Panasonic SB-AK340GC Service Manual

Please use this manual together with the service manual for Model No. [SB-AK340P-S, Order No.
MD0510379C1].
Specification
Type
Speaker(s)
Woofer
Tweeter
Super tweeter
Impedance
High
Low
Input power (IEC)
High
Low
Output sound pressure level
Cross over frequency
Frequency range
Dimensions (W x H x D)
CONTENTS
1 Notes
3 way, 3 speaker system (Bass reflex)
16 cm cone type
6 cm cone type
Piezo type
110 W (Max)
110 W (Max)
83 dB/W (1.0 m)
2.6 kHz, 10 kHz
37 Hz to 23 kHz (-16 dB)
44 Hz to 22 kHz (-10 dB)
247 x 330 x 221 mm
SB-AK340GC
Colour
(S)... Silver Type
Mass
Notes :
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
3 Ω
3. The labels "HIGH" and "LOW" on the rear of the speakers refer to
3 Ω
High frequency and Low frequency.
nSystem : SC-AK340PL-S
Page
2 2 Replacement Parts List
© 2005 Matsushita Electric Industrial Co. Ltd.. All
rights
distribution is a violation of law.
ORDER NO. MD0511427A3
Speaker System
Music Center : SA-AK340PL-S
Front Speaker : SB-AK340GC-S
reserved. Unauthorized
3.4 kg
Page
2
copying and
