Wiring Harness Parts - Whirlpool LSR7233DW0 Parts List

Illus. Part
No. No. DESCRIPTION
1 3349557 Clip, Harness
2 388498 Clip, Harness
3 3347812 Clip, Harness
4 3352501 Clip, Harness
5 90016 Clip, Harness
6 3390496 Clip, Harness
7 389379 Retainer,
(Suds Models)
8 352090 Timer, Block
Disconnect
(White)
9 352089 Timer, Block
Disconnect
(Black)
10 62889 Receptacle,
Terminal
(3−Way)
(Lid Switch)
(Use Term.94613)
Or 94614.)

WIRING HARNESS PARTS

For Models: LSR7233DW0, LSR7233DQ0, LSR7233DZ0
(White) (Designer White) (Designer Almond)
Illus. Part
No. No.
11 353424
12 62505
13 3348075
14 3347243
15 63523
16 717252
17 387566
18 3352944
FOR COMPLETE WIRING HARNESS REFER TO
CONTROL AND REAR PANEL PARTS PAGE
Illus. Part
DESCRIPTION No.
Plug, Terminal
19 3390423
(3−Way)
(Power Cord)
(Use Term.94613)
Block, Disconnect
20 3347730
(Motor 2 Speed)
(Use Term.352088)
Block, Disconnect
21
(Motor 3 Speed)
(Use Term. 94613
Or 94614.)
Block, Disconnect
22 3369366
(Use Term. 352088)
Protector
Connector
(2−Way)
23 3349494
(Use Term.94614)
24
Plug, Terminal
(4−Way)
(Power Cord)
25 3407125
(Use M3 Screws)
Clip, Harness
8
WH2D
No. DESCRIPTION
Block, Disconnect
(12−Way)
(Timer)
(Use Term. 94613)
Receptacle
(6−Way)
(Use Term. 94613)
388818 Plug, Terminal
(12−Way)
(Use Term. 94613
Or 94614.)
Timer, Block
Disconnect
(Black) (Amp)
(Use Term.3369365)
Connector, Etc
60687 Connector, Relay
(Use Term.308569
Or 338664.)
E.T.C. Control
881256
