Whirlpool LBR5432JQ1 Parts List page 4

CONTROL AND REAR PANEL PARTS
Illus. Part
No. No. DESCRIPTION
1 3976300 Washer, Water
Inlet Hose (4)
2 3400073 Screw, Ground
3 Hose, Water
Inlet
3949374 Blue Coupler
3949375 Red Coupler
4 3357027 Nozzle−Drain
Hose
5 8318255 Hinge, Console (2)
6 3357976 Panel, Rear
7 62747 Pad, Rear Panel
8 3951609 Hose, Drain
(4 ft.)
661577 Hose, Drain
(9 ft.)
(Not Included)
3357090 Extension,
Drain Hose
(21 Inches.)
(Not Included.)
9 3949620 Timer, Control
(60 Hz.)
(Motor Not A
Service Part)
For Models: LBR5432JQ1, LBR5432JT1
(Designer White) (Biscuit)
Illus. Part
No. No. DESCRIPTION
10 388326 Screw, 8−18 x 1.25
11 90767 Screw, 8−18 x 3/8
12 3366849 Switch, Water Level
13 3948814 Bracket, Control
14 3948063 Cord, Power
15 3952821 Strain Relief,
Power Cord
16 Cap, End (L.H.)
8271365 White
8271368 Biscuit
17 9740848 Screw, 8−18 x 1/2
18 3952164 Valve, Water
Mixing
19 90864 Screw, 10−24 x 1/2
20 3351614 Screw, 10−24 x 3/8
21 370451 Clamp, Hose
22 62662 Hose, Vacuum
Break
23 371503 Clamp, Hose
24 3347034 Break, Vacuum
25 8519200 Support, Rear
Panel
26 3361805 Hose−Corrugated
Assembly
27 3366912 Clamp, Hose
28 661606 Capacitor,
Motor Start
4
Illus. Part
No. No. DESCRIPTION
29 8318201 Clip, Capacitor
30 3363366 Clamp, Hose
31 660628 Clamp, Hose
32 3951449 Hose, Pump To Tub
36 3400064 Screw, Timer
Mounting (2)
39 Panel, Console
3954214 White
3954211 Biscuit
44 Knob, Timer
8274290 White
8274293 Biscuit
45 Dial, Timer
8274331 White
8274333 Biscuit
47 Knob, Control
8271339 White
8271348 Biscuit
50 62863 Screw, 10−16 x 3/8
51 Cap, End (R.H.)
8271359 White
8271362 Biscuit
52 3366913 Clamp, Drain
Hose
53 3390647 Screw, 8−18 x 1/2
54 3955005 Harness, Wiring
(For Detail See
Page 9 & 10)
8179567
