 24: Specifications
Specifications DC 16 V 10 % Power requirements: (AC adapter provided) Current consumption: 600 mA indicates safety information. GENERAL FUNCTIONS AND PERFORMANCE [Camera unit] Ambient operating temperature: 0 °C to +40 °C Imaging sensors: 1/2.8-type Full-HD MOS Storage temperature: –20 °C to +50 °C Lens: Motorized 3... - Page 25 SJ/T11363-2006. The content of poisonous/noxious substance for at least 1 type of homogeneous material regarding all corresponding parts is more than the industrial standard of SJ/T11363-2006. F1112-1123 PGQP1424YA © Panasonic System Networks Co., Ltd. 2012...
